Troubleshooting Guide
- mechanical -
XperiaTM Z3 Compact
D5803, D5833

Troubleshooting Guide (mech)
1291-4299 Rev 1
Sony Mobile Communications AB –Company Internal
2(59)
CONTENTS
1Problem Areas ................................................................................ 5
1.1 Power .................................................................................................... 5
1.1.1 Will not power on or will switch off randomly........................................... 5
1.2 Keys ...................................................................................................... 7
1.2.1 Back, Menu, Home and Multitask Keys ..................................................... 7
1.2.2 Volume Key .................................................................................................. 7
1.2.3 On/Off Key.................................................................................................... 8
1.2.4 Camera Key................................................................................................ 10
1.3 Touch Screen ..................................................................................... 12
1.3.1 Touch Screen malfunction........................................................................ 12
1.4 Display ................................................................................................ 13
1.4.1 Graphics & Illumination ............................................................................ 13
1.5 LED/Illumination................................................................................. 14
1.5.1 LED/Illumination ........................................................................................ 14
1.6 Speaker ............................................................................................... 15
1.6.1 Loudspeaker .............................................................................................. 15
1.7 Ear speaker......................................................................................... 17
1.7.1 Ear Speaker................................................................................................ 17
1.8 Microphone......................................................................................... 18
1.8.1 Primary Microphone .................................................................................. 18
1.8.2 Secondary Microphone ............................................................................. 19
1.9 Vibrator ............................................................................................... 20
1.9.1 Vibrator not generating alerts .................................................................. 20
1.10 Camera................................................................................................ 21
1.10.1 Main Camera .............................................................................................. 21
1.10.2 Chat Camera defects................................................................................. 23
1.11 Flash LED ........................................................................................... 24
1.11.1 Flash LED not flashing.............................................................................. 24
1.12 Bluetooth and WLAN ......................................................................... 25
1.12.1 Bluetooth or WLAN connection failure.................................................... 25
1.13 NFC ..................................................................................................... 26
1.13.1 NFC malfunctions ...................................................................................... 26
1.14 GPS ..................................................................................................... 27
1.14.1 GPS malfunctions...................................................................................... 27
1.15 Compass............................................................................................. 28
1.15.1 Compass fails ............................................................................................ 28
1.16 Accelerometer .................................................................................... 29
1.16.1 Accelerometer test fails ............................................................................ 29
1.17 Gyroscope .......................................................................................... 30
1.17.1 Gyroscope test fails .................................................................................. 30
1.18 Ambient Light Sensor ........................................................................ 31
1.18.1 Light Sensor malfunctions ....................................................................... 31

Troubleshooting Guide (mech)
1291-4299 Rev 1
Sony Mobile Communications AB –Company Internal
3(59)
1.19 Proximity Switch ................................................................................ 33
1.19.1 Proximity switch malfunctions................................................................. 33
1.20 Pressure Sensor................................................................................. 35
1.20.1 Pressure Sensor test fails......................................................................... 35
1.21 Water Resistance ............................................................................... 36
1.21.1 Water Resistance fails............................................................................... 36
1.22 Real Time Clock ................................................................................. 42
1.22.1 Real time clock test fails........................................................................... 42
1.23 Total call time ..................................................................................... 43
1.23.1 Total call time fails .................................................................................... 43
1.24 External Memory ................................................................................ 44
1.24.1 Memory Card not detected ....................................................................... 44
1.25 Security............................................................................................... 45
1.25.1 Security fails .............................................................................................. 45
1.26 FM Radio............................................................................................. 46
1.26.1 No/Poor FM Radio reception .................................................................... 46
1.27 Battery Health test ............................................................................. 47
1.27.1 Battery Health test fails............................................................................. 47
1.28 Flip Slider Counter ............................................................................. 48
1.28.1 Flip Slider Counter fails ............................................................................ 48
1.29 Verify Certificates............................................................................... 49
1.29.1 Verify Certificates fails .............................................................................. 49
1.30 IrDA Test ............................................................................................. 50
1.30.1 IrDA test fails ............................................................................................. 50
1.31 TV-Out Test......................................................................................... 51
1.31.1 TV-Out test fails ......................................................................................... 51
1.32 Network & Signal................................................................................ 52
1.32.1 No/Poor signal ........................................................................................... 52
1.33 SIM ...................................................................................................... 54
1.33.1 SIM not detected........................................................................................ 54
1.33.2 Incorrect UIM or SIM indicated ................................................................. 54
1.34 Charging ............................................................................................. 55
1.34.1 Battery will not charge by USB connector .............................................. 55
1.34.2 Battery will not charge by charge pad ..................................................... 55
1.35 Audio Jack test................................................................................... 57
1.35.1 Connection to headset fails...................................................................... 57
1.36 Data Communication ......................................................................... 58
1.36.1 Data transfer via System Connector fails................................................ 58
2Revision History ........................................................................... 59

Troubleshooting Guide (mech)
1291-4299 Rev 1
Sony Mobile Communications AB –Company Internal
4(59)
Always firstly disconnect the Battery BtB connector to cut off power supply when the Cover Rear
is disassembled.
Always finally connect the Battery BtB connector before the Cover Rear is reassembled.

Troubleshooting Guide (mech)
1291-4299 Rev 1
Sony Mobile Communications AB –Company Internal
5(59)
1 Problem Areas
1.1 Power
1.1.1 Will not power on or will switch
off randomly
Check:
Check whether the phone vibrates by pressing the on/off
key.
Action:
1. If activation of the vibrator is detected, refer to section 1.4
‘Display’.
2. If NO activation of the Vibrator is detected, check that the
battery is charging when connected to a charger.
Follow
Test Instruction - mechanical chapter 2.3.4
(Charging via USB and Easy Charger), Diagnostic
Battery / Charging status.
Check:
Inspect the on/off key.
Action:
Refer to section 1.2.3 ‘On/Off Key’.
Check:
Inspect the Bt
B connector of the Battery to Main PBA.
Action:
1. If not properly connected
–
disconnect and reconnect it.
2. If dirty or oxidized
–clean the both sides of the BtB
connector.

Troubleshooting Guide (mech)
1291-4299 Rev 1
Sony Mobile Communications AB –Company Internal
6(59)
Problem Areas: Power
3. If the BtB connector, the FPC or the Battery is damaged –
replace the Battery.
4. Replace Main PBA.

Troubleshooting Guide (mech)
1291-4299 Rev 1
Sony Mobile Communications AB –Company Internal
7(59)
Problem Areas
1.2 Keys
1.2.1 Back, Menu, Home and
Multitask Keys
Action:
1. Refer to section 1.3 ‘Touch Screen’.
2. Replace Main PBA.
1.2.2
Volume Key
C
heck:
Inspect the
external area of the Key Volume.
Action:
If
dirty –clean it.
Check:
Inspect the
BtB connector of Side Key FPC
to Main PBA.
Action:
1. If not properly connected
–
disconnect and reconnect it.
2. If
dirty or oxidized –clean it.
3. If the
Side Key FPC is damaged –replace it.
4. Replace Main PBA.

Troubleshooting Guide (mech)
1291-4299 Rev 1
Sony Mobile Communications AB –Company Internal
8(59)
Problem Areas: Keys
Check:
Inspect the rubber of the Volume Key (a) and Volume Key
switch (b).
Action:
1. If dirty –clean them.
2. If the
rubber of the Volume Key is damaged –replace
the
Fro
nt Cover.
3. If the
volume key switch is damaged –replace the
Side
Key FPC
.
1.2.3
On/Off Key
C
heck:
Inspect the
external area of the On/Off Key.
Action:
If
dirty –clean it.

Troubleshooting Guide (mech)
1291-4299 Rev 1
Sony Mobile Communications AB –Company Internal
9(59)
Problem Areas: Keys
Check:
Inspect the BtB connector of Side Key FPC to Main PBA.
Action:
1. If not properly connected –disconnect and reconnect it.
2. If dirty or oxidized –clean it.
3. If the
Side Key FPC is damaged –replace it.
4.
Replace Main PBA.
Check:
Inspect the rubber of the
On/Off Key (a) and On/Off Key
switch (b).
Action:
1. If dirty
–clean them.
2. If the
rubber of the On/Off Key is damaged –replace
the
Fro
nt Cover.

Troubleshooting Guide (mech)
1291-4299 Rev 1
Sony Mobile Communications AB –Company Internal
10(59)
Problem Areas: Keys
3. If the On/Off key switch is damaged –replace the Side
Key FPC.
1.2.4
Camera Key
C
heck:
Inspect the
external area of the Camera Key.
Action:
If
dirty –clean it.
Check:
Inspect the BtB connector of
Side Key FPC
to Main PBA.
Action:
1. If not properly connected
–
disconnect and reconnect it.
2. If dirty or oxidized
–clean it.
3. If the
Side Key FPC is damaged –replace it.
4. Replace Main PBA.

Troubleshooting Guide (mech)
1291-4299 Rev 1
Sony Mobile Communications AB –Company Internal
11(59)
Problem Areas: Keys
Check:
Inspect the rubber of the Camera Key (a) and Camera Key
switch (b).
Action:
1. If dirty –clean them.
2. If the
rubber of the Camera Key is damaged –
replace the
Front
Cover.
3. If the
Camera key switch is damaged –replace the
Side
Key FPC
.

Troubleshooting Guide (mech)
1291-4299 Rev 1
Sony Mobile Communications AB –Company Internal
12(59)
Problem Areas
1.3 Touch Screen
1.3.1 Touch Screen malfunction
Check:
Inspect the touch screen of the Front Cover.
Action:
1. If dirty –clean it.
2. If scratched or damaged
–replace the Front Cover.
Check:
Inspect the BtB connector of
LCD FPC to Main PBA.
Action:
1. If not properly connected
–disconnect and
reconnect it.
2. If dirty or oxidized
–clean it.
3. If the BtB connector of
LCD FPC or LCD
FPC is damaged
–
replace the Front Cover.
4. Replace Main PBA.

Troubleshooting Guide (mech)
1291-4299 Rev 1
Sony Mobile Communications AB –Company Internal
13(59)
Problem Areas
1.4 Display
1.4.1 Graphics & Illumination
Check:
Check whether the phone vibrates after the on/off key has
been pressed.
Action:
If the activation described above is not detected, refer to
section 1.1 ‘Power’.
2. If scratched or damaged
–replace the Front Cover.
Check:
Inspect the BtB
connector of LCD FPC to Main PBA.
Action:
1. If not properly connected
–
disconnect and reconnect it.
2. If dirty or oxidized
–clean it.
3. If the BtB connector of
LCD FPC or LCD
FPC is damaged
–
replace the Front Cover.
4. Replace Main PBA.

Troubleshooting Guide (mech)
1291-4299 Rev 1
Sony Mobile Communications AB –Company Internal
14(59)
Problem Areas
1.5 LED/Illumination
1.5.1 LED/Illumination
Check:
Inspect external port of LED on the Front Cover.
Action:
1. If dirty –clean it.
Check:
Inspect internal port of LED light guide on the Front Cover.
Action:
1.
If dirty –clean it.
Check:
Inspect
the LED on the Main PBA.
Action:
1. If dirty
–clean it.
2. Replace Main PBA.

Troubleshooting Guide (mech)
1291-4299 Rev 1
Sony Mobile Communications AB –Company Internal
15(59)
Problem Areas
1.6 Speaker
1.6.1 Loudspeaker
Check:
Inspect the Loudspeaker’s external port on the Front Cover.
Action:
1. If clogged –clean it.
2. If
damaged –replace the Front Cover.
Check:
Inspect the contact
pads on the Cover Rear
Action:
1. If dirty
–clean them.
2. If
damaged –replace Cover Rear.
Check:
Inspect the contact pins on the
Main PBA.
Action:
1. If dirty
–clean them.
2. If
damaged –replace the Main PBA.

Troubleshooting Guide (mech)
1291-4299 Rev 1
Sony Mobile Communications AB –Company Internal
16(59)
Problem Areas: Speaker
Check:
Inspect the contact pins on the Loudspeaker.
Action:
1. If dirty –clean them.
2. If damaged –replace the Loudspeaker.
Check:
Inspect the
connection of Cover Rear and Loud Speaker
.
Action:
1. If not properly connected
–disassemble and re
assemble
Cover Rear
.

Troubleshooting Guide (mech)
1291-4299 Rev 1
Sony Mobile Communications AB –Company Internal
17(59)
Problem Areas
1.7 Ear speaker
1.7.1 Ear Speaker
Check:
Inspect the external port of Ear Speaker on the Front Cover.
Action:
1. If clogged –clean it.
Check:
Inspect the contact pads on the
Main PBA.
Action:
1. If dirty
–clean them.
2. If
damaged –replace the Main PBA.
Check:
Inspect the contact p
ins of the Ear Speaker.
Action:
1. If dirty
–clean them.
2. If
damaged –replace the Ear Speaker.
Check:
Inspect the
connection of Main PBA and Ear Speaker.
Action:
1. If not properly connected
–disassemble and re
assemble
Main PBA
.

Troubleshooting Guide (mech)
1291-4299 Rev 1
Sony Mobile Communications AB –Company Internal
18(59)
Problem Areas
1.8 Microphone
1.8.1 Primary Microphone
Check:
Inspect the Primary Microphone’s external port on the Front
Cover.
Action:
1. If clogged –clean it.
Check:
Inspect the
primary microphone on the Main PBA.
Action:
1. If dirty
–clean it.
2. Replace
the Main PBA.
Check:
Inspect the
Cushion Holder 1st MIC Duct on the Front
Cover
.
Action:
1.
Replace it.

Troubleshooting Guide (mech)
1291-4299 Rev 1
Sony Mobile Communications AB –Company Internal
19(59)
Problem Areas: Microphone
1.8.2 Secondary Microphone
Check:
Inspect the external port of secondary microphone on the
Front Cover.
Action:
1. If clogged –clean it.
Check:
Inspect the
Holder 2nd MIC Duct on the Main PBA.
Action:
1. If
damaged or not properly connected –replace it.
Check:
Inspect the
secondary microphone on the Main PBA.
Action:
1. If dirty
–clean it.
2. Replace
the Main PBA.

Troubleshooting Guide (mech)
1291-4299 Rev 1
Sony Mobile Communications AB –Company Internal
20(59)
Problem Areas
1.9 Vibrator
1.9.1 Vibrator not generating alerts
Check:
Inspect the BtB connector of Side Key FPC to Main PBA.
Action:
1. If not properly connected –disconnect and reconnect it.
2. If dirty or oxidized –clean it.
3.
If the connector or FPC of Side Key FPC or vibrator is
damaged
–replace the Side Key FPC.
4. Replace Main PBA.
