Sony HT DDW1600 User manual

©2007 Sony Corporation
3-094-056-13(1)
Home Theatre
System
Operating Instructions
HT-DDW1600

2GB
To reduce the risk of fire or electric
shock, do not expose this apparatus to
rain or moisture.
To prevent fire, do not cover the ventilation of the
apparatus with newspapers, table-cloths, curtains,
etc. And don’t place lighted candles on the
apparatus.
To prevent fire or shock hazard, do not place objects
filled with liquids, such as vases, on the apparatus.
Install this system so that the power cord can be
unplugged from the wall socket immediately in the
event of trouble.
Don’t throw away batteries with
general house waste; dispose of
them correctly as chemical waste.
WARNING
Do not install the appliance in a confined space,
such as a bookcase or built-in cabinet.

3GB
About This Manual
• The instructions in this manual are for model
HT-DDW1600. In this manual, models of area
code SP is used for illustration purposes unless
stated otherwise. Any difference in operation is
clearly indicated in the text, for example, “Models
of area code MX only”.
•The instructions in this manual describe the
controls on the supplied remote. You can also use
the controls on the receiver if they have the same
or similar names as those on the remote.
The HT-DDW1600 consists of:
• Receiver STR-K1600
• Speaker system
– Front speakers SS-MSP16
– Center speaker SS-CNP16
– Surround/Surround SS-SRP16
back speakers
– Sub woofer SA-WP16
This receiver incorporates Dolby* Digital and Pro
Logic Surround and the DTS** Digital Surround
System.
* Manufactured under license from Dolby
Laboratories.
“Dolby”, “Pro Logic”, “Surround EX”, and the
double-D symbol are trademarks of Dolby
Laboratories.
** “DTS” and “DTS-ES Neo:6” are registered
trademarks of DTS, Inc. “96/24” is a trademark
of DTS, Inc.
This receiver incorporates High-Definition
Multimedia Interface (HDMITM) technology.
HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.
Note for the supplied remote
RM-AAU013 (Models of area code MX,
E51, AR only)
RM-AAU015 (Models of area code SP,
AU, TH only)
About area codes
The area code of the receiver you purchased is
shown on the lower right portion of the rear panel
(see the illustration below).
Any differences in operation, according to the area
code, are clearly indicated in the text, for example,
“Models of area code AA only”.
SURROUND BACK
SURROUND CENTER
O
NT
L
R
L
R
E
RS
Area code

4GB
Table of Contents
Getting Started
Description and location of parts...................5
1: Installing speakers ...................................15
2: Connecting speakers................................17
3a: Connecting the audio components.........19
3b: Connecting the video components ........20
3c: Connecting the lighting device ..............28
4: Connecting the antennas..........................29
5: Preparing the receiver and the remote .....30
6: Calibrating the appropriate settings
automatically
(AUTO CALIBRATION) .......................32
7: Adjusting the speaker levels and balance
(TEST TONE) ........................................36
Playback
Selecting a component.................................37
Listening/Watching a component ................39
Amplifier Operations
Navigating through menus...........................41
Adjusting the level (LEVEL menu).............44
Adjusting the tone (TONE menu) ...............45
Settings for the surround sound
(SUR menu)............................................45
Settings for the tuner (TUNER menu).........47
Settings for the audio (AUDIO menu).........47
Settings for the video (VIDEO menu).........48
(Models of area code SP, AU, TH only)
Settings for the system (SYSTEM menu) ...49
Calibrating the appropriate settings
automatically (A. CAL menu)................51
Enjoying Surround Sound
Enjoying Dolby Digital and DTS Surround
sound (AUTO FORMAT DIRECT)....... 52
Selecting a pre-programmed sound field .... 54
Using only the front speakers and sub
woofers (2CH STEREO) ....................... 57
Resetting sound fields to the initial
settings ................................................... 57
Tuner Operations
Listening to FM/AM radio.......................... 58
Presetting radio stations .............................. 60
Other Operations
Switching the audio input mode
(INPUT MODE) .................................... 62
Enjoying the DIGITAL MEDIA PORT
(DMPORT) ............................................ 63
(Models of area code SP, AU, TH only)
Creating a party environment
(X-ROUND) .......................................... 66
Naming inputs............................................. 67
Changing the display .................................. 67
Using the Sleep Timer ................................ 68
Recording using the receiver....................... 68
Using the Remote
Changing button assignments ..................... 69
Additional Information
Glossary ...................................................... 70
Precautions.................................................. 72
Troubleshooting .......................................... 73
Specifications.............................................. 77
Index ........................................................... 80

5GB
Getting Started
Description and location of parts
Front panel
Getting Started
Receiver
?/1
AUTO CAL MIC
AUTO CAL
TUNING MODE
TUNING
– +
PHONES
MEMORY/
ENTER SLEEPDIMMER
MULTI CHANNEL DECODING
SUR BACK
DECODING 2CH A.F.D. MOVIE MUSIC MODE SPEED
X-ROUND
DISPLAY INPUT MODE
INPUT SELECTOR
MASTER VOLUME
VIDEO 3 IN/PORTABLE AV IN
VIDEO L AUDIO R
6
q;
w
sqaqsw;wa ql
1
2
345 789
qfqgqhqjqk qd
Name Function
A?/1
(on/standby)
Press to turn the receiver
on or off (page 31, 39, 40,
57, 70, 78).
BAUTO CAL Press to activate the Auto
Calibration function (page
33).
CTUNING MODE Press to select the tuning
mode (page 58, 61, 78).
DDisplay The current status of the
selected component or a
list of selectable items
appears here (page 7).
EMULTI CHANNEL
DECODING
lamp
Lights up when multi
channel audio is decoded
(page 40).
FRemote sensor Receives signals from
remote commander.
Name Function
GDISPLAY Press to select information
displayed on the display
(page 66, 67).
HINPUT MODE Press to select the input
mode when the same
components are connected
to both digital and analog
jacks (page 62).
IMASTER
VOLUME
Turn to adjust the volume
level of all speakers at the
same time (page 36, 37,
39, 40).
JX-ROUND MODE Press to select the X-
ROUND mode (page 66).
X-ROUND
SPEED
Press to adjust the speed of
X-ROUND effect (page
66).
continued

6GB
Name Function
KINPUT
SELECTOR
Turn to select the input
source to playback (page
37, 39, 40, 58, 59, 60, 61,
62, 65, 67, 68, 69).
LMOVIE,
MUSIC
Press to select sound fields
(MOVIE, MUSIC) (page
54).
MA.F.D. Press to select A.F.D.
mode (page 52, 56).
N2CH Press to select 2CH
STEREO mode (page 56,
57).
OSUR BACK
DECODING
Press to select the
surround back decoding
mode (page 46).
PSLEEP Press to activate the Sleep
Timer function and the
duration which the
receiver turns off
automatically (page 68).
QDIMMER Press to change the
brightness of the display
(page 51).
RMEMORY/
ENTER
Press to store a station or
enter the selection when
selecting the settings
(page 31)
STUNING +/– Turn to scan a station
(page 58, 61).
TVIDEO 3 IN/
PORTABLE AV
IN jacks
To connect a camcorder or
video game (page 27, 37).
UAUTO CAL MIC
jack
Connects to the supplied
optimizer microphone for
the Auto Calibration
function (page 32).
VPHONES jack Connects to a headphone
(page 74).

7GB
Getting Started
About the indicators on the display
SW
LFE
LC
SL S
;
D EX
;
PL IIx
;
PL OPT DTS -ES 96/24 MEMORY ST
MONOD.RANGECOAX NEO:6
SB
R
SR
1 2 3 54 6 87
9q;qd qs qa
Name Function
ASW Lights up when the audio signal
is output from the SUB
WOOFER jack.
BLFE Lights up when the disc being
played back contains an LFE
(Low Frequency Effect)
channel and the LFE channel
signal is actually being
reproduced.
C; D (EX) “; D” lights up when Dolby
Digital signals are input.
“; D EX” lights up when
Dolby Digital Surround EX
signals are decoded.
Note
When playing a Dolby Digital
format disc, be sure that you
have made digital connections
and that INPUT MODE is not
set to “ANALOG” (page 62).
D; PL
(II)/(IIx)
“; PL” lights up when the
receiver applies Pro Logic
processing to 2 channel signals
in order to output the center and
surround channel signals.
“; PL II” lights up when the
Pro Logic II Movie/Music/
Game decoder is activated.
“; PL IIx” lights up when the
Pro Logic IIx Movie/Music/
Game decoder is activated.
Note
Dolby Pro Logic IIx decoding
does not function for DTS
format signals or for signals
with a sampling frequency of
more than 48 kHz.
Name Function
EOPT Lights up when INPUT MODE
is set to “AUTO IN” and the
source signal is a digital signal
being input through the
OPTICAL jack, or when
INPUT MODE is set to “OPT
IN” (page 62).
FDTS (-ES)/
(96/24)
“DTS” lights up when the
receiver is decoding DTS
signals.
“DTS-ES” lights up when the
receiver is decoding DTS-ES
signals.
“DTS 96/24” lights up when the
receiver is decoding DTS 96
kHz/24 bit signals.
Note
When playing a DTS format
disc, be sure that you have made
digital connections and that
INPUT MODE is not set to
“ANALOG” (page 62).
GMEMORY Lights up when a memory
function, such as Preset
Memory (page 60), etc., is
activated.
HTuner
indicators
Lights up when using the
receiver to tune in radio stations
(page 58), etc.
IPreset
station
indicators
Lights up when using the
receiver to tune in radio stations
you have preset. For details on
presetting radio stations, see
page 60.
JD.RANGE Lights up when dynamic range
compression is activated (page
44).
continued

8GB
Name Function
KNEO:6 Lights up when DTS Neo:6
Cinema/Music decoder is
activated (page 53).
LCOAX Lights up when INPUT MODE
is set to “AUTO IN” and the
source signal is a digital signal
being input through the
COAXIAL jack, or when
INPUT MODE is set to “COAX
IN” (page 62).
MPlayback
channel
indicators
L
R
C
SL
SR
S
SB
The letters (L, C, R, etc.)
indicate the channels being
played back. The boxes around
the letters vary to show how the
receiver downmixes the source
sound.
Front Left
Front Right
Center (monaural)
Surround Left
Surround Right
Surround (monaural or the
surround components obtained
by Pro Logic processing)
Surround back (the surround
back components obtained by
6.1 channel decoding)
Example:
Recording format (Front/
Surround): 3/2.1
Sound Field: A.F.D. AUTO
SW
LC
SL
R
SR

9GB
Getting Started
Rear panel
1
45
23
76
Y
PB/CB
PR/CR
HDMI
DVD IN VIDEO 2/BD IN OUT
SA-CD/CD/CD-R
D-LIGHT
SYNC OUT
TV
L
R
OUT IN IN
SAT
AUDIO IN
VIDEO IN
DVD
AUDIO IN
VIDEO IN
VIDEO 1
AUDIO OUT
VIDEO OUT VIDEO OUT SAT IN
MONITOR OUT
VIDEO 1 IN
SURROUND BACK
SURROUND CENTER FRONT
DVD IN
AUDIO IN AUDIO OUT
VIDEO IN
L
R
L
R
L
R
L
R
L
R
MONITOR
COMPONENT VIDEO
DIGITAL
DMPORT
OPTICAL
SAT
IN
DVD
IN
COAXIAL
ANTENNA
VIDEO 2/
BD IN
AM
SUB WOOFER SPEAKERS
ADIGITAL INPUT/OUTPUT section
OPTICAL
IN jack
Connects to a DVD
player, etc. The
COAXIAL jack
provides a better
quality of loud
sound (page 24,
26).
COAXIAL IN
jack
HDMI IN/
OUT jacka) Connects to a DVD
player, etc. The
image and the
sound are output to
a TV or a projector
(page 21).
DMPORT
jackb) Connects to a
DIGITAL MEDIA
PORT adapter
(page 64).
BANTENNA section
FM
ANTENNA
jack
Connects to the
FM wire antenna
supplied with this
receiver (page 29).
AM
ANTENNA
terminals
Connects to the
AM loop antenna
supplied with this
receiver (page 29).
CCOMPONENT VIDEO INPUT/
OUTPUT section
COMPONENT
VIDEO
INPUT/
OUTPUT
jacka)
Connects to a DVD
player, TV, a
satellite tuner, etc.
You can enjoy high
quality image (page
23, 24, 26).
DSPEAKER section
Connects to the
speakers (page 17).
Connects to the sub
woofers (page 17).
EVIDEO/AUDIO INPUT/OUTPUT
section
AUDIO IN/
OUT jack
Connects the video
and audio jacks of a
VCR, DVD player,
etc. (page 23, 24,
26, 27).
VIDEO IN/
OUT jacka)
Green
(Y)
Blue
(PB/CB)
Red
(PR/CR)
White (L)
Red (R)
Yellow
continued

10GB
a)You can watch the selected input image when you
connect the HDMI OUT or MONITOR OUT jack
to a TV (page 23).
b)Models of area code SP, AU, TH only.
FAUDIO INPUT/OUTPUT section
AUDIO IN/
OUT jack
Connects to an
Super Audio CD
player or CD
recorder, etc. (page
19).
GD-LIGHT SYNC OUT section
D-LIGHT
SYNC OUT
jack
Connects to a
lighting device
(page 28).
White (L)
Red (R)

11GB
Getting Started
You can use the supplied remote RM-AAU013 (models of area code MX, E51, AR only) or RM-
AAU015 (models of area code SP, AU, TH only) to operate the receiver and to control the Sony
audio/video components that the remote is assigned to operate. For details, see “Changing button
assignments” (page 69).
Remote commander
123
46
78
0/10 ENTER
9
SYSTEM STANDBY
TV INPUT
SLEEP DMPORT TV
?/1
AV ?/1
VIDEO 1 VIDEO 2 VIDEO 3 DVD
2CH A.F.D.
RETURN/EXIT
TV CH –
PRESET –
TV CH +
PRESET +
TUNING –
TV
TUNING +
REPLAY ADVANCE
MENU
MOVIE MUSIC
MEMORY DVD MENU
FM MODE
CLEAR
TOOLSDISPLAY MUTING
TV VOL
MASTER VOL
AUTO CAL
D.TUNING
D.SKIP
AMP MENU
SAT TV SA-CD/CD TUNER
?/1
-
F
Gg
f
.
HmM
Xx
< <
>
5
>10/
RM-AAU013
(Models of area code MX, E51, AR only)
123
46
78
0/10 ENTER
9
SYSTEM STANDBY
TV INPUT
SLEEP
AUTO
CAL
TV ?/1
AV ?/1
VIDEO 1 VIDEO 2 VIDEO 3 DVD
2CH A.F.D.
RETURN/EXIT
TV CH –
PRESET –
TV CH +
PRESET +
TUNING –
TV
TUNING +
REPLAY ADVANCE
MENU
MOVIE MUSIC
MEMORY DVD MENU
CLEAR
TOOLSDISPLAY MUTING
TV VOL
MASTER VOL
FM MODE
D.TUNING
D.SKIP
AMP MENU
SAT TV SA-CD/CD TUNER
?/1
-
F
Gg
f
.
HmM
Xx
< <
>
5
>10/
wf
qg
qj
qk
qh
qf
ql
w;
wd
qd
ws
1
3
2
5
6
7
8
q;
9
qs
qa
4
wa
RM-AAU015
(Models of area code SP, AU, TH only)
qg
qj
qk
qh
qf
ql
w;
wd
qd
ws
wa
3
6
8
1
2
5
7
q;
9
qs
qa
4
continued

12GB
Name Function
ATV ?/1
(on/standby)
Press TV ?/1and TV (M) at
the same time to turn the TV on
or off.
AV ?/1
(on/standby)
Press to turn on or off the Sony
audio/video components that
the remote is assigned to
operate.
If you press ?/1(B) at the
same time, it will turn off the
receiver and other components
(SYSTEM STANDBY).
Note
The function of the AV ?/1
switch changes automatically
each time you press the input
buttons (C).
B?/1
(on/standby)
Press to turn the receiver on or
off.
To turn off all components,
press ?/1and AV ?/1(A) at
the same time (SYSTEM
STANDBY).
CInput
buttons
Press one of the buttons to
select the component you want
to use. When you press any of
the input buttons, the receiver
turns on. The buttons are
factory assigned to control Sony
components as follows. You
can change the button
assignments following the steps
in “Changing button
assignments” on page 69.
Button Assigned Sony
component
VIDEO 1 VCR (VTR mode 3)
VIDEO 2 VCR (VTR mode 2)
VIDEO 3 Not assigned
DVD DVD player
SAT Digital Satellite
Receiver
TV TV
SA-CD/CD Super Audio CD/
CD player
TUNER Built-in tuner
DMPORT
(RM-AAU015
only)
DIGITAL MEDIA
PORT adapter
Name Function
DMOVIE Press to select sound fields
(MOVIE).
MUSIC Press to select sound fields
(MUSIC).
EAMP MENU Press to display the menu of
the receiver. Then, use V, v,
B, band (P) to perform
menu operations.
FFM MODE
(RM-AAU013
only)
Press to select the FM
monaural or stereo reception.
AUTO CAL
(RM-AAU015
only)
Press to activate the Auto
Calibration function (page
33).
GD.TUNING Press to enter direct tuning
mode.
D.SKIP Press to skip a disc when
using a multi-disc changer.
HDVD MENU Press to display the menu of
the DVD player on the TV
screen. Then, use V, v, B, b
and (P) to perform menu
operations.
FM MODE
(RM-AAU015
only)
Press to select the FM
monaural or stereo reception.
IENTER Press to enter the value after
selecting a channel, disc or
track using the numeric
buttons of the TV, VCR or
satellite tuner.
MEMORY Press to store a station.
JMUTING Press to activate the muting
function.
Press MUTING and TV (M)
at the same time to activate
the TV’s muting function.
KTV VOL
+a)/–
Press TV VOL +/– and TV
(M) at the same time to adjust
the TV volume level.
MASTER
VOL +a)/–
Press to adjust the volume
level of all speakers at the
same time.

13GB
Getting Started
Name Function
LTV CH +/– Press TV CH +/– and TV (M)
at the same time to select
preset TV channels.
PRESET +/– Press to select
– preset stations.
– preset channels of the VCR
or satellite tuner.
./>b) Press to skip a track of the CD
player, DVD player or Blu-
ray disc player.
REPLAY /
ADVANCE
Press to replay the previous
scene or fast forward the
current scene of the VCR,
DVD player or Blu-ray disc
player.
m/Mb) Press to
– search tracks in the forward/
reverse direction of the
DVD player.
– start fast forward/rewind of
the VCR, CD player or Blu-
ray disc player.
TUNING +/– Press to scan a station.
Ha)b) Press to start playback of the
VCR, CD player, DVD player
or Blu-ray disc player.
Xb) Press to pause playback or
recording of the VCR, CD
player, DVD player or Blu-
ray disc player. (Also starts
recording with components in
recording standby.)
xb) Press to stop playback of the
VCR, CD player, DVD player
or Blu-ray disc player.
MTV Press TV and the button you
want at the same time to
activate the buttons with
orange printing.
NMENU Press to display the menu of
the VCR, DVD player,
satellite tuner or Blu-ray disc
player on the TV screen.
Press MENU and TV (M) at
the same time to display the
TV’s menu. Then, use V, v,
B, band (P) to perform
menu operations.
<
<
Name Function
ORETURN/
EXIT OPress to – return to the previous menu.
– exit the menu while the
menu or on-screen guide of
the VCR, DVD player,
satellite tuner or Blu-ray
disc player is displayed on
the TV screen.
Press RETURN/EXIT and TV
(M) at the same time to return
to the previous menu or exit
the TV’s menu while the
menu is displayed on the TV
screen.
P
V/v/B/b
After pressing AMP MENU
(E), DVD MENU (H) or
MENU (N), press V, v, Bor
bto select the settings. Then,
press to enter the selection
for DVD MENU or MENU.
Press also to enter the
selection of the receiver,
VCR, satellite tuner, CD
player, DVD player or Blu-
ray disc player.
QDISPLAY Press to select information
displayed on the TV screen of
the VCR, satellite tuner, CD
player, DVD player or Blu-
ray disc player.
Press DISPLAY and TV (M)
at the same time to select TV
information displayed on the
TV screen.
RTOOLS Press to display options
applicable to the entire disc
(e.g. disc protection), recorder
(e.g. audio settings during
recording), or multiple items
on a list menu (e.g. erasing
multiple titles).
Press TOOLS and TV (M) at
the same time to display
options applicable to the TV.
continued

14GB
a)The number 5, MASTER VOL +, TV VOL + and
Hbuttons have tactile dots. Use the tactile dots
as references when operating the receiver.
b)This button is also available for DIGITAL
MEDIA PORT adapter operation. For details on
the function of the button, see the operating
instructions supplied with the DIGITAL MEDIA
PORT adapter.
Notes
• Some functions explained in this section may not
work depending on the model.
• The above explanation is intended to serve as an
example only. Therefore, depending on the
component, the above operation may not be
possible or may operate differently than described.
Name Function
S>10/xPress to select
– track numbers over 10 of the
VCR, satellite tuner or CD
player.
– channel numbers of the
Digital CATV terminal.
-/-- Press -/-- and TV (M) at the
same time to select the
channel entry mode, either
one or two digits of the TV.
CLEAR Press to clear a mistake when
you press the incorrect
numeric button.
TNumeric
buttons
(number 5a))
Press to
– preset/tune to preset
stations.
– select track numbers of the
CD player, DVD player or
Blu-ray disc player. Press 0/
10 to select track number 10.
– select channel numbers of
the VCR or satellite tuner.
Press the numeric buttons and
TV (M) at the same time to
select the TV channels.
UA.F.D. Press to select A.F.D. mode.
V2CH Press to select 2CH STEREO
mode.
WTV INPUT Press TV INPUT and TV (M)
at the same time to select the
input signal (TV input or
video input).
SLEEP Press to activate the Sleep
Timer function and the
duration which the receiver
turns off automatically.
XAUTO CAL
(RM-AAU013
only)
Press to activate the Auto
Calibration function.

15GB
Getting Started
1: Installing speakers
This receiver allows you to use a 6 channel
speaker with 4 sub woofers system.
To fully enjoy theater-like multi channel
surround sound requires five speakers (two
front speakers, a center speaker and two
surround speakers) and a sub woofer (5.1
channel).
You can enjoy high fidelity reproduction of
DVD software recorded sound in the Surround
EX format if you connect one additional
surround back speaker (6.1 channel) (see
“Using the surround back decoding mode
(SUR BACK DECODING)”) on page 46.
Example of 6 channel speaker
with 2 sub woofers system
configuration
AFront speaker (Left)
BFront speaker (Right)
CCenter speaker
DSurround speaker (Left)
ESurround speaker (Right)
FSurround back speaker
GSub woofer
HSub woofer
Tip
Since the sub woofer does not emit highly
directional signals, you can place it wherever you
want.
Before you install the center speaker, surround
speakers, surround back speaker and sub
woofers, be sure to attach the supplied foot
pads to prevent vibration or movement as
shown in the illustration below.
Installing the speakers on a flat
surface

16GB
You can install your surround and surround
back speakers on the wall.
1Prepare screws (not supplied)
that are suitable for the hook on
the back of each speaker as
shown in the illustrations
below.
2Fasten the screws to the wall.
The screws should protrude 5
to 7 mm.
3Hang the speakers on the
screws.
Notes
• Use screws that are suitable for the wall material
and strength. As a plaster board wall is especially
fragile, attach the screws securely to a beam and
fasten them to the wall. Install the speakers on a
vertical and flat wall where reinforcement is
applied.
• Contact a screw shop or installer regarding the wall
material or screws to be used.
• Sony is not responsible for accident or damage
caused by improper installation, insufficient wall
strength or improper screw installation, natural
calamity, etc.
Installing the speakers on the
wall
more than 4 mm
more than 25 mm
Hook on the back of the speaker
4.6 mm
10 mm
5 to 7 mm
4.6 mm
10 mm
Hook on the back of the speaker

17GB
Getting Started
2: Connecting speakers
AFront speaker (Left)
BFront speaker (Right)
CCenter speaker
DSurround speaker (Left)
ESurround speaker (Right)
FSurround back speaker
GSub woofer
HSub woofer
a) If you have additional subwoofers, connect them
to the SUBWOOFER jacks.
We recommend you to use SA-WP1600
subwoofer.
Tip
Use the supplied speakers to optimize the system’s
performance.
Y
PB/CB
PR/CR
HDMI
DVD IN VIDEO 2/BD IN OUT
SAT
AUDIO IN
VIDEO IN
DVD
AUDIO IN
VIDEO IN
VIDEO 1
AUDIO OUT
VIDEO OUT VIDEO OUT SAT IN
MONITOR OUT
VIDEO 1 INDVD IN
AUDIO IN
VIDEO IN
L
R
L
R
L
R
MONITOR
COMPONENT VIDEO
CENTER
FRONT
AUDIO OUT
L
R
L
R
SUB WOOFER
SURROUND
SPEAKERS
SURROUND BACK
GH
A
FDA
AB C C
CEB
BCB
AMonaural audio cord (supplied)
BSpeaker cord (short) (supplied)
CSpeaker cord (long) (supplied)
SUBWOOFER jacksa)
continued

18GB
To connect the speaker
correctly
Check the speaker type by referring to the
speaker label* on the speakers.
*The center speaker and sub woofer do not have any
character on the speaker label. For details on the
speaker type, see page 3.
Character
on speaker
label
Speaker type Location of
speaker label
LFront left Rear panel
RFront right Rear panel
SL Surround left Rear panel
SR Surround right Rear panel
SB Surround back Rear panel

19GB
Getting Started
3a: Connecting the audio components
The following illustration shows how to
connect a Super Audio CD player, CD player
or CD recorder.
After connecting your Super Audio CD player,
CD player or CD recorder, proceed to “3b:
Connecting the video components” (page 20)
or “4: Connecting the antennas” (page 29).
Connecting a Super Audio CD/CD
player or CD recorder
Y
PB/CB
PR/CR
HDMI
DVD IN VIDEO 2/BD IN OUT
D-LIGHT
SYNC OUT
TV
IN
SAT
AUDIO IN
VIDEO IN
DVD
AUDIO IN
VIDEO IN
VIDEO 1
AUDIO OUT
VIDEO OUT VIDEO OUT SAT IN
MONITOR OUT
VIDEO 1 IN
SURROUND BACK
SURROUND CENTER FRONT
DVD IN
AUDIO IN AUDIO OUT
VIDEO IN
L
R
L
R
L
R
L
R
L
R
MONITOR
COMPONENT VIDEO
DIGITAL
DMPORT
OPTICAL
SAT
IN
DVD
IN
COAXIAL
ANTENNA
VIDEO 2/
BD IN
AM
SUB WOOFER SPEAKERS
SA-CD/CD/CD-R
L
R
OUT IN
Super Audio
CD player/
CD player/
CD recorder
A
AAudio cord (not supplied)

20GB
3b: Connecting the video components
This section describes how to hook up your
components to this receiver. Before you begin,
refer to “Component to be connected” below
for the pages which describe how to connect
each component.
After hooking up all your components,
proceed to “4: Connecting the antennas” (page
29).
Component to be connected
The image quality depends on the connecting
jack. Refer to the illustration that follows.
Select the connection according to the jacks on
your components.
Notes
• Connect image display components such as a TV
or a projector to the MONITOR OUT jack on the
receiver.
• Turn on the receiver when the video and audio of a
playback component are being output to a TV
through the receiver. If the power supply of the
receiver is not on, neither video nor audio is
transmitted.
How to hook up your
components
Component Page
With HDMI jack 21
TV 23
DVD player/DVD recorder 24
Satellite tuner/Set-top box 26
VCR 27
Camcorder, video game, etc. 27
Video input/output jack to be
connected
?/1
AUTOCALMIC
AUTOCAL
TUNINGMODE
TUNING
– +
PHONES
MEMORY/
ENTER SLEEPDIMMER
MULTICHANNELDECODING
SURBACK
DECODING
2CH A.F.D. MOVIE MUSIC MODE SPEED
X-ROUND
DISPLAY INPUTMODE
INPUTSELECTOR
MASTERVOLUME
VIDEO3IN/PORTABLE AV IN
VIDEO L AUDIO R
TV, etc. INPUT jack
Receiver
MONITOR OUT
jack
Receiver INPUT
jack
Video component
OUTPUT jack
High quality image
COMPONENT
VIDEO VIDEO
HDMI
COMPONENT
VIDEO VIDEO
HDMI
COMPONENT
VIDEO VIDEO
HDMI
COMPONENT
VIDEO VIDEO
HDMI
