Network Video Receiver
DMX-NV1
Operating Instructions

2
Owner’s Record
The model and serial numbers are located at the bottom of the receiver.
Record these numbers in the spaces provided below. Refer to them
whenever you call upon your Sony dealer regarding this product.
Model No.
Serial No.
For Your Convenience
Contact Sony Customer Support at:
http://esupport.sony.com/bravialink
or to speak with a support representative:
United States
1-866-918-BIVL (2485)
Canada
Please Do Not Return the Product to the Store
1-877-899-SONY (7669)
Please contact Sony directly if you:
Have questionson the use of your module after reading the Operating Instruction manual
and Quick Setup Guide
Experience difficulty operating your module
Sony will work to resolve your questionsmore quickly than your retailer or place of purchase.
z
z
Register your BRAVIA®Internet Video Link at:
https://internet.sony.tv

3
WARNING
To reduce the risk of fire or electric shock, do
not expose this receiver to rain or moisture.
This symbol is intended to
alert the user to the presence
of uninsulated “dangerous
voltage” within the
product’s enclosure that
may be of sufficient
magnitude to constitute a
risk of electric shock to
persons.
This symbol is intended to
alert the user to the presence
of important operating and
maintenance (servicing)
instructions in the literature
accompanying the
appliance.
The receiver shall not be exposed to dripping or
splashing and no objects filled with liquids, such
as vases, shall be placed on the receiver.
CAUTION
To prevent electric shock, do not use this
polarized AC plug with an extension cord,
receptacle or other outlet unless the blades can
be fully inserted to prevent blade exposure.
NOTIFICATION
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment
generates, uses and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
sReorient or relocate the receiving
antenna.
sIncrease the separation between the
equipment and receiver.
sConnect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
sConsult the dealer or an experienced
radio/TV technician for help.
CAUTION
Do not attempt to modify this product in any
way without written authorization from Sony
Electronics, Inc. Unauthorized modification
could void the user's authority to operate this
product.
For Customers in Canada
This Class B digital receiver complies with
Canadian ICES-003.
Trademark Information
“BRAVIA” and are trademarks of
Sony Corporation.
“XrossMediaBar” is a trademark of Sony
Corporation. “XMB” is a trademark of Sony
Coproration and Sony Computer Entertainment
Inc.
"PLAYSTATION" is a registered trademark and
"PS3" is a trademark of Sony Computer
Entertainment Inc.
Yahoo! and the Yahoo! logo are registered
trademarks of Yahoo! Inc.
YouTube is a registered trademark of Google
Inc.
Amazon is a trademark of Amazon.com Inc.
CBS and Showtime are registered trademarks of
CBS Broadcasting Inc.
This device incorporates High-Definition
Multimedia Interface (HDMI™) technology.
HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing, LLC.
This product incorporates copyright protection
technology that is protected by U.S. patents and
other intellectual property rights. Use of this
copyright protection technology must be
authorized by Macrovision corporation, and is
intended for home and other limited consumer
uses only unless otherwise authorized by
Macrovision. Reverse engineering or
disassembly is prohibited.
Declaration of Conformity
Trade Name: SONY
Model: DMX-NV1
Responsible Party: Sony Electronics Inc.
Address: 16530 Via Esprillo
San Diego, CA 92127 U.S.A.
Telephone Number: 858-942-2230
This device complies with part 15 of the FCC
rules. Operation is subject to the following
two conditions: (1) This device may not
cause harmful interference, and (2) this
device must accept any interference received,
including interference that may cause
undesired operation.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
ATTENTION
RISQUE DE CHOC ELECTRIQUE,
NE PAS OUVRIR
PRECAUCION
RIESGO DE CHOQUE ELECTRICO
NO ABRIR
Pursuant to FCC regulations, you are
cautioned that any changes or modifications
not expressly approved in this manual could
void your authority to operate this
equipment.
(Continued)

4
Important
Safety
Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this receiver near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators,
heat registers, stoves, or other receiver (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety.
If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete
outlet.
10) Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
receiver.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the
receiver. When a cart is used, use caution when
moving the cart/receiver combination to avoid injury
from tip-over.
13) Unplug this receiver during lightning storms or when
unused for long periods of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the receiver has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the receiver, the receiver has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
USE
AC power cord and other cables
If you damage the AC power cord or other cables, it may result in a fire or
an electric shock. If the AC power cord or other cables is damaged, stop
using it at once and contact the Sony service center.
sDo not place the receiver where the power cord and cables are
subject to wear or abuse.
sDo not pinch, bend, or twist the cord excessively. The core lines may
be bared and cut, and cause a short-circuit, resulting in a fire or an
electric shock.
sDo not convert or damage the power cord and cables.
sDo not allow anything to rest on or roll over the power cord and
cables.
sDo not pull the power cord and cables.
sDo not move the receiver with the power cord and cables plugged in.
sKeep the power cord and cables away from heat sources.
sBe sure to grasp the plug when disconnecting the power cord and
cables.
Wall outlet
Do not use a poor fitting outlet.
Insert the plug fully into the outlet. If it is loose, it may
cause arcing and result in a fire.
Contact your electrician to have the outlet changed.
Cable wiring
For your safety, unplug the AC power cord when wiring cables.
Take care not to catch your feet on the cables. It may damage the receiver.
Electric shock
Do not touch the AC power cord or the receiver with
a wet hand. If you plug/unplug the AC power cord
from the receiver with a wet hand, it may cause
electric shock.
Lightning
For added protection for this receiver during a lightning storm, or when it
is left unattended and unused for long periods of time, unplug it from the
wall outlet. This will prevent damage to the receiver due to lightning and
power line surges.
Small accessories
Keep small accessories out of children's reach.
CLEANING
sClean the AC power plug regularly.
sIf the plug is covered with dust and it picks
up moisture, its insulation may deteriorate
and result in a fire.
sUnplug the AC power cord when cleaning
this receiver. If not, it may result in electric
shock.
sClean the casing of the receiver with a dry
soft cloth. Stubborn stains may be removed
with a cloth slightly moistened with a solution of mild soap and
warm water. Never use strong solvents such as thinner or benzine
for cleaning.
sIf using a chemically pretreated cloth, please follow the instruction
provided on the package.
sDust the ventilation holes with a dry cloth.

5
VENTILATION
The holes on the side of the receiver are provided for necessary ventilation.
To ensure reliable operation of the receiver, and to protect it from
overheating, these ventilation holes must never be blocked or covered.
Unless proper ventilation is provided, the receiver may gather dust and get
dirty. For proper ventilation, observe the following:
sNever block the ventilation holes by placing the receiver on a bed,
sofa, rug or other similar surface.
sNever place the receiver in a confined space, such as a bookcase or
built-in cabinet, unless proper ventilation is provided.
Objects and ventilation holes
Never push objects of any kind into the receiver through the ventilation
holes as they may touch dangerous voltage points or short out parts that
could result in a fire or an electric shock. Never spill liquid of any kind on
the receiver.
Do not place any objects on the receiver.
INSTALLATION
sThe receiver should be installed near an easily accessible power
outlet.
sDo not install the receiver in a hot or humid place, or in a place
subject to excessive dust or greasy vapor.
sAvoid operating the receiver at temperature below 41°F (5°C).
sWhen mounted to the back of TV, do not use the receiver as a handle
to pick up the TV set.
sMake sure that the cord and connected cables are placed so that
tripping or stumbling may be avoided.
SERVICING
Damage requiringservice
If the surface of the receiver cracks, do not touch the receiver until you
unplug the AC power cord.
Otherwise electric shock may result.
Servicing
Do not attempt to service the receiver yourself since opening the cabinet
may expose you to dangerous voltage or other hazards. Refer all servicing
to qualified service personnel.
Replacement parts
When replacement parts are required, be sure to have the
service technician certify in writing that he/she has used
replacement parts specified by the manufacturer that
have the same characteristics as the original parts.
Unauthorized substitutions may result in a fire, an
electric shock or other hazards.
Safety check
Upon completion of any service or repairs to the receiver, ask the service
technician to perform routine safety checks (as specified by the
manufacturer) to determine that the receiver is in safe operating condition,
and to so certify. Should the receiver not be repairable, ask a qualified
service technician to dispose of the receiver.
5

7
Contents
Getting Started
Welcome to the World of ®...........................................................................9
A Snapshot of the BRAVIA Internet Video Link ............................................................9
LED Indicators...........................................................................................................10
Settingup the BRAVIA Internet Video Link .................................................................11
Cable Connections....................................................................................................12
Connect to the Internet..............................................................................................13
Confirm Connection...................................................................................................15
Basic Remote Control Instruction ................................................................................16
Accessingthe Receiver on the XMB™.........................................................................16
Confirm Network Connection .......................................................................................17
Exiting Your Receiver................................................................................................19
Attachingthe Receiver to Your TV ...............................................................................20
Mounting to the Back of Your TV ..............................................................................20
Using the Receiver as a Stand-alone........................................................................25
Navigating with Your TV’s Remote Control
Remote Control ..............................................................................................................29
New Icons on the XMB™
Internet Video Menu......................................................................................................31
Video Menu ....................................................................................................................31
Network Menu................................................................................................................32
Internet Video Link Features
Internet Video Guide ......................................................................................................33
Video Playback..........................................................................................................34
My Video Links ..............................................................................................................35
Save this Link............................................................................................................35
View My Video Links .................................................................................................35
Remove this Link.......................................................................................................35
My Page...........................................................................................................................36
News .........................................................................................................................36
Messages ........................................................................................................................38
Reading Your Messages...........................................................................................39
Send from PC to TV .......................................................................................................40
Setting up Send from PC to TV.................................................................................40
Using Send from PC to TV........................................................................................41
Other Information
Usingthe HDMI Input Port.............................................................................................43
Updatingthe Receiver ...................................................................................................44
Device Information.........................................................................................................45
Optional Network Setup ............................................................................................46
Country and City List.....................................................................................................47
Troubleshooting.............................................................................................................49
Specifications.................................................................................................................51
Index................................................................................................................................53
Due to software updates, the screen images you see in this manual may differ from what you see on your TV.

9
Getting Started
Getting Started
Welcome to the World of ®
Thank you for purchasing this Sony BRAVIA Internet Video Link receiver.
This manual is for model DMX-NV1. The packing box contains accessories
that are listed on page 51.
For optimum picture performance, your BRAVIA TV with XMB
TM
(XrossMediaBar) and DMe
x
interface is capable of receiving high definition
programming through your high-speed Internet connection. (Broadband
Internet connection of at least 10 Mbps recommended for HD content.)
A Snapshot of the BRAVIA Internet Video Link
Item Description
1POWER LED Indicates the status of the receiver (see page 10).
2 NETWORK LED Indicates network connectivity and activity (see page
10).
3SERVICE Port For software update and future use.
4HDMI Input Port Connects to an additional HDMI device (e.g. HD-
DVR).
5HDMI OUT Port Connects to HDMI input on TV.
6 LAN Ethernet Port Connects to network device (e.g. router, wireless
bridge).
7DMexPort Connects to DMex/SERVICE input on TV.
8DC IN 9V Connects to the supplied AC adapter with AC cord.
HDMI input port 4works as a pass-through port which allows you to
connect an additional HDMI device (see page 43).
The BRAVIA Internet Video Link cannot be accessed through the TV’s
external inputs. Access it on the XMBTM. (See Accessingthe
Receiver on the XMBTM on page 16.)
OUT
LANDCIN 9V

NETWORK
INPUT
SERVICE




Getting Started
10
LED Indicators
Power LED Indicators
Green The receiver is powered on.
Orange (Blinking) The receiver is installing new software (do not
disconnect AC power).
Red (Blinking) Unable to connect to TV. Check cable
connections.
Network LED Indicators
Green The receiver is connected to the home network.
Green (Blinking) The receiver has network activity.
Make sure your home network is connected to the Internet.
Check the Troubleshooting section for additional information on
LED indicators.
1
NETWORK
Power LED
Network LED
1
NETWORK
