Component Replacement
- electrical -
XperiaTM Z3
D6603, D6643, D6653

1291-5740 Rev 2

Sony Mobile Communications AB – Company Internal
2(10)
CONTENTS
1Replaceable Components .............................................................3
2Component Placing........................................................................5
3Additional Repair info....................................................................6
4Revision History...........................................................................10
For general information about electrical repair related issues, refer to
1220-1336: Generic Repair Manual - electrical
Test after electrical replacement: refer to 1273-1772 Mechanical Test Instruction
Do not remove shield can lids (Heat pasta are added and RF performance will be damaged)

1291-5740 Rev 2

Sony Mobile Communications AB – Company Internal
3(10)
1 Replaceable Components
EXPLANATION OF ABBREVIATIONS USED IN THE COLUMN ‘COMMENTS’ BELOW
COMPONENT LOCATION
P= Primary side
S= Secondary side
REPAIR METHOD
HA = Hot Air (removal & mounting)
ST = Soldering Tool (removal & mounting)
HA/ST = Hot Air for removal - Soldering Tool for mounting
BGA = BGA Station
BH = Bottom Heater
ADDITIONAL INFORMATION
1 (2,3,4, etc.) = Proceed to ‘Additional Repair Info’ for further instructions in the indicated section(s).

1291-5740 Rev 2

Sony Mobile Communications AB – Company Internal
4(10)
Position
Component
Part no.
Comments
CN1300 Conn BtB Plug 4p HIROSE/BM22 1281-9973 S HA+BH 1
CN1301 Conn BtB Receptacle 4p HIROSE/BM22 1264-6156 S HA+BH 2
CN2200 Conn USB B Receptacle 5p 1268-3388 P HA+BH or BGA 3
CN2650 Conn Leaf Spring Plug 1p 1289-6405 S HA+BH 4
CN2651 Conn Leaf Spring Plug 1p 1289-6405
S HA+BH

4
CN2653 Conn Coax Receptacle 1p 1237-5326
S HA+BH

5
CN2654 Conn Coax Receptacle 1p 1261-3585
S HA+BH

6
CN2655
Conn Coax Receptacle 1p
1237-5326
S HA+BH

7
CN4000
Card Conn SIM Nano
1278-7930
P HA+BH or BGA

8
CN4100
Card Conn Micro SD
1281-9124
P HA+BH or BGA

9
CN8000 Conn Leaf Spring Plug 1p 1289-6405 S HA+BH 10
CN8003 Conn Coax Receptacle 1p 1237-5326 S HA+BH 11
D7800 LED flash LED 2.03mmx1.63mmx0.70mm 1277-7270 S HA+BH 12
R1304 Resistor 0.01 Ohm +/-1% 200.0 mW (1.6x0. 1238-2147 S HA+BH 13
R5100
Resistor 0.0 Ohm +/-5% 63.0 mW K0402
1000-0179
S HA+BH

14

1291-5740 Rev 2

Sony Mobile Communications AB – Company Internal
5(10)
2 Component Placing
To access the Component Placing document, double-click the icon below.
Applicable for on-screen viewing only – icon not shown on hard-copies.
Primary side
Secondary side

1291-5740 Rev 2

Sony Mobile Communications AB – Company Internal
6(10)
3 Additional Repair info
1
CN1300
Replace if mechanical damaged. (Phone dead or power
off)
Protect the BtB connectors with capton tape!
2
CN1301
Replace if mechanical damaged. (Magnet charger not
working)
Protect the BtB connectors with capton tape!
3
CN2200
Replace if mechanical damaged (USB charger or data
transfer not working)
4
CN2650, CN2651
Replace if mechanical damaged (No or bad GPS
/network secondary antenna)
Protect the BtB connector with capton tape!

1291-5740 Rev 2

Sony Mobile Communications AB – Company Internal
7(10)
Repair Actions: Additional Repair Info
5
CN2653
Replace if open circuit 1-3 (No or bad GPS /network
secondary antenna)
6
CN2654
Replace if mechanical damaged (No or bad network,
main antenna)
Protect the RF connector with capton tape!
7
CN2655
Replace if open circuit 1-3 (No or bad network, main
antenna)
Protect the RF connector with capton tape!
8
CN4000
Replace if mechanical damaged (No network, restart, No
SIM card inserted, NFC SIM problem, reset problem)
Protect the SD card connector with capton tape!

1291-5740 Rev 2

Sony Mobile Communications AB – Company Internal
8(10)
Repair Actions: Additional Repair Info
9
CN4100
Replace if mechanical damaged (No SD card )
Protect the SIM connector with capton tape!
10
CN8000
Replace if mechanical damaged ( no or bad WLAN/ BT)
Protect the RF connector with capton tape!
11
CN8003
Replace if open circuit 1-3 ( no or bad WLAN/ BT)

1291-5740 Rev 2

Sony Mobile Communications AB – Company Internal
9(10)
Repair Actions: Additional Repair Info
12
D7800
Replace if Flash LED not working
13
R1304
Replace if open circuit (Phone dead)
Protect the BtB connectors with capton tape!
14
R5100
Replace if open circuit (Vibrator not working)
Protect the BtB connectors with capton tape!

1291-5740 Rev 2

Sony Mobile Communications AB – Company Internal
10(10)
4 Revision History
Rev.
Date
Changes / Comments
1 2014-09-11 Initial release
2 2014-09-12 Added Additional Repair info
