SERVICE MANUAL
1/3” SONY DSP COLOR CCD CAMERA
TRUE DAY & NIGHT (IR-CUT REMOVABLE) &
O.S.D. (ON SCREEN DISPLAY) SERIES
The serial number of this product may be found
on the bottom of the unit.
You should note the serial number of this unit in
the space provided and retain this instruction as a
permanent record of your purchase to aid
identification in the event of theft.
Model No.
SerialNo.

▲Before attempting to connect this product, please read and keep this
manual for future use.
Safety Warning
1. Do not open the cover, it may cause electric shock.
Ask a qualified service person for maintenance when you encounter any
problems.
2. Install the camera away from TV, radio transmitter, magnet, electric
motor, transformer, audio speakers because the magnetic fields
generated from above devices will distort the video image.
3. Place this camera on a solid base. Install the camera away from
stoves or other heat generating devices as the high temperature could
cause deformation, discoloration or other damages to the camera.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK), NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is interned to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
①

Install the camera at where the temperature range does not exceed 0°C
to 50°C (32°F to 122°F)
4. Do not expose and operate the camera in the rain and humid areas.
5. Use only soft dry cloth to clean the camera. Also use lens tissue or
cotton tipped applicator and ethanol to clean the CCD sensor and
camera lens.
6. When the camera is not in use, put the cover cap on the lens mount.
Please do not touch the surface of CCD by bare hand.
Introduction
This OSD series CCD camera introduces a new level of high picture quality
through the digital signal processing LSI’s technology for advanced video
surveillance. It provides the most reliable and accurate color picture in
security industries.
Main Features
zColor camera with SONY 1/3” Super HAD CCD sensor in metal case.
zEmploys Digital Signal Processor (DSP) chip-set for image control.
zControlled by OSD Menu.
zAdditional Functions, motion detection, mirror, sharpness.
zOLPF auto switching (IR-Cut Removable).
zHigh sensitivity, CCD enables a clear image at 0.3Lux (0.1Lux B/W).
zVideo drive lens or DC drive lens can be selected. Supports both C and
CS mount lens
zThe PRIVACY function enables you to select areas that will be masked
during monitoring.
②

Parts Names & Components
Hex Screwdriver
Auto Iris Plug
C-Mount Ring
Manual
Power LED Selection & setting buttons
Hole to fix lens
Auto iris connector
③

Auto Iris Function
DC DRIVE VIDEO DRIVE
Pin 1 (Red) Drive - Volt +
Pin 2 (N.C) Drive + N.C
Pin 3 (White) Damp + IRIS
Pin 4 (Black) Damp - GND
④
Plug in auto iris
connector
Screw the auto iris
lens on CS mount

Installation Instructions
(1) Remove the cap from the lens mount.
(2) Select the C mount lens (with mount ring) or CS mount lens.
(3) Screw and fasten the lens into the lens mount.
(4) Connect the video output wire between monitor and camera through
75ohm type coaxial cable.
(5) Connect the power cord input.
(6) When monitor shows the picture, please adjust the focus and iris of the
lens to obtain the best image according to the following procedures:
‧ Choose objects at a distance about 5 ~ 10 meter away.
‧ Loosen the mount lens fixing screw (use L wrench), if necessary.
‧ Turn the lens and the mount together until image is clear.
‧ Screw the mount to camera.
(7) Fix camera to the bracket, if necessary.
⑤

Switch Definition
SET button
Press to display the menu. In the menu, this button functions as “ENTER”.
UP & DOWN buttons
Press to select the item of menu.
LEFT & RIGHT buttons
Press to change the item value.
MAIN MENU
DOWN button
LEFT SET RIGHT
button button button
UP button
⑥

Menu Operation
‧ Press the SET button to display the menu on screen.
‧ Press the UP or DOWN button to select the item.
‧ The selected item will be displayed in yellow text.
‧ Press the LEFT or RIGHT button to change mode.
‧ The ENTER symbol means there is a sub-menu. Press the SET button to
enter to the sub-menu.
‧ Select the EXIT item and press the SET button to finish setting.
LENS
To select the lens mode depending on the lens used:
‧ MANUAL When manual iris lens is used.
‧ DC When auto iris lens that requires a DC drive signal is used.
‧ VIDEO When auto iris lens that requires a video drive signal is used.
SHUTTER
To change the shutter setting and speed based on the environment.
‧ FLK Select when flickering occurs on the screen due to an imbalance
between illumination and frequency. Under this mode, the
shutter speed is NTSC: 1/100; PAL: 1/120
‧ FIXED Immobile control of the shutter speed can be achieved.
‧ MANUAL The shutter speed can be controlled manually.
‧ AUTO After an immobile brightness value is set, the shutter speed will
adjust automatically to achieve the value.
BLC (Backlight Compensation)
When there is strong backlight behind the object, enable this function to achieve a
clear image of the background as well as the object.
‧ ON To enable this function.
-- BLC Area: User defines which zone to enable.
-- BLC Ratio: Set between 0 and 63. When the value is bigger,
the compensation to the BLC area will be more.
‧ OFF To disable this function.
⑦

AGC (Auto Gain Control)
Enable this function to heighten the brightness signal automatically. The effective
value is between 0 and 255 (0dB ~ 40dB). (Bigger value, more noise).
<<ATTENTION>> Disable this function for IR-Cut Removable.
WHITE BAL.
To change the white balance mode:
‧ ATW Auto Tracking White Balance. The white balance will adjust
continually according to the color temperature of the object. The
rage of color temperature is 1,800°K~10,500°K.
‧ AWB Auto White Balance Control. The white is correct in any
condition. (To adjust the white balance, focus the camera to
white paper and press SET button to obtain the optimum state
under current illumination. If the environment including the light
source is changed, the white balance has to be adjusted again).
‧ FIXED Four modes are available for selection by user.
‧ MANUAL The manual adjustment mode enables finer adjustment of ATW
and AWB. Please select ATW mode or AWB mode first and
change to MANUAL mode. Set the appropriate color
temperature and then increase or decrease the red and blue color
values while monitoring the color changes on the object.
FUNCTION
‧ RETURN To save the option and return to the SETUP menu.
‧ CAMERA ID
1. Please move the cursor to the letter you wish to choose by
using the UP and DOWN buttons.
⑧

2. Select an ID from A~Z, a~ z, 0, 1~9 by using the UP, DOWN,
LEFT and RIGHT buttons.
3. Move the cursor to “C” to clear the letter.
4. Please lock in the letter by using the SET button.
5. Please repeat the above to input the ID, up to 15 letters.
6. When a name has been chosen, select a position on the screen
for the name to display. Move the cursor to and press the
SET button.
7. Select “RETURN” and press the SET button to complete
ID input.
‧ MIRROR Select “ON” for mirror image or “OFF” for normal image.
‧ DAY NIGHT
-- COLOR: Common mode.
--AUTO: Thedefaultsetting. Automatically changes between
color mode under bright light environment and B/W
mode under low light environment. Set the value of
“DELAY”, “START LEVEL” and “END LEVEL”
to define the changing time.
-- B/W: Stay in B/W mode for clearer image and better
visibility under low light environment.
<<ATTENTION>> Select AUTO for IR-Cut Removable.
‧ MOTION When the object on screen is moving, the camera will detect the
changes and display a warning on screen.
-- OFF: Not active.
-- ON : Any motion in the selected areas is observed.
1. AREA:
There are 64 areas. Adjust the size of zone by
pressing UP, DOWN, LEFT, RIGHT and SET
buttons.
2.MOTIONTH.:
Higher sensitivity when the value is bigger
3.MOTIONTRACE:
Shows the location where the motion was detected.
⑨

‧ PRIVACY Cover the areas you do not wish to appear on screen.
-- ON : Enable the PRIVACY mode. Using the UP, DOWN,
LEFT, RIGHT buttons to adjust the size and color
of the four zones or clean the selected zones.
-- OFF: Disable the PRIVACY mode.
‧ GAMMA Adjustable value between 0.05 and 1.00.
‧ LANGUAGE
Supports English, T.Chinese, S.Chinese, Japanese, Korean
‧ RESET Return to the default settings.
ADJUST
Depending on the environment, adjust CONTRAST, SHAPRNESS, CB_GAIN and
CR_GAIN for clearer and more colorful image.
Specification
PICK-UP DEVICE Sony 1/3" Super HAD Normal Resolution CCD Sony 1/3" Super HAD High Resolution CCD
SIGNAL PROCESSOR D.S.P. (Digital Signal Processor)
RESOLUTION 420 TV Lines 520 TV Lines
MIN. ILLUMINATION 0.05Lux / F1.2 0.1Lux / F1.2
S/N RATIO More than 50 dB
POWER SUPPLY DC12V; AC24V; AC110V; AC230V; AC90~260V Switching; DC12V/AC24V Dual Power
GAMMA CORRECTION 0.45 (0.05~1.0 Adjustable)
CONTROL O.S.D. (On Screen Display)
LANGUAGE English, T.Chinese, S.Chinese, Japanese, Korean
WHITE BALANCE ATW (1,800°K~10,500°K)
LENS MOUNT C / CS Mount
AUTO IRIS CONTROL Video Drive Auto Iris Lens & DC DriveAuto Iris Lens
AUTO ELECTRONIC
SHUTTER 1/60; 1/100; 1/250; 1/500; 1/2,000; 1/5,000; 1/10,000; 1/100,000 (Fixed) Auto / Manual 0 ~ 255 Sections / AES / FLK Mode
BASIC FUNCTION
Lens Selection (DC / VD / Manual)
Shutter Selection (Auto / Fixed / Manual / FLK)
ATW / AWB / Manual Selection
BLC (Area / Ratio Adjustable) Selection
AGC (0~40dB Adjustable) Selection
Adjust Contrast / Sharpness / CB_Gain / CR_Gain
EXTEND FUNCTION
Camera ID ON / OFF
Motion Detection ON / OFF (64 Area, Position / Size / Sensitivity)
Privacy Zone ON / OFF (4 Zone, Position / Size / Tone)
Day & Night (Electronic Conversion)
Mirror ON / OFF
Reset to Default
VIDEO OUTPUT 1 Vp-p Composite Video / 75 ohm Load
POWER CONSUMPTION 3.5W (Max.)
OPERATING TEMP. -10°C~50°C (14°F~122°F)
OLPF SWITCHING Automatically (1. Select DAY NIGHT: AUTO; 2. SelectAGC: OFF)
