Sony Xperia Z3+ dual E6533 User manual

User guide
Xperia™Z3+ Dual
E6533

&RQWHQWV
G
Getting started...............................................................................7
About this User guide........................................................................7
Overview............................................................................................7
Protecting the screen.........................................................................8
Assembly...........................................................................................8
Starting your device for the first time.................................................9
Why do I need a Google™ account?...............................................10
Charging your device.......................................................................10
Learning the basics......................................................................13
Using the touchscreen.....................................................................13
Locking and unlocking the screen...................................................15
Home screen....................................................................................15
Application screen...........................................................................17
Navigating applications....................................................................18
Small apps.......................................................................................19
Widgets............................................................................................20
Shortcuts and folders......................................................................20
Background and themes..................................................................21
Battery and power management.....................................................22
Taking a screenshot.........................................................................23
Recording your screen.....................................................................24
Notifications.....................................................................................24
Icons in the status bar.....................................................................26
Application overview........................................................................28
Downloading applications............................................................30
Downloading applications from Google Play™...............................30
Downloading applications from other sources................................30
Internet and networks..................................................................31
Browsing the web............................................................................31
Internet and MMS settings ..............................................................31
Wi-Fi®..............................................................................................32
Sharing your mobile data connection..............................................34
Controlling data usage.....................................................................35
Selecting a SIM card for data traffic................................................36
Selecting mobile networks...............................................................37
Virtual private networks (VPNs)........................................................37
Synchronising data on your device..............................................39
Synchronising with online accounts................................................39
Synchronising with Microsoft® Exchange ActiveSync®.................39
2
This is an Internet version of this publication. © Print only for private use.

Synchronising with Outlook® using a computer.............................40
B
Basic settings...............................................................................41
Accessing settings...........................................................................41
Sound, ringtone and volume............................................................41
Managing notifications.....................................................................42
SIM card protection.........................................................................43
Using multiple SIM cards.................................................................44
Screen settings................................................................................45
Daydream.........................................................................................46
Screen lock......................................................................................46
Language settings............................................................................47
Date and time...................................................................................48
X-Reality™ for mobile......................................................................48
Super-vivid mode.............................................................................48
Enhancing the sound output............................................................48
Noise cancellation............................................................................49
Multiple user accounts.....................................................................49
Typing text...................................................................................52
On-screen keyboard........................................................................52
Phonepad.........................................................................................53
Entering text using voice input........................................................54
Editing text.......................................................................................54
Personalising the on-screen keyboard............................................55
Calling..........................................................................................57
Making calls.....................................................................................57
Receiving calls.................................................................................58
Ongoing calls...................................................................................60
Using the call log.............................................................................60
Forwarding calls...............................................................................61
Restricting calls................................................................................62
Multiple calls....................................................................................62
Conference calls..............................................................................63
Voicemail..........................................................................................64
Emergency calls...............................................................................64
Contacts.......................................................................................65
Transferring contacts.......................................................................65
Searching and viewing contacts......................................................66
Adding and editing contacts............................................................67
Adding medical and emergency contact information......................68
Favourites and groups.....................................................................69
Sending contact information............................................................70
Avoiding duplicate entries in the Contacts application...................70
3
This is an Internet version of this publication. © Print only for private use.

Backing up contacts........................................................................70
M
Messaging and chat.....................................................................72
Reading and sending messages......................................................72
Organising your messages..............................................................73
Calling from a message...................................................................74
Messaging settings..........................................................................74
Instant messaging and video chat...................................................74
Email.............................................................................................75
Setting up email...............................................................................75
Sending and receiving email messages..........................................75
Organising your email messages.....................................................76
Email account settings.....................................................................77
Gmail™............................................................................................77
Music............................................................................................79
Transferring music to your device...................................................79
Listening to music............................................................................79
Music home screen menu................................................................80
Playlists............................................................................................81
Sharing music..................................................................................82
Enhancing the sound.......................................................................82
Visualiser .........................................................................................82
Recognising music with TrackID™..................................................83
FM radio.......................................................................................84
Listening to the radio.......................................................................84
Favourite radio channels..................................................................85
Sound settings.................................................................................85
Camera.........................................................................................86
Taking photos and recording videos...............................................86
Face detection.................................................................................87
Using Smile Shutter™ to capture smiling faces..............................87
Adding the geographical position to your photos...........................88
General camera settings..................................................................88
Still camera settings.........................................................................92
Video camera settings.....................................................................96
Photos and videos in Album........................................................99
Viewing photos and videos..............................................................99
Sharing and managing photos and videos....................................100
Editing photos with the Photo editor application...........................101
Editing videos with the Movie Creator application........................102
Hiding photos and videos..............................................................102
Album home screen menu.............................................................103
Viewing your photos on a map......................................................104
4
This is an Internet version of this publication. © Print only for private use.

V
Videos........................................................................................106
Watching videos in the Video application......................................106
Transferring video content to your device.....................................107
Managing video content................................................................107
Movie Creator................................................................................107
Connectivity...............................................................................109
Mirroring the screen of your device on a TV using a cable............109
Mirroring the screen of your device wirelessly on a TV.................109
Sharing content with DLNA Certified™ devices............................110
Connecting your device to USB peripherals..................................112
Connecting your device to a DUALSHOCK™ series wireless
controller........................................................................................113
NFC................................................................................................113
Bluetooth® wireless technology....................................................115
One-touch setup............................................................................117
Smart apps and features that save you time.............................118
Controlling accessories and settings with Smart Connect™........118
Using your device as a fitness hub with ANT+™...........................120
Using your device as a wallet........................................................120
Travel and maps.........................................................................121
Using location services..................................................................121
Google Maps™ and navigation.....................................................121
Using data traffic when travelling..................................................121
Using your device with a car infotainment system........................122
Airplane mode................................................................................122
Calendar and alarm clock..........................................................124
Calendar.........................................................................................124
Alarm and clock.............................................................................125
Support and maintenance..........................................................127
Support for your device.................................................................127
Computer tools..............................................................................127
Updating your device.....................................................................128
Finding a lost device .....................................................................129
Finding the identification number of your device...........................131
Memory and storage......................................................................131
Managing files using a computer...................................................133
Backing up and restoring content.................................................133
Running diagnostic tests on your device.......................................135
Restarting and resetting.................................................................136
Using your device in wet and dusty conditions.............................137
Warranty, SAR and usage guidelines............................................137
Limitations to services and features..............................................137
5
This is an Internet version of this publication. © Print only for private use.

Legal information...........................................................................138
6
This is an Internet version of this publication. © Print only for private use.

*HWWLQJVWDUWHG
A
About this User guide
This is the
;SHULDറ='XDO
User guide for the
$QGURLGറ
software version. If
you're not sure which software version your device is running, you can check it via
the Settings menu. For more information about software updates, see
Updating your
device
on page 128.
7RFKHFNWKHFXUUHQWVRIWZDUHYHUVLRQRI\RXUGHYLFH
From your Home screen, tap .
Find and tap
6HWWLQJV
>
$ERXWSKRQH
>
$QGURLGYHUVLRQ
.
Overview
7
This is an Internet version of this publication. © Print only for private use.

1. Charging light/Notification light
2. Front camera lens
3. Ear speaker
4. Proximity/Light sensor
5. Power key
6. Volume/Zoom key
7. Camera key
8. Speaker
9. Charger/USB cable port
10. Strap hole
11. Main Wi-Fi/Bluetooth antenna area
12. Main camera lens
13. Camera light
14. GPS antenna area
15. Headset jack*
16. Second Wi-Fi antenna area
17. Nano SIM/Memory card slot cover
18. NFC™ detection area
Your device supports headsets with a standard 3.5mm 3-pin or 5-pin headphone plug. The
headset jack also supports 4-pin plugs as long as the headphone plug uses the CTIA
standard.
P
Protecting the screen
At purchase, there are two sheets of plastic film on the front of your device. You can
peel off the outer, or disposable, sheet of film when you start using the device. It is
not recommended to peel off the inner, or second, sheet of film as it protects your
screen from damage and scratching.
Assembly
Your device only supports nano SIM cards.
Make sure you place the nano SIM card (or cards) in the nano SIM card holder before inserting
the nano SIM card (or cards) into the device. Also, don't confuse the nano SIM card slot with
the memory card slot.
7RLQVHUWWKHQDQR6,0FDUGV
If you insert the nano SIM card while the device is powered on, the device restarts
automatically.
8
This is an Internet version of this publication. © Print only for private use.

Open the cover for the nano SIM card and memory card slots.
Using a fingernail or other similar object, drag out the nano SIM card holder.
Place the nano SIM card (or cards) in the relevant nano SIM card slot (or slots )
in the holder, then re-insert the holder.
Close the cover.
Make sure you re-insert the nano SIM card holder in the correct orientation. When you drag
out the holder to insert the nano SIM card, do not turn the holder around.
7RLQVHUWDPHPRU\FDUG
Open the cover for the nano SIM card and memory card slots.
Insert the memory card into the memory card slot, then close the cover.
Make sure you insert the memory card in the correct orientation.
7RUHPRYHWKHQDQR6,0FDUG
Open the cover for the nano SIM card and memory card slots.
Using a fingernail or other similar object, drag out the nano SIM card holder.
Remove the nano SIM card (or cards) in the relevant nano SIM card slot (or
slots ) in the holder, then re-insert the holder.
Close the cover.
7RUHPRYHWKHPHPRU\FDUG
Turn off the device and open the cover for the nano SIM card and memory
card slots.
Press the memory card inwards and then release it quickly.
Close the cover.
You can also remove the memory card without turning the device off in step 1. To use this
method, you must first unmount the memory card under 6
6HWWLQJV
by tapping
6WRUDJH
>
8QPRXQW6'FDUG
.
Starting your device for the first time
The first time you start your device, a setup guide opens to help you configure basic
settings, sign in to some accounts and personalise your device. For example, if you
have a Sony Entertainment Network or Google™ account, you can sign in to it here
and get set up straight away.
You can also access the setup guide later from the Settings menu. To access the setup guide
on a device with multiple users, you must be logged in as the owner, that is, the primary user.
9
This is an Internet version of this publication. © Print only for private use.

7RWXUQRQWKHGHYLFH
Press and hold down the power key until the device vibrates.
Enter your SIM card PIN when requested, then tap .
Wait a while for the device to start.
7RWXUQRIIWKHGHYLFH
Press and hold down the power key until the options menu opens.
In the options menu, tap 3
3RZHURII
.
It may take a while for the device to shut down.
Why do I need a Google™ account?
Your Xperia™ device from Sony runs on the Android™ platform developed by
Google™. A range of Google™ applications and services is available on your device
when you purchase it, for example, Gmail™, Google Maps™, YouTube™ and the
Play Store™ application, which gives you access to the Google Play™ online store
for downloading Android™ applications. To get the most out of these services, you
need a Google™ account. For example, a Google™ account is mandatory if you want
to:
ವDownload and install applications from Google Play™.
ವSynchronise email, contacts and the calendar.
ವChat with friends using the Hangouts™ application.
ವSynchronise your browsing history and bookmarks.
For more information about Android™ and Google™, go to
www.sonymobile.com/support .
7RVHWXSD*RRJOHറDFFRXQWRQ\RXUGHYLFH
From your Home screen, tap .
Find and tap
6HWWLQJV
>
$FFRXQWV
>
$GGDFFRXQW
>
*RRJOH
.
Follow the registration wizard to create a Google™ account, or sign in if you
already have an account.
You can also sign in to or create a Google™ account from the setup guide the first time you
start your device. Or you can go online and create an account at
www.google.com/accounts .
Charging your device
Your device has an embedded, rechargeable battery that should be replaced only by
Sony or an authorised Sony repair centre. You should never try to open or take apart
the device yourself. Opening the device can cause damage that voids your warranty.
The battery is partly charged when the device is shipped from the factory. Depending
on how long your device was in the box before you purchased it, the battery level
may be quite low. It is therefore recommended that you charge the battery for at least
30 minutes before starting up your device for the first time. You can still use your
device while it is charging. To read more about how to improve the battery
performance, see
Battery and power management on page 22.
10
This is an Internet version of this publication. © Print only for private use.

If your device gets exposed to water, wipe it dry with a microfibre cloth and shake the
device at least 15 times with the USB port facing downwards. Repeat the procedure
if moisture is still visible in the USB port. Only insert the USB cable into the USB port
after the port has completely dried.
7RGU\WKH86%SRUW
Using a micro-fibre cloth, wipe away any excess moisture from your device.
With the device held firmly and the USB port facing downwards, shake the
device vigorously at least 15 times.
If moisture is still visible in the USB port, shake the device again several times.
Use a micro-fibre cloth to wipe away any remaining moisture from the USB
port.
11
This is an Internet version of this publication. © Print only for private use.

7RFKDUJH\RXUGHYLFH
Plug the charger into a power outlet.
Plug one end of the USB cable into the charger (or into the USB port of a
computer).
Plug the other end of the cable into the micro USB port on your device, with
the USB symbol facing up. The notification light illuminates when charging
begins.
When the device is fully charged, disconnect the cable from your device by
pulling it straight outwards. Make sure not to bend the connector.
If the battery is completely discharged, it may take a few minutes before the notification light
illuminates and the charging icon appears.
%DWWHU\QRWLILFDWLRQOLJKWVWDWXV
Green The battery is charging and the battery charge level is greater than 90%
Red The battery is charging and the battery charge level is less than 15%
Orange The battery is charging and the battery charge level is less than 90%
12
This is an Internet version of this publication. © Print only for private use.

/HDUQLQJWKHEDVLFV
U
Using the touchscreen
7DSSLQJ
ವOpen or select an item.
ವMark or unmark a checkbox or option.
ವEnter text using the on-screen keyboard.
7RXFKLQJDQGKROGLQJ
ವMove an item.
ವActivate an item-specific menu.
ವActivate selection mode, for example, to select several items from a list.
13
This is an Internet version of this publication. © Print only for private use.

3LQFKLQJDQGVSUHDGLQJ
ವZoom in or out on web pages, photos and maps, and when you’re taking photos or
shooting videos.
6ZLSLQJ
ವScroll up or down a list.
ವScroll left or right, for example, between Home screen panes.
14
This is an Internet version of this publication. © Print only for private use.

)OLFNLQJ
ವScroll quickly, for example, in a list or on a web page. You can stop the scrolling
movement by tapping the screen.
L
Locking and unlocking the screen
When your device is on and left idle for a set period of time, the screen darkens to
save battery power and locks automatically. This lock prevents unwanted actions on
the touchscreen when you are not using it. When you buy your device, a basic screen
swipe lock is already set. This means that you have to swipe upwards on the screen
to unlock it. You can change the security settings later and add other kinds of locks.
See
Screen lock on page 46.
7RDFWLYDWHWKHVFUHHQ
ವBriefly press the power key .
7RORFNWKHVFUHHQ
ವWhen the screen is active, briefly press the power key .
Home screen
The Home screen is the starting point for using your device. It's similar to the desktop
on a computer screen. Your Home screen can have up to seven panes, which extend
beyond the regular screen display width. The number of Home screen panes is
represented by a series of dots at the lower part of the Home screen. The highlighted
dot shows the pane that you are currently in.
15
This is an Internet version of this publication. © Print only for private use.

7RJRWRWKH+RPHVFUHHQ
ವPress .
7REURZVHWKH+RPHVFUHHQ
+RPHVFUHHQSDQHV
You can add new panes to your Home screen (up to a maximum of seven panes) and
delete panes. You can also set the pane that you want to use as the main Home
screen pane.
7RVHWDSDQHDVWKHPDLQ+RPHVFUHHQSDQH
Touch and hold an empty area on your Home screen until the device vibrates.
Flick left or right to browse to the pane that you want to set as your main Home
screen pane, then tap .
7RDGGDSDQHWR\RXU+RPHVFUHHQ
Touch and hold an empty area on your Home screen until the device vibrates.
To browse the panes, flick all the way to the right or left, then tap .
7RGHOHWHDSDQHIURP\RXU+RPHVFUHHQ
Touch and hold an empty area on your Home screen until the device vibrates.
Flick left or right to browse to the pane that you want to delete, then tap .
16
This is an Internet version of this publication. © Print only for private use.

+RPHVFUHHQVHWWLQJV
Use the +
+RPH6HWWLQJV
shortcut to adjust some basic settings of your Home screen.
For example, you can set your Home screen to auto rotate and adjust the size of
icons.
7RVHW\RXU+RPHVFUHHQWRDXWRURWDWH
Touch and hold an empty area on your Home screen until the device vibrates,
then tap
+RPH6HWWLQJV
.
Drag the slider beside
$XWRURWDWLRQ
to the right.
7RDGMXVWWKHVL]HRILFRQVRQ\RXU+RPHVFUHHQ
Touch and hold an empty area on your Home screen until the device vibrates,
then tap
+RPH6HWWLQJV
.
Tap
,FRQVL]H
, then select an option.
Application screen
The Application screen, which you open from the Home screen, contains the
applications that come pre-installed on your device as well as applications that you
download.
7RYLHZDOODSSOLFDWLRQVRQWKH$SSOLFDWLRQVFUHHQ
From your Home screen, tap .
Flick left or right on the Application screen.
7RRSHQDQDSSOLFDWLRQIURPWKH$SSOLFDWLRQVFUHHQ
ವFlick left or right to find the application, and then tap the application.
7RVHDUFKIRUDQDSSOLFDWLRQIURPWKH$SSOLFDWLRQVFUHHQ
When the Application screen is open, tap .
Enter the name of the application that you want to search for.
7RRSHQWKH$SSOLFDWLRQVFUHHQPHQX
ವWhen the Application screen is open, drag the left edge of the screen to the
right.
7RPRYHDQDSSOLFDWLRQRQWKH$SSOLFDWLRQVFUHHQ
To open the Application screen menu, drag the left edge of the Application
screen to the right.
Make sure that
&XVWRPRUGHU
is selected under
6+2:$336
.
On the Application screen, touch and hold the application until it becomes
selected, then drag it to the new location.
17
This is an Internet version of this publication. © Print only for private use.

7RDGGDQDSSOLFDWLRQVKRUWFXWWRWKH+RPHVFUHHQ
To open the Application screen menu, drag the left edge of the Application
screen to the right.
Make sure that &
&XVWRPRUGHU
is selected under
6+2:$336
.
On the Application screen, touch and hold an application icon, then drag the
icon to the top of the screen. The Home screen opens.
Drag the icon to the desired location on the Home screen, then release your
finger.
If
$OSKDEHWLFDO
or
0RVWXVHG
is selected under
6+2:$336
instead of
&XVWRPRUGHU
, you can
still add an application shortcut to the Home screen. Just touch and hold the relevant
application icon until the Home screen opens, then drag the icon to the desired location and
release your finger.
7RDUUDQJHDSSOLFDWLRQVRQWKH$SSOLFDWLRQVFUHHQ
To open the Application screen menu, drag the left edge of the Application
screen to the right.
Select the desired option under
6+2:$336
.
7RXQLQVWDOODQDSSOLFDWLRQIURPWKH$SSOLFDWLRQVFUHHQ
To open the Application screen menu, drag the left edge of the Application
screen to the right.
Tap
81,167$//
. All uninstallable applications are indicated by .
Tap the application that you want to uninstall, then tap
2.
.
Navigating applications
You can navigate between applications using the navigation keys, the favourites bar,
and the recently used applications window, which lets you switch easily between all
recently used applications. The navigation keys are the Home key, the Recent apps
key and the Back key. Some applications get closed when you press the Home key
to exit while others are paused or continue to run in the background. If an
application is paused or running in the background, you can continue where you left
off the next time you open the application.
1 Recently used applications window – Open a recently used application
2 Favourites bar – Use a shortcut to access applications or widgets
3 Recent apps key – Open the recently used applications window and the favourites bar
4 Home key – Exit an application and go back to the Home screen
5 Back key – Go back to the previous screen within an application or close the application
18
This is an Internet version of this publication. © Print only for private use.

7RRSHQWKHUHFHQWO\XVHGDSSOLFDWLRQVZLQGRZ
ವPress .
7RFORVHDOOWKHUHFHQWO\XVHGDSSOLFDWLRQV
ವTap and then tap .
7RRSHQDPHQXLQDQDSSOLFDWLRQ
ವWhile using the application, press .
A menu is not available in all applications.
S
Small apps
Small apps are miniature apps that run on top of other applications on the same
screen, to enable multi-tasking. For example, you can have a webpage open showing
details of currency exchange rates and then open the Calculator small app on top of
it and perform calculations. You can access your small apps via the favourites bar. To
download more small apps, go to Google Play™.
7RRSHQDVPDOODSS
To make the favourites bar appear, press .
Tap the small app that you want to open.
You can open several small apps at the same time.
7RFORVHDVPDOODSS
ವTap on the small app window.
7RGRZQORDGDVPDOODSS
From the favourites bar, tap , then tap and tap .
Search for the small app that you want to download, then follow the
instructions to download it and complete the installation.
7RPRYHDVPDOODSS
ವWhen the small app is open, touch and hold the top left corner of the small
app, then move it to the desired location.
7RPLQLPLVHDVPDOODSS
ವWhen the small app is open, touch and hold the top left corner of the small
app, then drag it to the right edge or to the bottom edge of the screen.
7RUHDUUDQJHWKHVPDOODSSVLQWKHIDYRXULWHVEDU
ವTouch and hold a small app and drag it to the desired position.
7RUHPRYHDVPDOODSSIURPWKHIDYRXULWHVEDU
Touch and hold a small app, then drag it to .
Tap
2.
.
7RUHVWRUHDSUHYLRXVO\UHPRYHGVPDOODSS
Open the favourites bar, then tap .
Touch and hold the small app that you want to restore, then drag it into the
favourites bar.
19
This is an Internet version of this publication. © Print only for private use.

7RDGGDZLGJHWDVDVPDOODSS
To make the favourites bar appear, press .
Tap > > .
Select a widget.
Enter a name for the widget, if desired, then tap 2
2.
.
Widgets
Widgets are small applications that you can use directly on your Home screen. They
also function as shortcuts. For example, the Weather widget allows you to see basic
weather information directly on your Home screen. But when you tap the widget, the
full Weather application opens. You can download additional widgets from Google
Play™.
7RDGGDZLGJHWWRWKH+RPHVFUHHQ
Touch and hold an empty area on your Home screen until the device vibrates,
then tap
:LGJHWV$SSV
.
Find and tap the widget that you want to add.
7RUHVL]HDZLGJHW
Touch and hold a widget until it magnifies and the device vibrates, then release
the widget. If the widget can be resized, for example, the Calendar widget,
then a highlighted frame and resizing dots appear.
Drag the dots inward or outward to shrink or expand the widget.
To confirm the new size of the widget, tap anywhere on the Home screen.
7RPRYHDZLGJHW
ವTouch and hold the widget until it magnifies and the device vibrates, then drag
it to the new location.
7RGHOHWHDZLGJHW
ವTouch and hold the widget until it magnifies and the device vibrates, then drag
it to .
Shortcuts and folders
Use shortcuts and folders to manage your applications and keep your Home screen
tidy.
20
This is an Internet version of this publication. © Print only for private use.
