Sony BKS-R3219A User guide

BKS-R1617A
INSTALLATION AND SYSTEM SETUP MANUAL
1st Edition (Revised 1)
Serial No. 10001 and Higher: BKS-R3219A
Serial No. 10001 and Higher: BKS-R1617A
32 BUTTON REMOTE PANEL
BKS-R3219A
16 BUTTON LED REMOTE PANEL

!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all servicing to
qualified service personnel.
!WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin
de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les
réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.
Pour toute réparation faire appel à une personne compétente uniquement.
BKS-R3219A/R1617A I&SSM

BKS-R3219A/R1617A I&SSM
Attention-when the product is installed in Rack:
1. Prevention against overloading of branch circuit
When this product is installed in a rack and is
supplied power from an outlet on the rack, please
make sure that the rack does not overload the supply
circuit.
2. Providing protective earth
When this product is installed in a rack and is
supplied power from an outlet on the rack, please
confirm that the outlet is provided with a suitable
protective earth connection.
3. Internal air ambient temperature of the rack
When this product is installed in a rack, please make
sure that the internal air ambient temperature of the
rack is within the specified limit of this product.
4. Prevention against achieving hazardous
condition due to uneven mechanical loading
When this product is installed in a rack, please make
sure that the rack does not achieve hazardous
condition due to uneven mechanical loading.
5. Install the equipment while taking the operating
temperature of the equipment into consideration
For the operating temperature of the equipment, refer
to the specifications of the Operation Manual.
6. When performing the installation, keep the
following space away from walls in order to
obtain proper exhaust and radiation of heat.
Rear: 10 cm (4 inches) or more
WARNING
This unit has no power switch.
When installing the unit, incorporate a readily
accessible disconnect device in the fixed wiring, or
connect the power cord to a socket-outlet which must be
provided near the unit and easily accessible, so that the
user can turn off the power in case a fault should occur.
WARNUNG
Dieses Gerät hat keinen Netzschalter.
Beim Einbau des Geräts ist daher im Festkabel ein
leicht zugänglicher Unterbrecher einzufügen, oder das
Netzkabel mu
ß mit einer in der Nähe des Geräts
befindlichen, leicht zugänglichen Wandsteckdose
verbunden werden, damit sich bei einer
Funktionsstörung die Stromversorgung zum Gerät
jederzeit unterbrechen lä
ß t.
BKS-R3219A/R1617A I&SSM
1 (P)

1
BKS-R3219A/R1617A I&SSM
Table of Contents
Manual Structure
Purpose of this manual ................................................................. 3
Related manuals ........................................................................... 3
Trademarks ................................................................................... 3
1. Overview
1-1. What is the Routing Switcher System? ..........................1-1
1-2. Functions of the Routing Switcher System ....................1-1
1-3. Compatibility between the S-BUS P1 (S-P1) Type
and S-BUS P2 (S-P2) Type ............................................ 1-2
1-4. Constituent Devices of Routing Switcher System .......... 1-3
1-5. Controls by Routing Switcher System ............................ 1-4
1-5-1. Specifications and Functions of Control Port .......1-4
1-5-2. S-BUS Control ...................................................... 1-5
1-5-3. RS-422A Control ................................................... 1-7
1-6. System Connection Example .......................................... 1-8
1-6-1. S-BUS Control System Connection Example ....... 1-8
1-6-2. REMOTE2 (RS-422A) Control System
Connection Example ............................................. 1-9
2. Installation
2-1. Installation Procedure ..................................................... 2-1
2-2. Operating Environment .................................................. 2-2
2-3. Power Supply ..................................................................2-2
2-4. Installation Space ............................................................ 2-3
2-5. Rack Mounting ............................................................... 2-4
2-6. For Use in an OB Van ....................................................2-4
2-7. Matching Connectors ......................................................2-4
2-8. Input and Output Signals of Connectors ......................... 2-5
2-9. Setting the On-Board Switches and
Description of LEDs .......................................................2-6
2-10. Attach the Key Label ......................................................2-7
2-10-1. Key Label Indications ........................................... 2-7
2-10-2. How to Attach the Key Label ................................ 2-8
2-11. Settings by Using the Buttons (Setup Function) ............. 2-8
2-11-1. Setting the Station Number ...................................2-8
2-11-2. Setup Operations ................................................... 2-9
2-11-3. List of Setup Operations ...................................... 2-10
3. Settings
3-1. Outline ............................................................................ 3-1
3-1-1. Flow of Settings ....................................................3-1
3-1-2. Symbols Used in This Manual ..............................3-3
3-2. Preparation ...................................................................... 3-3
3-3. Display Screens, and Moving between
the Display Screens ......................................................... 3-5
3-4. Setting Items of the Secondary Station ........................... 3-8
4. Confirmation of Function
4-1. Outline ............................................................................ 4-1
4-2. Function Check ............................................................... 4-1
4-2-1. Function Check after Power On ............................4-2
4-2-2. Function Check with Menu Item
[V : DISPLAY UNIT STATUS] ........................... 4-2
4-2-3. Function Check with Menu Item
[W : SYSTEM STATUS LOG] ............................4-2
4-2-4. System Status Log ................................................. 4-2
5. Technical Information
5-1. Route Function ................................................................ 5-1
5-1-1. Outline ................................................................... 5-1
5-1-2. Example of Using Route Function ........................5-2
5-1-3. Relationship With Z: SET PANEL STATUS
Setting Items .......................................................... 5-5
5-1-4. Restrictions ............................................................ 5-5
5-2. Multiple Terminal Name Function ................................. 5-6
5-3. Virtual Monitor Function ................................................ 5-8
5-3-1. Overview ............................................................... 5-8
5-3-2. Configuring the Settings ........................................ 5-9
5-3-3. Panel Display ......................................................... 5-9
6. Service Overview
6-1. Error Messages ............................................................... 6-1
6-2. Data Backup .................................................................... 6-2

3
BKS-R3219A/R1617A I&SSM
Manual Structure
Purpose of this manual
This manual is the installation and system setup manual of following models.
32 Button Remote Panel BKS-R3219A
16 Button LED Remote Panel BKS-R1617A
This manual is intended for use by trained system and service engineers, and
describes the information on setting the BKS-R3219A/R1617A.
Related manuals
The following manuals are prepared for this unit.
..
..
.Operation Guide (Supplied with the unit)
This manual describes the cautions on the operation of this unit and the setting of
station numbers.
..
..
.Operation Manual (Available on request)
This manual describes the detailed information on how to operate this unit.
The operation manual is stored as a PDF file in the CD-ROM supplied with the
IXS-6600-C/IXS-6700-C.
If this manual is required, please contact your local Sony Sales Office/Service
Center.
..
..
.Maintenance Manual (Available on request)
This manual describes the information that premises the parts level service
(parts replacement, parts list, diagrams, etc.).
If this manual is required, please contact your local Sony Sales Office/Service
Center.
..
..
.Protocol Manual (Available on request)
This manual describes the protocol for controlling this unit.
If this manual is required, please contact your local Sony Sales Office/Service
Center.
SONY ROUTING SWITCHER SYSTEM
REMOTE1 (S-BUS/ROT16) PROTOCOL and COMMAND SPECIFICATIONS
Part No.: 9-977-477-xx
SONY ROUTING SWITCHER SYSTEM
REMOTE2 (Cart++) PROTOCOL and COMMAND SPECIFICATIONS
Part No.: 9-967-261-2x
Trademarks
Trademarks and registered trademarks used in this manual are follows.
.Ethernet is a registered trademark of Xerox Corporation.
.Windows and MS-DOS are registered trademarks of Microsoft Corporation.
. IBM and AT are registered trademarks of International Business Machine Corporation.

1-1
BKS-R3219A/R1617A I&SSM
Section 1
Overview
1-1. What is the Routing Switcher
System?
Routing switcher system is the system that has the func-
tions of switching and control of signals using routing
switchers.
The main devices that constitute the integrated routing
system
.Routing switcher
.Remote control panel (routing switcher control unit)
.Personal computer
1-2. Functions of the Routing Switcher
System
The routing switcher system has the following functions.
For details, refer to the System Setup Manual correspond-
ing to each routing switcher.
..
..
.Secret function
This is the function that hides certain input channels
from all remote control panels to protect the cross-point
so that it cannot be switched.
..
..
.Protect function
This is the function that protects the cross-point set so
that it cannot be released from other remote control
panels.
..
..
.Cross-point input system limit function
Function that limits the input channels can be selected
for each output channels. It can also be used to fix the
area of cross-points selected so that only certain input
channels can be selected for certain output channels.
..
..
.Password function
It is possible to setup password so only authorized
person can perform the setup operation from the terminal
menu.
..
..
.Naming function
In the routing switcher system, names are given to all of
the input and output terminals and are controlled in order
to improve operating efficiency.
It is possible to setup multiple names to describe the
terminals, such as “Type + Number” name and “Descrip-
tion” name, or “Alias” name.
..
..
.Virtual mapping function
Several routing switchers can be mapped on a virtual
matrix with 1024 inputs and 1024 outputs in router
system. The matrix of one switcher can be also divided
into several virtual levels and mapped.
..
..
.Free assignment function
The same terminal number can be assigned, for each
terminal name, through levels 1 to 8. The different
physical number can also be assigned on each level.
..
..
.Tie line function
Tie line is used to effectively share the minimum number
of signal converters (SDTV to HDTV, HDTV to SDTV)
by the multiple input terminals and output terminals.
..
..
.Phantom function
Several cross-points can be switched simultaneously
with just one push of a button of the remote control
panel.
..
..
.Self-diagnosis function
Presence or absence of input/output signals and occur-
rence of error can be sent to a PC that is connected to the
primary station and display them.
..
..
.Others function
.When the optional Subnet Interface (BZR-IF810) and
the optional System Setup Software (BZR-2000) are
used, a maximum of 60,000 devices can be controlled
by a single routing switcher system.
.IXS-6600/IXS-6700 and HDS-X5800 has the built-in
system controller (primary station function). There-
fore, there is no need to prepare a controller to control
the routing switcher system.
.HDS-X5800 can increase the number of inputs by
cascade connection, and the number of outputs by the
signal distributor up to 1024 channels each.
n
The IXS-6600/IXS-6700, HKSP-R80 and HDS-X5800 do
not have the control function of the monitoring S-BUS
system.

1-2 BKS-R3219A/R1617A I&SSM
1-3. Compatibility between the S-BUS P1 (S-P1) Type and S-BUS P2 (S-P2)
Type
There are two types of Sony Routing Switcher. One is the “S-BUS P1” type (abbreviated as S-P1 hereaf-
ter) that supports the virtual matrix size 512, and the other is the “S-BUS P2” type (abbreviated as S-P2
hereafter) that supports the virtual matrix size 1024. S-BUS machines on sale now are all the S-P2 types.
The S-P2 type has the upward compatibility with the S-P1 type but has the several limitations.
The S-P2 type is realized by extending the type number of the terminal names from 16 to 32, and by
changing the data structure of the terminal names. The 16 types of the terminal number data that are used
in the S-P1 type do not have reversibility from the 32 types of terminal number data that are used in the S-
P2 type. The S-P2 device supports two types of data i.e., both the 16 type data and the 32 type data for
each terminal of terminal number 1 to 512.
Likewise, with the S-P2 controller, the 16 type data must be used for the terminal number of 1 to 512
when the S-P1 type display unit (BKS-R3280/R3281) and the remote control panel (routing switcher
control unit) are used in the system. The 32 type data must be used for the terminal numbers of 513 to
1024.
When all of the display units and the remote control panels within the system are of the S-P2 type, the 32
type data can also be operated for the terminal numbers of 1 to 512.
When use of the remote control panels of the S-P1 and S-P2 types are mixed, use of the S-P1 type remote
control panel is limited within the range of terminal number from 1 to 512. In such a case, the S-P2 type
remote control panel can handle the 32 type data with the terminal number of 513 to 1024.
This manual describes information of only the S-P2 type machine.
For the information on the S-P1 type machines, refer to the following manual.
.Installation Manual (Software) : 3-194-351-xx
It is supplied with the routing switcher of the S-P1 type machine.
m
All of the following models currently available belong to the S-P2 device.
.Routing switcher: IXS-6600/IXS-6700/HDS-X5800
.Remote control panel: BKS-R1617/BKS-R1618/BKS-R3216/BKS-R3219/BKS-R3220/BKS-R1617A/
BKS-R3219A/BKS-R6010

1-3
BKS-R3219A/R1617A I&SSM
1-4. Constituent Devices of Routing Switcher System
The routing switcher system consists of the following four types of equipment.
..
..
.Routing switcher controller (HKSP-R80)
It controls the signal switching for the routing switcher in accordance with the commands from the host
controller (such as host computer) and remote control panel.
..
..
.Routing switcher (IXS, HDS, DVS, BVS series)
The switcher with a built-in controller and the one without it are available.
The built-in controller type switches signals according to the command from the controller (such as
host computer) and the remote control panel. The routing switcher without a built-in controller (such as
a secondary station) switches signals by following the commands from the controller. Varied switchers
are available for different types of signals such as serial digital video, digital audio, time code, RS-
422A, etc.
..
..
.Routing switcher control unit (Remote control panel) (BKS-R series)
It is used to switch signals and to display the name of the selected signal. It is sometimes simply called
as “remote control panel”.
..
..
.Personal computer
A personal computer is required in order to establish the various setups that are necessary for configur-
ing and running the routing switcher system using a terminal emulator. The setup data are backed up
and restored with the BZR-20 that is supplied with the IXS-6600/IXS-6700, HKSP-R80 and HDS-
X5800.
A personal computer having the following specifications is recommended for use with the routing
switcher system.
.IBM PC/AT compatible personal computer
.Windows XP (English version or Japanese version)
.RS-232C port or Ethernet is installed.
.Terminal emulator (VT100 or higher) is installed.
.The codes of F1 to F5 are already set.
n
For the code setting procedure, refer to Section 2-2.
.BZR-20 (V2.11 or higher) is installed.
n
For the BZR-20 installation procedure, refer to the Installation Manual in the CD-ROM supplied with
the IXS-6600/IXS-6700, HKSP-R80 and HDS-X5800 .
.Microsoft Excel is installed.
.DirectX (V6.1a or higher) is installed.
.BZR-2000 (V1.70 or higher) is installed when using GUI for setup.
.

1-4 BKS-R3219A/R1617A I&SSM
1-5. Controls by Routing Switcher System
1-5-1. Specifications and Functions of Control Port
The Routing Switcher System has four kinds of remote ports : REMOTE 1 (standard S-BUS), REMOTE
2 (RS-422A), REMOTE 3 (RS-232C), and NETWORK (Ethernet)*1. Among the four remote systems,
BKS-R1617A and BKS-R3219A are equipped with two remote terminals supporting the two remote
systems: REMOTE 1 and REMOTE 2.
*1 : NETWORK (Ethernet) : IXS-6600/IXS-6700/BKS-R6010
DATA (Ethernet) : HKSP-R80 and HDS-X5800
The specifications and functions of the control ports are as follows.
REMOTE 1 BNC 75 ZZ
ZZ
Z
Protocol : S-BUS control
Data Transfer Speed 312.5 kbps
Max Cable Length 500 m (BELDEN 8281 cable or equivalent)
Function : Control of the equipment is executed by the S-BUS data link.
The various types of equipment related to the control, such as remote control panel, routing
switcher, and display unit, are connected to this data link.
REMOTE 2 D-sub 9-pin
Protocol : RS-422A
Transfer speed 38.4 kbps
Data bit 8 bits
Parity EVEN
Protocol Controllable size
16 xx
xx
x16 256 xx
xx
x256 4093 xx
xx
x4093
CART O_ _
CART+OO_
CART++OOO
Function : With this, the one-to-one port communication between two units is performed. It is used
when a Sony routing switcher is used as a simple matrix switcher when receiving controls
from the controller of other manufacturers via RS-422A.
RS-232C D-sub 9-pin
Protocol : RS-232C
Transfer speed 38.4 kbps
Data bit 8 bits
Parity none
Check none
Function : When connected with a personal computer, it performs program downloading and communi-
cation status monitoring.

1-5
BKS-R3219A/R1617A I&SSM
1-5-2. S-BUS Control
The Sony routing switcher system uses the Sony unique remote control protocol called S-BUS (Sony
serial bus) for controlling the switcher system.
In the S-BUS control, the multiple routing switchers and remote control panels are connected to a single
bus line to form a control network called the S-BUS data link.
The devices on the S-BUS data link are designated to a primary station which controls the whole system
(only one unit is set as this) and secondary stations. The primary station not only controls the communica-
tion between the secondary stations, it converts the output request signals from the secondary station in
accordance with the internally set conditions.
n
Be sure to attach the 75 Zterminator to all of the un-used S-BUS line connector regardless of the prima-
ry/secondary stations.
Basic Configuration of S-BUS Control System
The routing switcher system is connected with the S-BUS data link using a 75 Zcoaxial cable.
The main equipment of the S-BUS data link is shown in the table below.
Type in S-BUS Model (function name) Quantity Function/role
data link
Primary station (P)*Routing switcher controller 1 Controls the entire S-BUS data
HKSP-R80 link.
Routing switcher Can also function as a secondary
IXS-6700/IXS-6600 station.
(integrated routing switcher)
HDS-X5800
(routing switcher processor)
Secondary station (S)*Remote control unit 253 (max.) Controls the individual secondary
BKS-R3220 station.
(X-Y control unit) Operates in accordance with
BKS-R3219A the commands from the primary
(32 button remote panel) station.
BKS-R1617A
(16 button LED remote panel)
BKS-R1618
(16 button control unit)
BKS-R3216
(8 destination control unit)
BKS-R6010
(universal LCD remote panel)
Terminal Personal computer 1 Establishes the various setups of
(terminal emulator) the system.
The errors that have occurred in
the S-BUS line are displayed and
managed by the emulator.
* : (P) and (S) indicate the setting of the S/P selector switch on the CPU board (on the CA board for the IXS series) in the routing
switcher.
n
Switchers other than the IXS-6700/IXS-6600 can be also set as a primary station. In this case, some
functions are limited.

1-6 BKS-R3219A/R1617A I&SSM
Precautions for connection
.For the controller and routing switcher that are used as the primary station, set the S/P selector switch
on the CPU board (on the CA board for the IXS-6700/IXS-6600) to the “P” position.
.For the controller and routing switcher that are used as the secondary station, set the M/S switch (S/P
selector switch in the IXS-6700/IXS-6600) on the CPU board (on the CA board for the IXS-6700/IXS-
6600) to the “S” position.
.A primary station can control up to 253 secondary stations.
.A single S-BUS line can be connected to up to 128 secondary stations.
.The maximum length of a single S-BUS line cable is 500 m (when the BELDEN 8281 cable is used).
.Terminate the L-type and Y-type bridges that is connected to the last machine of the S-BUS line with a
75 Zterminator. Also, terminate the unused REMOTE1 connector of each switcher with a 75 Z
terminator.
.In the primary controller or routing switcher, two or more REMOTE 1 connectors can be used.
.In the secondary controller and routing switcher, only one REMOTE 1 connector can be used each.
How to use the L-type and Y-type bridges
The L-type and Y-type bridges are supplied with the BKS-R1617A/BKS-R3219A . Use the L-type and Y-
type bridges as follows.
BKS-R1617A/R3219A
(rear panel block)
Y-type bridge
L-type bridge
REMOTE1
(BNC-type connector, Male)

1-7
BKS-R3219A/R1617A I&SSM
1-5-3. RS-422A Control
SONY Routing switcher system can be controlled from an external control equipment that is connected to
the REMOTE2
(D-sub 9-pin) connector with the RS-422A interface. In addition, the protocol (CART++)
can be added so that up to 4093 inputs x4093 outputs x8 levels can be controlled.
When the extended protocol is the CART++ that has the control size of 256 or less, it is compatible with
the existing protocol (CART, CART+).
Two operation modes are available: S-BUS conversion mode, which converts the commands received via
RS-422 into the S-BUS protocol, and the direct mode, which controls the commands received via RS-
422A inside the reception station. When the routing switcher is set as a primary station, the mode is fixed
to the S-BUS conversion mode. When the routing switcher is set as a secondary station, the mode is fixed
to the direct mode.
The remote control panel is fixed to the S-BUS conversion mode.
m
.In the direct mode, the protect and secret functions set on the S-BUS protocol are not available.
.In the S-BUS conversion mode, the protect and secret functions set on S-BUS protocol are available.
However, these functions cannot be set from the 9-pin remote control and the contents of the setting
cannot be checked from the 9-pin remote control.

1-8 BKS-R3219A/R1617A I&SSM
1-6. System Connection Example
1-6-1. S-BUS Control System Connection Example
The connection example of the S-BUS data link using the IXS-6700 as the primary station is shown.
Either one of the REMOTE 1 connectors of the secondary station routing switchers can be used.
*1 : (S) indicates the secondary station. For the secondary stations, set the station ID in the range of ID = 2 to 254 in the manner that the
same ID must not be duplicated.
*2 : Install the 75 Zterminators to the T-type bridge or Y-type bridge of the last device on the S-BUS data link and to the unused
REMOTE 1 connector.
: S-BUS
: Signal system line
: Ethernet
: T-type bridge (A)
: T-type bridge (B)
: 75 Zterminator*2
: Layer of matrix
Terminal
Primary
station
Secondary
station
Tertiary station
Level 1
Personal computer
(Terminal emulator)
Personal computer
(Terminal emulator)
Ethernet
Switch
Integrated
routing system
IXS-6700
(P)
Source
VTR
REMOTE1 A REMOTE1 B1 REMOTE1 B2 REMOTE1 C
Destination
VTR
Video
Time code
Audio channel 1/2
Audio channel 3/4
Time code
Audio
Channel 1/2 Audio
Channel 3/4
Audio
routing switcher
(S)*1
Audio
routing switcher
(S)*1
Time code
routing switcher
(S)*1
Each
routing switcher
(S)*1
Maximum
128
equipment
Remote
control panel
BKS-R6010
Remote
control panel
BKS-R3219A
Remote
control panel
BKS-R1617A
Subnet Controller
Subnet Controller
Remote
control panel
BKS-R6010
Remote
control panel
BKS-R1617A
Display unit
Display unit
Display unit
Display unit
Level 8Level 4Level 3Level 2
Video
Terminal
Maximum
16 equipment
NETWORK A
NETWORK B
REMOTE1 A
REMOTE1 A

1-9
BKS-R3219A/R1617A I&SSM
1-6-2. REMOTE2 (RS-422A) Control System Connection Example
The connection example of the REMOTE 2 (RS-422A) control system is shown.
S-BUS conversion mode connection example 1 S-BUS conversion mode connection example 2
Controller
(Host CPU)
Routing
switcher
(S)
Routing
switcher
(S)
Routing
switcher
(S)
Routing
switcher
(S)
Routing
switcher
(S)
REMOTE2
RS-422A
: S-BUS
: RS-422A
: 75 Zterminator
: T-type bridge
: Standard units making up Sony routing system
(P) (S) : The setting of P/S switch on the CPU board.
REMOTE2
RS-422A
Remote
control
panel
S-BUS
REMOTE1
Routing
switcher
(S)
Routing
switcher
(S)
Routing
switcher
(S)
Routing
switcher
(S)
Routing
switcher
(S)
Routing
switcher
(S)
Routing
switcher
(S)
Subnet
controller
(P)
Controller
(Host CPU)
Direct mode connection example
Routing
switcher
(S)
Routing
switcher
(S)
Routing
switcher
(S)
Routing
switcher
(S)
Routing
switcher
(S)
Routing
switcher
(S)
Routing
switcher
(S)
Routing
switcher
(S)
Subnet
controller
(P)
S-BUS
REMOTE1
REMOTE2
RS-422A Controller
(Host CPU)

2-1
BKS-R3219A/R1617A I&SSM
Section 2
Installation
2-1. Installation Procedure
The following chart shows the procedure for installing the unit.
For details of the following chart, refer to the relevant section or related manual.
Start
Selection of installation
place
Rack mounting
Connection
2-2.
2-3.
2-4.
2-5.
2-7.
2-8.
Operating Environment
Power Supply
Installation Space
Rack Mounting
Matching Connectors
Input and Output Signals of Connector
End
Initial setting
Operation check
3. Settings
4. Confirmation of Function
Setting the On-Board
Switches
Attach the key Label
Settings by Using the
Buttons (Setup Function)
2-9.
2-10.
2-11.
Setting the On-Board Switches and
Description of LEDs
Attach the key Label
Settings by Using the
Buttons (Setup Function)

2-2 BKS-R3219A/R1617A I&SSM
2-2. Operating Environment
Operating guaranteed temperature : +5dC to +40dC
Performance guaranteed temperature : +10dC to +35dC
Operating humidity : 10 % to 90 %
Storage temperature : _20dC to +60dC
Mass :
BKS-R3219A/R1617A : Approx. 1.5 kg
To prevent overheating of the unit ensure that there is good
air circulation around the unit.
Select an installation place as operating temperature of the
unit is 5 dC to 40 dC. Do not place the unit near heart
sources.
2-3. Power Supply
1. Power Specifications
A switching regulator (+12 V) is used for the power
supply of this unit. A voltage within the range of AC 100
to 240 V can be used without changing the supply voltage.
Power requirements : AC 100 to 240 V
Power frequency : 50/60 Hz
Current consumption :
BKS-R3219A/R1617A : 0.35 to 0.15 A
n
As the inrush current at turn-on is a maximum of 13 A (at
100 V) /47 A (at 240 V) with the BKS-R3219A, or a
maximum of 12 A (at 100 V) /40 A (at 240 V) with the
BKS-R1617A, the capacity of the AC power must be
commensurate with this source load.
If the capacity of the AC power is not adequately large, the
AC power source breaker will operate or the unit will
abnormally operate.
For customers in the U.S.A. and Canada
1Power cord, 125 V 10 A (2.4 m) : !1-551-812-31
AC inlet
1
For customers in the all European countries
1Power cord, 250 V 10 A (2.5 m) : !1-782-929-12
1
AC inlet
2. Recommended Power Cord
w
.Use the approved Power Cord (3-core mains lead)/
Appliance Connector/Plug with earthing-contacts that
conforms to the safety regulations of each country if
applicable.
.Use the Power Cord (3-core mains lead)/Appliance
Connector/Plug conforming to the proper ratings (Volt-
age, Ampere).
If you have questions on the use of the above Power Cord/
Appliance Connector/Plug, please contact your local Sony
Sales Office/Service Center.
w
.Never use an injured power cord.
.Plugging the power cord in the AC inlet, push as far as it
will go.
