Sony Xperia M dual User manual

1277-1354 Rev 1
Sony Mobile Communications AB – Company Internal
Repair Movies
- mechanical -
C1904, C1905, C2004, C2005
Xperia
TM
M, Xperia
TM
M Dual

Repair Movie Repair Instruction Mechanical/
1277-1354 Rev 1
Sony Mobile Communications AB –
Company Internal
2(4)
CONTENTS
1 Movies .............................................................................................3
1.1 Disassembly.........................................................................................3
1.2 Reassembly..........................................................................................3
2 Revision History.............................................................................4
To view the embedded repair movies in this document, Acrobat Reader version 8 (or later) and
Flash Player version 8 (or later) must be installed on your computer.
For best picture quality, select “Actual size” or “100%” as zoom level in Acrobat Reader.
To magnify while keeping an acceptable picture quality, increase the zoom level to 200%.
If the movies appear to be jerky or blurred when viewing on-line, this is probably caused by the
connection speed being too slow.
In that case, right-click with the mouse on the document name and select Save Target As to
download the repair movie document for off-line viewing.
For general information about repair movies, refer to
1220-1333: Generic Repair Manual - mechanical

Repair Movie Repair Instruction Mechanical/
1277-1354 Rev 1
Sony Mobile Communications AB –
Company Internal
3(4)
1 Movies
1.1 Disassembly
1. Battery Cover Assy
2. Battery
3. Rear Cover Assy
4. Main PBA
5. ANT Board
6. Front Cover Assy
1.2 Reassembly
1. Front Cover Assy
2. ANT Board
3. Main PBA
4. Rear Cover Assy
5. Battery
6. Battery Cover Assy

Repair Movie Repair Instruction Mechanical/
1277-1354 Rev 1
Sony Mobile Communications AB –
Company Internal
4(4)
2 Revision History
Rev.
Date
Changes / Comments
1 2013-Aug-09 Initial release

1277-1364 Rev 1
©Sony Mobile Communications AB – Company Internal
Customization
- build swap -
C1904, C1905, C2004, C2005
XperiaTM M, XperiaTM M Dual
