Sony RM-AV2000T User manual

Sony Corporation Printed in Japan
Index
A
Aanleerfunctie 12
Automatisch uitschakelen
van de afstandsbediening 32
van de schermverlichting 33
B
Batterijen 5
Blokkeren van de toetsen 30
C, D, E, F
Codenummers 7
COMMANDER OFF uitschakeltoets 6
Component-keuzetoetsen
toevoegen van een extra functie 23
toewijzen van andere apparatuur 26
G
Geluiddempingstoets (¤) 6, 18
Geluidssterkte regelen 6, 17
Geluidssterktetoetsen (Á+/–) 6, 17
H, I, J, K
Hold beveiliging 30
Inschakelcommando
SYSTEM CONTROL toetsen 18
Toevoegen aan de component-
keuzetoetsen 23
L, M, N, O
LCD scherm
automatische uitschakeltijd 33
helderheid 33
P, Q, R
Preset Lock beveiliging 31
PROGRAM zenderkeuzetoets 6
S
Schermverlichting
batterijen voor 5
bijregelen 33
Schermverlichtingstoets ( ) 6, 33
SYSTEM CONTROL toetsen
bedieningsreeksen 18
programmeren voor vaak gebruikte
functies 28
T, U
Toewijzen van andere apparatuur aan de
component-keuzetoetsen 26
Uitschakelcommando
Zie “Systeem-uitschakelfunctie” 19
V
Verhelpen van storingen 35
Vooringestelde componenten 7
W, X, Y, Z
Wijzigen/wissen
aangeleerde signalen 15, 25, 29
bedieningsreeks (SYSTEM CONTROL)
21
Wissen
Zie “Wijzigen/wissen”.

3-862-793-11(1)
Integrated Remote
Commander
© 1998 by Sony Corporation
RM-AV2000T
Operating Instructions
Gebruiksaanwijzing NL
EN

2EN
Welcome!
The RM-AV2000T Remote Commander provides centralized control of all your AV
components from a single remote commander and saves the trouble of operating
differentAV components with different remote control devices. The following are its
main features.
Centralized control of Sony AV components with this one remote commander
This Commander is preset at the factory to operate Sony brand components, so you can
use it out of the box as a control center for your Sony AV components.
Remote control signals for non-Sony components are also preset
This Commander is preset for most major brands components including Sony. You can
remote control your components by setting their code numbers.
Learning function for programming other remote control signals you need
This Commander has a learning function, to learn remote control signals to operate
non-preset components or functions. In addition, the Commander can learn remote
control signals (infrared signals only) of non-Audio Visual components such as air-
conditioners, lights, etc. (some specific appliances or functions may not be available).
Reassigning new components
You can assign Component Select Buttons to freely operate other components. This is
useful when you have more than two of the same kind of AV components.
System Control function allows one-touch operation to execute a series of
commands
You can program up to 16 consecutive operation steps to execute a series of operations
by pressing a single button.
Easy-to-operate touch key LCD with blue back light
This Commander has a touch key LCD that changes the key display according to the
selected component. The Commander is easy to operate as only the keys necessary to
operate the selected component are displayed. The display backlight allows operation
even in the dark.
The CE mark on the unit is valid only for products marketed in the European
Union.

3EN
Table of Contents
Getting Started
Installing the Batteries ......................................................................................................... 5
When to replace the batteries.............................................................................................. 5
Location and Function of Controls ....................................................................................... 6
Basic Operations
Setting the Code for PresetAudio andVisual Components ................................................. 7
Setting a Component Code ................................................................................................. 8
Checking if the code number works .................................................................................. 9
OperatingYour Components with the Remote Commander .............................................. 10
Using Non-Preset Remote Control Operations — Learning Function ................................ 12
Changing or erasing the function of a learned key or button ...................................... 15
Advanced Features
Controlling theVolume ofVisual Components Connected to anAudio System................. 17
Executing a Series of Commands — System Control Function .......................................... 18
Programming a series of commands to the SYSTEM CONTROL buttons ................ 19
Executing the programmed commands .......................................................................... 20
Changing the programmed commands .......................................................................... 21
Adding an Extra Function to the Component Select Buttons............................................. 23
Programming the Power-On Command of the Selected Component (for Sony
Components only) ........................................................................................................... 23
Adding a Command that is Required when Selecting a Component ........................ 24
Turning Off the Power of All Components by a Single Button Operation
— System Power-Off Function (for Sony Components only) ........................................... 25
Assigning Other Components to the Component Select Buttons ...................................... 26
Programming a Frequently Used Key Operation to SYSTEM CONTROL Buttons ................ 28
Continued
EN

4EN
Using Other Functions
Locking the Controls — Hold Function............................................................................... 30
Protecting your settings and “learned” signals — Preset Lock Function .......................... 31
Changing the Auto Power-Off Time of the Commander ..................................................... 32
Adjusting the Backlight of the Display Window ................................................................. 33
Additional Information
Precautions ......................................................................................................................... 34
Maintenance ....................................................................................................................... 34
Specifications...................................................................................................................... 34
Troubleshooting .................................................................................................................. 35
Appendix
Table of Preset Functions.................................................................................................... 37
TV.......................................................................................................................................... 37
VCR 1, 2, 3 ........................................................................................................................... 37
DVD (DVD player) ............................................................................................................. 38
VD (LD player) ................................................................................................................... 38
SAT (Satellite tuner) ...........................................................................................................39
CBL (Cable box) .................................................................................................................. 39
AMP (Amplifier).................................................................................................................40
CD (CD player) ................................................................................................................... 40
MD deck............................................................................................................................... 41
DAT deck ............................................................................................................................. 41
DECK B/A(Tape deck) ..................................................................................................... 42
FM/AM (TUNER) (FM/AM tuner) ................................................................................ 42
DSP (Digital Surround Processor).................................................................................... 42
Quick Reference of Operations........................................................................................... 43
Index ................................................................................................................................... 44
Table of Contents
(continued)

5EN
Getting Started
Installing the Batteries
Slide open the battery compartment lid
and insert six R6 (size AA) batteries (not
supplied). Be sure to line up the + and –
on the batteries with the + and – on the
battery compartment.
When to replace the batteries
Batteries for remote control
operation (Four R6 (size AA)
batteries)
Under normal conditions, batteries will
last up to six months. If the Commander
does not operate properly, batteries
might be worn out and iis displayed
on the LCD touch panel. When the
display dims, replace the batteries with
new ones.
Note
Do not take more than one hour to replace the
batteries; otherwise, your setting of the code
numbers (page 7) and learned remote control
signals (page 12) will be erased.
Batteries for backlight (Two R6
(size AA) batteries)
When the backlight for the touch keys
grows dim, replace its batteries.
Notes on batteries
• Do not mix old batteries with new ones or
mix different types of batteries together.
• If the electrolyte inside the battery should
leak, wipe the contaminated area of the
battery compartment with a cloth and replace
the old batteries with new ones. To prevent
the electrolyte from leaking, remove the
batteries when you plan not to use the
Commander for a long period of time.
(for backlight) (for remote control
operation)
}
}]
}
]
}
]
]
}
]
}
]

6EN
5COMMANDER OFF button
Turns the power of the Commander
off.
6Component Select buttons
Selects the component to control.
7Á+/– buttons*
Adjust the volume.
8¤button*
Mutes the volume.
9PROGRAM + +/ – =buttons
Select the programme.
* The Commander controls or mutes the TV’s
volume when you select a visual component.
The Commander controls or mutes the
amplifier’s volume when you select an audio
component.
You can change this setting also (page 17).
Note on the power on and off of the
Remote Commander
To turn on the power, press any button except
the COMMANDER OFF button.
To turn off, press COMMANDER OFF, or if
you don’t use the Commander, it automatically
turns off after 10 minutes. This interval can
also be changed (page 32).
To turn off the key touch
confirmation beep
Press the ≥key. “OFF” is displayed and the
Commander no longer makes the key touch
confirmation beep. To switch the key touch
confirmation beep back on, press the ≥key
again.
Location and Function
of Controls
1Component display area
Displays the name of the component
selected.
2LCD touch key display
The keys used for operating each
component are displayed.
Note
Do not press the touch keys using sharp
objects such as pins or ball-point pens.
3SYSTEM CONTROL buttons
(page 18)
You can program up to 16 consecutive
key operations to each of the three
SYSTEM CONTROL buttons . You
can automatically carry out the entire
program by pressing one button.
4button
Used to light up the LCD display in
the dark. Press the button once to
turn on the light, and once again to
turn it off. You can also set the
backlight to go off automatically after
a certain period of time (page 33).
SYSTEM CONTROL COMMANDER
OFF
e
TV VCR1 VCR2 VCR3 DVD SAT/CBL
AMP CD MD/DAT DECK B/A TUNER DSP
PROGRAM
Á
–
+
–
+
=
+
123
¤
1
2
3
4
5
6
7
8
9

7EN
Basic Operations
Setting the Code for
Preset Audio and Visual
Components
The Commander is preset at the factory
to operate Sony brand AV components
(see the table below). If you are using the
Commander with factory-set Sony
components, skip the following
procedures.
You can use the Commander with other
preset AV components also. To use with
other AV components, you need to follow
the procedures to set the correct codes for
each component.
* Analog audio compact cassette deck
Component
Select
Button
TV
VCR1
VCR2
VCR3
DVD
SAT/CBL
AMP
CD
MD/DAT
DECK B/A
TUNER
DSP
Factory setting
Sony TV
Sony Beta VCR
(VTR1)
Sony 8mm VCR
(VTR2)
Sony VHS VCR
(VTR3)
Sony DVD
player
Sony satellite
tuner
Sony amplifier
Sony CD player
Sony MD deck
Sony cassette
deck
Sony FM/AM
tuner
Sony digital
surround
processor
Preset
component(s)
TV
VCR
VCR
VCR
DVD player
(DVD)/LD
player (VD)
Satellite tuner
(SAT)/Cable
box (CBL)
Amplifier
CD player
MD deck/DAT
deck
Cassette deck*
FM/AM tuner
Surround
processor
See “Table of Preset Functions” (page 37)
for the functions of keys and buttons as
for each component.
Continued

8EN
3Press the Component Select
button* for the desired
component.
The selected component remains
displayed, and the 0 – 9, ENTER and
DISPLAY keys flash.
* When you set the component code of the
DVD or SAT/CBL button, press
repeatedly until the desired component is
displayed.
4Press the double digit component
code number followed by the
ENTER key on the touch-key
display.
A beep sounds, and the code numbers
and “ENTER” appear twice.
TV
TV
123
456
78
0
9
ENTER
DISPLAY
123
456
78
0
9
ENTER
1
m
1
m
ENTER
Example: To set up a Philips’ TV
1See the tables in the supplied
“Component Code Numbers”,
and find the double digit code
number for the desired
component.
If more than one code number is
listed, use the number that is listed
first.
For example, to set up a Philips’ TV,
you would use the code number 11.
2While pressing COMMANDER
OFF, press ¤.
All the component names in the
display flash.
COMMANDER
OFF +
¤
TV VCR123 SAT DECK AB
CD FM/AM DSPMD CBLAMP DVD
Setting a Component Code
Setting the Code for Preset Audio
and Visual Components
(continued)
SYSTEM CONTROL COMMANDER
OFF
e
TV VCR1 VCR2 VCR3 DVD SAT/CBL
AMP CD MD/DAT DECK B/A TUNER DSP
CHANNEL
Á
–
+
–
+
=
+
123
¤
TV
123
456
78
0
9
ENTER
DISPLAY
4
32
6

9EN
5If you want to set a code for
another component, repeat Steps
3 and 4.
6Press COMMANDER OFF.
Notes
• If you press a component code number that is
not on the table in the supplied “Component
Code Numbers”, the Commander beeps and
“NG” flashes after you press the ENTER key.
If this happens,check the component code
number, and try setting again.
• If you don’t input anything into the
Commander for over two minutes between
each step, the setup procedure will be
canceled. To set the code, you must again
press ¤while pressing COMMANDER OFF.
To check which code number is
set
Press the DISPLAY key. The code
number and “ENTER” appear twice.
COMMANDER
OFF
Checking if the code number
works
1Press the corresponding
Component Select button for the
component you have set up.
The Commander turns on and the
touch-keys appear on the display.
2Power on the component with its
power switch.
3Aim the Commander at the
component and press the ukey
in the touch-key display.
When the remote control signal is
sent, is displayed on the display.
The component should power off.
TV
u
Continued
TV
123
456
78
0
9
-/--
1 -
RED
YELLOW
TELETEXT
BLUE
INPUT
u
GREEN
TV
