Sony VPL-EW246 User manual

4-464-386-11 (1)
© 2013 Sony Corporation
Data
Projector
Operating Instructions
Before operating the unit, please read this manual and supplied Quick Reference Manual
thoroughly and retain it for future reference.
VPL-EW276/EW246/EW226
VPL-EX276/EX272/EX246/EX242/EX226/EX222
Not all models are available in all countries and area. Please check
with your local Sony Authorized Dealer.

2Table of Contents
Table of Contents
Overview
Location and Function of Controls .... 4
Main Unit ..................................... 4
Connector Panel ........................... 5
Remote Commander and Control
Panel Keys ................................. 6
Preparation
Connecting the Projector ................... 9
Connecting a Computer ................ 9
Connecting a Video equipment ... 10
Connecting a microphone .......... 12
Connecting a USB memory
device ...................................... 12
Connecting a USB wireless LAN
module .................................... 13
Connecting an External Monitor and
Audio Equipment .................... 13
Projecting/Adjusting an
Projecting an Image ......................... 14
Adjusting the Projected image ... 15
Turning Off the Power ................ 18
Adjustments and Settings
Using a Menu
Using a MENU ................................ 19
The Picture Menu ............................. 20
The Screen Menu ............................. 21
The Function Menu .......................... 25
The Operation Menu ........................ 26
The Connection/Power Menu .......... 27
The Installation Menu ......................29
The Information Menu .....................30
Network
Using Network Features ...................31
Displaying the Control Window of
the Projector with a Web
Browser ...................................31
Confirming the Information
regarding the Projector ............32
Operating the Projector from a
Computer .................................32
Using the e-mail report
Function ...................................33
Presentation Function via
Network
Using Presentation Function via
Network .........................................35
Installing Projector Station for
Network Presentation ..............35
Starting Projector Station for
Network Presentation ..............35
Projecting an Image ....................36
Connection Settings ....................36
Using the Controller ...................37
Displaying Images or Files Sent
from a Tablet Device ...............37
Projecting an Image using
USB Connection
Projecting an Image using USB
Connection ....................................38
Starting USB Display .................38

3
Table of Contents
Projecting an Image ....................38
Using the Controller ...................38
USB Media Viewer
Using USB Media Viewer ................39
Thumbnail Mode ........................40
Option Menu ...............................40
Display Mode .............................41
Option Menu ...............................41
Slideshow Mode ......................... 41
Option Menu ...............................42
Others
Indicators ..........................................43
Messages List ................................... 44
Troubleshooting ...............................45
Replacing the Lamp .........................47
Cleaning the Air Filter .....................49
Specifications ...................................50
Projection Distance .......................... 58
Dimensions .......................................72
Index .................................................78

4Location and Function of Controls
BOverview
Location and Function of Controls
aFocus ring (page 15)
bZoom ring (page 15)
cLens
dRemote control detector
eON/STANDBY indicator
(page 43)
fLAMP/COVER indicator
(page 43)
gFront feet (adjustable) (page 16)
hFoot adjust button (page 16)
iAir filter cover/Ventilation holes
(intake) (page 49)
jLamp cover (page 47)
kVentilation holes (exhaust)
Do not place anything near the ventilation
holes as this may cause internal heat
buildup. Do not place your hand near the
ventilation holes and the circumference as
this may cause injury.
lSpeaker (VPL-EW276/EW246/
EW226/EX276/EX246/EX226
only)
mConnector panel (page 5)
nSecurity bar
Connects to a commercially available
security chain or wire.
oSecurity lock
Connects to an optional security cable
manufactured by Kensington.
For details, visit Kensington’s web site.
http://www.kensington.com/
pControl panel keys (page 6)
Main Unit
5
4
3
2
1
6
8
7
9
qa
qs
7
8
0
Caution
qh
qf
qd
q
g

5
Location and Function of Controls
Overview
VPL-EW276/EW246/EW226/EX276/EX246/EX226
VPL-EX272/EX242/EX222
Input (pages 9, 10)
aINPUT A
Video: RGB/YPBPRinput connector
(RGB/YPBPR)
Audio: Audio input connector (AUDIO)
bINPUT B
Video: RGB input connector (RGB)
Audio: Audio input connector (AUDIO)
cINPUT C
Video: HDMI input connector (HDMI)
Audio: HDMI input connector (HDMI)
dS VIDEO (S VIDEO IN)
Video: S video input connector (S
VIDEO IN)
Audio: Audio input connector (L
(MONO) AUDIO/R)
eVIDEO (VIDEO IN)
Video: Video input connector (VIDEO)
Audio: Audio input connector (L
(MONO) AUDIO/R)
• The audio inputs of S VIDEO and VIDEO
are shared.
• The audio input connector and audio output
from the HDMI connector are available only
on VPL-EW276/EW246/EW226/EX276/
EX246/EX226.
Output (page 13)
fOUTPUT
Video: Monitor output connector
(MONITOR)
Audio: Audio output connector
(AUDIO)
Connector Panel
54
4
5
7
6
1
29
8q;3
qs
qa
54
7
6
1
29
8q;3qa
Notes

6Location and Function of Controls
• This connector outputs the projected image
or audio only when INPUT A or INPUT B is
used.
• The audio output connector is available only
on VPL-EW276/EW246/EW226/EX276/
EX246/EX226.
Others
gRS-232C connector (RS-232C)
RS-232C compatible control connector.
Connects the computer’s RS-232C
connector and the RS-232C cross cables.
hLAN connector (page 31)
iAC IN (∼) socket
Connects the supplied AC power cord.
jUSB connector (Type A) ( )
(pages 12, 39)
kUSB connector (Type B) ( )
(page 38)
lMicrophone input ( )
Microphone input is available only on VPL-
EW276/EW246/EW226/EX276/EX246/
EX226.
Remote Commander
Control Panel Keys
aTurning on the power/Going to
standby mode
?/1(On/Standby) key
bSelecting an input signal
(page 14)
INPUT key
cOperating a menu (page 19)
MENU key
RESET key
ENTER /V/v/B/b(arrow) keys
RETURN key
dAdjusting the image (page 15)
ASPECT key (page 21)
KEYSTONE key (page 17)
PATTERN key (page 17)
APA (Auto Pixel Alignment) key*
(page 17)
*Use this key when inputting a computer
signal via the RGB input connector
(INPUT A or INPUT B).
Notes
Note
Remote Commander and Control Panel Keys
2
3
4
5
6
1
4
7
INPUT
MENU
APA ECO MODE
RETURN
ASPECT
D ZOOM
KEYSTONE
ENTER
VOLUME
PATTERN
FREEZE
BLANK
MUTING
RESET
36
12
Note

7
Location and Function of Controls
Overview
eUsing various functions during
projecting
D ZOOM (Digital Zoom) +/– key*1
Enlarges a portion of the image while
projecting.
1Press the D ZOOM + key to display
the digital zoom icon on the projected
image.
2Press the V/v/B/bkeys to move the
digital zoom icon to the point on the
image you want to enlarge.
3Press the D ZOOM + key or the D
ZOOM – key repeatedly to change the
enlargement ratio. The image can be
enlarged up to 4 times.
Press the RESET key to restore the
previous image.
BLANK key
Cuts off the projected image
temporarily. Press again to restore the
previous image. Picture muting helps
reduce power consumption.
MUTING key (VPL-EW276/EW246/
EW226/EX276/EX246/EX226 only)
Mutes the audio output temporarily.
Press again to restore the previous
volume.
VOLUME +/– key (VPL-EW276/
EW246/EW226/EX276/EX246/
EX226 only)
Adjusts the volume output.
FREEZE key*2
Pauses a projected image. Press again to
restore the image.
*1: Use this key when inputting a
computer signal. But it may not be
used depending on the resolution of
the input signal.
*2: Use this key when inputting a
computer signal.You cannot use this
key when “Type A USB”, “Type B
USB”or “Network”is selected as the
input.
fSetting the energy–saving mode
easily
ECO MODE key
Energy-saving mode can be set easily.
Energy-saving mode consists of “Lamp
Mode,” “With No Input,” “With Static
Signal” and “Standby Mode.”
1Press the ECO MODE key to display
the ECO Mode menu.
2Press the V/vkey or ECO MODE key
to select “ECO” or “User” mode.
ECO: Sets each mode to the optimum
energy-saving value.
Lamp Mode: Low
With No Input: Standby
With Static Signal: Lamp
Dimming
Standby Mode: Low
User: Sets each item of the ECO
Mode menu as you desire (go to
step 3).
3Select “User” then press the bkey.
The setting items appear.
4Press the V/vkey to select the item
then press the ENTER key.
5Press the V/vkey to select the setting
value.
6Press the ENTER key.
The screen returns to the User screen.
For details on ECO Mode settings, see
“Lamp Mode,” “With No Input,” “With
Static Signal” and “Standby Mode” on
the Connection/Power menu (page 27).
Notes
RETURN
ECO
User
ECO Mode
:Sel :Back
RETURN
Lamp Mode High
Auto Power Saving
Standby Mode
Off
With No Input
Lamp Dimming
With Static Signal
Standard
User
:Sel :Set :Back

8Location and Function of Controls
Others
gInfrared transmitter
About remote commander operation
• Direct the remote commander toward the
remote control detector.
• The shorter the distance between the
remote commander and the projector is,
the wider the angle within which the
remote commander can control the
projector becomes.
• Make sure that nothing obstructs the
infrared beam between the remote
commander and the remote control
detector on the projector.

9
Connecting the Projector
Preparation
BPreparation
Connecting the Projector
• Make sure all the equipment is powered off when connecting the projector.
• Use the proper cables for each connection.
• Insert the cable plugs firmly; Loose connections may reduce performance of picture signals or
cause a malfunction. When pulling out a cable, be sure to grip it by the plug, not the cable itself.
• For more information, refer also to the instruction manuals of the equipment you are connecting.
• Use a no-resistance audio cable.
Connection with a computer is explained for each input signal.
INPUT A/INPUT B
• The audio input connector is available only on VPL-EW276/EW246/EW226/EX276/EX246/
EX226.
• It is recommended that you set the resolution of your computer to 1280 × 800 pixels (VPL-EW276/
EW246/EW226) or 1024 × 768 pixels (VPL-EX276/EX272/EX246/EX242/EX226/EX222) for
the external monitor.
INPUT C
Notes
Connecting a Computer
For connecting a computer with an RGB output connector.
RGB output
connector
Audio output
connector
Mini D-sub 15-pin cable (supplied)
Computer
Audio cable (Stereo mini plug)
(not supplied)
Notes
For connecting a computer with an HDMI output connector.
HDMI output
connector
HDMI cable
(not supplied)
Computer

10 Connecting the Projector
• Audio output from the HDMI connector is available only on VPL-EW276/EW246/EW226/
EX276/EX246/EX226.
• Use HDMI-compatible equipment which has the HDMI Logo.
• Use a high speed HDMI cable(s) on which the cable type logo is specified. (Sony products are
recommended.)
• The HDMI connector of this projector is not compatible with DSD (Direct Stream Digital) Signal
or CEC (Consumer Electronics Control) Signal.
USB connector (Type B) ( )
For connecting to a computer with a USB connector (“Projecting an Image using USB
Connection” (page 38)).
Connections with a VHS video deck, DVD player, or BD player are explained for each input
signal.
S VIDEO IN
For connecting video equipment with an S-video output connector.
The audio input connector is available only on VPL-EW276/EW246/EW226/EX276/EX246/
EX226.
Notes
Connecting a Video equipment
USB A-B cable (not
supplied)
Computer
USB connector
(Type A)
Note
S video output
connector
Audio output
connector
S video cable (not supplied)
Computer
Audio cable (Phono plug × 2)
(not supplied)

11
Connecting the Projector
Preparation
VIDEO IN
For connecting video equipment with a video output connector.
The audio input connector is available only on VPL-EW276/EW246/EW226/EX276/EX246/
EX226.
INPUT A
For connecting video equipment with a YPBPRoutput connector.
The audio input connector is available only on VPL-EW276/EW246/EW226/EX276/EX246/
EX226.
Note
Note
Video cable (not supplied)
Audio cable (Phono plug × 2 – stereo mini plug) (not supplied)
Video output
connector
Audio output
connector
Video equipment
Component – Mini D-sub 15-pin cable (not supplied)
Audio cable (Phono plug × 2 – stereo mini plug) (not supplied)
Video equipment
YPBPRoutput
connector
Audio output
connector

12 Connecting the Projector
INPUT C
• Audio output from the HDMI connector is available only on VPL-EW276/EW246/EW226/
EX276/EX246/EX226.
• Use HDMI-compatible equipment which has the HDMI Logo.
• Use a high speed HDMI cable(s) on which the cable type logo is specified. (Sony products are
recommended.)
• The HDMI connector of this projector is not compatible with DSD (Direct Stream Digital) Signal
or CEC (Consumer Electronics Control) Signal.
Microphone ( )
For connecting a microphone.
• The microphone input is available only on VPL-EW276/EW246/EW226/EX276/EX246/EX226.
• Only dynamic microphones are supported.
USB connector (Type A) ( )
For connecting a USB memory device (“Using USB Media Viewer” (page 39)).
Notes
Connecting a microphone
Notes
Connecting a USB memory device
Video equipment
HDMI cable
(not supplied)
HDMI output
connector
For connecting video equipment with an HDMI output connector.
Microphone
(not supplied)
USB memory device
(not supplied)

13
Connecting the Projector
Preparation
USB connector (Type A) ( )
For connecting a USB wireless LAN module IFU-WLM3 (not supplied) (“Presentation
Function via Network” (page 35)).
• Undesignated USB wireless LAN modules do not work.
• When connecting/disconnecting the USB wireless LAN module, make sure that the projector is in
Standby mode (Standby Mode: “Low”), or the AC power cord is unplugged from the wall outlet.
OUTPUT
Projected images or input audio can be output to display equipment such as a monitor or audio
equipment such as speakers with a built-in amplifier.
• The audio input connector is available only on VPL-EW276/EW246/EW226/EX276/EX246/
EX226.
• Projected images and audio can be output.
Connecting a USB wireless LAN module
Notes
Connecting an External Monitor and Audio Equipment
Notes
USB wireless LAN module
IFU-WLM3 (not supplied)
Audio cable
(stereo mini plug)
(not supplied)
Audio input
connector
Mini D-sub 15-pin cable
(supplied)
RGB input
connector
Audio equipment
Display equipment

14 Projecting an Image
BProjecting/Adjusting an Image
Projecting an Image
The size of a projected image depends on the distance between the projector and screen. Install
the projector so that the projected image fits the screen size. For details on projection distances
and projected image sizes, see “Projection Distance” (page 58).
1Plug the AC power cord into the wall
outlet.
2Connect all equipment to the projector
(page 9).
3Press the ?/1key to turn on the unit.
4Turn on the connected equipment.
5Select the input source.
Press the INPUT key on the projector to
display the menu for switching input
signal on the screen. Press the INPUT
key repeatedly, or press the V/vkey to
select an image to be projected.
6When projecting a computer image,
switch your computer’s output to
external display.
The method to switch the output varies
depending on the type of computer.
(Example)
To project image files stored in a USB
memory device, see “USB Media
Viewer” (page 39). To project an image
using USB Connection, see “Projecting
an Image using USB Connection”
(page 38). To use Presentation Function
via Network, see “Presentation Function
via Network” (page 35).
Computer
Video equipment
Projector
Wall outlet
1
2
5
4
3
6
+

15
Projecting an Image
Projecting/Adjusting an Image
7Adjust the focus, size and position of
the projected image (page 15).
Adjusting the Projected image
Focus Size (Zoom) Position
Focus ring
Zoom ring
Foot
adjust
button
Front feet
(adjustable)

16 Projecting an Image
Adjusting the tilt of the projector with the front feet (adjustable)
By changing the tilt of the projector with the foot adjust buttons/front feet (adjustable), you can
adjust the position of the projected image.
How to adjust the angle
1Press and hold the foot adjust buttons.
2Lift up the front of the projector to
adjust the angle.
3Release the foot adjust buttons.
4Turn the front feet (adjustable) to set
the angle of the projector precisely.
• Be careful not to let the projector down on your fingers.
• Do not push hard on the top of the projector with the front feet (adjustable) extended.
Changing the aspect ratio of the projected image
Press the ASPECT key on the remote commander to change the aspect ratio of the projected
image. You can also change the setting in Aspect of the Screen menu (pages 21, 23).
Notes

17
Projecting an Image
Projecting/Adjusting an Image
Correcting trapezoidal distortion of the projected image (Keystone feature)
Normally the Keystone feature automatically adjusts the projected image. The Keystone
feature may not work automatically if the screen is tilted. In this case, set Keystone manually.
1Press the KEYSTONE key on the remote
commander or select V Keystone in the
Installation menu.
2Use the V/v/B/bkeys to set the value. The
higher the value, narrower the top of the
projected image. The lower the value, the
narrower the bottom.
Since the Keystone adjustment is an electronic
correction, the image may be deteriorated.
Displaying a pattern
You can display a pattern for adjusting the projected image or a grid pattern with the PATTERN
key on the remote commander. Press the PATTERN key again to restore the previous image.
You can use a grid pattern as a guide to write text or to draw lines and shapes on the whiteboard
or blackboard without using a computer.
You cannot use this key when “Type A USB”, “Type B USB” or “Network” is selected as the input.
Automatically adjusts Phase, Pitch and Shift of projected image while a
signal is input from a computer (APA (Auto Pixel Alignment))
Press the APA key on the remote commander. Press again to cancel adjusting during the setting.
You can also set APA in the Screen Menu (page 22). If Smart APA in the Function menu is set
to “On”, executes APA automatically when a signal is input (page 25).
Note
Increase the number
towards plus
Increase the number
towards minus
Note

18 Projecting an Image
1Press the ?/1key on the unit or the remote commander.
The projector starts shutdown and turns off. If you press the ?/1key within 10 seconds
again, shutdown is cancelled.
2Unplug the AC power cord from the wall outlet.
To turn off without displaying confirmation message
Press and hold the ?/1key on the unit for a few seconds (page 44).
ECO gauge
This gauge indicates the current effectiveness of the projector’s ECO function. (For details on
the ECO function, see “ECO MODE key” (page 7) and “ECO” (page 27).)
The leaf icons are displayed when the projector is shut down. The number of displayed icons
varies according to how much energy is saved as a result of using the ECO function.
Turning Off the Power
ECO gauge

19
Using a MENU
Adjustments and Settings Using a Menu
BAdjustments and Settings Using a Menu
Using a MENU
The menu displays used for the explanation below may be different depending on the model you are
using.
1Press the MENU key to display the
menu.
2Select the setting menu.
Use the V/vkey to select the setting
menu then press the b key or ENTER
key.
3Select the setting item.
Use the V/vkey to select the setting
menu then press the b key or ENTER
key.
To return to the selection screen of the
setting menu, press the Bor RETURN
key.
4Make the setting or adjustment for the
selected item.
The setting method varies, depending on
the setting item.
If the next menu window is displayed,
select the item according to the
operations in step 3and then press the
ENTER key to register the setting.
To return to the selection screen of the
setting items, press the Bor RETURN
key. You can press the RESET key to
reset an item to its factory setting value
to aid setting.
Using a pop-up menu
Press the V/v/B/bkey to select an item.
A selected item takes effect
immediately, except “Language”, which
will take effect after you press the
ENTER key.
Using the setting menu
Press the V/vkey to select the item.
Press the ENTER key to register the
setting and return to the previous screen.
Using the adjustment menu
To increase the value, press the V/bkey
and to decrease the number, press the
v/Bkey. Press the ENTER key to
register the setting and return to the
previous screen.
5Press the MENU key to clear the
menu.
The menu disappears automatically if no
operation is performed.
Note
Picture Mode Standard
Reset
Contrast
Brightness
Color
Hue
Color Temp.
Sharpness
Expert Setting
:Sel :Set :Back
Low
Setting menu
80
50
50
50
5
Picture Mode Standard
Reset
Contrast
Brightness
Color
Hue
Color Temp.
Sharpness
Expert Setting
:Sel :Set :Back
Low
Setting items
RETURN
Picture Mode
Dynamic
Standard
:Back
:Sel
Cinema
Game
Blackboard
Presentation
AdjustBack
Contrast

20 The Picture Menu
The Picture Menu
The Picture is used to adjust the picture for each input signal.
*1: When a computer signal is input, this option is available.
*2: The settings in the Picture return to their factory defaults, except for Picture Mode.
*3: When a video signal is input, this option is available.
*4: When the signal without color burst signal is input after selecting “Video” or “S-Video”, this
option is unavailable.
*5: When an analog TV signal is input, this option may not available, depending on the color system.
*6: When “Picture Mode” is set to the item other than “Presentation” or “Blackboard,” this option
is available.
*7: When “Picture Mode” is set to “Blackboard,” this option is unavailable.
Items Item descriptions
Picture Mode Dynamic: Emphasizes the contrast to produce a dynamic and vivid picture.
Standard: Provides an image which is natural and well balanced.
Presentation*1:Provides a bright image, suitable for presentations.
Blackboard: Provides an image suitable for displaying on a blackboard.
Game: Provides an image suitable for viewing games.
Cinema: Provides an image suitable for viewing movies.
Reset*2 Resets the factory setting.
Contrast The higher the value, the greater the contrast. The lower the value, the lower
the contrast.
Brightness The higher the value, the brighter the picture. The lower the value, the darker
the picture.
Color*3 *4 The higher the value, the greater the intensity. The lower the value, the lower
the intensity.
Hue*3 *4 *5 The higher the value, the more greenish the picture becomes. The lower the
value, the more reddish the picture becomes.
Color Temp.*6 High/Middle/Low: The higher the value, the more bluish the picture. The
lower the value, the more reddish the picture.
Sharpness The higher the value, the sharper the picture. The lower the value, the softer
the picture.
Expert Setting
Gamma
Mode*1 *7 Graphics1: Gamma correction to make halftones brighter. This setting is
suitable when projecting highly colorful images, such as photos, in a bright
place.
Graphics2: Gamma correction to improve the reproduction of halftones.
Highly colorful images, such as photos, can be reproduced in natural tones.
Text: Improves black and white contrast. Suitable for images with lots of text
content.
Notes
