XM-754HX
SERVICE MANUAL
STEREO POWER AMPLIFIER
SPECIFICATIONS
US Model
Canadian Model
AEP Model
UK Model
E Model
Other Specifications
Circuit system OTL (output transformerless) circuit
Pulse power supply
Inputs RCA pin jacks
High level input connector
Outputs Speaker terminals
Speaker impedance 1* – 8 Ω(stereo)
2* – 8 Ω(when used as a bridging amplifier)
Maximum outputs (HI-CURRENT/HI-VOLTAGE)
Four speakers :
90/170 W x 4 (at 4 Ω)
Three speakers :
90 W x 2 + 250W x 1 / 170W x 2 + 400W x 1
(at 4 Ω)
Two speakers :
250/400 W x 2 (at 4 Ω)
Rated outputs (HI-CURRENT/HI-VOLTAGE)
(supply voltage at 14.4 V)
Four speakers :
35/75 W x 4 (20 Hz – 20 kHz, 0.04% THD,
at 4 Ω)
50/100 W x 4 (20 Hz – 20 kHz, 0.1% THD,
at 2 Ω)
Two speakers :
100/200 W x2 (20 Hz – 20 kHz, 0.1% THD,
at 4 Ω)
Frequency response
+0.5
5 Hz – 50 kHz ( –3 dB)
AUDIO POWER SPECIFICATIONS (US model)
POWER OUTPUTAND TOTAL HARMONIC DISTORTION
75 watts per channel minimum continuous average power into
4 ohms, both channels driven from 20 Hz to 20 kHz with no more
than 0.04% total harmonic distortion per Car Audio Ad Hoc
Committee standards.
Harmonic distortion 0.005% or less (at lkHz, 4 Ω)
Input level adjustment range
0.2 – 4.0 V (RCA pin jacks)
0.4 – 8.0 V (High level input)
High-pass filter 50 – 200 Hz, –12 dB/oct
Low-pass filter 50 – 200 Hz, –12 dB/oct
Low boost 0 – 10 dB (40 Hz)
Power requirements 12 V DC car battery (negative ground)
Power supply voltage10.5 – 16 V
Current drain at rated output : 40 A
(4ΩHI-VOLTAGE mode)
Remote input : 1.5 mA
Dimensions Approx. 258 x 50 x 320 mm (w/h/d)
(10 l/4x 2 x 12 5/8in.) not incl. projecting parts and
controls
Mass Approx. 3.5 kg (7 lb. 11 oz.) not incl. accessories
Supplied accessories Mounting screws (4),
Terminal cap (1)
Design and specifications are subject to change without notice.
* HI-CURRENT only
1
Ver 1.1 2001. 08
Sony Corporation
e Vehicle Company
Shinagawa Tec Service Manual Production Group
9-925-796-12
2001H0400-1
© 2001. 8

– 2 –
Specifications ............................................................................. 1
1. SERVICING NOTE....................................................... 2
2. GENERAL ....................................................................... 3
3. DISASSEMBLY
3-1. Bottom Plate, Panel (Front), Panel (Rear),
SP (Front) Board, SP (Rear) Board Removal ..............5
3-2. Amplifier Board Removal ............................................5
4. ELECTRICAL ADJUSTMENT................................. 6
5. DIAGRAMS
5-1. Block Diagram..............................................................7
5-2. Printed Wiring Boards ................................................10
5-3. Schematic Diagram.....................................................15
6. EXPLODEDVIEW...................................................... 17
7. ELECTRICAL PARTS LIST.................................... 18
TABLE OF CONTENTS
SECTION 1
SERVICING NOTE
CANCELLINGTHE PROTECTOR DURING SERVICING
Cut JW132 on the amplifier board to cancel the protector.
After servicing always be sure to return JW132 to its original state.
T901
JW131 JW132
JW168
JW167
PROTECTOR OFF

– 3 –
SECTION 2
GENERAL This section is extracted from
instruction manual.

– 4 –

– 5 – – 6 –
SECTION 3
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
3-1. BOTTOM PLATE, PANEL (FRONT), PANEL (REAR), SP (FRONT) BOARD,
SP (REAR) BOARD REMOVAL
3-2. AMPLIFIER BOARD REMOVAL
1 Screws (+BTP 3X5)
1 Screws (+BTP 3X5)
2 Bottom plate
7 Screw (+BTP 3X8)
7 Screws
(+BTP 3X8
)
7 Screws
(+BTP 3X8)
!¡ Screws
9 Screws
8 Panel (rear)
!™ SP (rear) board
!º SP (front)
board
CN803
CN802
6 Panel (front)
5 Connector
Heat sink
4 Screws (+BTP 3X8)
3 Auto fuse (40A)
4 Screws
(+BTP 3X8)
4 Screw
(+BTP 3X8)
3 Screws
(+P 4X10)
2 High level board
1 Screws
(+BTP 3X5)
3 Screws
(+P 4X10)
3 Amplifier board
Heat sink
SECTION 4
ELECTRICAL ADJUSTMENT
Bias Adjustment
Procedure :
1. Rotare semi-fixed resistors RV104, RV204, RV304 and RV404
fully counterclockwise as viewed from the component side
2. No signal is entered, as input signal.
3. Apply the source voltage 14.4V between +12V, REMOTE and
GND terminals.
4. Adjust the RV104 (FRONT L-CH), RV204 (FRONT R-CH),
RV304 (REAR L-CH) and RV404 (REAR R-CH) so that the
digital voltmeter reading becomes the adjustment limits below.
Adjustment Limits : 3 ± 0.3mV
Adjustment Location :
[AMPLIFIER BOARD] (Component side)
digital
voltmeter
TP301 TP401
TP402
R343 R443
R143 R243
RV304
L-CH R-CH
RV404
digital
voltmete
r
TP202
TP201
TP101
RV104
L-CH
R-CH RV204
– REAR –
– FRONT –

– 15 – – 16 –
5-3. SCHEMATIC DIAGRAM XM-754HX

– 17 – – 18 –
SECTION 6
EXPLODED VIEW
NOTE :
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “ * ”are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• The mechanical parts with no reference
number in the exploded views are not
supplied.
• Hardware (# mark) list and accessories and
packing materials are given in the last of this
parts list.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
1 3-023-803-01 COVER
*2 3-023-796-01 PLATE, BOTTOM
*3 3-023-131-01 PANEL, FRONT
*4 3-023-795-01 BRACKET (FAN)
*5 3-023-801-01 HEAT SINK
*6 3-023-797-11 PLATE, ORNAMENTAL
*7 3-025-082-01 SHEET (DOUBLE-FACE)
*8 3-023-804-01 SHEET, DIFFUSION
*9 1-669-871-11 SP (REAR) BOARD
*10 3-023-132-01 PANEL, REAR
*11 1-669-870-11 SP (FRONT) BOARD
*12 A-3313-744-A AMPLIFIER BOARD, COMPLETE
*13 3-023-798-01 BRACKET (VR)
*14 3-023-799-01 BRACKET (HIGH LEVEL)
*15 1-669-872-11 HIGH LEVEL BOARD
*16 3-936-982-01 PLATE (TR), RETAINER
*17 3-025-081-01 SHEET (INSULATING)
*18 3-023-800-01 BRACKET (BOTTOM PLATE)
*19 3-025-083-01 RUBBER, LIGHT INTERCEPTION
CN802 1-694-425-11 TERMINAL BOARD (4P)
(FRONT SPEAKER OUT)
CN803 1-694-425-11 TERMINAL BOARD (4P) (REAR SPEAKER OUT)
CN818 1-537-479-11 TERMINAL
CN819 1-537-479-11 TERMINAL
D907 8-719-210-30 DIODE F10P20F(R)
D908 8-719-210-30 DIODE F10P20F(R)
D909 8-719-210-30 DIODE F10P20F(R)
D910 8-719-210-30 DIODE F10P20F(R)
F901 1-533-743-11 FUSE (BLADE TYPE) (AUTO FUSE) (40A)
FN801 1-763-107-11 MOTOR, FAN
Q109 8-729-038-52 TRANSISTOR IRF540(H)
Q110 8-729-038-01 TRANSISTOR IRF9540(H)
Q209 8-729-038-52 TRANSISTOR IRF540(H)
Q210 8-729-038-01 TRANSISTOR IRF9540(H)
Q309 8-729-038-52 TRANSISTOR IRF540(H)
Q310 8-729-038-01 TRANSISTOR IRF9540(H)
Q409 8-729-038-52 TRANSISTOR IRF540(H)
Q410 8-729-038-01 TRANSISTOR IRF9540(H)
Q904 8-729-030-72 TRANSISTOR MTAJ50N05HD
Q905 8-729-030-72 TRANSISTOR MTAJ50N05HD
Q906 8-729-030-72 TRANSISTOR MTAJ50N05HD
Q907 8-729-030-72 TRANSISTOR MTAJ50N05HD
TH802 1-809-664-51 THERMISTOR, POSITIVE
TH803 1-809-664-51 THERMISTOR, POSITIVE
#1
#1 #1
#2
#2
#2
#2
#3
#4
#5
#5
#4
#2 #2
#2
#2
#4
#4
#4 #4
#5
#4
#1
#10
#11
#11 #12
#12
#10
#8
#8
#9
#9
Q904-907
TH802
CN818,
CN819
F901
FN801
D907-910
Q309, 310
1
2
3
4
5
7
6
8
10
12
13
15
16
17
17
17
18
not
supplied
not supplied
9
11
14
14
18
CN803
CN802
16
16
16
TH803
Q409,
410
Q109, 11
0
Q209, 210
19
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example :
uA.... : µA.... , uPA.... : µPA....
uPB.... : µPB.... , uPC.... : µPC....
uPD.... : µPD....
• CAPACITORS
uF : µF
• COILS
uH : µH
When indicating parts by reference num-
ber, please include the board.
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
*A-3313-744-A AMPLIFIER BOARD, COMPLETE
*************************
< CAPACITOR >
C101 1-126-047-11 ELECT 4.7uF 20% 50V
C102 1-126-047-11 ELECT 4.7uF 20% 50V
C103 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C104 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C105 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C106 1-136-167-00 FILM 0.15uF 5% 50V
C107 1-136-167-00 FILM 0.15uF 5% 50V
C108 1-126-047-11 ELECT 4.7uF 20% 50V
C109 1-126-047-11 ELECT 4.7uF 20% 50V
C110 1-126-047-11 ELECT 4.7uF 20% 50V
C111 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C112 1-126-047-11 ELECT 4.7uF 20% 50V
C113 1-126-957-11 ELECT 0.22uF 20% 50V
C114 1-126-008-11 ELECT 47uF 20% 16V
C115 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C121 1-104-661-11 ELECT 330uF 20% 16V
C123 1-126-008-11 ELECT 47uF 20% 16V
C126 1-102-951-00 CERAMIC 15PF 5% 50V
C127 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C130 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C201 1-126-047-11 ELECT 4.7uF 20% 50V
C202 1-126-047-11 ELECT 4.7uF 20% 50V
C203 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C204 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C205 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C206 1-136-167-00 FILM 0.15uF 5% 50V
C207 1-136-167-00 FILM 0.15uF 5% 50V
C208 1-126-047-11 ELECT 4.7uF 20% 50V
C209 1-126-047-11 ELECT 4.7uF 20% 50V
C210 1-126-047-11 ELECT 4.7uF 20% 50V
C211 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C212 1-126-047-11 ELECT 4.7uF 20% 50V
C213 1-126-957-11 ELECT 0.22uF 20% 50V
C214 1-126-008-11 ELECT 47uF 20% 16V
C215 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C221 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C222 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C223 1-126-008-11 ELECT 47uF 20% 16V
C226 1-102-951-00 CERAMIC 15PF 5% 50V
C227 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C230 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C301 1-126-047-11 ELECT 4.7uF 20% 50V
C302 1-126-047-11 ELECT 4.7uF 20% 50V
C303 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C304 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C305 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C306 1-136-167-00 FILM 0.15uF 5% 50V
C307 1-136-167-00 FILM 0.15uF 5% 50V
C308 1-126-047-11 ELECT 4.7uF 20% 50V
C309 1-126-047-11 ELECT 4.7uF 20% 50V
C310 1-126-047-11 ELECT 4.7uF 20% 50V
C311 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C312 1-126-047-11 ELECT 4.7uF 20% 50V
C313 1-126-957-11 ELECT 0.22uF 20% 50V
C314 1-126-008-11 ELECT 47uF 20% 16V
C315 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C322 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C323 1-126-008-11 ELECT 47uF 20% 16V
C326 1-102-951-00 CERAMIC 15PF 5% 50V
C327 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C330 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C401 1-126-047-11 ELECT 4.7uF 20% 50V
C402 1-126-047-11 ELECT 4.7uF 20% 50V
C403 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C404 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C405 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C406 1-136-167-00 FILM 0.15uF 5% 50V
C407 1-136-167-00 FILM 0.15uF 5% 50V
C408 1-126-047-11 ELECT 4.7uF 20% 50V
C409 1-126-047-11 ELECT 4.7uF 20% 50V
C410 1-126-047-11 ELECT 4.7uF 20% 50V
C411 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C412 1-126-047-11 ELECT 4.7uF 20% 50V
C413 1-126-957-11 ELECT 0.22uF 20% 50V
C414 1-126-008-11 ELECT 47uF 20% 16V
C415 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C421 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C422 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C423 1-126-008-11 ELECT 47uF 20% 16V
C426 1-102-951-00 CERAMIC 15PF 5% 50V
C427 1-165-319-11 CERAMIC CHIP 0.1uF 50V
AMPLIFIER
• Abbreviation
G : German

– 19 –
C430 1-163-239-11 CERAMICCHIP 33PF 5% 50V
C801 1-124-282-00 ELECT 22uF 20% 16V
C802 1-163-141-00 CERAMICCHIP 0.001uF 5% 50V
C803 1-126-967-11 ELECT 47uF 20% 10V
C804 1-126-956-11 ELECT 0.1uF 20% 50V
C805 1-165-319-11 CERAMICCHIP 0.1uF 50V
C806 1-128-551-11 ELECT 22uF 20% 25V
C807 1-163-133-00 CERAMICCHIP 470PF 5% 50V
C808 1-163-133-00 CERAMICCHIP 470PF 5% 50V
C809 1-128-551-11 ELECT 22uF 20% 25V
C810 1-163-141-00 CERAMICCHIP 0.001uF 5% 50V
C811 1-163-141-00 CERAMICCHIP 0.001uF 5% 50V
C901 1-165-319-11 CERAMICCHIP 0.1uF 50V
C902 1-165-319-11 CERAMICCHIP 0.1uF 50V
C903 1-163-141-00 CERAMICCHIP 0.001uF 5% 50V
C904 1-163-141-00 CERAMICCHIP 0.001uF 5% 50V
C905 1-163-141-00 CERAMICCHIP 0.001uF 5% 50V
C906 1-163-141-00 CERAMICCHIP 0.001uF 5% 50V
C907 1-165-319-11 CERAMICCHIP 0.1uF 50V
C908 1-165-319-11 CERAMICCHIP 0.1uF 50V
C909 1-106-343-00 MYLAR 1000PF 5% 200V
C910 1-128-551-11 ELECT 22uF 20% 25V
C911 1-126-933-11 ELECT 100uF 20% 10V
C912 1-126-933-11 ELECT 100uF 20% 16V
C913 1-163-141-00 CERAMICCHIP 0.001uF 5% 50V
C914 1-163-141-00 CERAMICCHIP 0.001uF 5% 50V
C915 1-136-173-00 FILM 0.47uF 5% 50V
C916 1-106-383-00 MYLAR 0.047uF 5% 200V
C917 1-111-044-11 ELECT 2200uF 20% 16V
C918 1-111-044-11 ELECT 2200uF 20% 16V
C919 1-111-044-11 ELECT 2200uF 20% 16V
C920 1-126-052-11 ELECT 100uF 20% 50V
C921 1-126-052-11 ELECT 100uF 20% 50V
C922 1-136-177-00 FILM 1uF 5% 50V
C923 1-136-177-00 FILM 1uF 5% 50V
C924 1-126-052-11 ELECT 100uF 20% 35V
C925 1-126-052-11 ELECT 100uF 20% 35V
C926 1-125-826-11 CAPACIT OR 5600uF 50V
C927 1-125-826-11 CAPACIT OR 5600uF 50V
C928 1-165-319-11 CERAMICCHIP 0.1uF 50V
C929 1-165-319-11 CERAMICCHIP 0.1uF 50V
C930 1-126-009-11 ELECT 100uF 20% 16V
C931 1-126-009-11 ELECT 100uF 20% 16V
C932 1-107-364-11 MYLAR 0.01uF 10% 200V
C933 1-111-044-11 ELECT 2200uF 20% 16V
C933 1-165-319-11 CERAMICCHIP 0.1uF 50V
C934 1-165-319-11 CERAMICCHIP 0.1uF 50V
C935 1-126-157-11 ELECT 10uF 20% 16V
C936 1-126-157-11 ELECT 10uF 20% 16V
C937 1-164-232-11 CERAMICCHIP 0.01uF 50V
C938 1-163-141-00 CERAMICCHIP 0.001uF 5% 50V
C939 1-163-141-00 CERAMICCHIP 0.001uF 5% 50V
C940 1-163-141-00 CERAMICCHIP 0.001uF 5% 50V
C941 1-163-141-00 CERAMICCHIP 0.001uF 5% 50V
<CONNECTOR>
CN801 1-537-477-21 TERMINAL BOARD(3P)(REMOTE,+12V ,GND)
CN818 1-537-479-11 TERMINAL
CN819 1-537-479-11 TERMINAL
CNP802 1-784-917-11 CONNECTOR,BOARDTOBOARD9P
*CNP803 1-564-704-11 PIN,CONNECTOR(SMALLTYPE)2P
CNP804 1-564-320-00 PIN,CONNECTOR(B2P-VH)2P
CNP805 1-564-320-00 PIN,CONNECTOR(B2P-VH)2P
CNP806 1-564-320-00 PIN,CONNECTOR(B2P-VH)2P
CNP807 1-564-320-00 PIN,CONNECTOR(B2P-VH)2P
<PINJACK>
CNJ801 1-779-078-51 JACK,PIN4P(INPUT)
<DIODE>
D801 8-719-025-34 DIODE 02CZ6.8-TE85L
D802 8-719-801-78 DIODE 1SS184
D803 8-719-801-78 DIODE 1SS184
D804 8-719-801-78 DIODE 1SS184
D805 8-719-801-78 DIODE 1SS184
D806 8-719-158-49 DIODE RD12SB2
D807 8-719-801-78 DIODE 1SS184
D808 8-719-070-01 LEDSEC2764C(OVERCURRENT)
D809 8-719-070-01 LEDSEC2764C(OFFSET)
D810 8-719-070-01 LEDSEC2764C(THERMAL)
D811 8-719-070-01 LEDSEC2764C(HI-CURRENT)
D812 8-719-070-01 LEDSEC2764C(HI-VOL TAGE)
D901 8-719-025-34 DIODE 02CZ6.8-TE85L
D902 8-719-025-50 DIODE 02CZ16-TE85L
D903 8-719-987-67 DIODE 11EFS2
D904 8-719-987-67 DIODE 11EFS2
D905 8-719-054-55 DIODE 1SS306(TE85L)
D906 8-719-054-55 DIODE 1SS306(TE85L)
D907 8-719-210-30 DIODE F10P20F(R)
D908 8-719-210-30 DIODE F10P20F(R)
D909 8-719-210-30 DIODE F10P20F(R)
D910 8-719-210-30 DIODE F10P20F(R)
D911 8-719-801-78 DIODE 1SS184
D912 8-719-801-78 DIODE 1SS184
D913 8-719-025-49 DIODE 02CZ15-TE85L
D914 8-719-025-49 DIODE 02CZ15-TE85L
D915 8-719-025-49 DIODE 02CZ15-TE85L
D916 8-719-025-49 DIODE 02CZ15-TE85L
D917 8-719-987-67 DIODE 11EFS2
D918 8-719-987-67 DIODE 11EFS2
<IC>
IC801 8-759-711-82 IC NJM4580E
IC802 8-759-711-82 IC NJM4580E
IC803 8-759-711-82 IC NJM4580E
IC804 8-759-711-82 IC NJM4580E
IC805 8-759-711-82 IC NJM4580E
IC806 8-759-711-82 IC NJM4580E
IC807 8-759-711-82 IC NJM4580E
IC808 8-759-711-82 IC NJM4580E
IC809 8-759-711-82 IC NJM4580E
IC810 8-759-711-82 IC NJM4580E
IC811 8-759-711-82 IC NJM4580E
IC812 8-759-711-82 IC NJM4580E
IC813 8-719-156-72 PHOTOCOUPLERPS2501-1KA
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMPLIFIER

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMPLIFIER
– 20 –
IC901 8-759-144-88 ICUPC494GS
IC902 8-719-156-72 PHOTO COUPLER PS2501-1KA
< JUMPER RESISTOR >
JR1 1-216-295-00 CONDUCTORCHIP
JR2 1-216-295-00 CONDUCTORCHIP
JR3 1-216-295-00 CONDUCTORCHIP
JR4 1-216-295-00 CONDUCTORCHIP
JR5 1-216-295-00 CONDUCTORCHIP
JR6 1-216-295-00 CONDUCTORCHIP
JR7 1-216-295-00 CONDUCTORCHIP
JR8 1-216-295-00 CONDUCTORCHIP
JR9 1-216-295-00 CONDUCTORCHIP
JR10 1-216-295-00 CONDUCTOR CHIP
JR11 1-216-295-00 CONDUCTOR CHIP
JR12 1-216-295-00 CONDUCTOR CHIP
JR13 1-216-295-00 CONDUCTOR CHIP
JR14 1-216-295-00 CONDUCTOR CHIP
JR15 1-216-295-00 CONDUCTOR CHIP
JR16 1-216-295-00 CONDUCTOR CHIP
JR17 1-216-295-00 CONDUCTOR CHIP
JR18 1-216-295-00 CONDUCTOR CHIP
JR19 1-216-295-00 CONDUCTOR CHIP
JR20 1-216-295-00 CONDUCTOR CHIP
JR21 1-216-295-00 CONDUCTOR CHIP
JR22 1-216-295-00 CONDUCTOR CHIP
JR23 1-216-295-00 CONDUCTOR CHIP
JR24 1-216-295-00 CONDUCTOR CHIP
JR26 1-216-296-00 CONDUCTOR CHIP
JR27 1-216-296-00 CONDUCTOR CHIP
JR28 1-216-296-00 CONDUCTOR CHIP
JR29 1-216-296-00 CONDUCTOR CHIP
JR30 1-216-296-00 CONDUCTOR CHIP
JR31 1-216-296-00 CONDUCTOR CHIP
JR32 1-216-296-00 CONDUCTOR CHIP
JR33 1-216-296-00 CONDUCTOR CHIP
JR35 1-216-296-00 CONDUCTOR CHIP
JR41 1-216-296-00 CONDUCTOR CHIP
JR42 1-216-296-00 CONDUCTOR CHIP
JR43 1-216-296-00 CONDUCTOR CHIP
JR44 1-216-296-00 CONDUCTOR CHIP
JR45 1-216-296-00 CONDUCTOR CHIP
JR46 1-216-296-00 CONDUCTOR CHIP
JR47 1-216-296-00 CONDUCTOR CHIP
< COIL >
L9011-419-851-11INDUCTOR50uH
L902 1-410-396-71 INDUCTOR 0.45uH
L903 1-410-396-41 FERRITEBEADINDUCTOR 0.45uH
L904 1-410-396-41 FERRITEBEADINDUCTOR 0.45uH
L905 1-410-396-41 FERRITEBEADINDUCTOR 0.45uH
L906 1-410-396-41 FERRITEBEADINDUCTOR 0.45uH
L907 1-410-396-41 FERRITEBEADINDUCTOR 0.45uH
L908 1-410-396-41 FERRITEBEADINDUCTOR 0.45uH
< PILOT LAMP >
PL801 1-518-540-00 LAMP , PILOT
< TRANSISTOR >
Q101 8-729-422-29 TRANSISTOR 2SD601A-S
Q102 8-729-203-48 TRANSISTOR 2SC3327-A
Q103 8-729-119-78 TRANSISTOR 2SC403SP-51
Q104 8-729-173-38 TRANSISTOR 2SA733-K
Q105 8-729-119-78 TRANSISTOR 2SC403SP-51
Q106 8-729-173-38 TRANSISTOR 2SA733-K
Q107 8-729-209-18 TRANSISTOR 2SA1360-Y
Q108 8-729-203-45 TRANSISTOR 2SC3423-O
Q109 8-729-038-52 TRANSISTOR IRF540(H)
Q110 8-729-038-01 TRANSISTOR IRF9540(H)
Q111 8-729-954-51 TRANSISTOR 2SC1545
Q112 8-729-216-21 TRANSISTOR 2SA1162-Y
Q113 8-729-216-21 TRANSISTOR 2SA1162-Y
Q201 8-729-422-29 TRANSISTOR 2SD601A-S
Q202 8-729-203-48 TRANSISTOR 2SC3327-A
Q203 8-729-119-78 TRANSISTOR 2SC403SP-51
Q204 8-729-173-38 TRANSISTOR 2SA733-K
Q205 8-729-119-78 TRANSISTOR 2SC403SP-51
Q206 8-729-173-38 TRANSISTOR 2SA733-K
Q207 8-729-209-18 TRANSISTOR 2SA1360-Y
Q208 8-729-203-45 TRANSISTOR 2SC3423-O
Q209 8-729-038-52 TRANSISTOR IRF540(H)
Q210 8-729-038-01 TRANSISTOR IRF9540(H)
Q211 8-729-954-51 TRANSISTOR 2SC1545
Q212 8-729-216-21 TRANSISTOR 2SA1162-Y
Q213 8-729-216-21 TRANSISTOR 2SA1162-Y
Q301 8-729-422-29 TRANSISTOR 2SD601A-S
Q302 8-729-203-48 TRANSISTOR 2SC3327-A
Q303 8-729-119-78 TRANSISTOR 2SC403SP-51
Q304 8-729-173-38 TRANSISTOR 2SA733-K
Q305 8-729-119-78 TRANSISTOR 2SC403SP-51
Q306 8-729-173-38 TRANSISTOR 2SA733-K
Q307 8-729-209-18 TRANSISTOR 2SA1360-Y
Q308 8-729-203-45 TRANSISTOR 2SC3423-O
Q309 8-729-038-52 TRANSISTOR IRF540(H)
Q310 8-729-038-01 TRANSISTOR IRF9540(H)
Q311 8-729-954-51 TRANSISTOR 2SC1545
Q312 8-729-216-21 TRANSISTOR 2SA1162-Y
Q313 8-729-216-21 TRANSISTOR 2SA1162-Y
Q401 8-729-422-29 TRANSISTOR 2SD601A-S
Q402 8-729-203-48 TRANSISTOR 2SC3327-A
Q403 8-729-119-78 TRANSISTOR 2SC403SP-51
Q404 8-729-173-38 TRANSISTOR 2SA733-K
Q405 8-729-119-78 TRANSISTOR 2SC403SP-51
Q406 8-729-173-38 TRANSISTOR 2SA733-K
Q407 8-729-209-18 TRANSISTOR 2SA1360-Y
Q408 8-729-203-45 TRANSISTOR 2SC3423-O
Q409 8-729-038-52 TRANSISTOR IRF540(H)
Q410 8-729-038-01 TRANSISTOR IRF9540(H)
Q411 8-729-954-51 TRANSISTOR 2SC1545
Q412 8-729-216-21 TRANSISTOR 2SA1162-Y
Q413 8-729-216-21 TRANSISTOR 2SA1162-Y
Q801 8-729-216-21 TRANSISTOR 2SA1162-Y
Q802 8-729-230-49 TRANSISTOR 2SC2712-YG
Q803 8-729-230-49 TRANSISTOR 2SC2712-YG
Q804 8-729-216-21 TRANSISTOR 2SA1162-Y
Ver 1.1

– 21 –
Q805 8-729-230-49 TRANSISTOR 2SC2712-YG
Q806 8-729-230-49 TRANSISTOR 2SC2712-YG
Q807 8-729-230-49 TRANSISTOR 2SC2712-YG
Q808 8-729-230-49 TRANSISTOR 2SC2712-YG
Q809 8-729-230-49 TRANSISTOR 2SC2712-YG
Q810 8-729-230-49 TRANSISTOR 2SC2712-YG
Q811 8-729-216-21 TRANSISTOR 2SA1162-Y
Q812 8-729-230-49 TRANSISTOR 2SC2712-YG
Q813 8-729-216-21 TRANSISTOR 2SA1162-Y
Q814 8-729-106-68 TRANSISTOR 2SD1615A-GP
Q815 8-729-216-21 TRANSISTOR 2SA1162-Y
Q901 8-729-041-38 TRANSISTOR 2SB1241TV2Q
Q902 8-729-216-21 TRANSISTOR 2SA1162-Y
Q903 8-729-230-49 TRANSISTOR 2SC2712-YG
Q904 8-729-030-72 TRANSIST OR MT AJ50N05HD
Q905 8-729-030-72 TRANSIST OR MT AJ50N05HD
Q906 8-729-030-72 TRANSIST OR MT AJ50N05HD
Q907 8-729-030-72 TRANSIST OR MT AJ50N05HD
Q908 8-729-230-49 TRANSISTOR 2SC2712-YG
Q909 8-729-230-49 TRANSISTOR 2SC2712-YG
Q910 8-729-209-15 TRANSISTOR 2SD2012
Q911 8-729-141-83 TRANSISTOR 2SB1094-LK
Q912 8-729-119-78 TRANSISTOR 2SC403SP-51
Q913 8-729-173-38 TRANSISTOR 2SA733-K
<RESISTOR>
R101 1-208-518-11 RES,CHIP 22K 2% 1/10W
R102 1-208-518-11 RES,CHIP 22K 2% 1/10W
R103 1-216-238-00 RES,CHIP 47K 2% 1/8W
R104 1-216-238-00 RES,CHIP 47K 2% 1/8W
R105 1-208-518-11 RES,CHIP 22K 2% 1/10W
R106 1-208-518-11 RES,CHIP 22K 2% 1/10W
R107 1-208-462-11 RES,CHIP 10K 2% 1/10W
R108 1-216-230-00 RES,CHIP 22K 2% 1/8W
R109 1-208-462-11 RES,CHIP 10K 2% 1/10W
R110 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
R111 1-216-214-00 RES,CHIP 4.7K 2% 1/10W
R112 1-208-462-11 RES,CHIP 10K 2% 1/10W
R113 1-216-214-00 RES,CHIP 4.7K 2% 1/8W
R114 1-208-534-11 RES,CHIP 100K 2% 1/10W
R115 1-208-534-11 RES,CHIP 100K 2% 1/10W
R116 1-208-534-11 RES,CHIP 100K 2% 1/10W
R117 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R118 1-208-534-11 RES,CHIP 100K 2% 1/10W
R119 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R120 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R121 1-208-518-11 RES,CHIP 22K 2% 1/10W
R122 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
R123 1-208-462-11 RES,CHIP 10K 2% 1/10W
R124 1-208-760-11 RES,CHIP 120 2% 1/10W
R126 1-216-210-00 RES,CHIP 3.3K 2% 1/8W
R127 1-208-518-11 RES,CHIP 22K 2% 1/10W
R128 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R129 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R130 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R131 1-208-810-11 RES,CHIP 15K 2% 1/10W
R132 1-208-810-11 RES,CHIP 15K 2% 1/10W
R133 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R134 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R135 1-208-365-11 RES,CHIP 100 2% 1/8W
R136 1-208-365-11 RES,CHIP 100 2% 1/8W
R137 1-208-534-11 RES,CHIP 100K 2% 1/10W
R138 1-208-534-11 RES,CHIP 100K 2% 1/10W
R139 1-249-419-11 CARBON 1.5K 5% 1/4W
R140 1-247-843-11 CARBON 3.3K 5% 1/4W
R141 1-216-685-11 METAL CHIP 27K 0.5% 1/10W
R142 1-208-462-11 RES,CHIP 10K 2% 1/10W
R143 1-240-179-11 METAL PLATE 0.03X2 5W F
R144 1-208-810-11 RES,CHIP 15K 2% 1/10W
R145 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R146 1-208-800-11 RES,CHIP 5.6K 2% 1/10W
R147 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R148 1-208-510-11 RES,CHIP 10K 2% 1/8W
R149 1-208-510-11 RES,CHIP 10K 2% 1/8W
R150 1-208-550-11 RES,CHIP 470K 2% 1/10W
R152 1-208-441-11 RES,CHIP 1.5K 2% 1/10W
R201 1-208-518-11 RES,CHIP 22K 2% 1/10W
R202 1-208-518-11 RES,CHIP 22K 2% 1/10W
R203 1-208-526-11 RES,CHIP 47K 2% 1/10W
R204 1-208-526-11 RES,CHIP 47K 2% 1/10W
R205 1-208-518-11 RES,CHIP 22K 2% 1/10W
R206 1-208-518-11 RES,CHIP 22K 2% 1/10W
R207 1-208-462-11 RES,CHIP 10K 2% 1/10W
R208 1-208-518-11 RES,CHIP 22K 2% 1/10W
R209 1-208-462-11 RES,CHIP 10K 2% 1/10W
R210 1-208-506-11 RES,CHIP 6.8K 2% 1/8W
R211 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R212 1-208-462-11 RES,CHIP 10K 2% 1/10W
R213 1-216-214-00 RES,CHIP 4.7K 2% 1/8W
R214 1-208-534-11 RES,CHIP 100K 2% 1/10W
R215 1-208-534-11 RES,CHIP 100K 2% 1/10W
R216 1-208-534-11 RES,CHIP 100K 2% 1/10W
R217 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R218 1-216-246-00 RES,CHIP 100K 2% 1/8W
R219 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R220 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R221 1-208-518-11 RES,CHIP 22K 2% 1/10W
R222 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
R223 1-208-462-11 RES,CHIP 10K 2% 1/10W
R224 1-208-760-11 RES,CHIP 120 2% 1/10W
R226 1-208-437-11 RES,CHIP 1K 2% 1/10W
R227 1-208-518-11 RES,CHIP 22K 2% 1/10W
R228 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R229 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R230 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R231 1-208-810-11 RES,CHIP 15K 2% 1/10W
R232 1-208-810-11 RES,CHIP 15K 2% 1/10W
R233 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R234 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R235 1-208-365-11 RES,CHIP 100 2% 1/8W
R236 1-208-365-11 RES,CHIP 100 2% 1/8W
R237 1-208-534-11 RES,CHIP 100K 2% 1/10W
R238 1-208-534-11 RES,CHIP 100K 2% 1/10W
R239 1-249-419-11 CARBON 1.5K 5% 1/4W
R240 1-247-843-11 CARBON 3.3K 5% 1/4W
R241 1-216-685-11 METAL CHIP 27K 0.5% 1/10W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMPLIFIER

– 22 –
R242 1-208-462-11 RES,CHIP 10K 2% 1/10W
R243 1-240-179-11 METAL PLATE 0.03X2 5W F
R244 1-208-810-11 RES,CHIP 15K 2% 1/10W
R245 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R246 1-208-800-11 RES,CHIP 5.6K 2% 1/10W
R247 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R248 1-208-510-11 RES,CHIP 10K 2% 1/8W
R249 1-208-510-11 RES,CHIP 10K 2% 1/8W
R250 1-208-550-11 RES,CHIP 470K 2% 1/10W
R252 1-208-441-11 RES,CHIP 1.5K 2% 1/10W
R301 1-208-518-11 RES,CHIP 22K 2% 1/10W
R302 1-208-518-11 RES,CHIP 22K 2% 1/10W
R303 1-208-526-11 RES,CHIP 47K 2% 1/10W
R304 1-208-526-11 RES,CHIP 47K 2% 1/10W
R305 1-216-230-00 RES,CHIP 22K 2% 1/8W
R306 1-208-518-11 RES,CHIP 22K 2% 1/10W
R307 1-208-462-11 RES,CHIP 10K 2% 1/10W
R308 1-208-518-11 RES,CHIP 22K 2% 1/10W
R309 1-208-462-11 RES,CHIP 10K 2% 1/10W
R310 1-208-506-11 RES,CHIP 6.8K 2% 1/8W
R311 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R312 1-208-462-11 RES,CHIP 10K 2% 1/10W
R313 1-216-214-00 RES,CHIP 4.7K 2% 1/8W
R314 1-208-534-11 RES,CHIP 100K 2% 1/10W
R315 1-208-534-11 RES,CHIP 100K 2% 1/10W
R316 1-208-534-11 RES,CHIP 100K 2% 1/10W
R317 1-216-182-00 RES,CHIP 220 2% 1/8W
R318 1-208-534-11 RES,CHIP 100K 2% 1/10W
R319 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R320 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R321 1-208-518-11 RES,CHIP 22K 2% 1/10W
R322 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
R323 1-208-462-11 RES,CHIP 10K 2% 1/10W
R324 1-208-760-11 RES,CHIP 120 2% 1/10W
R326 1-208-437-11 RES,CHIP 1K 2% 1/10W
R327 1-208-518-11 RES,CHIP 22K 2% 1/10W
R328 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R329 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R330 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R331 1-208-810-11 RES,CHIP 15K 2% 1/10W
R332 1-208-810-11 RES,CHIP 15K 2% 1/10W
R333 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R334 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R335 1-208-365-11 RES,CHIP 100 2% 1/8W
R336 1-208-365-11 RES,CHIP 100 2% 1/8W
R337 1-208-534-11 RES,CHIP 100K 2% 1/10W
R338 1-208-534-11 RES,CHIP 100K 2% 1/10W
R339 1-249-419-11 CARBON 1.5K 5% 1/4W
R340 1-247-843-11 CARBON 3.3K 5% 1/4W
R341 1-216-685-11 METAL CHIP 27K 0.5% 1/10W
R342 1-208-462-11 RES,CHIP 10K 2% 1/10W
R343 1-240-179-11 METAL PLATE 0.03X2 5W F
R344 1-208-810-11 RES,CHIP 15K 2% 1/10W
R345 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R346 1-208-800-11 RES,CHIP 5.6K 2% 1/10W
R347 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R348 1-208-510-11 RES,CHIP 10K 2% 1/8W
R349 1-208-510-11 RES,CHIP 10K 2% 1/8W
R350 1-208-550-11 RES,CHIP 470K 2% 1/10W
R352 1-208-441-11 RES,CHIP 1.5K 2% 1/10W
R401 1-208-518-11 RES,CHIP 22K 2% 1/10W
R402 1-208-518-11 RES,CHIP 22K 2% 1/10W
R403 1-208-526-11 RES,CHIP 47K 2% 1/10W
R404 1-208-526-11 RES,CHIP 47K 2% 1/10W
R405 1-208-518-11 RES,CHIP 22K 2% 1/10W
R406 1-208-518-11 RES,CHIP 22K 2% 1/10W
R407 1-208-462-11 RES,CHIP 10K 2% 1/10W
R408 1-208-518-11 RES,CHIP 22K 2% 1/10W
R409 1-208-462-11 RES,CHIP 10K 2% 1/10W
R410 1-208-506-11 RES,CHIP 6.8K 2% 1/8W
R411 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R412 1-208-462-11 RES,CHIP 10K 2% 1/10W
R413 1-216-214-00 RES,CHIP 4.7K 2% 1/8W
R414 1-208-534-11 RES,CHIP 100K 2% 1/10W
R415 1-208-534-11 RES,CHIP 100K 2% 1/10W
R416 1-208-534-11 RES,CHIP 100K 2% 1/10W
R417 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R418 1-208-534-11 RES,CHIP 100K 2% 1/10W
R419 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R420 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R421 1-208-518-11 RES,CHIP 22K 2% 1/10W
R422 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
R423 1-208-462-11 RES,CHIP 10K 2% 1/10W
R424 1-208-760-11 RES,CHIP 120 2% 1/10W
R426 1-208-437-11 RES,CHIP 1K 2% 1/10W
R427 1-208-518-11 RES,CHIP 22K 2% 1/10W
R428 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R429 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R430 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R431 1-208-810-11 RES,CHIP 15K 2% 1/10W
R432 1-208-810-11 RES,CHIP 15K 2% 1/10W
R433 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R434 1-216-635-11 METAL CHIP 220 0.5% 1/10W
R435 1-208-365-11 RES,CHIP 100 2% 1/8W
R436 1-208-365-11 RES,CHIP 100 2% 1/8W
R437 1-208-534-11 RES,CHIP 100K 2% 1/10W
R438 1-208-534-11 RES,CHIP 100K 2% 1/10W
R439 1-249-419-11 CARBON 1.5K 5% 1/4W
R440 1-247-843-11 CARBON 3.3K 5% 1/4W
R441 1-216-685-11 METAL CHIP 27K 0.5% 1/10W
R442 1-208-462-11 RES,CHIP 10K 2% 1/10W
R443 1-240-179-11 METAL PLATE 0.03X2 5W F
R444 1-208-810-11 RES,CHIP 15K 2% 1/10W
R445 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R446 1-208-800-11 RES,CHIP 5.6K 2% 1/10W
R447 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R448 1-208-510-11 RES,CHIP 10K 2% 1/8W
R449 1-208-510-11 RES,CHIP 10K 2% 1/8W
R450 1-208-550-11 RES,CHIP 470K 2% 1/10W
R452 1-216-202-00 RES,CHIP 1.5K 2% 1/8W
R801 1-208-558-11 RES,CHIP 1M 2% 1/10W
R802 1-208-437-11 RES,CHIP 1K 2% 1/10W
R803 1-208-510-11 RES,CHIP 10K 2% 1/8W
R804 1-216-698-11 METAL CHIP 91K 0.5% 1/10W
R805 1-208-522-11 RES,CHIP 33K 2% 1/10W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMPLIFIER

– 23 –
R806 1-208-462-11 RES,CHIP 10K 2% 1/10W
R807 1-208-462-11 RES,CHIP 10K 2% 1/10W
R808 1-208-462-11 RES,CHIP 10K 2% 1/10W
R809 1-208-462-11 RES,CHIP 10K 2% 1/10W
R810 1-208-558-11 RES,CHIP 1M 2% 1/10W
R811 1-208-494-11 RES,CHIP 2.2K 2% 1/8W
R812 1-208-486-11 RES,CHIP 1K 2% 1/8W
R813 1-216-210-00 RES,CHIP 3.3K 2% 1/8W
R814 1-208-486-11 RES,CHIP 1K 2% 1/8W
R815 1-216-210-00 RES,CHIP 3.3K 2% 1/8W
R816 1-208-486-11 RES,CHIP 1K 2% 1/8W
R817 1-216-210-00 RES,CHIP 3.3K 2% 1/8W
R818 1-208-462-11 RES,CHIP 10K 2% 1/10W
R819 1-208-510-11 RES,CHIP 10K 2% 1/8W
R820 1-208-462-11 RES,CHIP 10K 2% 1/10W
R821 1-208-462-11 RES,CHIP 10K 2% 1/10W
R822 1-216-210-00 RES,CHIP 3.3K 2% 1/8W
R823 1-208-462-11 RES,CHIP 10K 2% 1/10W
R824 1-216-238-00 RES,CHIP 47K 2% 1/8W
R825 1-208-462-11 RES,CHIP 10K 2% 1/10W
R826 1-208-510-11 RES,CHIP 10K 2% 1/8W
R827 1-208-462-11 RES,CHIP 10K 2% 1/10W
R828 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R829 1-208-462-11 RES,CHIP 10K 2% 1/10W
R830 1-208-462-11 RES,CHIP 10K 2% 1/10W
R832 1-216-210-00 RES,CHIP 3.3K 2% 1/8W
R833 1-208-522-11 RES,CHIP 33K 2% 1/10W
R834 1-208-522-11 RES,CHIP 33K 2% 1/10W
R835 1-208-526-11 RES,CHIP 47K 2% 1/10W
R836 1-208-526-11 RES,CHIP 47K 2% 1/10W
R837 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R838 1-208-423-11 RES,CHIP 270 2% 1/10W
R839 1-208-558-11 RES,CHIP 1M 2% 1/10W
R840 1-208-486-11 RES,CHIP 1K 2% 1/8W
R841 1-208-486-11 RES,CHIP 1K 2% 1/8W
R842 1-208-425-11 RES,CHIP 330 2% 1/10W
R843 1-208-441-11 RES,CHIP 1.5K 2% 1/10W
R844 1-208-486-11 RES,CHIP 1K 2% 1/8W
R850 1-208-462-11 RES,CHIP 10K 2% 1/10W
R901 1-208-462-11 RES,CHIP 10K 2% 1/10W
R902 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R903 1-208-518-11 RES,CHIP 22K 2% 1/10W
R904 1-208-812-11 RES,CHIP 18K 2% 1/10W
R905 1-218-760-11 RES,CHIP 220K 2% 1/10W
R906 1-216-210-00 RES,CHIP 3.3K 2% 1/8W
R907 1-216-202-00 RES,CHIP 1.5K 2% 1/8W
R908 1-216-202-00 RES,CHIP 1.5K 2% 1/8W
R909 1-208-449-11 RES,CHIP 3.3K 2% 1/10W
R910 1-208-453-11 RES,CHIP 4.7K 2% 1/10W
R911 1-249-429-11 CARBON 10K 5% 1/4W
R912 1-208-474-11 RES,CHIP 330 2% 1/8W
R913 1-208-478-11 RES,CHIP 470 2% 1/8W
R914 1-208-478-11 RES,CHIP 470 2% 1/8W
R915 1-208-405-11 RES,CHIP 47 2% 1/8W
R916 1-216-150-00 RES,CHIP 10 2% 1/8W
R917 1-208-437-11 RES,CHIP 1K 2% 1/10W
R918 1-208-437-11 RES,CHIP 1K 2% 1/10W
R919 1-208-405-11 RES,CHIP 47 2% 1/8W
R920 1-216-150-00 RES,CHIP 10 2% 1/8W
R921 1-216-150-00 RES,CHIP 10 2% 1/8W
R922 1-216-150-00 RES,CHIP 10 2% 1/8W
R923 1-216-210-00 RES,CHIP 3.3K 2% 1/8W
R924 1-216-210-00 RES,CHIP 3.3K 2% 1/8W
R925 1-208-506-11 RES,CHIP 6.8K 2% 1/8W
R926 1-208-506-11 RES,CHIP 6.8K 2% 1/8W
R927 1-208-478-11 RES,CHIP 470 2% 1/8W
R928 1-208-478-11 RES,CHIP 470 2% 1/8W
<VARIABLERESIST OR>
RV104 1-241-761-11 RES,ADJ,CARBON1K(BIAS)
RV204 1-241-761-11 RES,ADJ,CARBON1K(BIAS)
RV304 1-241-761-11 RES,ADJ,CARBON1K(BIAS)
RV404 1-241-761-11 RES,ADJ,CARBON1K(BIAS)
RV801 1-225-647-11 RES, VAR20K/20K/20K/20K
(FRONTLOWBOOST)
RV802 1-225-648-11 RES, VAR5K/5K(FRONT LOW BOOST)
RV803 1-225-648-11 RES, VAR5K/5K(FRONT LEVEL)
RV804 1-225-647-11 RES, VAR20K/20K/20K/20K (REARLOWBOOST)
RV805 1-225-648-11 RES, VAR5K/5K(REARLOW BOOST)
RV806 1-225-648-11 RES, VAR5K/5K(REARLEVEL)
<SWITCH>
S801 1-572-185-11 SWITCH,SLIDE(FRONT FILTER)
S802 1-572-185-11 SWITCH,SLIDE(REARFIL TER)
S901 1-771-387-11 SWITCH, TOGGLE(HI-CURRENT/HI-VOL TAGE)
<TRANSFORMER>
T901 1-431-882-21 TRANSFORMER,DC-DCCONVER TER
<THERMISTOR>
TH801 1-808-877-11 THERMISTOR
TH802 1-809-664-51 THERMISTOR,POSITIVE
TH803 1-809-664-51 THERMISTOR,POSITIVE
TH804 1-808-877-11 THERMISTOR
************************************************************
*1-669-872-11 HIGHLEVELBOARD
****************
<CAP ACIT OR>
C117 1-163-251-11 CERAMICCHIP 100PF 5% 50V
C118 1-163-251-11 CERAMICCHIP 100PF 5% 50V
C119 1-164-222-11 CERAMICCHIP 0.22uF 25V
C120 1-164-222-11 CERAMICCHIP 0.22uF 25V
C217 1-163-251-11 CERAMICCHIP 100PF 5% 50V
C218 1-163-251-11 CERAMICCHIP 100PF 5% 50V
C219 1-164-222-11 CERAMICCHIP 0.22uF 25V
C220 1-164-222-11 CERAMICCHIP 0.22uF 25V
C317 1-163-251-11 CERAMICCHIP 100PF 5% 50V
C318 1-163-251-11 CERAMICCHIP 100PF 5% 50V
C319 1-164-222-11 CERAMICCHIP 0.22uF 25V
C320 1-164-222-11 CERAMICCHIP 0.22uF 25V
C417 1-163-251-11 CERAMICCHIP 100PF 5% 50V
C418 1-163-251-11 CERAMICCHIP 100PF 5% 50V
C419 1-164-222-11 CERAMICCHIP 0.22uF 25V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMPLIFIER HIGH LEVEL

– 24 –
XM-754HX
C420 1-164-222-11 CERAMICCHIP 0.22uF 25V
<CONNECTOR >
CN804 1-784-904-21 CONNECTOR4P
(REAR HIGH LEVEL INPUT L/R)
CN805 1-784-904-31 CONNECTOR4P
(FRONT HIGH LEVEL INPUT L/R)
CNJ802 1-784-916-11 CONNECTOR, BOARD TO BOARD 9P
< RESISTOR >
R125 1-216-471-11 MET ALOXIDE 27 5 % 3W F
R225 1-216-471-11 MET ALOXIDE 27 5 % 3W F
R325 1-216-471-11 MET ALOXIDE 27 5 % 3W F
R425 1-216-471-11 MET ALOXIDE 27 5 % 3W F
************************************************************
*1-669-870-11 SP(FRONT) BOARD
****************
< CAP ACIT OR >
C128 1-106-383-00 MYLAR 0.047uF 5% 200V
C228 1-106-383-00 MYLAR 0.047uF 5% 200V
<CONNECTOR >
CN802 1-694-425-11 TERMINAL BOARD (4P)
(FRONT SPEAKER OUT)
< RESISTOR >
R151 1-215-857-11 MET ALOXIDE 10 5 % 1W F
R251 1-215-857-11 MET ALOXIDE 10 5 % 1W F
************************************************************
*1-669-871-11 SP(REAR) BOARD
***************
< CAP ACIT OR >
C328 1-106-383-00 MYLAR 0.047uF 5% 200V
C428 1-106-383-00 MYLAR 0.047uF 5% 200V
<CONNECTOR >
CN803 1-694-425-11 TERMINAL BOARD (4P) (REAR SPEAKER OUT)
< RESISTOR >
R351 1-215-857-11 MET ALOXIDE 10 5 % 1W F
R451 1-215-857-11 MET ALOXIDE 10 5 % 1W F
************************************************************
MISCELLANEOUS
*************
CN802 1-694-425-11 TERMINAL BOARD (4P)
(FRONT SPEAKER OUT)
CN803 1-694-425-11 TERMINAL BOARD (4P) (REAR SPEAKER OUT)
CN818 1-537-479-11 TERMINAL
CN819 1-537-479-11 TERMINAL
D907 8-719-210-30 DIODE F10P20F(R)
D908 8-719-210-30 DIODE F10P20F(R)
D909 8-719-210-30 DIODE F10P20F(R)
D910 8-719-210-30 DIODE F10P20F(R)
F901 1-533-743-11 FUSE (BLADE TYPE) (AUTO FUSE) (40A)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
FN801 1-763-107-11 MOTOR,F A N
Q109 8-729-038-52 TRANSISTOR IRF540(H)
Q110 8-729-038-01 TRANSISTOR IRF9540(H)
Q209 8-729-038-52 TRANSISTOR IRF540(H)
Q210 8-729-038-01 TRANSISTOR IRF9540(H)
Q309 8-729-038-52 TRANSISTOR IRF540(H)
Q310 8-729-038-01 TRANSISTOR IRF9540(H)
Q409 8-729-038-52 TRANSISTOR IRF540(H)
Q410 8-729-038-01 TRANSISTOR IRF9540(H)
Q904 8-729-030-72 TRANSIST OR MT AJ50N05HD
Q905 8-729-030-72 TRANSIST OR MT AJ50N05HD
Q906 8-729-030-72 TRANSIST OR MT AJ50N05HD
Q907 8-729-030-72 TRANSIST OR MT AJ50N05HD
TH802 1-809-664-51 THERMISTOR, POSITIVE
TH803 1-809-664-51 THERMISTOR, POSITIVE
************************************************************
ACCESSORIES & P ACKING MA TERIALS
*******************************
3-013-264-01 COVER, 3P TERMINAL T ABLE
3-367-410-01 SCREW (DIA. 5X15), T APPING
3-701-639-00 BAG,POL YETHYLENE
3-862-338-11 MANUAL,INSTRUCTION (ENGLISH, FRENCH)
(EXCEPT G)
3-862-338-21 MANUAL,INSTRUCTION(GERMAN, IT ALIAN)
(AEP ,UK,G,E)
3-862-338-31 MANUAL, INSTRUCTION (SP ANISH,
POR TUGUESE) (AEP ,UK,E)
3-862-338-41 MANUAL, INSTRUCTION (DUTCH, SWEDISH)
(AEP ,UK,E)
************************************************************
**************
HARDW ARELIST
**************
#1 7-685-544-14 SCREW +BTP 3X5 TYPE2 N-S
#2 7-685-546-19 SCREW +BTP 3X8 TYPE2 N-S
#3 7-685-797-09 SCREW +PTT 2.6X16 (S)
#4 7-685-646-79 SCREW +P 3X8 TYPE2 N-S
#5 3-912-431-11 SCREW M 4X8 (P)
#8 7-685-144-11 SCREW +P 3X5 TYPE2 N-S
#9 7-685-649-79 SCREW +P 3X14 TYPE2 N-S
#10 7-685-660-79 SCREW +P 4X10 TYPE2 N-S
#11 7-685-645-79 SCREW +P 3X6 TYPE2 N-S
#12 7-682-949-01 SCREW +PSW 3X10
HIGH LEVEL SP (FRONT) SP (REAR)

SERVICE MANUAL
SUPPLEMENT-1
File this supplement with the service manual.
XM-754HX
Subject:
Red Color Panal Addition
(ECN-CS804006)
Sony Corporation
Personal & Mobile Communication Company
9-925-796-81
99A0478-1
Printed in Japan © 1999.1
Published by Quality Assurance Dept.
*33-023-131-01PANEL, FRONT
*53-023-801-01HEAT SINK
*63-023-797-11PLATE, ORNAMENTAL
*10 3-023-132-01PANEL, REAR
The difference parts are described in this service manual
supplement-1.
Please refer to XM-754HX service manual previously issued
for the other information.
• DIFFERENCE PARTS LIST
Ref. No. Part No. Description Remark
Page Former New
17
Ref. No. Part No. Description Remark
US Model
Canadian Model
AEP Model
UK Model
E Model
*33-023-131-01PANEL, FRONT (BLUE)
*33-023-131-11PANEL, FRONT (RED)
*53-023-801-01HEAT SINK (BLUE)
*53-023-801-11HEAT SINK (RED)
*63-023-797-11PLATE, ORNAMENTAL (BLUE) .....(BLUE)
*6 3-023-797-31PLATE, ORNAMENTAL (CLEAR).....(RED)
*10 3-023-132-01PANEL, REAR (BLUE)
*10 3-023-132-11PANEL, REAR (RED)
NOTE:
•Color Indication of Appearance Parts
Example:
KNOB, BALANCE (WHITE) . . . (RED)
↑↑
Parts ColorCabinet's Color
•Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.

XM-754HX
REVISION HISTORY
Clicking the version allows you to jump to the revised page.
Also, clicking the version at the upper on the revised page allows you to jump to the next revised page.
Ver. Date Description of Revision
1.1 2001. 08 The CORRECTION-1 is included into Ver 1.1
1.0 1998. 01 New
