Sony DVP-NS900V - Sacd/dvd Player User manual

3-070-853-l l(1)
SACD/DVD
Player
Operating Instructions
V I D E 0”‘
@B
SUPER AUDIO CD
DVP-NSSOOV
0 2001 Sony Corporation
..
1

..- I-._ .._.. a ..- _ -.<s
WARNING Welcome!
To preventfire or shock hazard,
do not expose the unit to rain or
moisture.
To avoid electrical shock, do
not open the cabinet. Refer
servicing to qualified personnel
only.
CAUTION
The useof optical instruments with
this product will increase eye
hazard. As the laser beam used in
this SACD/DVD player is harmful
to eyes, do not attempt to
disassemble the cabinet.
Refer servicing to qualified
personnel only.
This symbol is intended
to alert the userto the
presenceof uninsulated
“dangerous voltage”
within the product’s
enclosurethat may be of sufficient
magnitude to constitute arisk of
electric shock to persons.
A I
This symbol is intended
to alert the user to the
presenceof important
. operating and
maintenance(servicing)
instructions in the literature
accompanying the appliance.
CAUTION
TO PREVENT ELECTRIC SHOCK
MATCH WIDE BLADE OF PLUG
TO WIDE SLOT, FULLY INSERT.
For customers in the USA
Owner’s Record
The model andserial numbers are
located atthe rearof the unit. Record
the serial number in the space
provided below. Refer to them
whenever you call upon your Sony
dealer regarding this product.
Model No. DVP-NS900V
Serial No.
CAUTION
You arecautioned that anychangeor
modifications notexpresslyapproved
in this manual could void youi
authority to operatethis equipment.
This equipment hasbeentestedand
found to comply with the limits for a
ClassB digital device, pursuant to
Part 15of the FCC Rules. These
limits aredesignedto provide
reasonableprotection against
harmful interference in aresidential
installation. This equipment
generates,uses,andcanradiate radio
frequency energyand, if not installed
andusedin accordancewith the
instructions, may causeharmful
interference to radio
communications. However, there is
no guaranteethat interference will
not occur in aparticular installation.
If this equipment doescauseharmful
interference to radio or television
reception, which can be determined
by turning the equipment off and on,
the useris encouraged to try to
correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving
antenna.
-Increase the separation between
the equipment and receiver.
-Connect the equipment into an
outlet on acircuit different from
that to which the receiver is
connected.
-Consult the dealeror an
experiencedradio/TV technician
for help.
Thank you for purchasing this Sony
SACD/DVD Player. Before
operating this player, pleasereadthis
manual thoroughly andretain it for
future reference.
2

Precautions
On safety
l Caution - The useof optical instruments with
this product will increaseeye hazard.
l Should any solid object or liquid fall into the
cabinet, unplug theplayer andhaveit checked by
qualified personnel before operating it any
further.
On power sources
l The player is not disconnected from the AC
power sourceaslong asit is connectedto the wall
outlet, evenif the player itself hasbeen turned
off.
l If you arenot going to usethe player for a long
time, be sureto disconnect the player from the
wall outlet. To disconnect the AC power cord,
graspthe plug itself; never pull the cord.
l Should the AC power cord needto be changed,
have it done at a qualified service shop only.
On placement
l Placethe player in a location with adequate
ventilation to prevent heatbuild-up in the player.
* Do not place the player on a soft surface such as
arug that might block the ventilation holes on the
bottom.
l Do not place the player in a location near heat
sources,or in aplace subject to direct sunlight,
excessive dust, or mechanical shock.
On operation
* If the player is brought directly from a cold to a
warm location, or is placed in avery damp room,
moisture may condenseon the lensesinside the
player. Should this occur, the player may not
operateproperly. In this case,remove the disc
and leave the player turned on for about half an
hour until the moisture evaporates.
l When you move theplayer, take out any discs. If
you don’t, the disc may be damaged.
On adjusting volume
Do not turn up the volume while listening to a
section with very low level inputs or no audio
signals. If you do, the speakersmay be damaged
when apeak level section is played.
On cleaning
Clean the cabinet, panel, and controls with a soft
cloth slightly moistened with a mild detergent
solution. Do not useany type of abrasive pad,
scouring powder or solvent such asalcohol or
benzine.
If you have any questions or problems concerning
your player, pleaseconsult your nearestSony
dealer.
On cleaning discs
Do not useacommercially available cleaning disc.
It may causea malfunction.
1IMPORTANT NOTICE
Caution: This player is capable of holding a
still video image or on-screendisplay image on
your television screenindefinitely. If you leave
the still video image or on-screen display
image displayed on your TV for an extended
period of time you risk permanent damageto
your television screen.Projection televisions
areespecially susceptible to this.
3

Tableof Contents
WARNING .......... . .............. . .2
Welcome! .......................... . .2
Precautions ........................ . .
3
About this Manual ................... . .6
This Player Can Playthe Following Discs ... . . ......... 6
Notes about the Discs ................ . ......... 7
Index to Parts and Controls ............ . ......... . .
8
Guide to the RemoteControl LCD Screen . . . ......... . . .12
Guide to the Control Menu Display ...... . . . . ......... . . .13
. .
.
. .
. .
. .
.
. .
. .
. .
. .
. .
.........
.........
.........
.........
. .
. .
. .
. .
GettingStarted ................................... .I6
QuickOverview .............................................. ..16
Stepl:Unpacking ............................................ ..16
Step 2: Inserting Batteries into the Remote .......................... .16
Step3:TVHookups.............................................17
Step4:PlayingaDisc .......................................... .19
.............. . ..........................
Hooking Up the Player .......................................... .20
Step 1:Connecting the Video Cords ............................... .20
Step 2: Connecting the Audio Cords ............................... .23
Step 3: Connecting the Power Cord ................................ .31
Step4:QuickSetup.. ......................................... ..3 1
......................................
PlayingDiscs ................................................ ..3 7
Resuming Playbackfrom the PointWhere You Stoppedthe Disc
(ResumePlay) ............................................ ..3 9
Using the DVD’s Menu .......................................... .40
Selecting “ORIGINAL” or “PLAY LIST” on a DVD-RW Disc .............. .40
Selecting a Playback Area for an SACD Disc ........................ .41
PlayingVIDEO CDs with PBC Functions (PBC Playback) .............. .42
Various Play Mode Functions (Program Play, Shuffle Play,
Repeat Play,A-B Repeat Play) ................................ .43
Searchingfor a Scene............................... .49
Searching for a Particular Point on a Disc
(Search, Scan, Slow-motion Play, Freeze Frame) .................. .49
Searchingfor a Title/Chapter/Track/Index/Scene ..................... .50
Searching by Scene (VIEWER) ................................... .52

ViewingInformationAboutthe Disc . . . . . . . . . . . . . . . . . . . . . . 54
Viewing the Playing Time and Remaining Time on the
Front Panel Display ............................
Checking the Playing Time and Remaining Time ........
Checking the Play Information (ADVANCED) ..........
............
54
............ 55
............ 57
SoundAdjustments ................................. 58
Changingthe Sound.. .......................................... 58
SURROUND Mode Settings ...................................... 60
EnjoyingMovies ................................... 64
ChangingtheAngles ........................................... 64
Displaying the Subtitles ......................................... 65
Adjusting the Picture Quality (BNR) ................................ 66
Adjusting the Playback Picture (VIDEO EQUALIZER) .................. 67
Enhancing the Playback Picture (DIGITAL VIDEO ENHANCER) ......... 70
UsingVariousAdditionalFunctions ...................... 71
Labeling the Disc ...............................
Locking Discs (CUSTOM PARENTAL CONTROL,
PARENTAL CONTROL) .......................
Operation Sound Effects (Sound Feedback) ..........
Controlling Your TV or AV Amplifier (Receiver) with the
Supplied Remote ............................
. . . . . . . .
. . . . . .
. . . . .
. . .
. 71
. 72
. 77
. 78
SettingsandAdjustments..................... , ....... 80
Using the Setup Display ......................................... 80
Setting the Display or Sound Track Language (LANGUAGE SETUP) ...... 81
Settings for the Display (SCREEN SETUP) .......................... 82
Custom Settings (CUSTOM SETUP) ............................... 86
Settings for the Sound (AUDIO SETUP) ............................ 88
Settings for the Speakers (SPEAKER SETUP) ....................... 91
AdditionalInformation ............................ s.. 94
Troubleshooting ............................................... 94
Self-diagnosis Function (When letters/numbers appear in the display) ..... 97
Glossary ..................................................... 97
Specifications ................................................ 101
LanguageCodeList ........................................... 102
List of Setup Display Items ...................................... 103
Index ....................................................... 107
5

Format of discs
6
l Instructions in this manual describe the
controls on theremote. You canalsousethe
controls on the player if they have the same
or similar namesasthose on the remote.
l The meaning of the icons usedin this
manual is described below:
I !
Functions available for DVD-
m RWs in VR (Video Recording)
mode
I-l
Functions available for VIDEO
CDs or CD-R&D-RWs
I
Functions available for music
CDs or CD-R&D-RWs
I
More convenient features I
“DVD” maybeusedasageneraltermfor DVD
VIDEOS,DVD-Rs, andDVD-RWs.
ThisPlayerCanPlaythe
FollowingDiscs
DVD-RW I
SACD
SUPERAUDIO CD
VIDEO CD
Music CD flrgs
DIGITALAUDIO
“DVD VIDEO” and“DVD-RW” aretrademarks.
,, ,,
Your player hasaregion code printed on the
back of the unit and only will play DVD
VIDEO discs (playback only) labeled with
identical region codes.
DVDs labeled e will also play on this
player.
0
If you try to play any other DVD, the
message“Playback prohibited by area
limitations.” will appearon the TV screen,
Depending on the DVD, no region code
indication may be labeled even though
playing the DVD is prohibited by area
restrictions.
The player cannot play the following discs:
l CD-ROMs (PHOTO CDs included)
l All CD-Rs/CD-RWs other than music and
VCD format CD-R&D-RWs
l Data part of CD-Extras
l DVD-ROMs
l DVD Audio discs
Also, the player cannot play the following
discs:
l A DVD with adifferent regioncode(page97).
l A disc recorded in acolor system other than
NTSC, suchasPAL or SECAM (this player
conforms to the NTSC color system).
l A disc that hasa non-standard shape(e.g.,
card, heart).
l A disc with paper or stickers on it.
l A disc that has the adhesive of cellophane
tape or a sticker still left on it.

Some DVD-Rs, DVD-RWs, CD-Rs. or CD-RWs
cannot he played on this player due to the recording
quality or physical condition of the disc. 01.the
characteristics of the recording device. DVD-RWs in
VR mode may also take time to play hack due to the
recording condition.
Furthermore, the disc will not play if it has not been
correctly finalized. For more information. seethe
operating instructions for the recording device.
Some playback operations of DVDs and
VIDEO CDs may be intentionally setby
software producers. Since this player plays
DVDs andVIDEO CDs according to the disc
contents the software producers designed,
someplayback featuresmay not be available.
Also, refer to the instructions supplied with
the DVDs or VIDEO CDs.
This product incorporates copyright
protection technology that is protected by
method claims of certain U.S. patents, other
intellectual property rights owned by
Macrovision Corporation, and other rights
owners. Use of this copyright protection
technology must be authorized by
Macrovision Corporation, andis intended for
home and other limited viewing usesonly
unless otherwise authorized by Macrovision
Corporation. Reverse engineering or
disassembly is prohibited.
Notesaboutthe Discs
On handling discs
l To keepthe disc clean,handle thedisc by its
edge.Do not touch the surface.
l Do not exposethe disc to direct sunlight or
heat sourcessuch ashot air ducts, or leave
it in acar parked in direct sunlight asthe
temperature may rise considerably inside
the car.
l After playing, store the disc in its case.
On cleaning
l Before playing, clean the disc with a
cleaning cloth.
Wipe the disc from the center out.
l Do not usesolvents such asbenzine,
thinner, commercially available cleaners,or
anti-static spray intended for vinyl LPs.
7

Indexto PartsandControls
For more information, refer to the pagesindicated in parentheses.
q POWER switch/indicator (37)
q q (remote sensor) (16)
q Disc tray (37)
q MULTI CHANNEL indicator
Lights up when:
- playing adisc that contains multiple
audio signal channels
- the disc is not inserted
q Front panel display (9)
q fi RETURN button (42)
q MENU button (40)
q TOP MENU button (40)
!@ DISPLAY button (13)
q W/HI (previous/next) buttons (38)
q SACD indicator
Lights up when the disc is aSuper Audio
q %D indicator
p (open/close) button (37)
D (play) button/indicator (37)
II (pause)button/indicator (38) (77)
n (stop) button (37)
C/W+/+/ ENTER button (31)
Click shuttle (49)
JOG button/indicator (50)
Lights up when the disc is aDVD
FL OFF button/indicator (86)
VIDEO OFF button/indicator (37)
PHONES LEVEL control (37)
PHONES jack (37)

When playing back a DVD VIDEO/DVD-RW
Lights up when the player Lights up when you can change
outputs progressive signals (84) the angle (64)
Disc type
ANG.C i%ii----- MIN
! SEC; ......,. ....... ....... ....... ........
: ;. ;
: 2 :i I! ;* i...... )..... . ......j
&.i ‘*my. ‘,.y,.. *.-.~ i .:’ L..+.f j
-_--..l.“-l
Current audio Current play Current title (54) Current chapter (54) Playing time (54)
signal (59) mode (43)
When playing back a VIDEO CD (PBC)
Lights up when the player
Disc type outputs progressive signals (84)
Current scene (54)
Current play mode (43) Playing time (54)
When playing back an SACD, CD, or VIDEO CD (without PBC)
Lights up when the
player outputs Lrghts up when playing the multi-
progressive signals channel playback area on SACDs (41)
(84)
Disc type Current play mode (43) Playing time (54)
Current track and index (54)
When playing the SACD layer of SACD disc\. the dtsc type is not dicplayed
.“C
c You can turn off the front panel displq b):
-preGng FL OFF on the playa
-urmg the scroll key and LCD screen 011the remote (page 12)
~ aetting “DIMMER” of “CUSTOM SETUP” to “OFF” or “AUTO OFF” in the Setup Display (page 86).
When the front panel display tsrns off. the FL OFF indicator- lights up on the player.
continued- 9

q DIGITAL OUT (COAXIAL) jack (25)
(27) (29)
q DIGITAL OUT (OPTICAL) jack (25)
(27) (29)
q S-LINK/CONTROL S IN jack (17)
q AUDIO OUT L/R l/2 jacks (24) (27)
(29)
q 5.1CH OUTPUT jacks (25)
q COMPONENT VIDEO OUT/SCAN
SELECT switch (84)
q COMPONENT VIDEO OUT (Y, PB, PR)
jacks (20)
q S VIDEO OUT l/2 jacks (20)
q VIDEO OUT l/2 jacks (20)
10

q TV/DVD switch (78)
q + OPEN/CLOSE button (38)
q LCD (Liquid Crystal Display) screen
(12)
q PROGRAM button (43)
q VIDEO EQ (video equalizer) button (67)
q Q/8 SEARCH buttons (49)
q w/w PREV/NEXT (previous/next)
buttons (38)
q D PLAY button (37)
The D button hasa tactile dot.
q VIDEO ON/OFF button (37)
q Click shuttle (49)
q DISPLAY button (13)
q TOP MENU button (40)
q Number buttons (40)
The number 5 button hasa tactile dot.
q CLEAR button (43)
q SEARCH MODE button (50)
q I/e (on/standby) button (37) (78)
q Scroll key (12)
q PICTURE MEMORY button (83)
q BOOKMARK button (53)
q REPLAY button (38)
q n STOP button (37)
q II PAUSE button (38)
q JOG button (50)
q ENTER button (31)
q C/+/+/d buttons (31)
q 6, RETURN button (42)
q MENU button (40)
q CH (channel) +/- buttons (78)
The + button has atactile dot.
q VOL (volume) +/- buttons (78)
The + button hasa tactile dot.
q ENTER button
q WIDE MODE button (78)
q TV/VIDEO button (78)
11

Guideto the RemoteControlLCDScreen
The supplied remote has anLCD (Liquid Crystal Display) screenand scroll key for controlling
the player without using the Control Menu Display. By pushing the scroll key up or down, you
can call up various displays and functions such as“TIME/TEXT” and “SUBTITLE.”
Scroll key-
-
LCD screen
The following commands arecontained in the LCD. The commands will scroll continuously if
you keep the scroll key pushedup or down.
TIME/TEXT (page 55) * FL ON/OFF
1 (page
86)
AUDIO (page 58)
1
SUBTITLE (page 65)
t
ANGLE (page64)
r
SURROUND (page 60)
t
SHUFFLE (page45) 4
++ MULTI/2CH (page41)
1
SACDKD (page42)
1
DVE (page 70)
1
BNR (page 66)
t
A-B (page47)
l
-+ REPEAT (page46)
1 Togglethescrollkeyupordownto selecta command.
2 PointtheremoteattheH (remotesensor)ontheplayerandpressdownonthewordPUSH
imprintedonthescrollkeysothat + appearsinthe LCDscreen.
The player will respond to the selectedcommand aslong asthe command remains in theLCD
screen.Some commands require you to pressdown on the scroll key repeatedly. For a
description of eachcommand listed above, refer to the pagesin parentheses.
12

Guideto the ControlMenuDisplay
Use the Control Menu to select a function that you would like to use.The Control Menu display
appearswhen the DISPLAY button is pressed.For details, pleaserefer to the pagein parentheses.
Total number of titles or tracks recorded-
Currently playing title number
(VIDEO CD/SACD/CD: track number) Total number of chapters or indexes recorded
Playback status
Currently playing chapter
number (VIDEO CD/SACD/
CD: index number)
Playing time
Icon of selected ‘. -
Control Menu item
II Pause, W Stop, etc.)
Type of disc being
played back
Current setting
Control Menu items---. Options
Function name of selected .’
Control Menu item
Operation message-.--
List of Control Menu Items
TIME/MEMO (page 50) Input the time code for picture and music
s the label (Disc Memo) you assigned
pe of titles (DVD-RW) to be
RIGINAL one, or an edited
continued - 13

the disc while
Use Quick Setup to choose the desired
language of the on-screen display, the aspect
ratio of the TV, the audio output, and the
In addition to the Quick Setup setting, you can
st other various settings.
the settings in “SETUP” to the default
REPEAT (page 46)
that best suits the
14

.S’C
$’ Each time you press DISPLAY. the Control Menu display changes as follows:
Control Menu display I
+
Control Menu display 2
+
ADVANCED display (Appears if you select any setting other than “OFF.” See page 57.)
4
L Control Menu display off
When playing an SACDKD disc. only the Control Menu display I will appear. The Control Menu items are different
depending on the disc.
L”.
c The Control Menu icon indicator lights up in green + when you select any item except
“OFF.” (“SURROUND, ” “PROGRAM,” “SHUFFLE,” “REPEAT,” “A-B REPEAT,” “BNR,” “DIGITAL VIDEO
ENHANCER” only). The “ANGLE” indicator lights up in green only when the angles can be changed. The “VIDEO
EQUALIZER” indicator lights up in green when any setting other than “STANDARD” is selected. The “VIEWER”
indicator lights up in green when a bookmark is set.
15

QuickOverview
A quick overview presentedin this chapter will give you enough information to start using the
player for your enjoyment. To usethe surround soundfeatures of this player, refer to “Hookups”
on page 20.
l You cannotconnectthis playerto aTV that doesnothavea video inputjack.
l Besureto turn off thepowerof eachcomponentbeforeconnecting.
Step1:Unpacking
Check that you have the following items:
l Audio/video cord (pinplug x 3 t, pinplug x 3) (1)
l SVIDEOcord(l)
l Remote commander (remote) Rh4T-D140A (1)
l Size AA (R6) batteries (2)
Step2: InsertingBatteriesintothe Remote
You can control the player using the supplied remote. Insert two size AA (R6) batteries by
matching the @ and0 endson thebatteries to the markings inside the compartment. When using
the remote, point it at the remote sensor q on the player.
. Do not leavetheremotein anextremelyhot or humid place.
l Do not dropanyforeign object into theremotecasing,particularly whenreplacingthe batteries.
l Do not exposetheremotesensorto direct light from thesunor alighting apparatus.Doing somaycausea
malfunction.
l If you do notusetheremotefor anextendedperiodof time, removethebatteriesto avoid possibledamagefrom
batteryleakageandcorrosion.
16

Connect the supplied audio/video cord andthe power cord in the order (m-m) shown below.
Be sureto connect the power code last.
El
Audio/video
cord (supplied)
to AUDIO OUT
q S-LINK cord
(not supplied)
To S-LINK (control S)
To S-LINKCONTROL S IN
\,.
Step3: TVHookups
When connecting to a wide screen TV
Depending on the disc, the image may not fit your TV screen.
If you want to change the aspectratio, pleaserefer to page 82.

When connecting to a TV that accepts progressive (480~) format signals
You needto usethe COMPONENT VIDEO OUT jacks to view progressive signals. Hook up
your TV using pattern @ on page 20, and then run Quick Setup on page 31.
If your TV has an S-LINK (control S) input jack
You cancontrol the player from aSony TV, or control aSony TV using the player. For instance,
when you play a DVD, the TV’s input will automatically switch to thejack to which you
connected the player.
Correct the TV via the S-LINK/CONTROL S IN jack using an S-LINK cord (not supplied).
Refer to the instructions supplied with the TV.

Step4: Playinga Disc
q Turnonthe TV.
a Switchthe input selector onthe TVto the player.
With the playback side facing down
q
PressPOWERonthe player.
q
PressP onthe playerto openthe disctray.
@ Placethe disc onthe tray with the playbacksidefacing down.
a PressD.
The disc tray closes and the player begins playing the disc
After Step 6
Depending on the disc, amenu may bedisplayed on theTV screen.If so,selecttheitem you wan1
from the menu and play the DVD VIDEO (page40) or VIDEO CD disc (page42).
To stop playing
PressW.
To take out the disc
PressA.
To turn off the player
Press I/& on the remote. The player is set to standby mode and the power indicator lights up in
red. PressPOWER on the player to turn off completely.

HookingUpthe Player
Follow Steps 1to 4 to hook up and adjust the settings of the player.
Before you start, turn off thepower, check that you have all of the supplied accessories,andinsert
the batteries into the remote (page 16).
l Plug cords securely to prevent unwanted noise.
l Refer to the instructions supplied with the components to be connected.
Step1:ConnectingtheVideoCords
Connect this player to your TV monitor, projector, or AV amplifier (receiver) using a video cord.
Selectoneof thepatterns0 through 0, according to theinput jack on your TV monitor, projector,
or AV amplifier (receiver). In order to view progressive signal (480~) pictures with acompatible
TV, projector, or monitor, you must useconnection @.
20
