BID SPECIFICATION
FOR
BROADCAST CRT MONITORS
MODEL NUMBER
BVM-D24E1WU
INSTRUCTIONS:
REMOVE THIS COVER PAGE AND ADD TO REQUESTS FOR QUOTATION AND
PROPOSALS. THE OBJECTIVE OF THIS BID SPECIFICATION IS TO ASSIST YOU IN
CLEARLY SPECIFYING THE SONY PRODUCT IDENTIFIED ABOVE, AND ENSURING
THAT THE BUYER IS WELL INFORMED OF THE HIGH STANDARD OF
PERFORMANCE THAT IS TO BE EXPECTED OF A SONY PRODUCT. THE
INFORMATION IN THIS DOCUMENT IS CURRENT AS OF JUNE 2002. PRODUCT
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
SONY ELECTRONICS INC.
DISPLAY PRODUCTS GROUP
1 SONY DRIVE, MD 3D9
PARK RIDGE, NJ 07656
TEL# [phone], FAX# [phone]

1.0 General Information
The purpose of this information is to provide the specification for a product whose
primary purpose is the reproduction of video information for one or more viewers.
This reproduction of this information is to be accomplished via a direct-view CRT
monitor. This document provides theminimum specifications for this device.
The performance comparison of displays is not only technical in nature, but is also
subjective to the user, when viewed in the final display environment. It is
recommended that devices meeting the requirements of this specification be
compared in the user’s application and environment, if possible.
2.0 Description
This product shall be classified as a direct-view CRT color monitor, or propduction
display. This device shall be directly compatible with video sources, without the use
of external devices to provide this compatibility.
This device shall employ the use of an HR Trinitron CRT for optimum display of high-
resolution sources.
This device shall be encased in a metal enclosure for durability.
3.0 Source Compatibility / Suitability for Application
3.1 Compatible Display Formats
SMPTE 170M NTSC
SMPTE 240M 1035 line HDTV
SMPTE 274M 1080 line HDTV
SMPTE 296M 720 line HDTV
SMPTE 145 type C phosphor standard
ITU 601 colorimetry
ITU 709-2 colorimetry
3.2 Compatible Input Formats
SMPTE 170M NTSC Composite
ITU 601 PAL Composite
SMPTE 259M 525/625 Component serial digital video
SMPTE 292M HD Component serial digital video

4.0 User Interface / Controllability Information
Control of this device shall be accomplished through one of the following methods:
Parallel Remote Control
RS-485 Serial Control
This device shall provide a Type II PCMCIA card slot to store monitor settings
locally.
The optional parallel remote control shall provide access to allmonitor setup
functions.
The serial control jack shall employ the use of a standardized device control
protocol that is understood by external control unit available as an accessory. This
control jack shall accept bi-directional serial commands that provide full control over
the device.
All monitor control functions shall be available for control through the serial control
jack. This jack shall be capable of connection to an optional serial controller that is
capable of controlling up to 32 monitors. This optional controller shall be capable of
storing monitor settings using a Type II PCMCIA flash card.
Monitor control functions also include auto landing, uniformity adjustments, andauto
white balance setup using Minolta, Philips, Thoma, and Grasby light probes.
5.0 Performance Specifications
This device shall employ the use of an HR TrinitronCRT with a minimum CRT
resolution of 1000 lines in 16:9 mode and 1000 lines in 4:3 mode. The CRT shall
employ the use ofSMPTE-C phosphors.
This device shall be equipped with color temperature alignment system for easy set-
up with industry standard color analyzers.Different colorimetery settings shall be
able to be recalled for ITU or SMPTE production or film applications.
This device shall employ built-in auto setup, allowing for automatic adjustment of
chroma and phase.
This device shall provide color temperature stability using a beam current feedback
circuit.
This device shall employ on-screen display of time code for editing and duplication
references.

This device shall support switchable aspect ratios of 4:3 and 16:9, and shall offer a
4:3 area marker.
This device shall provide beam landing correction to compensate for changes in the
terrestrial magnetic field in different operating environments.
This device shall include digital point convergence for complete RGB convergence
accuracy within the image area. A built-in test pattern generator shall be included for
assistance in convergence and other monitor setup functions.
This device shall include a 16:9 tube with the ability to display 4:3 format video.
6.0 Dimensional Information
This device shall employ the use of a24” diagonal (21.88” viewable) CRT.
This device shall have maximum cabinet dimensions of 17.25 inches high by 22.38
inches wide and 23.13 inches deep.
This device shall not weigh more than 113 pounds.
7.0 Connectivity Information
This device shall provide for direct connection of a single source device, and shall
be built with expansion capabilities (4slots) for additional source devices, with a
maximum of 25 directly connected sources. This connection shall include the
following:
Component Video or RGB Video on BNC Connectors with loop-through
Optional source connections shall include the following:
Composite Video on a BNC Connector with loop-through
S-Video on two BNC Connectorswith loop-through
Component Video or RGB Video on BNC Connectors with loop-through
SDI Video on a BNC Connector with loop-through
HD-SDI Video on a BNC Connector with loop-through
8.0 Power Requirements

This device shall accept power at 100-240 VAC at either 50 or 60 Hz.
This device shall consume no more than 205 watts.
Power to this device shall be supplied via a detachable standard power cord that is
readily available for replacement from local suppliers.
9.0 Safety Compliance Information
This device shall be fully compliant with the following standards:
UL 1950
CSA 950 (cUL listed)
FCC Class-A
IC Class-A
DHHS
DNHW
10.0 Warranty Information
This device shall carry a2-year manufacturer’s warranty. Authorized servicing
dealers of the devices’ manufacturer shall perform warranty service.
