VPL-VW90ES
Key Features
Active 3D Front Projector with 2D to 3D
upconversion
Supports Frame Packing, Side by Side, and
Over Under formats
Full HD 1080p with 3 NEW SXRD™1920 x 1080
Panels
Brightness of 1000 ANSI lumens
150,000:1 Dynamic Contrast
Supports Deep Color , x.v.Color, and 24p True
Cinema
Built in IR transmitter for 3D / supports wired 3D
transmitter accessory
Anamorphic mode (2D Only)
144 zone panel alignment
Motorized zoom / shift / focus
Key Technologies
Full HD 1080p with 3 SXRD ™ 1920 x 1080 Panels Three SXRD 1920 x 1080p micro - display panels support Full
HD 1080p resolution for an impressive combination of vivid color, film - like image quality, and high - definition brilliance.
Enjoy cinematic - quality images.
TM
200W Ultra - High - Pressure Lamp A 200W Ultra - High - Pressure Lamp delivers natural color with a brightness of 1000
ANSI lumens .
3
BRAVIA Engine™ 2 BRAVIA Engine 2 fully digital video processor uses a collection of unique Sony ® algorithms to
significantly reduce noise, enhance overall image detail, and optimize contrast so every scene produces sharp,
vibrant, life - like images.
Advanced Iris 3 The Advanced Iris 3 function provides up to a 150,000:1 Dynamic contrast ratio by optimizing both
dark and bright scenes to produce deep black levels with stunning details.
2
Motionflow™240Hz Panel Drive with Dark Frame Insertion Technology Doubles the frame rate in video
sources to reduce judder and deliver a smoother more natural viewing experience.
24p True Cinema™ 24p True Cinema technology provides a direct connection to 24p video sources so you can
avoid conversions and enjoy films at their intended 24 fps (frames per second).
x.v.Color™ x.v.Color technology takes HD color expression to new levels. When connected to x.v.Color capable video
sources, such as select Sony ® camcorders, the VPL - VW85 can display nearly twice as many (1.8x) viewable colors as
the existing RGB color standard, resulting in more natural, life - like images.
Deep Color By combining a 10 - bit processor with 10 - bit SXRD™panels, the VPL - VW90ES can create and display 64
times the level of color expression of 8 - bit projectors, resulting in smoother color gradations and helping to avoid a
“ paint - by - numbers ” look.
ARC - F (All Range Crisp Focus) Lens A specially developed ARC - F (All Range Crisp Focus) lens takes full
advantage of the SXRD ™panels to deliver Full HD 1080p resolution with superior clarity and focus.
Noise reduction functions The VPL - VW90ES features noise reduction functions that analyze scenes in real time to
identify various types of noise and reduce unwanted artifacts, such as mosquito noise and block noise, without
compromising the video signal.
Panel Alignment function A Panel Alignment function enables pixel alignment to within 1/10th of a pixel, making
it possible to shift the entire picture or specific zones to adjust for color gaps and produce a brighter, clearer, and
more detailed picture.

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 01/27/2011
VPL-VW90ES
Please visit the Dealer Source for current
information at www.sony.com/dealersource
Features
General
VerticalKeystone: Yes
High Altitude Mode: Off, On
InformationMenu: Horizontal and Vertical
frequency display
Acceptable Computer Signals: fH: 19 to 72
kHz, fV: 48 to 92 Hz, fV: 60 Hz
InputA: D - sub 15 Pin, Analog
RGB/Component
Display
DisplayTechnology: SXRD™Technology
Video
VerticalPosition: Yes
DotPhase: Yes
Title Area Control: Yes
FilmMode: Yes
Acceptable Video Signals: Composite
video, Y/C video, 15 kHz
(RGB/Component) 50/60Hz; Progressive
component 50/60 Hz; DTV (480/60i,
480/60p, 575/50i, 575/50p, 720/50p,
720/60p, 1080P24sF(48i),1080/50i,
1080/50p, 1080/60i), HDMI inputs only:
1080/60p, 1080/24p
10 - bit Video Processing: Yes
3D Comb Filter: Yes
x.v.Color ™ Technology: Yes
Motionflow ™ Technology: Yes
Lens Shift Function: Yes
VerticalSize: Yes
Convenience
Multiple Language Display: 15 languages
(including English, French, Spanish,
German and Chinese)
Auto Input Search: Yes
TestPattern: Yes
ImageFlip: HV, H, V, Off
IRReceiver: Front & Rear, Front, Rear
Illumination: Logo (Off, On)
RemoteControl: Yes (RM - PJVW85)
Specifications
General
Projection Picture Size: 40" to 300"
measured diagonally
TelevisionType: HD Front Projectors
Display
Screen Size (measured diagonally): 40" to
300" measured diagonally (projected)
NativeResolution: 1080p
DisplayResolution: 1920 x 1080 (Full HD)
AspectRatio: 16:9
TV System
ColorSystem: Auto, NTSC, PAL, SECAM
Video
ContrastRatio: Up to 150,000:1 (with
Advanced Iris Auto 1 ON)
Brightness: 1000 Lumens
Inputs and Outputs
Component Video (Y/Pb/Pr ) Input(s): 2
(Side): 1 (RCAx3), 1 (15 Pin HD)
Composite Video Input(s): 1 (Side) Vp - p+/ -
2 dB sync negative (75 ohms
terminated)
PC Video Input(s): Yes
Remote Network Connection(s): 1 (Side)
RS - 232C: D - sub 9 - pin (female)
HDMI™Connection(s)(Total): 2 (Side)
Digital RGB/Y/Cb(Pb)Cr(Pr) with PC
timing support
RS - 232CInput(s): Yes
12V Trigger Output(s): Mini Jack - Power
On: DC 12V, output impedance: 4.7
kilohms Power Off: 0V (Selectable -
Power/Anamorphic zoom)
3D Sync: 1 (Side) RJ45
IRInput(s): 1 (Side)
Power
Power Consumption (in Operation): 320W
max
Power Consumption (in Standby): 8W;
0.5W in low mode
PowerRequirements: AC 100 - 240V, 1.4 -
3.2A, 50/60Hz
Operating Conditions
OperatingTemperature: 5 ° C to 35 ° C (41 ° F
to 95 ° F)
OperatingHumidity: 35% to 85%
(condensation)
Service and Warranty Information
Limited Warranty Term: Product Warranty -
Limited 3 Years Parts and Labor except
the lamp. Lamp Warranty - 90 Days from
date of purchase.
3D Capability
3D Glasses BRT Adjustment: Yes
AutoSearch: Yes
DepthAdjustment: Yes
Format: Frame Packing/ Side by Side/ Over -
Under/Simulated 3D
Signal: (HDMI inputs only)
1080:24p/60p/50p/60i/50i ;
720:60p/50p
Simulated3D: Yes
Transmitter: Yes
Weights and Measurements
Dimensions (Approx) Width: 18 5/8"
Dimensions (Approx) Height: 7 1/8"
1
Dimensions (Approx) Depth: 19"
Weight(Approx.): 26.5 lbs
Dimensions(Approx.): 18 5/8 x 7 1/8 x 19
in
Supplied Accessories
Remote Control (RM - PJVW85)
Instruction Manual
AC Cord
CD ROM (Image Director 3)
Size AA (R6) batteries x2
(2) 3D Glasses with Filter attachments
Optional Accessories
Ultra High Pressure Replacement Lamp
(LMP - H201)
Black Ceiling Mount (PSS - H10)
UPC Code: 027242807709
1.AnamorphiclensisnotavailablefromSony ® .
2.150,000:1contrastratioachievedwithAdvancedIris AutoON.
3.ANSI lumens is a measuringmethodof the American National
StandardsInstitute IT7.228. Since there isno uniform method of
measuring brightness, specifications will vary among manufactures.
4.Whenused with supporting video sources such asselectSony
camcorders.
5.Pixel convergence to 1/10th inchiscalculated as ± 2.0dot by0.1 dot
pitch.Dependingon the adjustments made, the number of display
pixelsmay decrease. Also, colors may becomeunevenor the
resolutionmaychange
6.BRAVIA Sync™works with select Sony® HDTVs,front projectors,and
hometheater products. Check owners ’ manuals for compability.
©2009 Sony ElectronicsInc. All rightsreserved.Reproduction inwholeor
inpartwithoutwrittenpermission is prohibited.
Sony,HDNA, BRAVIA,BRAVIAEngine, RemoteCommander, SXRD, 24p
TrueCinema,x.v. Color, Handycam and their respective logos are
trademarksofSony.HDMI,theHDMIlogo,andHigh - DefinitionMultimedia
InterfacearetrademarksofHDMILicensingLLC.Blu - rayDiscisa
trademark.All othertrademarksare trademarksof their respective
owners.
Non - metricweightsandmeasurementsare approximate and may vary.
