Sony CDX-CA710X Addendum to User manual

Signal-to-noise ratio 90 dB
Frequency response 10  20,000 Hz
Wow and lutter Below measurable limit
General
Design and Speci ications subject to change without notice.
CD Player Section
FM
Tuning range 87.5  107.9 MHz
Antenna terminal External antenna connector
Intermediate requency 10.7 MHz/450 kHz
Usable sensitivity 9 dB
Selectivity 75 dB at 400 kHz
Signal-to-noise ratio 67 dB (stereo), 69 dB (mono)
Harmonic distortion at 1 kHz 0.5% (stereo), 0.3% (mono)
Separation 35 dB at 1 kHz
Frequency response 30  15,000 Hz
AM
Tuning range 530  1,710 kHz
Antenna terminal External antenna connector
Intermediate requency 10.7 MHz/450 kHz
Sensitivity 30 µV
Outputs Speaker outputs (sure seal connectors)
Speaker impedance 4  8 ohms
Maximum power output 52 W × 4 (at 4 ohms)
Outputs Audio outputs (rear)
Power antenna relay control terminal
Power ampli ier control terminal
Input Telephone ATT control terminal
BUS control input terminal
BUS audio input terminal
Remote controller input terminal
Antenna input terminal
Tone controls Bass ±10 dB at 62 Hz
Treble ±10 dB at 16 kHz
Loudness +8 dB at 100 Hz
+2 dB at 10 kHz
Power requirements 12 V DC car battery (negative ground)
Dimensions Approx. 178 × 50 × 177 mm
(7 1/8 × 2 × 7 in.) (w/h/d)
Mounting dimensions Approx. 182 × 53 × 161 mm
(7 1/4 × 2 1/8 × 6 3/8 in.) (w/h/d)
Mass Approx. 1.2 kg
(2 lb. 10 oz.)
Supplied accessories Parts or installation and connections (1 set)
Front panel case (1)
Card remote commander RM-X118
This unit cannot be connected to a UniLink digital preampli ier or equalizer.
CDX-CA710X
FM/AM Compact Disc Player
Power Amplifier Section
Note
2003 SONY MOBILE
PRODUCT GUIDE
Tuner Section
 CD/MD Control w/Custom File
memory
 XT-XM1 Control
 DSO, EQ7
 52W x 4 High Power
 XM Ready, CD Text
 SSIR-EXA Tuner
 Flip-down Detachable Face
 18FM + 12AM memory presets
 Station Memo, Disc Memo, Memo List unctions
 3-color, 13-segment LED Display
 Supplied Wireless Card Remote (RM-X118)
 Optional Wired Rotary Remote (RM-X4S)
 Indicates step-up
POWER OUTPUT AND TOTAL HARMONIC DISTORTION
23.2 watts per channel minimum continuous average power into 4 ohms, 4 channels driven rom 20 Hz to 20 kHz with no more than 5%
total harmonic distortion.
Audio Power Specifications
Plug shown with wires acing viewer.
Pin Number Wire Color Description
1 White Le t ront +
2 Green Le t rear +
3 Purple Right rear +
4 Gray Right ront +
5 Blue/white AMP Remote
6 Blue ANT Remote
7 Red Accessory
8 Black Ground
9 White/black Le t ront -
10 Green/black Le t rear -
11 Purple/black Right rear -
12 Gray/black Right ront -
13 Sky blue ATT
14
15
16 Yellow Battery
Harness Plug Configuration
16
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15
 Rear Preamp Output
 8 s, 1-Bit D/A Converter
 Active Servo Control
 60 Degree Install
 CD-R/RW Playback

178 mm (7)
2003 SONY MOBILE
PRODUCT GUIDE
CDX-CA710X
FM/AM Compact Disc Player
50 mm (2)
Fuse (10A)
From car antenna
182 mm (7 1/4)
160 mm (6 3/8)
50 mm (2)
47 mm (1 7/8)
53 mm ( 2 1/16)
88 mm (3 7/16)
Design and Speci ications subject to change without notice.
Audio OUT Rear
33 mm (1 5/16)
27 mm (1 1/16)
BUS Control IN
BUS Audio IN
Remote IN
