UNITIZED CAMERA/LENS/ENVIRONMENTAL HOUSING PACKAGE
PRELIMINARY
Page 1of 4
UniPak™Unitized Camera Package
Sony Security Systems is pleased to announce the introduction of its expanded UniPak product line.
The new UniPak models utilize Sony’s standard resolution and high resolution Super HAD™ CCD,
Exwave HAD™ CCD, and Hyper HAD® CCD cameras to provide excellent picture quality. Whether
the application is indoor or outdoor, color or black and white, the new UniPak models provide the right
configuration for your specific needs.
UNITIZED Indoor and Outdoor Models
CAMERA/LENS/
ENVIRONMENTAL -UNI-PM124 series with SPT-M124 Standard resolution Hyper HAD CCD black & white camera
HOUSING -UNI-PM324 series with SPT-M324 High resolution Exwave HAD CCD black & white camera
PACKAGE -UNI-PC134 series with SSC-DC134 Standard resolution Super HAD CCD color camera
-UNI-PC314 series with SSC-DC314 High resolution Super HAD CCD color camera
-UNI-PC334 series with SSC-DC334 High resolution Exwave HAD CCD color camera
Lens
-Back-focused vari-focal 5 to 50mm DC auto iris lenses for both indoor and outdoor models
-Back-focused vari-focal 3.5 to 8mm DC auto iris lenses for both indoor and outdoor models
-Back-focused vari-focal 3.5 to 8mm manual iris lenses for both indoor and outdoor models
Housing
-Extruded aluminum housing
-Tamper resistant camera housing lock down screws provided
-High strength steel wall mount bracket included
-Outdoor models include AC 24V heater and blower

UNITIZED CAMERA/LENS/ENVIRONMENTAL HOUSING PACKAGE
PRELIMINARY Page2of 4
UniPak™
UniPak Component Table
Model Name
Camera Camera Camera Camera Camera Lens Lens Lens Housing Housing
SPT-M124
B&W SPT-M324 B&W SSC-DC134 Color SSC-DC314 Color SSC-DC334 Color C-70306DCPS Auto Iris (3.5-8mm)
C-70308
Manual Iris (3.5-8mm)
13VG550-SQ
Auto Iris (5-50mm) Outdoor with Heater/Blower Indoor without Heater/Blower
UNI-PM124A1 •••
UNI-PM124A1HB •••
UNI-PM124A2 •••
UNI-PM124A2HB •••
UNI-PM124M1 •••
UNI-PM124M1HB •••
UNI-PM324A1 •••
UNI-PM324A1HB•••
UNI-PM324A2 •••
UNI-PM324A2HB •••
UNI-PM324M1 •••
UNI-PM324M1HB •••
UNI-PC134A1 •••
UNI-PC134A1HB •••
UNI-PC134A2 •••
UNI-PC134A2HB •••
UNI-PC134M1 •••
UNI-PC134M1HB •••
UNI-PC314A1 •••
UNI-PC314A1HB •••
UNI-PC314A2 •••
UNI-PC314A2HB •••
UNI-PC314M1 •••
UNI-PC314M1HB •••
UNI-PC334A1 •••
UNI-PC334A1HB •••
UNI-PC334A2•••
UNI-PC334A2HB •••
UNI-PC334M1 •••
UNI-PC334M1HB •••

UNITIZED CAMERA/LENS/ENVIRONMENTAL HOUSING PACKAGE
PRELIMINARY
Page 3of 4
UniPak™
UniPak Black and White Models
SPECIFICATION
BLACK & WHITE CAMERA SPT-M124 SPT-M324
Image Pickup Device 1/3” Hyper HAD CCD 1/3” Exwave CCD
Active Picture Elements 510 X 492 768 X 494
Lens Mount C/CS C/CS
Signal System NTSC Monochrome NTSC Monochrome
Scanning System 525 lines, 2:1 interlace 525 lines, 2:1 interlace
Synchronization AC Line Lock, 60Hz AC Line Lock, 60Hz
V-Phase Control +90°+90°
Horizontal Resolution 380 TV Lines 570 TV Lines
Minimum Illumination 0.6 lux F1.2, 30 IRE 0.04 lux F1.2, 30 IRE
AGC ON/OFF Selectable ON/OFF Selectable
CCD Iris Range 1/60 ~ 1/100,000 sec. 1/60 ~ 1/100,000 sec.
Video Output 1 Vp-p @ 75 Ohms
Sync Negative 1 Vp-p @ 75 Ohms Sync Negative
Video Signal to Noise 45dB (AGC OFF, Weight ON) 50dB (AGC OFF, Weight ON)
White Balance Not Applicable Not Applicable
Power Requirements AC 24V +10%, 60Hz AC 24V +10%, 60Hz
Power Consumption 2.5W 2.6W
Operating Temperature 14°F to 122°F14°F to 122°F
LENS M1 Series A1 Series A2 Series
Lens Mount CS CS CS
Format 1/3” 1/3” 1/3”
Focal Length 3.5 –8mm 3.5 –8mm 5 –50mm
Maximum Aperture F1.4 F1.4 F1.4
Iris Range F1.4 to Close F1.4 to F200 F1.4 to F185
Angle of View (Horizontal) Wide –79.8°Tele –35.4°
Wide –78.5°Tele –35.2°Wide –53.4°Tele –5.3°
Angle of View (Vertical) Wide –58.8°Tele –26.6°Wide –58.2°Tele –26.4°Wide –40.1°Tele –4.1°
HOUSING All UniPak Models
Material Extruded Aluminum
Environmental Spec Complies with IP65 Standards
Endcaps LexanMolded
Viewing Window Material Clear Lexan
Camera/LensAccess Side Hinged Opening to Allow Access
Wall Mount Bracket High strength steel
Outdoor UniPak Models
Blower Power Consumption 24V AC, input rectified, 1.4VA
Heater Power Consumption 24V AC, 1.04A; 25VA
How to read the UniPak Model Number
C M 2
U N I -P M 1 2 4 A 1 H B
Fixed: UniPak Color/ Camera Number Manual/ Type of Heater Blower
UniPak Monochrome Auto Lens
Iris Lens

UNITIZED CAMERA/LENS/ENVIRONMENTAL HOUSING PACKAGE
PRELIMINARY
Page 4of 4
UniPak™
UniPak Color Models
SPECIFICATION:
Color CAMERA SSC-DC134 SSC-DC314 SSC-DC334
Image Pickup Device 1/3” Super HAD CCD 1/3” Super HAD CCD 1/3” Exwave HAD CCD
Active Picture Elements 510 X 492 768 X 494 768 X 494
Lens Mount C/CS CS* C/CS
Signal System NTSC Color NTSC Color NTSC Color
Scanning System 525 lines, 2:1 interlace 525 lines, 2:1 interlace 525 lines, 2:1 interlace
Synchronization AC Line Lock, 60Hz AC Line Lock or Internal AC Line Lock or Internal
V-Phase Control +90°+90°+90°
Horizontal Resolution 330 TV Lines 480 TV Lines 480 TV Lines
Minimum Illumination 0.45 lux F1.2, 30 IRE
AGC ON, Turbo mode 0.7 lux F1.2, 30 IRE AGC ON, Turbo mode 0.4 lux F1.2, 30 IRE AGC ON, Turbo mode
AGC Always Turbo Always Turbo Turbo / Normal / Off Selectable
CCD Iris Range 1/60 ~ 1/100,000 sec. 1/60 ~ 1/100,000 sec. 1/60 ~ 1/100,000 sec.
Video Output 1 Vp-p @ 75 Ohms
Sync Negative 1 Vp-p @ 75 Ohms Sync Negative 1 Vp-p @ 75 Ohms Sync Negative
Video Signal to Noise 50dB (AGC OFF, Weight ON) 50dB (AGC OFF, Weight ON) 50dB (AGC OFF, Weight ON)
White Balance ATW ATW ATW Pro/ATW
Power Requirements AC 24V +10%, 60Hz AC 24V +10%, 60Hz AC 24V +10%, 60Hz
Power Consumption 4.0W 3.5W 4.5W
Operating Temperature 14°F to 122°F14°F to 122°F14°F to 122°F
LENS M1 Series A1 Series A2 Series
Lens Mount CS CS CS
Format 1/3” 1/3” 1/3”
Focal Length 3.5 –8mm 3.5 –8mm 5 –50mm
Maximum Aperture F1.4 F1.4 F1.4
Iris Range F1.4 to Close F1.4 to F200 F1.4 to F185
Angle of View (Horizontal) Wide –79.8°Tele –35.4°Wide –78.5°Tele –35.2°Wide –53.4°Tele –5.3°
Angle of View (Vertical) Wide –58.8°Tele –26.6°Wide –58.2°Tele –26.4°Wide –40.1°Tele –4.1°
HOUSING All UniPak Models
Material Extruded Aluminum
Environmental Spec Complies with IP65 Standards
Endcaps LexanMolded
Viewing Window Material Clear Lexan
Camera/Lens Access Side Hinged Opening to Allow Access
Wall Mount Bracket High strength steel
Outdoor UniPak Models
Blower Power Consumption 24V AC, input rectified, 1.4VA
Heater Power Consumption 24V AC, 1.04A; 25VA
*C mount adaptor included
Supplied Accessories: Cable Strain Relief Plugs (2)
Black Nylon Lock Nuts (2)
Security Hex Screws (2)
Security Hex Tool (1)
Wall Mount Bracket (1)
Operating Instructions Manual (1)
