Sony VPL-CWZ10 Reference guide

Help Guide
Data Projector
VPL-CWZ10/CXZ10
This manual is for those who encounter issues or have questions when using the Data Projector.
Not all models are available in all countries and areas. Please check with your local Sony Authorized Dealer.
Before Use
Checking the Supplied Accessories
Inserting the Battery into the Remote Commander
Attaching the Air Filter (For the Customers in India only)
Parts and Controls
Parts and Controls (Main Unit)
Parts and Controls (Connection Terminals)
Parts and Controls (Remote Commander and Control Panel)
Connecting
Precautions When Connecting
Connecting to a Computer
Connecting to a Computer with an RGB Output Terminal
1

Connecting to a Computer with an HDMI Output Terminal
Connecting to a Computer via a Hub or Router
Connecting to Video Equipment
Connecting to a Video Device with a Video Output Terminal
Connecting to a Video Device with a Y PB PR Output Terminal
Connecting to a Video Device with an HDMI Output Terminal
Connecting to Audio Equipment
Fixing the HDMI Cable to the Projector
Projecting
Turning Power On/Off
Selecting the Menu Language
Projecting Images
Adjusting
Adjusting the Screen Focus
Adjusting the Screen Size
Adjusting the Screen Position
Changing the Screen Aspect Ratio
Correcting a Trapezoidal Screen
Correcting a Vertical Trapezoid
Correcting a Horizontal Trapezoid
Correcting Screen Distortion
Displaying Patterns
Using the Auto Adjustment Function
Useful Functions
Use the Intelligent Setting Function
Using the Digital Zoom Function
Using Eco Mode
Adjustment and Setting Menus
Navigating Menus
2

Projection Setting Menu
Menu Operation: Intelligent Setting
Menu Operation: Picture Mode
Menu Operation: Reset
Menu Operation: Contrast
Menu Operation: Brightness
Menu Operation: Color
Menu Operation: Hue
Menu Operation: Color Temp.
Menu Operation: Sharpness
Menu Operation: Light Settings
Menu Operation: Expert Setting
Screen Menu
Menu Operation: Aspect
Aspect Ratio
Menu Operation: Adjust Signal
Function Menu
Menu Operation: Presentation timer
Menu Operation: Volume
Menu Operation: Speaker
Menu Operation: Speaker Setting
Menu Operation: Smart APA
Menu Operation: CC Display
Menu Operation: Start Up Image
Operation Menu
Menu Operation: Language
Menu Operation: Status
Menu Operation: Security Lock
Menu Operation: Control Key Lock
Menu Operation: Menu Settings Lock
3

Menu Operation: Set Password
Connection/Power Menu
Menu Operation: Network Setting
Menu Operation: Communication Mode
Menu Operation: Dynamic Range
Menu Operation: Input-A Signal Sel.
Menu Operation: ECO
Menu Operation: Remote Start
Menu Operation: Standby Mode
Menu Operation: Direct Power On
Installation Menu
Menu Operation: Screen Fitting
Menu Operation: V Keystone
Menu Operation: H Keystone
Menu Operation: Corner Keystone
Menu Operation: Digital Shrink
Menu Operation: Image Flip
Menu Operation: High Altitude Mode
Information Menu
Viewing the Projector Information
Using Network Features
Uses for Network Features
Displaying the Control Window of the Projector with a Web Browser
Operating the Control Panel
Using the E-mail Report Function
Configuring the Network Settings of the Projector
Setting Projector Control Protocol
Setting Advertisement
Setting PJ Link
Setting PJ Talk
4

Setting ADCP
Setting AMX DDDP/Crestron Room View
Resetting the Network Settings
Setting the Date and Time
Using the Software Update Function
Using https Communication
Configuring https Communication
Connecting with https for the First Time
Installing a CA Certificate to Your Computer
Deleting a CA Certificate Installed to Your Computer
Precautions
Precautions
On Installation
On Cleaning the Lens and the Cabinet
On Illumination
On Heat Dissipation
On Screen
On Fan
On Inspection of Light Source Related Parts
On Disposing Used Products
On LCD Projector
On condensation
Notes on Security
Do not place this product close to medical devices
Disclaimer
Cleaning the Air Filter
Cleaning the Air Filter (For Installing to the Ceiling) (For the Customers in India only)
Updating Software
Specifications
5

Specifications
Pin Assignment
Pin Assignment (HDMI Terminal)
Pin Assignment (RGB Input Terminal)
Pin Assignment (RS-232C Terminal)
Pin Assignment (USB Terminal)
List of Compatible Signals
Compatible Signal List (Computer Signal)
Compatible Signal List (Video Signal)
Projection Distance
Projection Distance
Projection Distance/Projection Distance Formula (VPL-CWZ10)
Projection Distance/Projection Distance Formula (VPL-CXZ10)
Error Handling
Reading the Indicator
Message List
Troubleshooting
No Power
No Image is Displayed
Cannot Connect to Computer
No On-screen Display
Screen Aspect Ratio is Strange/Screen Display is Small/Part of Image Not Displayed
Trapezoidal Screen
Screen Distortion
Screen is Too Dark/Bright
Blurry Screen
Screen Noise
No Sound
Remote Commander Does Not Function
Loud Fan
6

5-014-280-13(1) Copyright 2020 Sony Corporation
Others
Notice on the Software
Notifications Related to GNU GPL/LGPL-applicable Software
Other Software
Trademarks
7

Help Guide
Data Projector
VPL-CWZ10/CXZ10
Checking the Supplied Accessories
Confirm that the following components are included. The () indicates the quantity of the component.
Remote Commander (RM-PJ8) (1)
Lithium battery (CR2025) (1)
The battery is already installed. Before using the Remote Commander, remove the insulation film.
AC power cord (1)
Mini D-sub 15-pin cable (1.8 m) (1)
(1-970-584-11/Sony)
Extension studs (4)
Air filter cover (1)*1
Dust cover assembly (1)*1
Setup Guide (1)
5-014-280-13(1) Copyright 2020 Sony Corporation
For the customers in India only
*1
8

Help Guide
Data Projector
VPL-CWZ10/CXZ10
Inserting the Battery into the Remote Commander
The lithium battery is attached to the Remote Commander at the time of purchase. Before using the Remote
Commander, remove the insulation film.
If the Remote Commander can no longer be operated, exchange the lithium battery for a new one by the following
procedure.
5-014-280-13(1) Copyright 2020 Sony Corporation
Pull out the lithium battery compartment.
Pull the battery compartment toward you while releasing the lock.
1
Insert a lithium battery.
The lithium battery should be placed in the compartment with the plus side facing up.
2
Close the lithium battery compartment.
3
9

Help Guide
Data Projector
VPL-CWZ10/CXZ10
Attaching the Air Filter (For the Customers in India only)
The supplied accessories required vary depending on the installation method.
For installing to the floor
For installing to the ceiling
Attach the dust cover assembly to the unit by pushing the two levers on it. (The product is pre-fitted with a dust cover
assembly when shipped.)
Remove the air filter (B) from the dust cover assembly (A), and then attach the air filter to the air filter cover
(C).
Pull the pull stick (D) upwards when removing the air filter from the dust cover assembly.
When attaching the air filter to the air filter cover, make sure the correct side is being attached so that the pull stick
is protruding from the air filter.
1
Attach the air filter cover to the unit by pushing the two levers on it.
2
10

Note
When installing to the floor, securely attach the air filter to the air filter cover, taking care not to hit the hook of the air filter cover. If
the air filter is attached to the air filter cover incorrectly, malfunction may occur.
When installing to the ceiling, securely attach the dust cover assembly to the unit. Incorrect attachment of the dust cover
assembly may cause a malfunction.
5-014-280-13(1) Copyright 2020 Sony Corporation
11

Help Guide
Data Projector
VPL-CWZ10/CXZ10
Parts and Controls (Main Unit)
Top/Front /Right
Rear/Bottom
ON/STANDBY indicator1.
WARNING indicator2.
Control panel3.
Zoom lever4.
Focus lever5.
Projection lens6.
Ventilation holes (intake)7.
Remote control receiver8.
Ventilation holes (exhaust)9.
Speaker10.
Top cover11.
12

Caution
Do not place anything near the ventilation holes. The temperature may rise inside the unit, leading to a possible
malfunction or fire. Do not place your hand or easily deformable objects near the ventilation holes (exhaust) and its
vicinity. Doing so may result in the burning or deformation of these objects.
Related Topic
Parts and Controls (Connection Terminals)
Parts and Controls (Remote Commander and Control Panel)
Cleaning the Air Filter
Reading the Indicator
5-014-280-13(1) Copyright 2020 Sony Corporation
Antitheft bar
For attaching theft prevention chains (wires) and such sold commercially.
1.
Front feet (adjustable)2.
Air filter cover3.
Ventilation holes (intake)4.
Antitheft lock
For attaching theft prevention cables manufactured by Kensington.
For details, visit the Kensington website.
http://www.kensington.com/
5.
Terminals6.
13

Help Guide
Data Projector
VPL-CWZ10/CXZ10
Parts and Controls (Connection Terminals)
Related Topic
Connecting to a Computer with an RGB Output Terminal
Connecting to a Computer with an HDMI Output Terminal
Connecting to a Computer via a Hub or Router
Connecting to a Video Device with a Video Output Terminal
Connecting to a Video Device with a Y PB PR Output Terminal
Connecting to a Video Device with an HDMI Output Terminal
Connecting to Audio Equipment
5-014-280-13(1) Copyright 2020 Sony Corporation
Input A (INPUT A)
Video: RGB/Y PB PR input terminal (RGB/Y PB PR)
1.
Input B (INPUT B)
Video: HDMI input terminal (HDMI)
Audio: HDMI input terminal (HDMI)
2.
Input B (INPUT C)
Video: HDMI input terminal (HDMI)
Audio: HDMI input terminal (HDMI)
3.
Video (VIDEO IN)
Video: Video input terminal
4.
Audio (AUDIO IN)
Audio: Audio input terminal
5.
Audio (AUDIO OUT)
Audio: Audio output terminal
6.
RS-232C terminal (RS-232C)
A control terminal compliant to RS-232C. Connect to the RS-232C computer terminal with an RS-232C cable (cross).
7.
LAN terminal8.
USB terminal (Type A) ( )
Terminal for software update.
9.
AC IN socket ( )
Connect the supplied AC power cord.
10.
14

Help Guide
Data Projector
VPL-CWZ10/CXZ10
Parts and Controls (Remote Commander and Control Panel)
Remote Commander
Control panel
/ (On/Standby) key
Turn on/Standby.
1.
INPUT (Input selection) key
Select the input.
2.
MENU (Menu) key
RESET (Reset) key
ENTER (Enter)/ / / / (Arrow) keys
RETURN (Return) key
Perform menu operations, etc.
3.
ASPECT (Aspect) key
Switch the aspect ratio of the projected image.
KEYSTONE (Trapezoidal correction) key/PATTERN (Pattern) key
Adjust the projected image.
APA (Auto Pixel Alignment) key
Adjust the input signal to fit to the screen automatically when there is a computer signal being input from the RGB
input terminal (Input A).
4.
D ZOOM (Digital zoom) +/- key
Zoom in or out on a part of the projected image. This can be used when there is a computer signal being input.
However, depending on the input signal resolution, it may not be usable.
BLANK (Eliminate image) key
Temporarily turn off the projected image. Press again to release.
MUTING (Mute) key
When sound is output, temporarily mute the audio. Press again to release.
VOLUME (Sound volume) +/- key
5.
15

Remote Commander Operation
Direct the Remote Commander toward the remote control receiver.
The shorter the distance between the Remote Commander and the projector, the wider the angle within which the
Remote Commander can control the projector.
If there is any obstruction between the Remote Commander and the remote control receiver on the projector, the
projector may not be able to receive signals from the Remote Commander.
Related Topic
Turning Power On/Off
Projecting Images
Using the Digital Zoom Function
Using Eco Mode
Navigating Menus
5-014-280-13(1) Copyright 2020 Sony Corporation
Adjust the sound volume.
FREEZE (Freeze) key
Temporarily freeze the image. Press again to release. This can be used when there is a computer signal being input.
ECO MODE (Eco Mode) key
Allows you to set to Eco Mode.
6.
Infrared transmitter7.
16

Help Guide
Data Projector
VPL-CWZ10/CXZ10
Precautions When Connecting
Turn off all devices before making any connections.
Use the proper cables for each connection.
Firmly insert the cable plugs. Loose connections may reduce the performance of picture signals or cause a
malfunction. When unplugging a cable, be sure to grip the plug, not the cable itself.
For more information, refer also to the instruction manual of the device to be connected.
Use a no-resistance audio cable.
5-014-280-13(1) Copyright 2020 Sony Corporation
17

Help Guide
Data Projector
VPL-CWZ10/CXZ10
Connecting to a Computer with an RGB Output Terminal
Connect the INPUT A terminal to a computer’s RGB output terminal and the AUDIO IN terminal to a computer’s audio
output terminal.
A: Audio cable (stereo mini plug) (not supplied)
B: Mini D-sub 15-pin cable (supplied)
Hint
For the screen settings of your computer, it is recommended that you set the resolution of an external monitor as below;
VPL-CWZ10: 1,280 × 800 pixels
VPL-CXZ10: 1,024 × 768 pixels
Related Topic
Parts and Controls (Connection Terminals)
Precautions When Connecting
5-014-280-13(1) Copyright 2020 Sony Corporation
18

Help Guide
Data Projector
VPL-CWZ10/CXZ10
Connecting to a Computer with an HDMI Output Terminal
Connect the INPUT B terminal or INPUT C terminal to a computer’s HDMI output terminal.
A: HDMI cable (not supplied)
Note
Use an HDMI-compatible device with the HDMI Logo.
Use a high speed HDMI cable(s) on which the cable type logo is specified. (Sony products are recommended.)
The HDMI terminal of this projector is not compatible with DSD (Direct Stream Digital) signals and CEC (Consumer Electronics
Control) signals.
Related Topic
Parts and Controls (Connection Terminals)
Precautions When Connecting
5-014-280-13(1) Copyright 2020 Sony Corporation
19

Help Guide
Data Projector
VPL-CWZ10/CXZ10
Connecting to a Computer via a Hub or Router
Connect the LAN terminal and the computer LAN terminal via a hub or router.
A : LAN cable (straight) (not supplied)
B: Hub or router, etc.
Note
Connect the projector to the network that is constructed to control the access from the internet, such as LAN. If the projector is
connected directly to the internet, the security risk is increased.
When you monitor and control the projector via the network, display the control window of the projector with a web
browser and enable the desired control protocol.
Related Topic
Parts and Controls (Connection Terminals)
Precautions When Connecting
Setting Advertisement
Setting PJ Link
Setting PJ Talk
Setting ADCP
5-014-280-13(1) Copyright 2020 Sony Corporation
20
