VPL-T Series
Affordable, Compact Teacher’s Pet™
Projectors for Education
VPL-TX70
VPL-TX7
sony.com/projectors
SONY55440_VPL-T.indd 1 6/11/09 9:55:47 AM

LCD panel of the VPL-TX70
INTRODUCING THE VPL-TX7 and VPL-TX70 NETWORKED
EDUCATION PROJECTORS
Go to the head of the class with Sony’s affordable new Teacher’s Pet™ education projectors, destined
to be a teacher’s favorite.The VPL-TX7 and VPL-TX70 were designed and developed specifically with
students and teachers in mind, ready to handle any lesson plan.Both projectors offer native XGA
resolution, delivering astonishing color light output ranging from 2000 (VPL-TX7) to 2600 lumens
(VPL-TX70).The VPL-TX70 utilizes Sony’s 3LCD BrightEra™ imaging technology - the latest generation of
LCD panels that reproduce high quality images with bright and natural colors.
These new projectors redefine“smart” – from their stylish looks to classroom-friendly features like
closed captioning; a 5-Watt built-in speaker, so students can hear the audio loud and clear; a variety
of inputs, including composite video,s-video,2 Analog RGB/Component inputs,plus 1 monitor out
with variable audio out; and RJ-45 connection for remote monitoring and maintenance.They also
offer synchronized lamp and filter replacements at 3000/4000 hours.And thanks to 3LCD and
BrightEra imaging technology, these projectors use smaller lamps - smaller lamps are less expensive
and use less power than single chip DLP projectors – for a lower total cost of ownership.
To top that, Sony’s Eye on Education™ program offers educational institutions competitive pricing,an
Extra Credit Frequent Purchase Program,trade-in opportunities, extended lamp warranties,and
exceptional service.Visit www.sony.com/EyeOnEducation and www.sony.com/extracredit for details.
FEATURES & BENEFITS
Affordable
Priced to bring excellent brightness and advanced features
within reach. It’s simple mathematics with 3LCD and BrightEra
technology: less general maintenance costs and longer
lasting projectors = a lower total cost of ownership.
Sleek Design
The design features a unique
body shape that broadens
towards the front allowing
images to project upwards on
the screen and therefore minimal tilt adjustment is required.
Accepts a wide variety of Interfaces
The new TX series of projectors accept a wide variety of input
signals from standard definition (SD) to high definition (HD)
including composite video, S-Video, and 2 analog RGB/
component inputs via an HD D-sub 15-pin. Both models are
equipped with a 5W speaker,RJ45 and a monitor out with
variable audio out.
High Brightness & Picture Quality
No need to turn out the lights! The VPL-TX70
delivers 2600 lumens and the VPL-TX7 delivers
2000 lumens, bright enough to be clearly
seen in normal room lighting, so students
can take notes and follow along with
handouts. High picture quality, long-life
imagers and optical efficiencies are
achieved with the VPL-TX70’s
BrightEra 3LCD panel system.
Network Functions
The network allows users to monitor the projector’s status and
will even e-mail updates.
Closed Captioning
Allows presenters to display a transcription of the audio
portion from video sources to provide interpretive information
to viewers who wish or require to access it.
2
Side
SONY55440_VPL-T.indd 2 6/11/09 9:55:50 AM

Anti-Theft Features
Password protection helps prevent unauthorized usage. The
control panels can be locked to help prevent inadvertent or
unauthorized adjustments. And there’s even a security bar to
allow connection to an optional security cable such as
antitheft chain or wire.
Direct Power On/Off
With this function, standby mode can be skipped over to
activate the projector immediately. The projector can be
turned on or off using a circuit-breaker switch on the wall.
VPL-TX7/TX70 KEY FEATURES
tXGA Resolution
tColor Light Output
t➾2000 Lumen Color Light Output (VPL-TX7)
t➾2600 Lumen Color Light Output (VPL-TX70)
t3LCD Panels:
t➾0.63-inch 3LCD Panels (VPL-TX7)
t➾0.63-inch 3LCD BrightEra™ Panels (VPL-TX70)
tClosed Captioning
t2 RGB/Component Inputs: HD D-sub 15 pin
tComposite Video: Phono Type
tS-Video: Mini DIN 4-pin
tMonitor Out with Variable Audio Out
tOff & Go - Terminate the power without
twaiting for the projector to cool down
t190W UHP Lamp (LMP-E191)
tCeiling Mountable
tRS232C
t5W Speaker
tRJ45: Network Control & Monitoring
Remote Commander unit
3
CONNECTOR PANEL
CONTROL PANEL
6OJUJODIFTNN
12 3/8(314)
12 3/8(314)
2 5/8
(69.5)
2 7/8
(72.2)
4 3/8
(109)
10 5/8(269)
10 5/8(269)
DIMENSIONS
OPTIONAL ACCESSORIES
LMP-E191
3FQMBDFNFOU-BNQ
GPS71-5959
PAM-200
$FJMJOH.PVOU
GPS71-5959
Rear Panel
621<B93/7LQGG 30

DI-0183 (MK10555V1)
© 2009 Sony Electronics Inc. All rights reserved.
Reproduction in whole or in part without written permission is prohibited.
Features and specications are subject to change without notice.
All non-metric weights and measurements are approximate.
Sony, BrightEra, Remote Commander and Teacher’s Pet are trademarks of Sony.
HDMI, the HDMI logo, and High-Denition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.
All other trademarks are the property of their respective owners.
Printed in USA (5/09)
Sony Electronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
sony.com/projectors for product information
click: sony.com/sonysports
sony.com/EyeOnEducation for education programs
click: sony.com/sonysports
SPECIFICATIONS
VPL-TX7 VPL-TX70
Optical
Projection System 3 LCD panels, 1 lens projection system
LCD Panel 0.63 inch XGA LCD panel, 2,359,296 (1024 x 768 x 3) pixels 0.63 inch XGA LCD panel, (BrightEra) 2,359,296 (1024 x 768 x 3) pixels
Color Light Output 2000 lm (lamp mode: high), 1500 lm (lamp mode: standard) 2600 lm (lamp mode high), 2000 lm (lamp mode: standard)
Light Output 2000 lm (lamp mode: high), 1500 lm (lamp mode: standard) 2600 lm (lamp mode high), 2000 lm (lamp mode: standard)
Contrast Ratio 500:1 900:1
Lamp Power 190W ultra high pressure lamp
Lamp Life 3000/4000H
Projection Lens 1.2 times zoom lens (manual), f = 18.53 to 22.18mm, F = 1.65-1.93
Throw Ratio 1.5-1.7
Screen Size 40" - 300" (Viewable Area Measured Diagonally)
Signals
Color System NTSC3.58, PAL, SECAM, NTSC4.43, PAL-M, PAL-N, PAL60 system
Resolution 750 horizontal TV lines (Video input), 1,024 x 768 dots (RGB input)
Acceptable Computer
Signals fH: 19 to 92kHz, fV: 48 to 92Hz, Maximum input signal resolution: Up to SXGA+ (fV 60Hz)
Acceptable Video Signals Composite Video, Y/C Video, 15kRGB 50/60Hz, Progressive Component 50/60Hz, DTV (480/60i, 480/60p, 575/50i, 575/50p, 720/50p, 720/60p,
1080/50i, 1080/60i)
Interface
Video In S-Video: Y/C Mini DIN 4 pin, Composite: Phono, Audio: Stereo Mini Jack
Input A Analog RGB / Component (HD D-sub 15 pin),Audio: Stereo Mini Jack
Input B Analog RGB / Component (HD D-sub 15 pin),Audio: Stereo Mini Jack
Network Wired (10Base-T / 100Base-TX)
Monitor Out Video Analog RGB / Component (HD D-sub 15 pin)
Audio Stereo Mini Jack
Remote RS-232C D-sub 9 pin
General
Dimensions WxHxD approx. 12 3/8 x 4 3/8 x 10 5/8 inches (excluding projection parts)
Weight approx. 6 lb 10 oz
Power Requirements AC 100 to 240 V, 2.6 to 1.1A, 50/60 Hz
Power Consumption Max: 260W, Standby: Approx 3W Max: 270W, Standby: Approx. 3W
Speaker 5W
Operating Temperature 32 to 95 F degrees (0 to 35 C degrees)
Operating Humidity 35 to 85% (no condensation)
Storage Temperature -4 to 140 F degrees (-20 to 60 C degrees)
Storage Humidity 10 to 90%
Supplied Accessories
Remote Commander® (1),Lithium battery CR2025 (1), HD D-sub 15-pin cable (1.8m)(1), Security label (1), CD-ROM (operating instructions) (1),
Quick reference manual (1), Safety regulations (1), Lens cap (1), AC power cord (1),Warranty card (1)
