Sony DVP-NW50 - In-wall Dvd Player User manual

Dan Quittman, Sony CS&A
Version 0.85 July 18, 2005WallStation
Antenna Hints
Sony Electronics, CS&A dept.
1 Sony Drive
Park Ridge, NJ 07656
WallStation Antenna Antenna
Installation Hints and Guidelines
0.85
0.8
Version
Dan Quittman
Dan Quittman
Name
Version History
ChangesDate
Cosmetic mods7/18/05
Initial pre-release5/27/05
Disclaimer: Sony Electronics reserves the right to
change any specification or information contained in
this document at any time and without notice. Sony
does not warrant the information contained to be
factually correct, and the reader assumes any and all
responsibility for damages incurred from the use of
the information contained herein.

Dan Quittman, Sony CS&A
Version 0.85 July 18, 2005WallStation
Antenna Hints
Antenna Installation Hints and Guidelines
General
• Keep all antenna wiring away from AC electrical wiring to minimize interference. Avoid
long antenna runs that closely parallel AC wires.
• All antennas placed behind the wall must be rigidly affixed to studs and conform to all
local codes.
• Any antenna mounted outdoors must be properly grounded and lightning-arrested, and
should be installed by persons knowledgeable and experienced in these matters.
AM Antenna
• The AM antenna should be mounted a few feet above the WallStation and facing edge-
on to transmiters to maximize reception.
• Extending AM antenna leads is not recommended and can lead to reduced reception
and increased levels of interference.
• AM reception may be particularly compromised in some types of home construction,
particularly those using foil-wrapped insulation and/or aluminum siding.
FM Antenna
• Connection to an external FM antenna is recommended for best performance.
• When distributing the signal from an external antenna throughout the home, be sure to
use a quality splitter and CATV-type RG-6 coax.

Dan Quittman, Sony CS&A
Version 0.85 July 18, 2005WallStation
Antenna Hints
Wall Station
Wall Station Wall Station
Wall Station
Preferred Antenna Installation
Preferred Antenna InstallationPreferred Antenna Installation
Preferred Antenna Installation
Master Bedroom
Living room
AM Antenna
Mounted on stud
Amplified or passive FM Antenna
Mounted on roof, in attic or indoors
Splitter, 5-1000MHz
located at antenna
Kids’ room
Kitchen
AM Antenna
Mounted on stud
AM Antenna
Mounted on stud
AM Antenna
Mounted on stud
Coax RG-6/RG-59
Captive twin-lead

Dan Quittman, Sony CS&A
Version 0.85 July 18, 2005WallStation
Antenna Hints
Wall Station
Wall Station Wall Station
Wall Station
Alternate Antenna Installation
Alternate Antenna InstallationAlternate Antenna Installation
Alternate Antenna Installation
Master Bedroom
Living room
Coax RG-6/RG-59
Captive twin-lead
Kids room
Kitchen
Included AM Antenna
Mounted on stud
Passive FM Antenna (dipole)
Mounted to stud
Included AM Antenna
Mounted on stud
Passive FM Antenna (dipole)
Mounted to stud
Included AM Antenna
Mounted on stud
Passive FM Antenna (dipole)
Mounted to stud
Included AM Antenna
Mounted on stud
Passive FM Antenna (dipole)
Mounted to stud
