Troubleshooting Guide
- mechanical -
Xperia
TM
ZR
C5502, C5503, M36h

Troubleshooting Guide (mech)
1273-7035 Rev 3
© Sony Mobile Communications AB – Company Internal
2(40)
CONTENTS
1Problem Areas ................................................................................ 4
1.1 Power .................................................................................................... 4
1.1.1 Will not power on or will switch off randomly........................................... 4
1.2 Keys ...................................................................................................... 5
1.2.1 Camera Key.................................................................................................. 5
1.2.2 Volume Key .................................................................................................. 6
1.2.3 On/Off Key.................................................................................................... 7
1.2.4 Back, Home, Menu and Multitask Keys ..................................................... 8
1.3 Touch Screen ....................................................................................... 9
1.3.1 Touch Screen malfunction.......................................................................... 9
1.4 Display ................................................................................................ 10
1.4.1 Graphics & Illumination ............................................................................ 10
1.5 LED/Illumination................................................................................. 11
1.5.1 Illumination ................................................................................................ 11
1.6 Speaker ............................................................................................... 13
1.6.1 Loudspeaker .............................................................................................. 13
1.7 Earphone ............................................................................................ 15
1.7.1 Earphone .................................................................................................... 15
1.8 Microphone......................................................................................... 16
1.8.1 Primary Microphone .................................................................................. 16
1.8.2 Secondary Microphone ............................................................................. 18
1.9 Vibrator ............................................................................................... 19
1.9.1 Vibrator not generating alerts .................................................................. 19
1.10 Camera................................................................................................ 20
1.10.1 Camera defects.......................................................................................... 20
1.10.2 Secondary Camera .................................................................................... 21
1.11 Flash LED ........................................................................................... 22
1.11.1 Flash LED not flashing.............................................................................. 22
1.12 Bluetooth, WLAN or GPS................................................................... 23
1.12.1 Bluetooth, WLAN or GPS connection failure .......................................... 23
1.13 NFC ..................................................................................................... 24
1.13.1 NFC connection failure ............................................................................. 24
1.14 Compass............................................................................................. 25
1.14.1 Compass fails ............................................................................................ 25
1.15 Accelerometer .................................................................................... 25
1.15.1 Accelerometer test fails ............................................................................ 25
1.16 Gyroscope .......................................................................................... 25
1.16.1 Gyroscope test fails .................................................................................. 25
1.17 Ambient Light Sensor ........................................................................ 26
1.17.1 Light Sensor malfunctions ....................................................................... 26
1.18 Proximity switch................................................................................. 27
1.18.1 Proximity switch malfunctions................................................................. 27

Troubleshooting Guide (mech)
1273-7035 Rev 3
© Sony Mobile Communications AB – Company Internal
3(40)
1.19 Pressure Sensor................................................................................. 28
1.19.1 Pressure Sensor test fails......................................................................... 28
1.20 Water Proof......................................................................................... 28
1.20.1 Water Proof fails ........................................................................................ 28
1.21 Real Time Clock ................................................................................. 29
1.21.1 Real Time Clock test fails ......................................................................... 29
1.22 Total call time ..................................................................................... 29
1.22.1 Total call time test fails ............................................................................. 29
1.23 Storage................................................................................................ 30
1.23.1 Memory Card not detected ....................................................................... 30
1.24 Security............................................................................................... 30
1.24.1 Security fails .............................................................................................. 30
1.25 FM Radio............................................................................................. 31
1.25.1 No/Poor FM Radio reception .................................................................... 31
1.26 Battery Health test ............................................................................. 32
1.26.1 Battery Health test fails............................................................................. 32
1.27 Flip slider counter .............................................................................. 32
1.27.1 Flip slider counter fails ............................................................................. 32
1.28 Verify Certificates............................................................................... 32
1.28.1 Verify certificates fails............................................................................... 32
1.29 IrDA Test ............................................................................................. 33
1.29.1 IrDA test fails ............................................................................................. 33
1.30 TV-Out Test......................................................................................... 33
1.30.1 TV-Out test fails ......................................................................................... 33
1.31 SIM ...................................................................................................... 34
1.31.1 SIM not detected........................................................................................ 34
1.31.2 Incorrect SIM indicated ............................................................................. 34
1.32 Charging (USB and Easy charger) .................................................... 35
1.32.1 Battery will not charge .............................................................................. 35
1.33 Accessory by Wire ............................................................................. 37
1.33.1 Connection with accessory to Audio Jack fails...................................... 37
1.34 Data Communication ......................................................................... 38
1.34.1 Data transfer via System Connector fails................................................ 38
1.35 Network & Signal................................................................................ 39
1.35.1 No/Poor signal ........................................................................................... 39
2Revision History ........................................................................... 40
You shall always after verifying the problem, start the trouble shooting with the Emma
Service“Refurbish”.
Software release information about improvements are found: www.sonymobile.com/Update

Troubleshooting Guide (mech)
1273-7035 Rev 3
© Sony Mobile Communications AB – Company Internal
4(40)
1 Problem Areas
1.1 Power
1.1.1 Will not power on or will switch
off randomly
Check:
Check if the phone vibrates by pressing the power key.
Action:
1. If activation of the Vibrator is detected, refer to section
1.4 ‘Display’.
2. If NO activation of the Vibrator is detected, check that the
battery is charging when connected to a charger.
Follow Test Instruction Charging via USB, Diagnostic
Battery / Charging status.
Check:
Inspect the contact pads on the Battery.
Action:
1. If dirty or oxidized – clean the pads.
2. If damaged – replace the Battery.
Check:
Inspect the battery contact pins.
Action:
If dirty or oxidized – clean the contact pins.
Check:
Inspect the power key.
Action
Refer to section 1.2.3 ‘On/Off Key’.

Troubleshooting Guide (mech)
1273-7035 Rev 3
© Sony Mobile Communications AB – Company Internal
5(40)
Problem Areas
1.2 Keys
1.2.1 Camera Key
Check:
Inspect the Key Camera and the Gasket Key Cam.
Action:
1. If the Key Camera or the Gasket key Cam is dirty or
clogged – clean them.
2. If any of these two parts are damaged – replace that part.
Check:
Inspect the connection between the FPC Relay and the
main PBA.
Action:
1. If not properly connected – disconnect and reconnect.
2. If dirty or oxidized – clean the BtB connector.
Check:
Inspect the FPC Relay.
Action:
1. If the FPC Relay is damaged – replace it.
2. Replace the Main PBA.

Troubleshooting Guide (mech)
1273-7035 Rev 3
© Sony Mobile Communications AB – Company Internal
6(40)
Problem Areas: Keys
1.2.2 Volume Key
Check:
Inspect the Key Volume and the two Gaskets Key.
Action:
1. If the Key Volume or any of the Gaskets Key is dirty or
clogged – clean them.
2. If any of these three parts are damaged – replace that
part.
Check:
Inspect the connection between the FPC Relay and the
main PBA.
Action:
1. If not properly connected – disconnect and reconnect.
2. If dirty or oxidized – clean the BtB connector.
Check:
Inspect the FPC Relay.
Action:
1. If the FPC Relay is damaged – replace it.
2. Replace the Main PBA.

Troubleshooting Guide (mech)
1273-7035 Rev 3
© Sony Mobile Communications AB – Company Internal
7(40)
Problem Areas: Keys
1.2.3 On/Off Key
Check:
Inspect the Key Power, Panel Key Power and the Gasket Key.
Action:
1. If the Key Power, Panel Key Power or the Gasket Key is
dirty or clogged – clean them.
2. If any of these parts are damaged – replace that part.
Check:
Inspect the connection between the FPC Relay and the
main PBA.
Action:
1. If not properly connected – disconnect and reconnect.
2. If dirty or oxidized – clean the BtB connector.
Check:
Inspect the FPC Relay.
Action:
1. If the FPC Relay is damaged – replace it.
2. Replace the Main PBA.

Troubleshooting Guide (mech)
1273-7035 Rev 3
© Sony Mobile Communications AB – Company Internal
8(40)
Problem Areas: Keys
1.2.4 Back, Home, Menu and
Multitask Keys
Action
Refer to section 1.3 ‘Touch Screen’.

Troubleshooting Guide (mech)
1273-7035 Rev 3
© Sony Mobile Communications AB – Company Internal
9(40)
Problem Areas
1.3 Touch Screen
1.3.1 Touch Screen malfunction
Check:
Inspect the touch screen and try the function of the touch
keys in the front.
Action:
If dirty – clean it.
Check:
Inspect the connection between the touch flex and the
display flex. And also the connection between the Display
and the main PBA.
Action:
1. If not properly connected – disconnect and reconnect.
2. If dirty or oxidized – clean the connectors.
Check:
Inspect the Display, the flex film and the connectors on the
Display and also the connector on the Main PBA.
Action:
1. If the Display, the flex film or the connectors is damaged
- replace the Display.
2. Replace the Main PBA.

Troubleshooting Guide (mech)
1273-7035 Rev 3
© Sony Mobile Communications AB – Company Internal
10(40)
Problem Areas
1.4 Display
1.4.1 Graphics & Illumination
Note: After a replacement of the Display or the Main
PBA should always the Display calibration be
performed: Trouble Shooting Application 1269-2060 .
Check:
Check whether the phone vibrates after the Key Power has
been pressed.
Action:
If the phone doesn’t vibrate, refer to section 1.1 ‘Power’.
Check:
Inspect the connection between the Display and the main
PBA.
Action:
1. If not properly connected – disconnect and reconnect.
2. If dirty or oxidized – clean the BtB connector.
Check:
Inspect the Display, the flex film and the connector on the
Display and also the connector on the Main PBA.
Action:
1. If the Display, the flex film or the connector is damaged
- replace the Display.
2. Replace the Main PBA.

Troubleshooting Guide (mech)
1273-7035 Rev 3
© Sony Mobile Communications AB – Company Internal
11(40)
Problem Areas
1.5 LED/Illumination
1.5.1 Illumination
Check:
Inspect the lower part of the Display.
Action:
If dirty – clean it.
Check:
Inspect the Lightguide and the Lightguide Sheet.
Action:
1. If not properly mounted – remount the Lightguide or
replaces the Lightguide Sheet.
2. If they are damaged – replace them.
Check:
Inspect the FPC Relay.
Action:
1. If not properly connected – disconnect and reconnect.
2. If the FPC Relay is damaged – replace it.
Check:
Inspect the connection between the Display and the main
PBA.
Action:
1. If not properly connected – disconnect and reconnect.
2. If dirty or oxidized – clean the BtB connector.

Troubleshooting Guide (mech)
1273-7035 Rev 3
© Sony Mobile Communications AB – Company Internal
12(40)
Problem Areas: Illumination
Check:
Inspect the Display, the flex film and the connector on the
Display and also the connector on the Main PBA.
Action:
1. If the Display, the flex film or the connector is damaged
- replace the Display.
2. Replace the Main PBA.

Troubleshooting Guide (mech)
1273-7035 Rev 3
© Sony Mobile Communications AB – Company Internal
13(40)
Problem Areas
1.6 Speaker
1.6.1 Loudspeaker
Check:
Inspect the speaker‘s external port on the Cover Battery.
Action:
1. If clogged – clean the speaker port.
2. If the Cover Battery is damaged – replace it.
Check:
Inspect the Net Speaker on the Cover Main.
Action:
If the net is clogged or damaged – replace it.

Troubleshooting Guide (mech)
1273-7035 Rev 3
© Sony Mobile Communications AB – Company Internal
14(40)
Problem Areas: Speaker
Check:
Inspect the Loudspeaker’s pins and the contact pads on
FPC Relay.
Action:
If Loudspeaker’s pins or the Loudspeaker is damaged –
replace the Loudspeaker.
Check:
Inspect the whole FPC Relay with connectors.
Action:
1. If not properly connected – disconnect and reconnect.
2. If the FPC Relay is damaged – replace it.
3. Replace the Main PBA.

Troubleshooting Guide (mech)
1273-7035 Rev 3
© Sony Mobile Communications AB – Company Internal
15(40)
Problem Areas
1.7 Earphone
1.7.1 Earphone
Check:
Inspect the speaker‘s external port on the Cover Main.
Action:
If the external port is damaged – replace the Cover Main.
Check:
Inspect the flex of the ear speaker.
Action:
1. If the flex or its pads are damaged – replace the Cover
Main.
2. Replace the Main PBA.

Troubleshooting Guide (mech)
1273-7035 Rev 3
© Sony Mobile Communications AB – Company Internal
16(40)
Problem Areas
1.8 Microphone
1.8.1 Primary Microphone
Check:
Inspect the microphone’s external port on the Cover Main.
Action:
1. If clogged – clean the port.
2. If Cover Main is damaged – replace it.
Check:
Inspect the Cushion Mic in the Cover Main.
Action:
If the Cushion Mic is damaged or misalign – replace it.

Troubleshooting Guide (mech)
1273-7035 Rev 3
© Sony Mobile Communications AB – Company Internal
17(40)
Problem Areas: Microphone
Check:
Inspect the whole FPC Relay with the BtB connector.
Action:
1. If not properly connected – disconnect and reconnect.
2. If the FPC Relay is damaged – replace it.
3. Replace the Main PBA.

Troubleshooting Guide (mech)
1273-7035 Rev 3
© Sony Mobile Communications AB – Company Internal
18(40)
Problem Areas: Microphone
1.8.2 Secondary Microphone
Check:
Inspect the Gasket 2nd MIC and the microphone’s external
port on the Cover Main.
Action:
1. If the external port is clogged – clean it.
2. If the Gasket 2nd MIC is damaged – replace it.
Check:
Inspect the Cushion 2nd MIC on the FPC PBA NFC.
Action:
1. If the Cushion 2nd MIC is damaged or misaligned –
replace it.
2. If the BtB connector isn’t properly connected – disconnect
and reconnect.
3. If the MIC or the flex of the FPC PBA NFC is damaged –
replace the FPC PBA NFC.
4. Replace the Main PBA.

Troubleshooting Guide (mech)
1273-7035 Rev 3
© Sony Mobile Communications AB – Company Internal
19(40)
Problem Areas
1.9 Vibrator
1.9.1 Vibrator not generating alerts
Check:
Inspect the vibrator on the FPC Relay.
Action:
If the vibrator is clogged – clean it.
Check:
Inspect the whole FPC Relay with the BtB connector.
Action:
1. If not properly connected – disconnect and reconnect.
2. If the FPC Relay is damaged – replace it.
3. Replace the Main PBA.

Troubleshooting Guide (mech)
1273-7035 Rev 3
© Sony Mobile Communications AB – Company Internal
20(40)
Problem Areas
1.10 Camera
1.10.1 Camera defects
Check:
Inspect the camera lens on the Cover Main.
Action:
1. If dirty – clean it carefully.
2. If the camera lens is scratched or damaged – replace
the Cover Main.
Check:
Inspect the connection between the Camera and the Main
PBA.
Action:
1. If not properly connected – disconnect and reconnect.
2. If the Camera or the flex film is damaged – replace the
Camera.
3. If camera functional occurred – verify with a known
functioning Camera before replacement of the Camera.
4. Replace the Main PBA.
