Sony STR-ZA3000ES User manual

MULTI CHANNEL AV RECEIVER
STR-ZA3000ES/STR-ZA2000ES/STR-
ZA1000ES
Preparation
Before using
Procedure to start using the receiver [1]
Supplied accessories [2]
Notes on installing the receiver [3]
Function for conversion of video signals [4]
Digital audio formats supported by the receiver [5]
Notes on connecting cables [6]
Using HDMI connections [7]
Installing and connecting speakers
Installing speakers [8]
Connecting speakers (for STR-ZA3000ES) [9]
Connecting speakers (for STR-ZA2000ES/STR-ZA1000ES) [10]
Connecting the speakers in zone 2 [11]
Connecting audio-visual devices and the antennas (aerials)
Connecting a TV (for STR-ZA3000ES) [12]
Connecting a TV (for STR-ZA2000ES/STR-ZA1000ES) [13]
Connecting devices with HDMI jacks (for STR-ZA3000ES) [14]
Connecting devices with HDMI jacks (for STR-ZA2000ES/STR-ZA1000ES) [15]
Connecting devices with jacks other than HDMI jacks [16]
Connecting the antennas (aerials) [17]
Connecting another amplifier in zone 2/3 [18]

Connecting to the network
System requirements for a wired LAN connection [19]
Connecting the receiver to the network (for STR-ZA3000ES) [20]
Connecting the receiver to the network (for STR-ZA2000ES/STR-ZA1000ES) [21]
Turning on the receiver/preparing the remote control
Inserting batteries into the remote control [22]
Turning on the receiver [23]
Initial setup of the receiver
Setting up the receiver using the Easy Setup [24]
Enjoying Video and Sound
Basic operations
Using the menu on the TV screen [25]
Enjoying video/sound from the connected device [26]
Listening to the radio
Listening to FM/AM radio [27]
Presetting FM/AM radio stations (Preset Memory) [28]
Tuning to a station directly (Direct Tuning) [29]
Changing the AM tuning scale [30]
Enjoying sound effects
Selecting a sound field (Sound Field) [31]
Resetting sound fields to the default settings [32]
Adjusting the equalizer (Equalizer) [33]
Enjoying clear and dynamic sound at a low volume (Sound Optimizer) [34]
Enjoying more natural sound with speakers installed in the ceiling (In-Ceiling Speaker
Mode) [35]

Enjoying high-fidelity sound (Pure Direct) [36]
Using the Multi-Zone Features
Enjoying sound in two rooms (multi-zone feature using the receiver with
2 pairs of speakers)
Connecting the speakers in zone 2 [37]
Setting the speakers for zone 2 [38]
Enjoying sound in zone 2/3 [39]
Enjoying sound in two rooms (multi-zone feature using the receiver and
another amplifier)
Connecting another amplifier in zone 2/3 [40]
Setting the volume control for zone 2/3 (Line Out) [41]
Setting the zone 2 HDMI audio output of connected devices (Zone2 Audio Out) [42]
Setting the priority for the main zone (Priority) [43]
Enjoying sound in zone 2/3 [44]
Using Other Features
Interlocking with BRAVIA TV and other devices (“BRAVIA” Sync)
What is “BRAVIA” Sync? [45]
Preparing for “BRAVIA” Sync [46]
Interlocking other devices using an HDMI connection (“BRAVIA” Sync) [47]
Configuring video and sound settings
Enjoying sound of TV broadcasts from the receiver [48]
Switching the monitors that output the HDMI video signals [49]
Switching between digital and analog audio (Input Mode) [50]
Using other video/audio input jacks (Input Assign) [51]
Saving and recalling various settings for the receiver (Custom Preset)

About Custom Preset [52]
Recalling the settings saved to the scene [53]
Saving the settings to a preset [54]
Items for which you can save settings and the default values for each item [55]
Configuring speaker settings
Adjusting the sound balance automatically (Auto Calibration) [56]
Using bi-amplifier connections [57]
Using the sleep timer
Using the sleep timer (Sleep) [58]
Checking information on the receiver
Viewing information on the display panel [59]
Adjusting Settings
Input Setup
Changing the assignment and display for the input jacks [60]
Changing the name for each input (Name) [61]
Speaker Setup
Performing automatic calibration (Auto Calibration) [62]
Calibrating the phase characteristics of the speakers (Automatic Phase Matching) [63]
Selecting the Auto Calibration type (Calibration Type) [64]
Selecting the speaker pattern (Speaker Pattern) [65]
Setting the assignment for the speaker terminals (SB Speaker Assign) [66]
Adjusting the speaker size (Size) [67]
Adjusting the speaker distance (Distance) [68]
Adjusting the speaker level (Level) [69]
Outputting a test tone from each speaker (Test Tone) [70]

Setting the crossover frequency of the speakers (Crossover Frequency) [71]
Adjusting the equalizer (Equalizer) [72]
Lifting up the sound of the center speaker (Center Speaker Lift Up) [73]
Setting the height from the floor to the ceiling speakers (Ceiling Speaker Height) [74]
Selecting the unit of measurement (Distance Unit) [75]
Network Setup
Setting up a network (Internet Setup) [76]
Checking the network information (Information) [77]
Enabling the network function even when this receiver is in standby mode (Network
Standby) [78]
Enjoying Hi-Fi System sound (Music Connect) [79]
Audio Setup
Playing audio signals with high-quality sound (Digital Legato Linear (D.L.L.)) [80]
Enjoying clear and dynamic sound at a low volume (Sound Optimizer) [81]
Selecting a sound field (Sound Field) [82]
Selecting the HD-D.C.S. effect type (HD-D.C.S. Type) [83]
Enjoying more natural sound with speakers installed in the ceiling (In-Ceiling Speaker
Mode) [84]
Enjoying high-fidelity sound (Pure Direct) [85]
Setting the low-pass filter for the subwoofer output (Subwoofer Low Pass Filter) [86]
Synchronizing audio with video output (A/V Sync) [87]
Selecting the language of digital broadcasts (Dual Mono) [88]
Compressing the dynamic range (Dynamic Range Compressor) [89]
HDMI Setup
Up-converting video signals to 4K (4K Scaling) [90]
Controlling HDMI devices (Control for HDMI) [91]
Passing HDMI signals through (Pass Through) [92]
Setting the HDMI audio signal output of connected devices (Audio Out) [93]
Setting the zone 2 HDMI audio output of connected devices (Zone2 Audio Out) [94]
Setting the level of the subwoofer (Subwoofer Level) [95]

Selecting the method to use the HDMI OUT B jack (HDMI Out B Mode) [96]
Setting the priority for the main zone (Priority) [97]
Speeding up the display when switching the HDMI input (Fast View) [98]
Zone Setup
Presetting the volume in the main zone (Main Preset Volume) [99]
Turning on/off the power for zone 2/3 (Power) [100]
Selecting the source signals for zone 2/3 (Input) [101]
Adjusting the volume for zone 2/3 (Volume) [102]
Presetting the volume in zone 2/3 (Zone2/3 Preset Volume) [103]
Setting the volume control for zone 2/3 (Line Out) [104]
System Setup
Selecting the language (Language) [105]
Tuning on/off the display for the volume level or sound field (Auto Display) [106]
Setting standby mode (Auto Standby) [107]
Changing the volume display (Volume Display) [108]
Switching the brightness of the display panel (Dimmer) [109]
Using the sleep timer (Sleep) [110]
Checking the software version (Software Version) [111]
Updating the software using the USB flash drive (USB Update) [112]
Setting the tuner (Tuner Setup) [113]
Install Setup
Turning on control mode for maintenance (External Control) [114]
Switching on/off the 12V trigger output (Trigger 1/2/3) (STR-ZA3000ES) [115]
Switching on/off the 12V trigger output (Trigger) (STR-ZA2000ES/STR-ZA1000ES) [116]
Displaying a test screen (Test Picture) [117]
Locking settings of the receiver (Settings Lock) [118]
Easy Setup
Setting up the receiver using the Easy Setup [119]

Using the menu on the display panel
Operating the receiver with the menu on the display panel [120]
Viewing information on the display panel [121]
Reverting to the factory default settings
Reverting to the factory default settings [122]
Parts and Controls
Receiver
Front panel [123]
Rear panel (STR-ZA3000ES) [124]
Rear panel (STR-ZA2000ES/STR-ZA1000ES) [125]
Indicators on the display panel [126]
Remote control
Remote control [127]
Announcements
Specifications
Specifications [128]
Supplied accessories [129]
Trademarks
Trademarks [130]
Software License Information
Software License Information [131]

Troubleshooting
Error messages
PROTECTOR [132]
UPDATE FAILED [133]
FAN STOPPED (for STR-ZA3000ES) [134]
List of messages after Auto Calibration measurements [135]
Network features message list [136]
Power
The receiver is turned off automatically. [137]
The receiver does not turn on after performing USB Update. [138]
No image appears on the TV. [139]
No 3D image appears on the TV. [140]
No 4K image appears on the TV. [141]
No image is output from the TV when the receiver is in standby mode. [142]
The GUI menu does not appear on the TV screen. [143]
The display panel is turned off. [144]
Sound
No sound or only a very low level of sound is heard, no matter which device is selected.
[145]
There is severe humming or noise. [146]
No sound or only a very low level of sound is heard from specific speakers. [147]
There is no sound from a specific device. [148]
The left and right sound is unbalanced or reversed. [149]
Dolby Digital or DTS multi-channel sound is not reproduced. [150]
The surround effect cannot be obtained. [151]
A test tone is not output from the speakers. [152]
A test tone is output from a different speaker than the speaker displayed on the TV

screen. [153]
No sound is output from the TV when the receiver is in standby mode. [154]
Tuner
The FM reception is poor. [155]
The FM stereo reception is poor. [156]
You cannot tune to radio stations. [157]
USB devices
A USB device is not recognized. [158]
A USB device cannot be connected to the USB port. [159]
Network connection
An error message appears. [160]
Cannot connect to the network. [161]
“BRAVIA” Sync (Control for HDMI)
The Control for HDMI function does not work. [162]
The Audio Return Channel (ARC) function does not work. [163]
Remote control
The remote control does not function. [164]
If the problem is not solved
Reverting to the factory default settings [165]
Resetting sound fields to the default settings [166]
Customer support websites [167]
[1] Preparation Before using
Procedure to start using the receiver

See the following topics in this order to start using the receiver properly.
1. Installing speakers
2. Connecting speakers (for STR-ZA3000ES)
Connecting speakers (for STR-ZA2000ES/STR-ZA1000ES)
3. Connecting a TV (for STR-ZA3000ES)
Connecting a TV (for STR-ZA2000ES/STR-ZA1000ES)
4. Connecting devices with HDMI jacks (for STR-ZA3000ES)
Connecting devices with HDMI jacks (for STR-ZA2000ES/STR-ZA1000ES)
5. Connecting devices with jacks other than HDMI jacks
6. Connecting the receiver to the network (for STR-ZA3000ES)
Connecting the receiver to the network (for STR-ZA2000ES/STR-ZA1000ES)
7. Attaching the front cover onto the front panel
8. Inserting batteries into the remote control
9. Turning on the receiver
10. Setting up the receiver using the Easy Setup
[2] Preparation Before using
Supplied accessories
Quick Setup Guide (1)
Startup Guide (1)
Reference Guide (1)
Remote control (1)
R03 (size AAA) batteries (2)
AC power cord (mains lead) (1)
AM loop antenna (aerial) (1)
FM wire antenna (aerial) (1)
(for USA and Canadian models)
(for other models)

Optimizer microphone (1)
Front cover (1)
[3] Preparation Before using
Notes on installing the receiver
Do not install the appliance in a confined space, such as a bookcase.
Sufficient space around the receiver is needed to release heat. When placing the receiver
in a rack, leave more than 44.45 mm (1.75 in) space above the receiver, and more than
44.45 mm (1.75 in) space along the sides of the receiver. The rack behind the receiver
should be open. If you place the receiver with its back against the wall, leave more than
88.9 mm (3.5 in) space between the receiver and the wall.
Make sure to use a “WS-RE1” dedicated rack mount kit for this receiver when mounting
the receiver on a rack mount.
Place the receiver in a location with adequate ventilation to prevent heat buildup and
prolong the life of the receiver.
Do not place the receiver near heat sources, or in a place subject to direct sunlight,
excessive dust, or mechanical shock.
Do not place anything on top of the cabinet that might block the ventilation holes and
cause malfunctions.
Magnets are attached to both the front panel and front cover. Do not place cards with
magnetic stripes, such as bank cards or ID passes, near the receiver. These cards may
become unusable due to the effects of the magnets on the receiver.
[4] Preparation Before using
Function for conversion of video signals
The receiver is equipped with a function for converting video signals. Video signals and
component video signals can be output as HDMI video signals (*1).
The correspondence of the INPUT jacks to the OUTPUT jacks is shown below.
HDMI IN:HDMI OUT
COMPONENT VIDEO IN:HDMI OUT (*1), COMPONENT VIDEO MONITOR OUT (*2)

VIDEO IN:HDMI OUT (*1), MONITOR VIDEO OUT (*2), ZONE2 VIDEO OUT (*2)
*1 Video signals are upconverted and upscaled (up to 4K) when outputting to HDMI OUT A jack.
Video signals are upconverted but video resolution is the same as the input video source when
outputting to HDMI OUT B jack.
*2 The same type of signal as the input signal is output.
Note
When video signals from a VCR, etc., are upconverted on this receiver and then viewed
on your TV, the image on the TV screen may appear distorted horizontally or no image
may be seen depending on the status of the video signal output.
If you are using image improvement circuitry with your VCR, it may impact the video
signal conversion. It is recommended that you turn off this function on your VCR.
Converted HDMI image output does not support “x.v.Color,” Deep Color, or 3D.
HDMI video signals cannot be converted to component video signals or video signals.
1080p component video signals cannot be upconverted.
When [4K Scaling] is set to [Auto], if the HDMI input signals are [email protected]/24 Hz and
a 4K-compatible TV is connected to HDMI OUT A jack, the HDMI input signals are
automatically upscaled to 4K images and output from the HDMI OUT A jack.
When [HDMI Out B Mode] is set to [Zone2], component video signals or video signals
selected in zone 2 can be output from the HDMI OUT B jack.
If you select different component video signals or video signals in the main zone and
zone2 when [HDMI Out B Mode] is set to [Zone2], only audio signals can be output from
HDMI OUT B jack and the screen will blackout.
[5] Preparation Before using
Digital audio formats supported by the receiver
The digital audio formats that this receiver can decode depend on the digital audio output
jacks of the connected device. This receiver supports the following audio formats. The words
in brackets are those indicated on the display panel.
Dolby Digital [DOLBY DIGITAL]
Maximum number of channels: 5.1
Connection with the receiver: COAXIAL/OPTICAL, HDMI
Dolby Digital EX [DOLBY DIGITAL EX]
Maximum number of channels: 6.1
Connection with the receiver: COAXIAL/OPTICAL, HDMI
Dolby Digital Plus [DOLBY DIGITAL+](*)

Maximum number of channels: 7.1
Connection with the receiver: HDMI
Dolby TrueHD [DOLBY TrueHD](*)
Maximum number of channels: 7.1
Connection with the receiver: HDMI
DTS [DTS]
Maximum number of channels: 5.1
Connection with the receiver: COAXIAL/OPTICAL, HDMI
DTS-ES Discrete [DTS-ES Dscrt]
Maximum number of channels: 6.1
Connection with the receiver: COAXIAL/OPTICAL, HDMI
DTS-ES Matrix [DTS-ES Mtrx]
Maximum number of channels: 6.1
Connection with the receiver: COAXIAL/OPTICAL, HDMI
DTS 96/24 [DTS 96/24]
Maximum number of channels: 5.1
Connection with the receiver: COAXIAL/OPTICAL, HDMI
DTS-HD High Resolution Audio [DTS-HD HI RES](*)
Maximum number of channels: 7.1
Connection with the receiver: HDMI
DTS-HD Master Audio [DTS-HD MSTR](*)
Maximum number of channels: 7.1
Connection with the receiver: HDMI
DSD [DSD] (*)
Maximum number of channels: 5.1
Connection with the receiver: HDMI
Multi Channel Linear PCM (*) [LINEAR PCM]
Maximum number of channels: 7.1
Connection with the receiver: HDMI
*Audio signals are output in another format if the playback device does not correspond to the
actual format. For details, refer to the operating instructions of the playback device.
[6] Preparation Before using
Notes on connecting cables

Be sure to disconnect the AC power cord (mains lead) before connecting cables.
It is not necessary to connect all of the cables. Connect cables according to the
availability of jacks on the connected device.
Use a High Speed HDMI cable. 1080p, Deep Color, 4K or 3D images may not be
displayed properly if you use a Standard HDMI cable.
We do not recommend using an HDMI-DVI conversion cable. If you connect an HDMI-DVI
conversion cable to a DVI-D device, the sound and/or image may be lost. Connect
separate audio cables or digital connecting cables, then reassign the input jacks if the
sound is not output correctly. For details, see “Using other video/audio input jacks (Input
Assign).”
When connecting optical digital cables, insert the plugs straight until they click into place.
Do not bend or tie optical digital cables.
Hint
All of the digital audio jacks are compatible with 32 kHz, 44.1 kHz, 48 kHz, and 96 kHz
sampling frequencies.
If you want to connect several digital devices, but cannot find an unused
input
See “Using other video/audio input jacks (Input Assign).”
[7] Preparation Before using
Using HDMI connections
High-Definition Multimedia Interface (HDMI) is an interface that transmits video and audio
signals in digital format. Connecting devices made by Sony that are “BRAVIA” Sync-
compatible makes operations simpler. See “Interlocking other devices using an HDMI
connection (“BRAVIA” Sync).”
HDMI features
Digital audio signals transmitted by HDMI can be output from the speakers and the PRE
OUT jacks on this receiver (the PRE OUT jacks are only for STR-ZA3000ES). This signal
supports Dolby Digital, DTS, DSD, and Linear PCM. For details, see “Digital audio formats
supported by the receiver.”
The receiver can receive Multi Channel Linear PCM (up to 8 channels) with a sampling
frequency of 192 kHz or less via an HDMI connection.
Analog video signals input to the VIDEO jack or COMPONENT VIDEO jacks can be
output as HDMI signals. Audio signals input to the OPTICAL IN, COAXIAL IN and
ANALOG IN jacks can be output as HDMI signals with converted analog video signals

from the HDMI OUT B jack when [HDMI Out B Mode] is set to [Zone2].
This receiver supports High Bitrate Audio (DTS-HD Master Audio, Dolby TrueHD), Deep
Color, “x.v.Color,” and 4K or 3D transmission.
To enjoy 3D images, connect a 3D-compatible TV and video device (Blu-ray Disc Player,
Blu-ray Disc recorder, PlayStation 3, etc.) to the receiver using High Speed HDMI cables,
put on 3D glasses, and then play 3D-compatible content.
To enjoy 4K images, connect a 4K-compatible TV or video device (Blu-ray Disc Player,
etc.) to the receiver using High Speed HDMI cables, and then play 4K-compatible
content.
The HDMI jacks designated as being “HDCP 2.2” support High-bandwidth Digital Content
Protection System Revision 2.2 (HDCP 2.2). Connect these HDMI jacks to jacks that
support HDCP 2.2 on a TV or a player. Refer to the operating instructions of the
connected device for details.
Note
Depending on the TV or video device, 4K or 3D images may not be displayed. Check the
HDMI video formats supported by the receiver.
Refer to the operating instructions of each connected device for details.
[8] Preparation Installing and connecting speakers
Installing speakers
This receiver allows you to use up to a 7.2-channel system (7 speakers and two
subwoofers).
Typical examples of speaker system configurations are as follows.
5.1-channel speaker system
To fully enjoy theater-like multi-channel surround sound, you need five speakers (two front
speakers, a center speaker, and two surround speakers) and a subwoofer.
7.1-channel speaker system using surround back speakers
You can enjoy high-fidelity reproduction of recorded sound from a DVD or Blu-ray Disc in
6.1-channel or 7.1-channel format.
5.1 -channel speaker system and zone 2
If you make a 5.1ch connection in the main zone, you can also enjoy the sound in another
location (“Zone 2”) by connecting additional zone 2 speakers.
Note
You cannot use the surround back speakers and the front high speakers simultaneously.

[9] Preparation Installing and connecting speakers
Connecting speakers (for STR-ZA3000ES)
Connect each speaker as illustrated below.
Be sure to disconnect the AC power cord (mains lead) before connecting cables.
For details on how to connect speaker cables to the receiver, see “How to connect speaker
cables.”
Monaural audio cable (not supplied)
Speaker cable (not supplied)
*1 If you connect a subwoofer with an auto standby function, turn off this function when watching
movies. If the auto standby function is turned on, it switches to standby mode automatically based
on the level of the input signal to the subwoofer, and the sound may not be output.
*2 Notes on connections to the SPEAKERS SURROUND BACK/FRONT HIGH/FRONT B/BI-
AMP/ZONE 2 terminals
If connecting only one surround back speaker, connect it to the L (+/-) terminals.
If you have an additional front speaker system, connect it to these terminals. In this case,
perform the following procedure:

1. Select [Speaker Pattern] in the Speaker Setup menu, then select a speaker pattern
that does not have surround back and front high speakers.
2. Set [SB Speaker Assign] in the Speaker Setup menu to [Front B].
You can select the front speaker system you want by using the SPEAKERS button on the
receiver.
You can connect the front speakers to this terminal using a bi-amplifier connection. In this
case, set [SB Speaker Assign] in the Speaker Setup menu to [Bi-Amp].
Note
After you have installed and connected your speakers, be sure to select the speaker
pattern you want using [Speaker Pattern] in the Speaker Setup menu.
[10] Preparation Installing and connecting speakers
Connecting speakers (for STR-ZA2000ES/STR-
ZA1000ES)
Connect each speaker as illustrated below.
Be sure to disconnect the AC power cord (mains lead) before connecting cables.
For details on how to connect speaker cables to the receiver, see “How to connect speaker
cables.”

Monaural audio cable (not supplied)
Speaker cable (not supplied)
*1 If you connect a subwoofer with an auto standby function, turn off this function when watching
movies. If the auto standby function is turned on, it switches to standby mode automatically based
on the level of the input signal to the subwoofer, and the sound may not be output.
*2 Notes on connections to the SPEAKERS SURROUND BACK/FRONT HIGH/FRONT B/BI-
AMP/ZONE 2 terminals
If connecting only one surround back speaker, connect it to the L (+/-) terminals.
If you have an additional front speaker system, connect it to these terminals. In this case,
perform the following procedure:
1. Select [Speaker Pattern] in the Speaker Setup menu, then select a speaker pattern
that does not have surround back and front high speakers.
2. Set [SB Speaker Assign] in the Speaker Setup menu to [Front B].
You can select the front speaker system you want by using the SPEAKERS button on the
receiver.
You can connect the front speakers to this terminal using a bi-amplifier connection. In this
case, set [SB Speaker Assign] in the Speaker Setup menu to [Bi-Amp].
Note
After you have installed and connected your speakers, be sure to select the speaker
pattern you want using [Speaker Pattern] in the Speaker Setup menu.
[11] Preparation Installing and connecting speakers
Connecting the speakers in zone 2
You can enjoy sound from a device connected to the receiver in a zone other than the main
zone. For example, you can watch a DVD in the main zone and listen to a CD in zone 2.
Connect each speaker as illustrated below.
Be sure to disconnect the AC power cord (mains lead) before connecting cables. For details
on how to connect speaker cables to the receiver, see “How to connect speaker cables.”

TV
HDMI cable (not supplied)
Speakers
Speaker cable (not supplied)
Note
The following settings are required for this connection.
Set [HDMI Out B Mode] in the HDMI Setup menu to [Zone2]
Set [Zone2 Audio Out] in the HDMI Setup menu to [Zone2 TV + AMP]
Turn the volume of the TV down or set [Zone2 Audio Out] in the HDMI Setup menu to
[AMP] if you do not want to output sound from the TV in zone 2.
You cannot remedy the time gap between video on zone 2 TV and audio from zone 2
speakers using the A/V Sync function.
When using this zone 2 connection, you need to set up the SPEAKERS SURROUND
BACK/FRONT HIGH/FRONT B/BI-AMP/ZONE 2 terminals. For details, see “Setting the
speakers for zone 2.”
[12] Preparation Connecting audio-visual devices and the antennas (aerials)
Connecting a TV (for STR-ZA3000ES)
Connect a TV to the HDMI OUT or MONITOR VIDEO OUT jack. You can operate this
receiver using a GUI (Graphical User Interface). GUI is used only for HDMI OUT A jack.
Be sure to disconnect the AC power cord (mains lead) before connecting cables.
To watch 4K resolution content
The HDMI jacks designated as being “HDCP 2.2” (HDMI IN 2/IN 3, HDMI OUT A/OUT B)
support High-bandwidth Digital Content Protection System Revision 2.2 (HDCP 2.2).

Connect these HDMI jacks to jacks that support HDCP 2.2 on a TV or a player. Refer to the
operating instructions of the connected device for details.
Connecting a TV compatible with the Audio Return Channel (ARC)
function via an HDMI connection
To use the ARC function, set [HDMI Out B Mode] to [Main] and [Control for HDMI] to [On].
HDMI cable (not supplied)
Sony recommends that you use an HDMI-authorized cable or HDMI cable made by Sony.
Connecting a TV and a projector
HDMI cable (not supplied)
Sony recommends that you use an HDMI-authorized cable or HDMI cable made by Sony.
Note
For this connection, set [HDMI Out B Mode] in the HDMI Setup menu to [Main].
Connecting a TV incompatible with the Audio Return Channel (ARC)
function via an HDMI connection
The solid lines show recommended connections and the dashed lines show alternative
connections.
