FWD -32LX2
LCDProDisplay
Key Features
HighResolutionPanel-1366x768WXGA
Burn -inresistantLCDtechnology
DualOptionSlots
NetworkingandTunerOptions
2HDMIinputs
AutoInputSelection
TrueColorControl
VideoWallsupportbuilt -in(upto4x4grid)
Key Technologies
Superiorimagequality and sound UsingSony'svideoengineeringexpertise,superiorimagequalityis
achievedinbothPCandVideomodes.HighqualitysoundisachievedthroughtheadoptionofBBEand
SRSWOWaudioenhancementsystems.
I/OExpandability ExpandabilityofI/Osignalswithdual-slots;2HDMIinputs;Selectablesignalssuch
asAnalogcomposite,S-video,Componentinputs.SelectableRS-232CinterfaceorNetwork
communication.
ExceptionalLCDperformance Highbrightness,superiorcontrastandsuper-fast8msvideoresponse
timecombinetodelivercrisp,cleartextandsmoothmotionimagesforvideoapplications.
TrueColorControl ™ ( TC ™ ) Offersusercontrolofcolorsaturationandhueofeitherred,yellow,
greenandblueindividuallywithoutchangingothercolors.Whitebalanceremainsthesame.
2
Automaticinputselection Eachinputautomaticallydetectsthemodeoftheinputsignaland
switchestotheappropriateinputeliminatingtheneedformanualselection.
Specialhotelmenu Includingadvancedsettingsforcommercialapplications.
Builtinvideowall support Usefrom4to16displaystocreatealargevenuevideoexperience.
Networkingoptions Optionalnetworkcardsandboxes(soldseparately)letyoucentrallycontrol,
deliverandtroubleshootdigitalcontentacrossastandardIPnetworktooneorhundredsof
networkeddisplays.Reducelaborandproductioncostsassociatedwithmanagingindividualcontent.
WEGAEngine™system Intelligentdigitalprocessingsystemdeliverssuperbpicturequalityby
minimizingsignaldeteriorationcausedbydigital-to-analogconversion.
LowCostofOwnership Burn-inresistantLCDtechnologyensureslonglifewhenusingstaticimages.
Lowpowerconsumptionandlong-lifepaneldelivershoursofusetokeepyourtotalcostofownership
low.

SonyElectronicsInc. • 1SonyDrive • ParkRidge,NJ07656 • 800.222.7669 • www.sony.com
LastUpdated:12/05/2006
FWD -32LX2
LCDProDisplay
PleasevisittheDealerNetworkforcurrent
informationatwww.sony.com/dn
Features
Video
Picture Modes: Custom, Vivid, Standard
Display Technology: LCD
Convenience
Multiple Language Display: English, French,
Spanish, Italian, German, Japanese, Dutch,
Swedish, Russian, Chinese
Picture and Picture: Yes
HDMI ™ Technology: Yes
Specifications
General
Screen Size: 32.0"
Video
Closed Caption Decoder: Yes
Display Resolution: 1366 x 768
Display Response Time: 8 ms
Viewing Angle: Horizontal: 176 ° , Vertical: 176 °
Format(s) Supported: NTSC, PAL, SECAM,
NTSC4.43, PAL60, PAL-M, PAL- N
Convenience
Cable Management System: Yes
On Screen Controls: Yes
Wall/Arm Mount: Yes
Inputs and Outputs
Analog Audio Input(s): Pinjack (x2)
Analog Audio Output(s): Speaker OUT(L/R) 7W +
7W
PC Audio Input(s): Shared between 2x HDMI
and HD15
Control-S Input(s): Mini jack (x1)
Control- S Output(s): Mini jack (x1)
Dual Option Slot: Yes
RS232 Control: D-sub 9-pin (x1)
S -Video Input(s): Mini DIN 4-pin (x1) (when S-
Video is used, Composite Video is inactive)
S -Video Output(s): Mini DIN 4-pin (x1) Loop-
through
Video In (BNC): 1 (when Video is used, S-Video
is inactive)
HDMI ™ Connection(s): 2 HDMI ver 1.1
HD Component Video Input(s):
RGB/COMPONENT IN: D-sub 15-pin female (x1)
Power
Internal Power Supply: Yes
Power Requirements: 100V - 240V AC, 50-60Hz
Power Consumption (in Operation): 120W
Output Power: 14W Total (7Wx2 Digital AMP)
Regulation and Standard Compliance
Safety Regulations: Safety (60950): UL, cUL,
NEMKO, CB, Den-an
EMC: FCC, IC, cE, C-Tick, Den-an, VCCI, JEITA
Service and Warranty Information
Extended Warranty: Optional Extended Service
Plans for up to 5 years of coverage.
Limited Warranty: 2 years parts, 2 years labor,
1 year panel
Dimensions
Weight: 16 kg
Measurements: 796 x 486 x 107mm
Operating Conditions
Colors: 16.7 million
Screen Treatment: Anti-Glare, Anti-Reflective
Color Temperature Control: Cool, Neutral,
Warm
Operating Temperature: 0 ° to 35 ° C (32 ° to 95 ° F)
Operating Humidity: 20% to 90%, non
condensing
Hardware
Mount Design: Landscape, Portrait
Remote Control: Multi-Function Remote
Supplied Accessories
AC Power Cord (1), AC Plug Holder (2),
Component Video signal cable 3m (D-sub 15
- RCAx3) (1), BNC-RCA conversion adaptor (1),
Cable Holder (6), RM-FW001 Remote
Commander (1), Size AA (R6) Batteries(2),
Operating Instructions
Optional Accessories
Networking: NSP- 1 (Digital Signage Player), EBS -
N200D (Network and MultiMedia Player),
BKM-FW40 (High Definition streaming
adapter), BKM-FW32 (Internal Network
Management Device for status and control
over IP), ICS-SP20 (TV Tuner and Hospitality
System), ICS-SP30 (HDTV Tuner and
Hospitality System), BKM-FW50 (Network
Media Card),
Stationary Wall Mount Kit supports Landscape
mode (SFM2).
Wall Mount Kit supporting Portrait, Landscape
and Tilt (up to 15 degrees). Also, allows room
for EBS accessories (PLP-91/D).
Input Boards: BKM-FW11 (Component/RGB
Input Adapter), BKM-FW12 (RGB Component
Loop Through), ICS-FW40 (HD Streaming
Card), ICS-FW40D (HD Digital Signage Card)
Speakers: SS-SP32FW/B, SS-SP32FW/S (Speakers
for Black and Silver models
Software: PJNet (Asset Management tool to
control up to 255 Sony Plasmas or
Projectors), DCDS (Asset Management tool
to schedule and control up to 10,000 points)
Tuners: EBS-SP35: HD TV Tuner for Hotels
Color: FWD-32LX2F/B - Matte Black, FWD-
32LX2F/S - Matte Silver
