VPL-FH300L
VPL-FW300L
In-room, Large-venue Projectors
SONY54052_VPL-FH300L.qxd 2/25/08 3:06 PM Page 3

2
Packing the most advanced projector technologies into a
uniquely designed round chassis, the VPL-FH300L and VPL-FW300L
Data Projectors deliver extremely high-quality images of 2K x 1K
and WXGA resolution, respectively.
These projectors also offer an incredibly high brightness of 6000
(VPL-FH300L) or 7000 (VPL-FW300L) lumens, thanks to the newly
developed BrightEra™ LCD panel and a dual-lamp system.
The VPL-FH300L and VPL-FW300L adopt a bayonet mount that
allows a lens to be easily attached and detached, and a variety
of lens options are available to meet a range of installation
needs.
System integrators will appreciate the projectors' design, which
includes features for easy installation, such as a centered lens,
simple cabling, and auto-flip image, as well as power zoom,
focus, and shift, while maintenance personnel can easily
replace lamps and filters at the same time, thanks to their easy
access.
Furthermore, the VPL-FH300L and VPL-FW300L consume less than
820 W of power, which is the lowest level for projectors that
provide the same level of brightness with a dual-lamp system.
With all of these features and functionality, which are only
available from Sony, the VPL-FH300L and VPL-FW300L projectors
are the best choice for a range of applications, from business
conferences and seminars to education, simulations, and rental
and staging, in locations such as boardrooms, large conference
rooms, university classrooms, and art museums.
Dynamic 2K x 1K and WXGA Projections
Powered by an Astonishing Brightness –
the VPL-FH300L and VPL-FW300L Data Projectors
SONY54052_VPL-FH300L.qxd 2/25/08 3:06 PM Page 2

3
■Features ■
High-quality Images
✜Extremely High Resolution (2K x 1K or WXGA)
in Widescreen
With a 2K x 1K LCD panel incorporated, the VPL-FH300L
projects extremely clear and detailed high-quality
images with a 2K X 1K (2048 x 1080)* resolution, even on
a large widescreen. While the VPL-FW300L offers WXGA
(1366 x 800) resolution for high-quality widescreen
images.
*2K X 1K (2048 x 1080) signals supplied to the VPL-FH300L are converted
to 2046 x 1080 signals by removing one vertical line from each side, and
then processed and displayed as a 2K x 1K image.
✜Outstanding Brightness (6000 or 7000 Lumens)
From BrightEra LCD Panel and Dual-lamp
System
The VPL-FH300L and VPL-FW300L Data Projectors
achieve an outstanding brightness of 6000 and 7000
lumens, respectively. This allows for dynamic,
large-screen presentations even in high ambient lighting
environments. By combining a new generation of
inorganic LCD panels that utilize Sony's BrightEra
technology with a powerful dual-lamp system, these
projectors offer both brilliant pictures and stable
operations.
BrightEra Technology
BrightEra is a brand name for the category of next-generation
LCD panels that have pixels with large aperture ratios and that
adopt inorganic alignment films. Sony is the first manufacturer
to succeed in developing this technology for a High-
Temperature Polysilicon (HTPS) TFT LCD panel.
LCD Panel of the VPL-FH300L
LCD Panel of the VPL-FW300L
Dual-lamp System
The VPL-FH300L and VPL-FW300L adopt a unique lamp system
that uses two lamps for reliable, flexible, and efficient use of
light sources. In dual-lamp mode, the VPL-FH300L and
VPL-FW300L offer a maximum brightness of 6000 and 7000
lumens, respectively. In single-lamp mode, users can select
either of the two lamps manually, or the projector can
automatically select a lamp based on each lamp's operating
time.
In addition, the dual-lamp system enables virtually
fail-safe operations. In dual-lamp mode, if one bulb burns out,
the other can keep projecting images. In single-lamp plus
auto-lamp-select mode, if one bulb burns out, the other
automatically lights up to keep projecting images.
✜3LCD Projection System
Because the VPL-FH300L and VPL-FW300L adopt a
3LCD projection system, projected images are bright
and natural. 3LCD is a projection system using three
LCD panels. This system provides high light transmission
and excellent color reproduction. It also provides
smooth gradients in dark areas, and even helps
prevent color breakup.
✜Dynamic Detail Enhancer (DDE) for
High-quality Video Images
This unique video-enhancing technology from Sony
that is incorporated in the VPL-FH300L and VPL-FW300L
generates high-quality images of outstanding clarity.
For interlaced video sources, I/P (Interlace/Progressive)
conversion is applied to the signals to project clear
and sharp progressive images. When displaying film-
originated sources, signals converted by 2-3/2-2 pull
down are detected, and each frame of the original
film is accurately reproduced.
✜12-bit 3D Gamma Correction and
3D Digital Comb Filter
The VPL-FH300L and VPL-FW300L incorporate 12-bit 3D
Gamma Correction circuitry to perform highly
accurate gamma correction, achieving uniform image
color and brightness that extends light to the corners of
the screen. What's more, the 3D Digital Comb Filter
separates Y signals from C signals with great accuracy,
which emphasizes fine images and shape boundaries.
Odd-Numbered Lines
Even-Numbered Lines
(Simulated image)
I/P Conversion
SONY54052_VPL-FH300L.qxd 2/25/08 3:06 PM Page 3

✜Variety of Optional Bayonet-mount Lenses
The VPL-FH300L and VPL-FW300L adopt a bayonet
mount that allows an optional lens to be easily
attached and detached. This flexibility allows the
VPL-FH300L and VPL-FW300L to be used for a number
of applications – from long-distance projection in large
auditoriums to short-distance rear-projection
applications. The projectors are not supplied with a
lens as standard, but any of the following five optional
lens types can be selected.
✜Power Zoom/Focus/Picture Shift
(Horizontal and Vertical)
The Zoom, Focus, and Horizontal and Vertical Picture
Shift functions available with the projectors' optional
lenses* can be controlled from both the projector
control panel and the supplied Remote Commander™
unit. Images can be easily adjusted to their desired
settings both during installation and when the projector
is in use.
* Not available with the optional VPL-4008 Fixed Short Focus Lens.
✜Flexible Orientation
The VPL-FH300L and VPL-FW300L
can be tilted 90 degrees upwards
or downwards. This flexibility allows
the projectors to be used in several
different ways, including in a rear
projection system.
✜Auto-flip Image
The VPL-FH300L and VPL-FW300L can automatically turn
projected images upside down, thanks to a built-in
angle sensor that can detect the orientation of the
projector. This function is very useful for ceiling mount
installations or rear projection systems.
4
Installation Flexibility
✜Round-body Design
The VPL-FH300L and VPL-FW300L adopt a unique and
stylish round-body design that fits in well to any
installation location. This design also provides the
following benefits for system integrators to simplify
installation of the projector.
Centered Lens Design
The centered lens incorporated in the round chassis of the
VPL-FH300L and VPL-FW300L provides symmetry for a
balanced installation, and makes setup very simple.
Carrying Holes
The VPL-FH300L and VPL-FW300L are equipped with carrying
holes on their underside, situated along the rim of the round
chassis. These carrying holes make it easy for system integrators
to carry the projector.
Simple Cabling
Both the VPL-FH300L and VPL-FW300L
have connector panels situated
within their round body that are
covered by connector-panel lids.
These allow the user to hide any
cables connected to the projector
for a sleeker appearance. This can
also be achieved when mounting
the projector to a ceiling with the
optional PSS-630 Projector Suspension
Support, thanks to its cable covers.
Security Bars
The VPL-FH300L and VPL-FW300L are equipped with four
security bars on their underside. A chain or wire can be
connected to these security bars to help prevent the
projectors from being stolen.
* Distance between the center of the projector lens and the screen, divided by the screen width.
** Viewable area measured diagonally.
Fixed Short Focus Lens Short Focus Zoom Lens Standard Focus Zoom Lens Middle Focus Zoom Lens Long Focus Zoom Lens
VPLL-4008 VPLL-Z4015 VPLL-Z4019 VPLL-Z4025 VPLL-Z4045
Zoom ratio - x1.3 x1.3 x1.9 x1.8
Throw ratio* 0.8:1 1.5:1 to 1.9:1 1.9:1 to 2.5:1 2.5:1 to 4.5:1 4.5:1 to 8.0:1
F-number 2.0 2.2 to 2.6 1.7 to 2.1 2.2 to 3.1 2.2 to 3.6
Screen size** 40-inch to 600-inch 60-inch to 600-inch
Rear Projection System
Optional Lenses
SONY54052_VPL-FH300L.qxd 2/25/08 3:06 PM Page 4

On the left of the lens
On the right of the lens
Option slot
5
✜Picture Muting Function via Built-in
Mechanical Shutter
The VPL-FH300L and VPL-FW300L can interrupt the
projection of images on a screen via a built-in
mechanical shutter. This function can be easily
operated with just the touch of a button on the
supplied Remote Commander unit, and is very
convenient for presentations in large venues such as
board rooms and conference rooms.
Operational Convenience and Versatility
✜Multiple Inputs
The VPL-FH300L and VPL-FW300L accept a wide variety
of input signals – including component, composite
video, S-Video (Y/C), computer analog signals up to
UXGA (fV: 60 Hz), and digital signals up to 2K x 1K
(fV: 24 Hz) – which expands system-connection
possibilities greatly. The VPL-FH300L and VPL-FW300L
are equipped with five BNC connectors, enabling them
to accept signals from sources such as workstations and
professional video equipment. Furthermore, these
interfaces support long-distance signal transmission,
allowing the sources to be located far away from the
projector. The VPL-FH300L and VPL-FW300L are
equipped with an HDMI™ interface that is the latest
standard for digitally connecting to high-definition
systems. In addition, with the optional BKM-FW16
HD-SDI Input Adaptor installed, the projectors can also
accept HD-SDI/SD-SDI signals (from sources such as
Sony's HDCAM™ VTRs and XDCAM™-HD/XDCAM-SD
recorders) to project high-quality digital video.
✜Monitor Output for Presenters
Projected images can be monitored by connecting a
PC monitor to the VPL-FH300L and VPL-FW300L
projectors' monitor output and placing it in the
presenter's field of view. This allows the presenter to
continually face the audience during the presentation
for a fluid and professional delivery.
✜Direct Power On
Activating this function allows the user to skip standby
mode to power on the VPL-FH300L and VPL-FW300L
immediately. Direct Power On is ideal for large-scale
facilities such as museums, auditoriums, and
conference halls, with images ready for projection as
soon as the circuit-breaker on the switchboard is
turned on.
✜ID Function for Multi-projector Installation
The VPL-FH300L and VPL-FW300L have a built-in ID
function, so each projector can be controlled
independently from a single Remote Commander unit.
For multi-projector installations in a single room, this
feature is indispensable both during installation and
operation.
✜Multi-function Remote Commander Unit
The supplied Remote Commander
unit for the VPL-FH300L and
VPL-FW300L is useful for both
setting up the projector during
installation and changing settings
for a presentation. This unit has
buttons for direct input selection,
so users do not have to toggle
through the entire range of inputs
to select the desired one. With
the projector ID function, each
projector in a multiple-projector
installation can be controlled
independently from a single
Remote Commander unit.
Connector Panels (without connector-panel lids)
SONY54052_VPL-FH300L.qxd 2/25/08 3:06 PM Page 5

Hardware CPU: Intel®Pentium®III 600-MHz processor or faster, and
and CPU recommended by OS
Memory: 64 MB or more (128 MB or more is recommended),
and Memory recommended by OS
Hard disk: 10 MB or more of free capacity
Other hardware requirements: CD-ROM drive
Operating System Microsoft®Windows®98 SE, Windows ME, Windows 2000,
Windows XP Home Edition, Windows XP Professional Edition,
Windows Vista Home Basic, Windows Vista Home Premium,
Windows Vista Ultimate, Windows Vista Business
Browser Internet Explorer 5.0 or higher
Display Color resolution: 16-bit, 24-bit, or 32-bit
Network RJ-45: 10BASE-T/100BASE-TX
Sony cannot guarantee that application software will run properly even though
all of the above system requirements are met.
6
✜Network Presentation
When the VPL-FH300L and VPL-FW300L are installed on
a LAN, presentations can be projected from any PC
on that network* – whether connected via a LAN
cable or wirelessly. Switching from presenter to
presenter is as easy as clicking a mouse – there's no
fussing with cables.
* Requires supplied application software to be installed on your PC.
✜High-speed Image Transfer over IP Networks
Because the VPL-FH300L and VPL-FW300L employ
efficient compression and transmission techniques,
they can receive and project images via IP networks
for effective presentations from any networked PC.
In fact, they can even handle animated Microsoft®
PowerPoint®presentations.
✜Network Presentations Using up to
Five Projectors
Up to five VPL-FH300L and VPL-FW300L projectors can
be connected to a network, with the image from a
single PC projected by each of them. This feature is
ideal for both large venues and multiple rooms in
which images have to be projected from various
locations.
✜Network Presentations Almost Anyware
By manually registering a PC's IP address to the
VPL-FH300L and VPL-FW300L, images can be
projected not only across the country, but across the
globe. This is ideal for applications such as distance
learning and long-distance corporate
communication.
LAN
Wireless
Access
Point
Room A Room B
VPL-FH300L
VPL-FW300L
VPL-FH300L
VPL-FW300L
PC
PC
PC
PC
Notice Regarding Network Presentations:
• Animation effects and the slide show function in Microsoft PowerPoint
presentations can be used; however, transmission delays may occur if a
large number of effects are performed at once or if several slides are
turned at once.
• Network transmission is not suitable for video.
• Network transmission should not be used with sound.
• Applications that use DirectX®application programming interface may
not be displayed properly.
• When using Windows Vista, Windows XP, or Windows 2000 Operating
Systems, the user must be logged into an account with computer
administrator access.
• Application software is provided in English and Japanese.
• Network presentations may not be possible depending on the network
environment and available bandwidth.
Network Presentation System Diagram
System Requirements to Run Supplied Software
SONY54052_VPL-FH300L.qxd 2/25/08 3:06 PM Page 6

7
■Optional Accessories ■
Easy Maintenance
✜Low Power Consumption
(Enviromentally-friendly Design)
The VPL-FH300L and VPL-FW300L consume less than
820 W of power, which is the lowest level for projectors
that provide the same level of brightness with a
dual-lamp system. In addition, these projectors offer
a choice of two standby modes – standard and
low – that minimize power consumption further. The
standard mode and low mode of 30 W and 0.5 W of
power, respectively.
This low-power-consumption allows operators to save
significant electricity expenses in their operations.
✜Easy Lamp and Filter Replacement
When it's time to replace the lamp and filters in the
VPL-FH300L and VPL-FW300L, a timely message
appears clearly on the screen. The lamp is accessible
from the back of the projector and the filter is
accessible from the side, so lamp and filter
replacement can be performed without having to
uninstall the projector.
Replacement filters are included in the optional
LMP-F271 Projector Lamp, so both the lamp and filters
can be replaced at the same time, saving
maintenance time and cost.
✜Lamp Memory Function
When exchanging the lamp of a conventional
projector, operators typically have to reset the built-in
timer that records the lamp usage hours. However,
this is unnecessary with the VPL-FH300L and
VPL-FW300L, because their lamps incorporate a
memory that can record the lamp usage hours.
✜Remote Operation and Maintenance
Notifications via Network
Because the VPL-FH300L and VPL-FW300L can be
connected to a LAN, a number of functions can be
performed remotely using a web browser*.
For example, the projector's current status can be
verified and simple controls, such as powering the unit
on or off, can be performed. Also, the system can be
set up to send automatic e-mail reports to designated
recipients for scheduled maintenance, including
projected lamp life and error reports.
*Internet Explorer 5.0 or higher is required.
✜Other Features
• Digital Keystone Adjustment
• Multi-language OSD (On-Screen Display)
• Smart APA (Auto Pixel Alignment)
• Password-authentication System
VPLL-4008
Fixed Short Focus Lens
VPLL-Z4015
Short Focus Zoom Lens
VPLL-Z4019
Standard Focus Zoom
Lens
VPLL-Z4025
Middle Focus Zoom Lens
VPLL-Z4045
Long Focus Zoom Lens
LMP-F271
Projector Lamp
(with filters included)
PAM-400
Projector Suspension
Support
PAM-400EXP
Projector Suspension
Support Joint Pole
BKM-FW16
HD-SDI Input Adaptor
SONY54052_VPL-FH300L.qxd 2/25/08 3:07 PM Page 7

8
■Dimensions ■
■Preset Signal Chart ■
27 5/8(Ø699)
27 5/8(Ø699)
11 3/4 (298)
7 (176) 13 5/8(347) 6 1/4 (157.3)
7 5/8
(193.4) 81/2 (214) 7 5/8 (193.4)
7 3/32
(179.5)
3 1/2
(90)
7 13/16
(198)
21 1/2 (545)
31 (785)
Unit: inches (mm)
- Preset signal Nos. 1,2, 21-25, 27-31, 33-35, 38-43, 46, 48, 49, 51, and 56 are analog only.
- Preset signal Nos. 12-15 are digital only.
- Images may not be reproduced correctly when signals other than those listed above are input.
Contact your local Sony sales office for more information regarding signals not listed.
No. Preset signal fH (kHz) fV (Hz) Sync
31 800 X 600 VESA 56 35.156 56.250 H-pos, V-pos
32 VESA 60 37.879 60.317 H-pos, V-pos
33 VESA 72 48.077 72.188 H-pos, V-pos
34 VESA 75 (IBM M5) 46.875 75.000 H-pos, V-pos
35 VESA 85 53.674 85.061 H-pos, V-pos
36 832 X 624 Mac 16 49.724 74.550 H-neg, V-neg
37 1024 X 768 VESA 60 48.363 60.004 H-neg, V-neg
38 VESA 70 56.476 70.069 H-neg, V-neg
39 VESA 75 60.023 75.029 H-neg, V-pos
40 VESA 85 68.677 84.997 H-neg, V-pos
41 1152 X 864 VESA 70 63.995 70.019 H-pos, V-pos
42 VESA 75 67.500 75.000 H-pos, V-pos
43 VESA 85 77.487 85.057 H-pos, V-pos
45 1280 X 960 VESA 60 60.000 60.000 H-pos, V-pos
46 VESA 75 75.000 75.000 H-pos, V-pos
47 1280 X 1024 VESA 60 63.974 60.013 H-pos, V-pos
48 VESA 75 79.976 75.025 H-pos, V-pos
49 VESA 85 91.146 85.024 H-pos, V-pos
50 1400 X 1050 VESA 60 65.317 59.978 H-neg, V-pos
51 1600 X 1200 VESA 60 75.000 60.000 H-pos, V-pos
55 1280 X 768 1280 X 768/60 47.776 59.870 H-neg, V-pos
56 1280 X 720 1280 X 720/60 44.772 59.855 H-neg, V-pos
60 1360 X 768 1360 X 768/60 47.720 59.799 H-neg, V-pos
61 1440 X 900 1440 X 900/60 55.935 59.887 H-neg, V-pos
62 1680 X 1050 1680 X 1050/60 65.290 59.954 H-neg, V-pos
63 1280 X 800 1280 X 800/60 49.702 59.810 H-neg, V-pos
No. Preset signal fH (kHz) fV (Hz) Sync
1 Video 60 Hz Video 60 Hz 15.734 59.940 –
2 Video 50 Hz Video 50 Hz 15.625 50.000 –
3 480/60i DTV 480/60i 15.734 59.940 S on G/Y
4 575/50i DTV 575/50i 15.625 50.000 S on G/Y
5 480/60p 480/60p 31.470 60.000 S on G/Y
(NTSC Progressive component)
6 575/50p 575/50p 31.250 50.000 S on G/Y
(PAL Progressive component)
7 1080/60i 1035/60i, 1080/60i 33.750 60.000 S on G/Y
8 1080/50i 1080/50i 28.130 50.000 S on G/Y
10 720/60p 720/60p 45.000 60.000 S on G/Y
11 720/50p 720/50p 37.500 50.000 S on G/Y
12 1080/60p 1080/60p 67.500 60.000 S on G/Y
13 1080/50p 1080/50p 56.260 50.000 S on G/Y
14 1080/24p 1080/24p 26.973 23.976 S on G/Y
15 1080/30p 1080/30p 33.750 29.970 S on G/Y
21 640 X 350 VGA mode 1 (VGA 350) 31.469 70.086 H-pos, V-neg
22 VESA 85 (VGA 350) 37.861 85.080 H-pos, V-neg
23 640 X 400 NEC PC 98 24.823 56.416 H-neg, V-neg
24 VGA mode 2 (TEXT) / VESA 70 31.469 70.086 H-neg, V-pos
25 VESA 85 (VGA 400) 37.861 85.080 H-neg, V-pos
26 640 X 480 VESA 60 31.469 59.940 H-neg, V-neg
27 Mac 13 35.000 66.667 H-neg, V-neg
28 VESA 72 37.861 72.809 H-neg, V-neg
29 VESA 75 (IBM M3) 37.500 75.000 H-neg, V-neg
30 VESA 85 (IBM M4) 43.269 85.008 H-neg, V-neg
SONY54052_VPL-FH300L.qxd 2/25/08 3:07 PM Page 8

Screen size*40 60 80 100 120 150 180 200 250 300 400 500 600
a’ min (inches) (77 3/8) (106 3/4) (141 3/4) (176 7/8) (212 1/4) (265) (317 7/8) (352 7/8) (441) (528 7/8) (704 7/8) (880 7/8) (1056 7/8)
mm 1810 2710 3600 4490 5390 6730 8070 8690 11200 13430 17900 22370 26840
max (inches) (90 1/4) (135 1/8) (179 5/8) (224 1/2) (269) (335 7/8) (403 1/4) (447 3/4) (559 5/8) (671) (894 1/4) (1117 7/8) (1341 1/8)
mm 2290 3430 4560 5700 6830 8530 10240 11370 14210 17040 22710 28390 34060
bmin (inches) c+7 1/8
mm c+180
max (inches) c+7 1/2
mm c+188
c13 7/8, 15, 16 1/4, 17 3/8, 18 5/8, 19 3/4 inches
(350, 380, 410, 440, 470, 500 mm)
24 7/8, 26, 27 1/4, 28 3/8, 29 5/8, 30 3/4 inches
(630, 660, 690, 720, 750, 780 mm)
35 7/8, 37 1/8, 38 1/4, 39 3/8, 40 5/8, 41 3/4 inches
(910, 940, 970, 1,000, 1,030, 1,060 mm)
47, 48 1/8, 49 1/4, 50 1/2, 51 5/8, 52 7/8 inches
(1,190, 1,220, 1,250, 1,280, 1,310, 1,340 mm)
xmin (inches) c+7 1/8
mm c+180
max (inches) (c+18 1/8) (c+23 1/4) (c+28 3/8) (c+33 1/2) (c+38 5/8) (c+46 3/8) (c+54) (c+59 1/8) (c+72) (c+84 7/8) (c+110 1/2) (c+136 1/8) (c+161 3/4)
mm c+459 c+589 c+719 c+850 c+980 c+1175 c+1371 c+1501 c+1827 c+2153 c+2805 c+3456 c+4108
Using PSS-630
Using PSS-630 and
PSS-630P (x1)
Using PSS-630 and
PSS-630P (x2)
Using PSS-630 and
PSS-630P (x3)
Screen size*40 60 80 100 120 150 180 200 250 300 400 500 600
a’ min (inches) (69 3/4) (104) (138 1/4) (172 1/2) (206 3/4) (258 3/8) (310) (344 1/4) (430) (515 7/8) (687 1/8) (858 7/8) (1030 1/2)
mm 1770 2640 3510 4380 5250 6560 7870 8740 10920 13100 17450 21810 26170
max (inches) (88 1/4) (131 5/8) (175 1/4) (219) (262 1/4) (327 5/8) (393) (436 3/4) (545 3/8) (654 1/2) (872 1/4) (1090) (1307 3/4)
mm 2240 3340 4450 5560 6660 8320 9980 11090 13850 16620 22150 27680 33210
bmin (inches) c+7 1/8
mm c+180
max (inches) c+7 1/2
mm c+188
c13 7/8, 15, 16 1/4, 17 3/8, 18 5/8, 19 3/4 inches
(350, 380, 410, 440, 470, 500 mm)
24 7/8, 26, 27 1/4, 28 3/8, 29 5/8, 30 3/4 inches
(630, 660, 690, 720, 750, 780 mm)
35 7/8, 37 1/8, 38 1/4, 39 3/8, 40 5/8, 41 3/4 inches
(910, 940, 970, 1,000, 1,030, 1,060 mm)
47, 48 1/8, 49 1/4, 50 1/2, 51 5/8, 52 7/8 inches
(1,190, 1,220, 1,250, 1,280, 1,310, 1,340 mm)
xmin (inches) c+7 1/8
mm c+180
max (inches) (c+19) (c+24 1/2) (c+30 1/8) (c+35 5/8) (c+41 1/4) (c+49 1/2) (c+57 7/8) (c+63 1/2) (c+77 3/8) (c+91 1/4) (c+119) (c+146 7/8) (c+174 5/8)
mm c+480 c+622 c+763 c+904 c+1045 c+1257 c+1469 c+1610 c+1963 c+2316 c+3022 c+3728 c+4434
Using PSS-630
Using PSS-630 and
PSS-630P (x1)
Using PSS-630 and
PSS-630P (x2)
Using PSS-630 and
PSS-630P (x3)
Screen size*40 60 80 100 120 150 180 200 250 300 400 500 600
amin (inches) (65 3/8) (100 7/8) (135 7/8) (171) (206 3/8) (259 1/8) (311 7/8) (347) (435 1/8) (523) (699) (875) (1051)
mm 1660 2560 3450 4340 5240 6580 7920 8810 11050 13280 17750 22220 26690
max (inches) (84 3/4) (129 1/4) (174 1/8) (218 5/8) (263 1/2) (330 3/8) (397 3/8) (441 7/8) (553 3/8) (665 1/2) (888 3/4) (1112) (1335 1/4)
mm 2150 3280 4420 5550 6690 8390 10090 11220 14060 16900 22570 28240 33910
bmin (inches) (x-10 3/8) (x-15 1/2) (x-20 5/8) (x-25 3/4) (x-30 7/8) (x-38 1/2) (x-46 1/4) (x-51 3/8) (x-64 1/4) (x-77) (x-102 3/4) (x-128 3/8) (x-154)
mm x-261 x-391 x-521 x-652 x-782 x-977 x-1173 x-1303 x-1629 x-1955 x-2607 x-3258 x-3910
max x-0
cminmm x-459 x-589 x-719 x-850 x-980 x-1175 x-1371 x-1501 x-1827 x-2153 x-2805 x-3456 x-4108
(inches) (x-18 1/8) (x-23 1/4) (x-28 3/8) (x-33 1/2) (x-38 5/8) (x-46 3/8) (x-54) (x-59 1/8) (x-72) (x-84 7/8) (x-110 1/2) (x-136 1/8) (x-161 3/4)
max (inches) (x-7 7/8)
mm x-198
Screen size*40 60 80 100 120 150 180 200 250 300 400 500 600
amin (inches) (63 7/8) (98 1/8) (132 3/8) (166 5/8) (200 7/8) (252 1/2) (304) (338 1/4) (424 1/8) (509 5/8) (681 1/4) (852 7/8) (1024 1/8)
mm 1620 2490 3360 4230 5100 6410 7720 8590 10770 12940 17300 21660 260160
max (inches) (82 3/8) (126) (169 3/8) (213 1/8) (256 3/4) (322 1/8) (387 1/2) (430 7/8) (539 7/8) (648 5/8) (866 1/4) (1084) (1302 1/4)
mm 2090 3200 4300 5410 6520 8180 9840 10940 13710 16470 22000 27530 33070
bmin (inches) (x-11 1/8) (x-16 3/4) (x-22 1/4) (x-27 7/8) (x-33 3/8) (x-41 3/4) (x-50 1/8) (x-55 5/8) (x-69 1/2) (x-83 1/2) (x-111 1/4) (x-139) (x-166 7/8
mm x-282 x-424 x-565 x-706 x-847 x-1059 x-1271 x-1412 x-1765 x-2118 x-2824 x-3530 x-4236
max x-0
cmin (inches) (x-19) (x-24 1/2) (x-30 1/8) (x-35 5/8) (x-41 1/4) (x-49 1/2) (x-57 7/8) (x-63 1/2) (x-77 3/8) (x-91 1/4) (x-119) (x-146 7/8) (x-174 5/8)
mm x-480 x-622 x-763 x-904 x-1045 x-1257 x-1469 x-1610 x-1963 x-2316 x-3022 x-3728 x-4434
max (inches) (x-7 7/8)
mm x-198
VPL-FH300L
9
■Installation Diagrams ■
a
x
Wall
Floor
Center of the screen
Center of the lens b
c
a: Distance between the screen and the center of the lens
b: Distance between the floor and the center of the lens
c: Distance between the floor and the center of the lens
x: Distance between the floor and the center of the screen
(free)
(When using the VPL-FH300L or VPL-FW300L with the optional VPLL-Z4019 lens)
Floor Installation
VPL-FH300L
VPL-FW300L
VPL-FW300L
* Viewable area measured diagonally.
For both floor and ceiling mount installations, images can be shifted horizontally by +/-10% of the screen width.
* Viewable area measured diagonally.
a: Distance between the screen and the center of the lens
b: Distance between the ceiling and the center of the lens
c: Distance between the ceiling and the surface of
suspension support (PSS-630 recommended)
x: Distance between the floor and the center of the screen
Wall
Ceiling
Center of the screen
Center of the lens
a'
x
bc
Ceiling Mount Installation
SONY54052_VPL-FH300L.qxd 2/25/08 3:07 PM Page 9

Printed in USA (2/08)
©2008 Sony Electronics Inc. All rights reserved.
Reproduction in whole or in part without written permission is prohibited.
Features and specifications are subject to change without notice.
All non-metric weights and measurements are approximate. Projected images in this
brochure are simulated. Sony, BrightEra, Remote Commander, HDCAM, and XDCAM
are trademarks of Sony. HDMI, the HDMI logo, and High-Definition Multimedia
Interface are trademarks or registered trademarks of HDMI Licensing LLC. Microsoft,
PowerPoint, Windows,and DirectX are trademarks of Microsoft Corporation.Intel and
Pentium are trademarks of Intel Corporation.
DI-0148 (MK10465V1)
Sony Electronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
www.sony.com/professional
VPL-FH300L VPL-FW300L
Optical
Projection system 3 LCD panels, 1 lens projection system
LCD panel 1.2-inch TFT LCD panel, 1.2-inch TFT LCD panel,
6,635,520 (2048 x 1080 x 3) pixels 3,278,400 (1366 x 800 x3) pixels
Projection lens Not supplied, refer to "Optional Lens"
Lamp 275 W ultra high pressure lamp x 2
Screen coverage 40 to 600 inches* (with lenses except VPLL-Z4045), 60 to 600 inches* (with VPLL-Z4045)
Light output 6000 lumens (lamp mode high), 7000 lumens (lamp mode high),
(with VPLL-Z4019) 4800 lumens (lamp mode standard) 5600 lumens (lamp mode standard)
Signals
Color system NTSC3.58, PAL, SECAM, NTSC4.43, PAL-M, PAL-N, PAL60 (automatically/manually selected)
Resolution Video: 750 TV lines, RGB: 2048 x 1080 pixels Video: 750 TV lines, RGB: 1366 x 800 pixels
Acceptable computer signals fH: 19 to 92 kHz, fV: 24 to 92 Hz
Maximum input signal resolution (analog): up to UXGA (fV: 60 Hz)
Maximum input signal resolution (digital): up to 2K x 1K (fV: 24 Hz)**
Acceptable video signals Composite Video, Y/C Video, 15 kHz RGB, Component 50/60 Hz, Progressive Component 50/60Hz,
DTV (480/60i, 575/50i, 480/60p, 575/50p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/60p, 1080/50p, 1080/24p, 1080/30p)
General
Dimensions (W x H x D) 27 5/8 x 11 3/4 x 31 inches (699 x 298 x 785 mm) (including projection parts)
Weight Approx. 67 lb 4 oz (30.5 kg)
Power requirements AC 100 to 240 V, 8.2 to 3.4 A, 50/60 Hz
Power consumption Max.:820 W, standby mode: 30 W (standard mode)/0.5 W (low mode)
Operating temperature 32 to 95 °F (0 to 35 °C)
Operating humidity 35 to 85% (no condensation)
Storage temperature -4 to 140 °F (-20 to 60 °C)
Storage humidity 10 to 90%
Inputs/Outputs
Video In Composite Video BNC
S Video Y/C, mini DIN 4-pin
Video Out Composite Video BNC (Loop-through output)
S Video Y/C, mini DIN 4-pin (Loop-through output)
Input A RGB Analog RGB: HD D-sub 15-pin (female)
Input B RGB Analog RGB: HD D-sub 15-pin (female)
Input C RGB/Component Analog RGB/Component: 5 BNC
Input D RGB/Component Digital RGB/Y CB (PB) CR (PR): HDMI (HDCP)
Input E Open for optional board
Input F Input F RJ-45: 10BASE-T/100BASE-TX
Output *** RGB Analog RGB: HD D-sub 15-pin (female)
Remote RS-232C D-sub 9 pin (female)
Control S IN Control S in/plug in power: stereo mini jack
Supplied accessories
Remote Commander (1), Size AA (R6) batteries (2) for Remote Commander, Lens hole cover (1),
Security label (1), CD-ROM (Operating instructions, Application software) (1), Quick reference manual (1), Safety regulations (1) ,
Dust cover (1), AC connector cover (1), HDMI connector cover (1), AC power cord (1), Warranty card (1)
• Halogenated flame retardants are not used in cabinets or printed wiring boards.
• Standby power consumption: 0.5 W (in low mode).
* Viewable area measured diagonally.
** When a 2K x 1K (2048 x 1080) signal is input, information of a vertical one line at both ends is not displayed. The signal being displayed is not native. 2K x 1K equivalent.
*** RGB signals can be output from input A, input B, and input C connectors.
■Specifications ■
SONY54052_VPL-FH300L.qxd 2/25/08 3:06 PM Page 2
