Sony CDX-CA400 - Compact Disc Changer System User manual

Note
General
Design and Specifications subject to change without notice.
Signal-to-noise ratio 90 dB
Frequency response 10 20,000 Hz
Wow and flutter Below measurable limit
Power Amplifier Section
Tuner Section
FM
Tuning range 87.5 107.9 MHz
Antenna terminal External antenna connector
Intermediate frequency 10.7 MHz
Usable sensitivity 11 dBf
Selectivity 75 dB at 400 kHz
Signal-to-noise ratio 65 dB (stereo), 68 dB (mono)
Harmonic distortion at 1 kHz 0.7% (stereo), 0.5% (mono)
Separation 33 dB at 1 kHz
Frequency response 30 15,000 Hz
AM
Tuning range 530 1,710 kHz
Antenna terminal External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
Sensitivity 30 µV
Outputs Speaker outputs
Speaker impedance 4 8 ohms
Maximum power output 50 W × 4 (at 4 ohms)
Outputs Audio outputs
Power antenna relay control lead
Power amplifier control lead
Tone controls Bass ±10 dB at 20 Hz (CDX-CA400)
Treble ±10 dB at 20 kHz (CDX-CA400)
Power requirements 12 V DC car battery (negative ground)
Dimensions Approx. 178 × 50 × 177 mm
(7 1/8 × 2 × 7 in.) (w/h/d)
Mounting dimensions Approx. 182 × 53 × 161 mm
(7 1/4 × 2 1/8 × 6 3/8 in.) (w/h/d)
Mass Approx. 1.2 kg
(2 lb. 10 oz.)
Supplied accessories Parts for installation and connections (1 set)
Front panel case (1)
Card remote commander
RM-X115
 CD/MD Control
 Detachable Face
 MBP (My Best Position)
 50W x 4 High Power
 Supplied Wireless Remote
(RM-X114)
 8fs, 1-Bit D/A Converter
 Active Servo Control
 60 Degree Install
 CD-RW Playback
 Indicates step-up
This unit cannot be connected to a digital preamplifier or an equalizer.
CDX-CA400
FM/AM Compact Disc Player
 D-Bass
 SSIR-EX Tuner
 18FM + 12AM memory presets
 Rear Preout
 7-segment LCD
 Active Display w/Demo Mode
POWER OUTPUT AND TOTAL HARMONIC DISTORTION
23 watts per channel minimum continuous average power into 4 ohms, 4 channels driven from 20 Hz to 20 kHz with no more than 5%
total harmonic distortion.
Audio Power Specifications
CD Player Section
2002 SONY MOBILE
PRODUCT GUIDE
Plug shown with wires facing viewer.
Pin Number Wire Color Description
1 White Left front +
2 Green Left rear +
3 Purple Right rear +
4 Gray Right front +
5 Blue/white AMP Remote
6 Blue ANT Remote
7 Red Accessory
8 Black Ground
9 White/black Left front -
10 Green/black Left rear -
11 Purple/black Right rear -
12 Gray/black Right front -
13 Sky blue ATT
14 Illumination
15
16 Yellow Battery
Harness Plug Configuration
16
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15

178 mm (7)
2002 SONY MOBILE
PRODUCT GUIDE
CDX-CA400
FM/AM Compact Disc Player
50 mm (2)
Fuse (10A)
From car antenna BUS Control IN
182 mm (7 1/4)
170 mm (6 11/16)
50 mm (2)
47 mm (1 7/16)
53 mm ( 2 1/16)
88 mm (3 7/16)
Design and Specifications subject to change without notice.
Audio OUT Rear
BUS Audio IN
33 mm (1 5/16)
27 mm (1 1/16)
