Sony XR-5450 User manual

CS ONY 3-754-853-21 (1)
FM/AM Cassette Car Stereo
XR-5450
Operating Instructions pase 2
Before operating the unit, please read this manual thoroughly and
retain it for future reference.
Owner’s Record
The model and serial numbers are located on the top of the unit.
Record the serial number in the space provided below. Refer to
trem whenever you call upon your Sony dealer regarding this
froduct.
Model No.XR-5450 Serial No.
Mode d’emploii page 22
Avant la mise en service de cet appareil, priére de lire attentivement
ce mode d'emploi que l'on conservera pour toute référence
ultérieure.
For installation and connections, see the supplied installation/
connections manual.
En ce qui concere I'installation et les connexions, consulter le
manuel correspondant fourni.
©1992 by Sony Corporation

INFORMATION
This equipment generates and uses radio
frequency energy and if not installed and used
properly, that ts, in strict accordance with the
manufacturer's instructions, may cause
interference to radio and television reception. It
has been type tested and found to comply with
the limits for a Class B computing device in
accordance with the specifications in Subpart J
of Part 15 of FCC Rules, which are designed to
provide reasonable protection against such
interference in a residential installation.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
interference to radio or television reception.
which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of
the following measures:
Reorient the receiving antenna
Relocate the equipment with respect to the
receiver
Move the equipment away from the receiver
Plug the equipment into a different outlet so
that equipment and receiver are on different
branch circuits.
If necessary, the user should consult the dealer
or an experienced radio/television technician for
additional suggestions. The user may find the
following booklet prepared by the Federal
Communications Commission helpful:
“How to Identify and Resolve Radio-TV
Interference Problems”. This booklet is
available from the U.S. Government Printing
Office, Washington, DC 20402, Stock No. 004-
000-00345-4.
| English |
iF }0) (=o) m Cle) aic=iales
F@atUureS: 2 is) sossiiliaecsice ays te bei 3
Precautions ........... ccc cece eee cece ee ee 3
Location and function of controls ........... 4
Detaching and attaching the front panel .... 7
Setting the ClOCK ........... ccc cece cece eens 8
| Cassette deck operation *
Tape playback ........... ccc cece eee eee eee 9
[Radio reception |
Automatic tuning ............ ccc eee cece eee 12
Manual tuning ............... ccc ce eee ee eee 14
Memory preset tuning ................c ee eee 15
Maintenance ............ 0. cece cee erence eee 19
Specifications ......... ccc eee eee ee eee 20

wd asiorsiendte) ars)
Tuner section
¢ SSIR (Sony Super interference Rejection) PLL
synthesizer tuner for precise tuning
¢BTtA (Gest Tuning Memory) function
automatically selects and stores the stations
with strong signals on the preset number
buttons in order of frequency.
¢Memory preset tuning allows you to store 12
stations on the AM band and 18 stations on
the FM band in the memory.
¢Memory scan function scans preset stations
each for five seconds in order.
Cassette deck section
¢ The auto-reverse function changes tape
directions automatically.
ATA (Automatic Tuner Activation) function
automatically turns on the tuner while fast-
winding a tape.
General
¢ Detachable-front panel enables you to take
the ‘ront panel away with you when you leave
your car.
With the built-in amplifier, you can enjoy a
4-sp-eaker system.
¢Line output for connecting an optional power
ame lifier
¢ Quariz controlled digital clock
¢\f your car was parked in direct sunlight and
there was a considerable rise in temperature
inside the car, allow the unit to cool off before
operating.
¢ If no power is being supplied to the unit, check
the connections first. if everything is in order,
check the fuse.
¢ {If no sound comes from the speakers of a
2-speaker system, set the fader control to
the center position.
If you have any questions or problems
concerning your unit that are not covered in this
manual, please consult your nearest Sony
dealer.
Notes on Cassettes
Cassette care
¢ Avoid touching the tape surface of a cassette,
as any dirt or dust may contaminate the head.
¢Keep cassettes away from equipments with
magnets such as speakers and amplifiers, as
erasure or distortion of the recorded tape
could occur.
*Do not expose cassettes to direct sunlight,
extremely cold temperatures or moisture.
Note on cassettes longer than 90 minutes
The use of cassettes longer than 90 minutes is
not recommended except for long continuous
playback.
Notes on the Front Panel
When you remove the front panel, be sure to
turn off the power of the unit. However, if you
detach the front panel while the unit is turned
on, the power will automatically be turned off.
This will protect speakers from being damaged.
¢ Do not expose the front panel to direct
sunlight, heat sources such as hot air-ducts,
extremely cold temperatures or moisture.

Moyer: ifelamec late mm alUlaleiilelame)mexelaiege)(-
Refer to the pages in @ for details.
[1] M.SCAN (memory scan)/BTM (best
tuning memory) button
Press lightly to scan the memorized
stations, or press for more than two
seconds to memorize the clearest receiving
Stations.
[2] DSPL (display change/time set) button
[3] 4 (eject) button
Press to stop tape playback and to eject the
cassette.
[4] Cassette insertion door
[5] <</> > (fast winding)/DIR (tape
transport direction change) buttons @
Ouring playback, press <4<¢ or ®P for fast
winding, or press both <<@ and PP
simultaneously to listen to the other side of
the cassette.
[6] OFF (power off) button
Press to turn off the unit.
FM/AM (radio on/band select) button @
RELEASE (front panel release) button @
[9] SEEK (automatic tuning) button @
Press the — side to search stations in lower
frequencies and the + side to search
stations in higher frequencies.
MANU (manual) button ®
Press to tune in the desired stations
manually.
[11] SENS (sensitivity) button ®
(12) LOUD (loudness) button
Press to reinforce bass and treble especially
when listening at a low volume level. To
disengage the button, press it again.

[13) Display window fis] (bass/treble/batance/
SEL (control mode select) button fader/volume control) buttons
Pressio galedt the desired mode, BAS These buttons normally function as the
volume control. Adjust the level within three
a ala peniact Paeiwe EAD seconds after selecting the desired contro!
mode. Otherwise, the mode will go back to
the volume control mode.
oy |eomanen | SESE
S
Treble contro! | For less treble For more treble
Balance To decrease the right-speakers’ | To decrease the left-speakers’
t control volume volume
I To decrease the rear-speakers’ | To decrease the front-speakers’

Movers
hlolamcialem
alelateilelame)merejaitce)
|)
During tape playback
ATA (automatic tuner activation) button ®
During radio reception
Preset number buttons @
POWER SELECT switch (located on the
bottom of the unit)
See the description about the POWER
SELECT switch in the Installation/
Connections manual.
To mute the beep sound
Press L¢_} while pressing the SEL button.
To obtain the beep sound again, press these buttons
once more

WI To alia ve Me-latomenac(eal lace (am acelel@ ars l alc
The front panel of this unit can be detached in order to prevent
the unit from being stolen.
[ Detaching the Front Panel
Before detaching the front panel, be sure to
pres; the OFF button first. Then press the
REL =ASE button and detach the front panel by
pulting it towards you as illustrated.
Note
Be scre not to drop the front panel when detaching it
from ihe unit.
RELEASE button
[ Aitaching the Front Panel ——
Apply the right hand side of the front panel to
the unit by attaching the part © of the front
panel to the part @ of the unit as illustrated and
push until it clicks.
Main unit Rear of the front panel
o<}
Notes
Make: sure that the front panel is the right way up
wher attaching it to the unit as it cannot be attached
upsice down.
¢Do not press the front panel hard against the unit
wher attaching it. It can be easily attached by
Pressing it lightly against the unit.
¢When you carry the front panel with you, put it in the
suppiied front panel case.
*Do not press hard or give excessive pressure to the
display window of the front panel when attaching it to
the u rit.

Setting the Clock
Turn the ignition key to the ON position before setting the clock.
When setting the time digits
Press once to display the time digits.
Press to set the time digits while pressing
the DSPL button.
-: To advance the hour digits
+: To advance the minute digits
To advance the digits rapidly, keep the
button pressed.
\\ yom 1
18
hi
Note
Minute and hour digits do not go backward. it the POWER SELECT switch of the unit is set to the
*"00" comes after “59°. The hour digits do not change OFF position, the clock cannot be set unless the
then
power 1s turned on Set the clock after you turn on the
fadho or play back a tape.

E ape Playback
C-t-t JC)
eni\S/—cai-_-T-l
JCJ
insert a cassette.
Playback starts automatically.
Adjust the volume.
) =|
Befor.3
turning
off
the
unit:
Side
of
the
cassette
being
played
back
Be sure to eject the tape to avoid tape damage.
Indicator Side
> The side facing upwards
kw The side facing downwards
To gat the clock indication during tape
playback
Press the DSPL button. Press again to go back to the
previc us indication.

Tape Playback
Other Operations
To listen to the other
side of the cassette
To wind the tape : -
rapidly S Direction _
indicator*
|
To
advance
To
rewind
! press SS: (<<) a ies eS.
Z =i
To resume playback, press (>) or (9 lightly so as not to
depress it.
To stop playback and
listen to the radio
To stop playback and
turn off the unit Press and then press ,
i
“<I>” indicator will flash while fast-winding the tape.
10

Turning on the Radio Automatically while Fast-winding the Tape
(ATA Function)
The tuner turns on automatically when you press the <4 or
®P button during tape playback. When you resume tape
playback, the tuner turns off automatically. “ATA” indication
flashes while the ATA function is activated.
To cancel the mode
Press the button once more.
Note
You can release this function only during tape playback.
| The: car antenna will automatically be
: extended while the ATA function is
activated. (Only the cars equipped with
If you do not press the ATA button again to stop the
ATA function, the car antenna will be kept extended in
order to receive radio programs during tape playback.
| power antennas)

ssa sSUGpes
Press to select the desired band, FMI, FMll,
FMili, AMI or AMI.
The tuner turns on at the same time.
Press to start scanning.
-: For lower frequency stations
+: For higher frequency stations
The scanning automatically stops when a
station is tuned in.
Repeat this step until the desired station is
tuned in.
Adjust the volume.
Note To get the clock indication during radio -
FM has three bands (FMI. FMII and FMIII). Three reception
bands cover the same frequency range. To change the Press the DSPL button. Each time you press the
band. press (wad. button, the display mode changes as follows:
Frequency Clock display
| display mode mode |
12

— =>
Other Operations _
To stop the radio and
start tape playback
To stop the radio and
turn off the unit
When
there
are
too
many
stations
and
the
scanning
stops
too
frequently
during
automatic
tuning
:
*
Only
the
stations
with
Press
(sens)
once.
relatively
strong
signals
can
be
tuned
in.
* The noise will be reduced.
Press
(sens)
twice.
The
sound
will
be
monaural
instead.
*Each
time
you
press
the
button,
the
display
mode
When
an
FM
stereo
program
of
sufficient
charges
as
follows:
signal
strength
is
tuned
in
z LCL (local) —» MONO——+ normal
The program is automatically received in stereo.

Radio reception
WUETaTUre mm Rel aliare
Use this method when you know the frequency of the desired station, or when the
desired station is too weak to be tuned in by the automatic tuning.
Press to select the desired band, FMI, FMil,
FMill, AMI or AMII.
The tuner turns on at the same time.
Press to sefect the desired station.
-: For lower frequency stations
+: For higher frequency stations
To change the frequency rapidly, keep the
button pressed.
Adjust the volume.
Warning
While driving. keep your eyes on the road and use the
automatic tuning or memory preset tuning!

Radio reception
emory Preset Tuning
[ Memorizing the Stations Automatically (etm Function)
This unit can memorize up to 6 stations on each band, one on each preset number.
Press to select the desired band, FMI, FMIl,
FMilt, AMI or AMI).
The tuner turns on at the same time.
Keep the BTM button pressed for more than
two seconds.
Checking
What
is
Being
Broadcasted
on
the
Memorized
Stations
(Memory
Scan
Function)
M.SCAN The tuner will receive in order, all the memorized stations for
Press
(__)
lightly.
five
seconds
each.
To
cancel
this
function,
press
the
button
BTM lightly once more.
Note
There may be cases where even the memorized stations cannot be
received due to weak signals in the vicinity of your car.
15

Memory Preset Tuning
| The BTM function — how this function operates _
This function starts by scanning stations from
the lowest frequency of the currently tuned in
band. When a station is tuned in, it will be
stored in the memory on the preset number
button whose number is indicated on the
display window. If there is no preset number
indicated, it will be stored in the memory on the
preset number button 1 onward. It continues to
store the stations in the memory until all the
preset number buttons are occupied.
For example, if the FMi band was selected, it
will continue until the preset number button 6 on
the FMII! band is occupied. When all the preset
number buttons are occupied with the
memories before the highest receivable
frequency is scanned, the unit will start
scanning higher frequencies from where it was
left off. This is to check if there are any more
stations with clearer receptions than the ones
already stored in the memory.
Notes
¢There may be a situation where there are not enough
receivable stations due to the lack of stations in the
vicinity or weak broadcasting signals. In such cases,
the BTM operation may stop without all the preset
number buttons being stored with a memory.
elt you start the BTM operation from the FM! band, it
will continue to store stations in the memory on the
FMit and FMitt bands. Care must be taken if you wish
to keep the stored stations on the FMIl or FMIll
bands.
16
If a station with clearer reception ts found, the
unit will store it in the memory in place of a
station with an inferior reception.
Lastly, it rearranges all the stations in the order
of frequency from the lowest and stores them in
the memory. The whole operation is now
completed. The stations with clearer receptions
are stored in the memory on the preset number
buttons in the order of frequency.
eit you start the BTM operation from the FMI band,
will stop when all the memories on the FMill band are
occupied. it wilt not continue to the FMI band.

[
Memorizing
Only
the
Desired
Stations
Manually
|
You
can
memorize
up
to
6
stations
on
each
band
(FMI,
FMIl,
FMill,
AMI
and
AMI)
in
order
of
your
choice.
Exampie: To memorize on the preset number button 1
Press to select the desired band, FMI, FMIl,
Fill, AMI or AMII.
The tuner turns on at the same time.
Tune in a desired station
using the automatic or manual tuning.
Press for more than two seconds.
The number of the pressed preset number button
will be displayed. “MEM” indication appears to
show that the station has been memorized.
("MEM” indication will disappear in a few
seconds.)
Repeat these steps for each preset number button.
important
Ever, preset number button has only one memory for
a band. The previously memorized station will be
erased when you enter a new station of the same
band on the same preset number button.

Memory Preset Tuning
Receiving the Preset Station
Press to select the desired band.
Press the desired preset number button
lightly.
i
Notes
olf you keep pressing the preset number button for more
than two seconds. the currently received station will be
memonzed To receive the previously memorized
$tation, press the preset number button lightly.
¢ There may be cases where even the memorized
stations cannot be received due to weak signals in the
vicinity of your car
18

raitacsiatslalerss
[Fuse Replacement
If the fuse blows, check the power connection Warning
anc replace the fuse. If the fuse blows again Use the specified amperage fuse for each lead.
after the replacement, there may be an internal Use of a higher amperage fuse may cause
ma tunction. In this case, consult your nearest serious damage.
Sony dealer.
[ Cleaning the Head and the Tape Path
Prolonged use may contaminate the tape head
anc: the tape path. Contamination may cause
sound drop-out in playback. Clean the tape
heed and the tape path every two weeks to
enjoy optimum hi-fi stereo sound. Use a
commercially available cleaning cassette.
[ Cleaning the Connector
The unit may not function properly if the Main unit
connectors between the unit and the front panel
are contaminated with dirt. In order to prevent
this from happening, detach the front panel by
pressing the RELEASE button and clean the
connectors from time to time.
Clean the connectors with a cotton swab as
illustrated. Be sure to clean them with a Rear of the front panel
horizontal motion. Never clean them vertically
as this could damage the connecting points. SS

Specifications
| AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION 10 watts
per channel minimum continuous average power into 4 ohms, both
channels driven, from 30 to 20,000 Hz with no more than 1% total
harmonic distortion.
| Other Specifications -
Power amplifier section
Outputs Speaker outputs (sure seal
connectors)
Speaker impedance 4-8 ohms
Maximum power output
20 W x 4 (at 4 ohms)’
+ Measured at 14.4 V
Cassette player section
Tape track 4-track 2-channel stereo
Frequency response 30- 16,000 Hz
Signal-to-noise ratio 55 dB
Wow and flutter 0.13% (WRMS)
Tuner section
System Superheterodyne tuner
computerized quartz-locked
synthesizer system
Antenna terminal External antenna connector
FM
Tuning range 87.9 - 107.9 MHz
Intermediate frequency
10 7 MHz
Usable sensitivity 12 dBt (75 ohms)
Selectivity 75 OB at 400 kHz
Signal-to-noise ratio 65 dB (stereo). 70 dB (mono)
Harmonic distortion at 1 kHz
0 §% (stereo), 0.3% (mono)
Separation 35 dB at 1 kHz
Frequency response 30 - 15,000 Hz
Capture ratio 208
AM
Tuning range $30 - 1.710 kHz
Intermediate frequency
450 kHz
Sensitivity 35 pV
20
General
Tone controls
Loudness
Output lead
Power requirements
Dimensions
Mounting dimensions
Weight
Accessones supplied
Bass +8 dB at 100 Hz
Treble +8 dB at 10 kHz
+6 dB at 100 Hz
+6 dB at 10 kHz
Power antenna relay control
lead
Power amplifier control lead
12 V OC car battery (negative
ground)
Approx. 186 « 57 « 170 mm
(wih/d)
(73/8 x 2a x 63/a in.)
not incl_prosecting parts and
controls
Approx. 182 » 53 x 154mm
(witvd)
(7a x 2% x 6" in.)
Not incl. projecting parts and
controls
Approx. 1.3 kg (2 Ib 14 02.)
Mounting hardware (1 set)
Power connecting cord (1)
Front panel case (1)
Design and specifications subject to change without
notice.
