VPL-EW275 VPL-EW245 VPL-EW225
VPL-EX275 VPL-EX245 VPL-EX225
VPL-E200 Series
Data Projectors
®

2
Good TCO, Energy-efficient Design and
Operational Convenience
The VPL-E200 Series delivers a full range of brightness options to meet virtually
many types of education or business projection environments
Good TCO, Energy-efficient Design
Auto Power Saving Function
• Auto Mode (Auto Brightness Adjustment Function)
The brightness of the lamp’s output is automatically
adjusted depending on the brightness of the projected
image, to avoid unnecessary power consumption.
When showing darker images that don’t require high
brightness, lamp output decreases.
• Blank
The VPL-E200 Series projectors can
temporarily disable video signal output. This
function can be easily operated with just the
touch of a button on the supplied Remote
Commander™ unit. In addition, this function
allows blank image projection with low power
consumption using lamp control technology.
Lamp dimming scheme
FEATURES
3Lamp high mode. The values are approximate.
The values are approximate.
Lamp dimming
Input (image)
Lamp power3
100%
85%
(-15%)
30%
(-70%)
A B B CB
Slowly
Slowly Quickly
(Restart)
In useNot in useIn use
Automatically Automatically
Time
5/10/15/20 min.0 sec. 10 sec.
Lamp Drive
Example of
class room
Projection Blank Projection
Normal
condition
(100%)
Lamp 30% with blank image
Quick restartQuick restart
Class time Recess time Class time
Energy Saving Design
The VPL-E200 Series projectors offer remarkably low power
consumption, helping to save electricity expenses.
ECO MODE Key
With a single push of the ECO MODE key on either the
projector or the supplied Remote Commander unit, users can
select an energy-saving setting from the ECO Mode menu.
Long-lasting Lamp
By incorporating a high-performance lamp and advanced
lamp-control technology, the VPL-E200 Series projectors deliver
an extremely long lamp replacement time of up to 7,000
hours.4
4 Approximate period, in low mode. Actual performance varies based on
settings, environmental conditions, and usage.
• Lamp Dimming Function
The VPL-E200 Series projectors are equipped with a lamp
dimming function. After 10 seconds of a static signal feed, the
lamp dims by approximately 15% (lamp mode condition:
high) which is hardly noticeable. If one of these projectors
is left powered on while not in use, after a set period of time
it will automatically detect no change of signal input and
will dim the lamp to as low as approximately 30% of original
brightness to significantly reduce energy consumption.
Lamp drive
High
The Sony VPL-E200 Series data projectors are designed for optimum energy efficiency, and ease of use.
Features such as the Auto Power Saving function with lamp control technology and long-lasting lamp contribute
to the energy saving design. Additionally a variety of network functions such as Web Control and Network
Presentation can be performed. Rich inputs and outputs are also provided, to suit a broad range of applications.
The VPL-EW275,VPL-EW245, and VPL-EW225 present clear and dynamic images in native WXGA resolution on a
widescreen with high brightness (up to 3700 lumens1), while the VPL-EX275, VPL-EX245, and VPL-EX225 provide high
picture quality in native XGA resolution, also with up to 3700 lumens brightness.2
Delivering superb images along with simple operation, the Sony VPL-E200 Series projectors provide an excellent
balance between quality and cost, ideal for use in education or business.
1ISO 2118
2VPL-EW275, and VPL-EX275: 3700 lumens;VPL-EX245: 3200 lumens;VPL-EW245: 3100 lumens; VPL-EX225: 2700 lumens; VPL- EW225: 2600 lumens.

3
Multiple Inputs & Outputs
VPL-E200 Series projectors include a high wattage speaker
(16 W) and a variety of interfaces (2xRGB, HDMI, S-Video,
RS-232C, RJ-45, USB Type-A, USB Type-B, and Microphone
inputs) that accept a wide variety of inputs signals, greatly
expanding system connection possibilities.
Superb Picture Quality
Brilliant Color Performance
The VPL-E200 Series projectors adopt a 3LCD projection
system incorporating three LCD panels. This system enables
each projector to present bright and natural images.
By combining an advanced generation of inorganic LCD
panels that utilize the Sony BrightEra™ technology with a
3LCD projection system, the VPL-E200 Series projectors offer
high picture quality and brightness.
12-bit 3D Gamma Correction
The VPL-E200 Series projectors incorporate 12-bit 3D gamma
correction circuitry to perform highly accurate gamma
correction, achieving smoother gradations and a richer gray
scale.
Other Features
Closed Captioning
Official teletext broadcasting, developed by the NCI, USA
Network and Control
Controls and monitors projector status
Compatible with various control systems
USB Media Viewer
By attaching a USB memory device6to the VPL-E200 Series USB
connector, the operator can directly project data files stored
on the USB memory device.
Supported file formats are JPG, BMP, PNG,TIF, and GIF.
6USB memory device is not included.
Creston Connected certified
The VPL-E200 Series projectors shipping from Sony in Oct 2012
are planned to be compatible with Crestron Connected
control and management system. Crestron Connected
provides control capability over an IT network without custom
programming or a control processor.
Lamp and Filter Synchronized Maintenance
The expected lamp maintenance time for each model can
reach up to 7,000 hours depending on the selected lamp
mode, and dust filters require the same maintenance interval.
Synchronizing the timing of lamp and filter maintenance
enables users to reduce the number of “ladder climbs” for
maintenance.
A Variety of Network Functions
– Via LAN Cable or Wirelessly
Web Control
When VPL-E200 Series projectors are installed in a local area
network (LAN), their versatile network functions are available
to any PC on that network.
Installation can be via a LAN cable, and there is no need to
install any additional network software on the PC.
Network Presentation
When VPL-E200 Series projectors are installed on a LAN,
presentations can be projected from any PC on the network
– whether connected via a LAN cable or wirelessly.5
5Requires IFU-WLM3 sold separately.
Up to four users can project PC images simultaneously;
up to eight users* can connect to one projector.
* Up to seven users for wireless.
Broad Range of Applications
Convenient, Simple Projector Adjustment
The projectors’ 1.6x* flexible standard zoom lens allows the
projector to fit wide range of installations, and simplifies
replacement of an existing projector.
* The VPL-EW225 and VPL-EX245 are 1.3x zoom projectors.
WLAN (wireless)
1.0:1 1.5:1 2.0:1Throw ratio*
VPL-EW245/EX275/
EX245
(1.6x)
VPL-EW225/EX225
(1.3x)
VPL-EW275
(1.6x)
1.5:1–1.8:1:Typical 1.2x compact projectors throw ratio
* Throw distance=Throw ratio x Screen width. The values are approximate.
1.79:11.10 :1
1.80:11.37:1
2.27:11. 40:1

4
DIMENSIONS Unit: inches (mm)
Top
Front
CONNECTOR PANELS
VPL-EW275 / VPL-EW245 / VPL-EW225
VPL-EX275 / VPL-EX245 / VPL-EX225
VPL-EW245 / VPL-EX275 / VPL-EX245
VPL-EX225 / VPL-EX225
VPL-EW275
14 3/8(365)
3 11/32 (85)
1/4(6.7)
Center of Lens
9 29/32 (252) 11/32 (9)
Center of Lens
14 3/8(365)
3 11/32 (85)
9 29/32 (252)
15/16 (24.2) 31/32 (24.7)
1/32 (0.5)
14 3/8(365)
3 11/32 (85)
Center of Lens
13/32 (10.4) 23/32 (18.1)
9 29/32 (252)
Center of Lens
4 5/32 (105.3)
3 25/32 (96.2)
1 3/4
(44.3)
OPTIONAL ACCESSORIES
LMP-E212
Projector Lamp (for replacement)
IFU-WLM3
USB wireless LAN module

SPECIFICATIONS
VPL-EW275 VPL-EW245 VPL-EW225 VPL-EX275 VPL-EX245 VPL-EX225
Display system 3 LCD system
Display device Size of effective
display area
0.75” (19 mm) x 3
BrightEra™
Aspect ratio: 16:10
0.59” (15 mm) x 3
BrightEra
Aspect ratio: 16:10
0.63” (16 mm) x 3
BrightEra
Aspect ratio: 4:3
Number of pixels 3,072,000 (1280 x 800 x 3) pixels 2,359,296 (1024 x 768 x 3) pixels
Projection lens Zoom Optical: Manual (Approx. x 1.6) Optical: Manual
(Approx. x 1.3) Optical: Manual (Approx. x 1.6) Optical: Manual (Approx. x 1.3)
Focus Manual
Throw ratio 1.10:1 to 1.79:1 1.40:1 to 2.27:1 1.37:1 to 1.80:1 1.40:1 to 2.27:1 1.37:1 to 1.80:1
Light source Ultra high pressure mercury lamp 210 W type
Recommended lamp replacement time*13000 H / 5000 H / 7000 H (Lamp mode: High / Standard / Low)
Filter cleaning cycle*1Max. 7000 H, Same time as the lamp replacement is recommended
Screen size 30” to 300” (0.76 m to 7.62 m)
Light output
(Lamp mode: High / Standard / Low)
3700 lm / 2800 lm*2/
2100 lm*2
3100 lm / 2000 lm*2/
1600 lm*2
2600 lm / 1900 lm*2/
1500 lm*2
3700 lm / 2700 lm*2/
2100 lm*2
3200 lm / 2200 lm*2/
1700 lm*2
2700 lm / 2100 lm*2/
1600 lm*2
Color light output
(Lamp mode: High / Standard / Low)
3700 lm / 2800 lm*2/
2100 lm*2
3100 lm / 2000 lm*2/
1600 lm*2
2600 lm / 1900 lm*2/
1500 lm*2
3700 lm / 2700 lm*2/
2100 lm*2
3200 lm / 2200 lm*2/
1700 lm*2
2700 lm / 2100 lm*2/
1600 lm*2
Contrast ratio (full white / full black)*33000:1 2300:1 3000:1
Displayable scanning
frequency
Horizontal 19 kHz to 92 kHz
Vertical 48 Hz to 92 Hz
Display resolution Computer signal
input
Maximum display resolution:UXGA 1600 x 1200 dots*4
Panel display resolution: 1280 x 800 dots Panel display resolution:1024 x 768 dots
Video signal input NTSC, PAL, SECAM, 480/60i, 576/50i, 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/60p, 1080/50p
Color system NTSC3.58, PAL, SECAM, NTSC4.43, PAL-M, PAL-N
Keystone correction Vertical: Max. +/- 20 degrees Vertical: Max. +/- 30 degrees
OSD language 23-languages (English, Dutch, French, Italian, German, Spanish, Portuguese,Turkish, Polish, Russian, Swedish, Norwegian, Japanese, Simplified
Chinese,Traditional Chinese, Korean,Thai,Vietnamese,Arabic, Farsi, Finnish*7, Indonesian*7, Hungary*7)
Computer and video
signal input/output
INPUT A RGB / Y PBPRinput connector: Mini D-sub 15-pin (female),Audio input connector: Stereo mini jack
INPUT B RGB input connector: Mini D-sub 15-pin (female),Audio input connector:Stereo mini jack
INPUT C HDMI®input connector: HDMI 19-pin, HDCP support
Audio input connector:HDMI audio support
S VIDEO IN S video input connector: Mini DIN 4-pin,Audio input connector: Pin jack (x2) (shared with VIDEO IN)
VIDEO IN Video input connector: Pin jack,Audio input connector: Pin jack (x2) (shared with S VIDEO IN)
OUTPUT Monitor output connector*5:Mini D-sub 15-pin (female),Audio output connector*6: Stereo mini jack (variable out)
Control signal input/output, Others RS-232C connector: D-sub 9-pin (male)
LAN connector: RJ-45, 10BASE-T/100BASE-TX
USB:Type-A,Type-B
Microphone input: Mini jack
Speaker 16 W x 1 (monaural)
Operating temperature (Operating humidity) 32°F to 104°F to 40°C (35% to 85%; no condensation)
Storage temperature (Storage humidity) -4°F to +140°F / -20°C to +60°C (10% to 90%)
Power requirements AC 100 to 240 V,
3.1 A to 1.3 A,
50 Hz / 60 Hz
AC 100 V to 240 V,
3.2 A to 1.3 A,
50 Hz / 60 Hz
AC 100 to 240 V,
2.9 A to 1.2 A,
50 Hz / 60 Hz
AC 100 to 240 V,
3.1 A to 1.3 A,
50 Hz / 60 Hz
AC 100 to 240 V,
3.2 A to 1.3 A,
50 Hz / 60 Hz
AC 100 V to 240 V,
3.0 A to 1.2 A,
50 Hz / 60 Hz
Power consumption
(Lamp mode: High /
Standard / Low)
AC 100 V to 120 V 303 W / 256 W*2/
226 W*2
311 W / 255 W*2/
226 W*2
287 W / 251 W*2/
228 W*2
306 W / 256 W*2/
226 W*2
315 W / 254 W*2/
225 W*2
293 W / 257 W*2/
228 W*2
AC 220 V to 240 V 294 W / 247 W*2/
218 W*2
299 W / 246 W*2/
218 W*2
277 W / 242 W*2/
218 W*2
298 W / 249 W*2/
220 W*2
305 W / 248 W*2/
220 W*2
285 W / 250 W*2/
222 W*2
Standby mode power
consumption (Standby
mode: Standard / Low)
AC 100 V to 120 V 5.9 W / 0.1 W
AC 220 V to 240 V 5.9 W / <0.2 W
Heat dissipation AC 100 V to 120 V 1034 BTU 1061 BTU 980 BTU 1044 BTU 1075 BTU 1000 BTU
AC 220 V to 240 V 1003 BTU 1020 BTU 945 BTU 1017 BTU 1041 BTU 973 BTU
Outside dimensions W 14 3/8 x H 3 25/32 x D 9 29/32 inches (W 365 x H 96.2 x D 252 mm) (without protrusions)
Weight 9 lb 1 oz / 4.1 kg 8 lb 9 oz / 3.9 kg 8 lb 8 oz / 3.9 kg 8 lb 11 oz / 4 kg 3.9 kg / 8 lb 8 oz
Supplied accessories RM-PJ8 Remote Commander (1), Lithium battery: CR2025 (1), AC Power Cord (1),Operating Instructions (CD-ROM) (1),Quick Reference Manual (1),
Mini D-sub 15-pin cable (1), Projector Station for Network Presentation application (CD-ROM) (1)
Replacement lamp LMP-E212
*1 Expected maintenance time not guaranteed. Lamp and filter performance will vary based on operating environment and use.
*2 These values are estimate.
*3 This value is average.
*4 Available for the VESA Reduced Blanking signal.
*5 Not available in standby. From INPUT A and INPUT B.
*6 Works as an audio switcher function. Output from a selected channel; not available in standby.
*7 Will be applied.
©2012 Sony Corporation. All rights reserved.
Reproduction in whole or in part without written permission is prohibited.
Features and specifications are subject to change without notice.
The values for mass and dimension are approximate.
Sony; the Sony make.believe logo, BrightEra, and Remote Commander are trademarks of Sony.
Trademark PJLink is a trademark applied for trademark rights in Japan,
the United States of America and other countries and areas.
The terms HDMI and HDMI High-Definition Multimedia Interface,
and the HDMI Logo are trademarks or registered trademarks of
HDMI Licensing LLC in the United States and other countries.
All other trademarks are the property of their respective owners.
Printed in USA (8/12)
Sony Electronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
sony.com/professional
DI-0280 (MK10949V2)
