SNC-DF/85P/80N/80P/50P Network Mini-Dome Cameras
www.sonybiz.net/videosecurity

Introducing Sony’s
SNC-DF85/80/50 intelligent
mini-dome camera lineup.
Why choose the SNC-DF85/DF80/DF50 Network Mini-dome Cameras
Features Benefits SNC-DF85 SNC-DF80 SNC-DF50 Page
Weather-resistant
and Rugged Design Enables Outdoor Use Yes
(Outdoor/Indoor)
Yes
(Outdoor/Indoor)
No
(Indoor) P.5
Wide Dynamic Range
(DynaView)
Provides Backlight
Compensation Yes No*2 Yes P.3
Day/Night Function
Enables Night
Monitoring,
Without Visible Light
Yes Yes No P.4
*2The SNC-DF80 has a conventional backlight compensation function.
Sony’s SNC-DF85/DF80/DF50 is an intelligent mini-dome camera lineup, designed
for a variety of surveillance and monitoring applications. The SNC-DF50 offers a
wide dynamic range; the SNC-DF80 offers a tough camera body and Day/Night
function; the SNC-DF85 combines the benefits of both.
Ideal for outdoor applications the SNC-DF85/DF80
heavy-duty aluminum die-cast enclosure with
impact-resistant polycarbonate dome, provides
protection against vandalism and
guards against damage from
dust and water ingress. The
optional heater* enables the
camera to operate down to
-40° C (-40° F). The camera’s
Day/Night function provides
clear monitoring images in
low light conditions.

The DEPA Platform –
Intelligent Video Analytics
The SNC-DF85, SNC-DF80, and SNC-DF50
cameras offer intelligent video analytics,
based on the Sony DEPA platform.
This comprises two elements: intelligent
built-in camera functions, such as IMD
and IOD, and rules/filters that determine
which images should be recorded or
when an alarm should be triggered.
When the network cameras perform
IMD or IOD, ‘tagged’ objects and their
associated metadata, including object
position data, are sent either to the NSR
Series recorder or the IMZ-RS400 Series
software. These products then use
the metadata, together with filters, to
analyze object movement and to
perform a predefined action, such as
image recording or alarm triggering.
This method of distributed processing
minimizes server workload, network
bandwidth, and storage requirements.
Stunning video and audio brought
to you by the “IPELA” series of visual
communication products that
encompass the three-pronged
concept of “Reality,” “Intelligence,”
and “Usability.” “IPELA” connects
people, places, and information
with reality. “IPELA” lets you share,
understand, and experience as if
you are actually there, when in fact,
you are miles away. It allows you to
quickly grasp a situation to make better
business decisions. Real audiovisual
communication over networks –
this is “IPELA.”
The SNC-DF85/DF50 incorporates
DynaView Technology, which
contributes to the camera’s wide
dynamic range. It reduces ‘white-out’
in high-contrast shooting environments,
such as when the camera is located at
the entrance of a building where there
is a strong backlight.
The SNC-DF85/DF80/DF50 incorporates
advanced compression technologies
to transmit image data in three
different formats, JPEG, MPEG-4, and
H.264, so that users can choose the
best compression format depending
on their applications. With a 3.6x zoom,
vari-focal lens that covers up to 100.8°,
the SNC-DF85/DF80/DF50 can be used
to monitor facilities that require a wide
angle of view.
The PoE (Power-over-Ethernet,
IEEE802.3af compliant) function
gives users more freedom over where
to install the cameras, while saving
cost. Plus, they are all equipped
with Intelligent Video Analytics to
give you an intelligent and dynamic
detection system.
Features
Sends Relevant Images
Sends Object ID and Position
Intelligent Motion Detection
NSR Series/IMZ-RS400 Series
Analyzes Object Movement
Requests Relevant
Images
Mini-dome
Camera
Person1
Person2
Filter (Passing-Directional)
Person1
Person2
– Intelligent Motion Detection
– Intelligent Object Detection
– High Frame Rate
– Dynamic Frame Integration
– JPEG, MPEG-4, H.264
Compression Formats
– Dual Encoding Capability
– User-Friendly GUI
IntelligenceReality Usability

Wide Dynamic Range With
DynaView Technology
DynaView technology in the SNC-DF85
and SNC-DF50, enhance the cameras’
dynamic range by 128 times. The
cameras capture the same image
twice – combining the dark areas
from a normal shutter speed with the
bright areas at high shutter speed into
one image. Advanced white balance
circuits reproduce high-contrast with
proper colour.
SuperExwave Technology
The SNC-DF80 incorporates an
advanced 1/3-type CCD with
SuperExwave technology that
achieves extremely high sensitivity
levels. The camera provides a minimum
illumination of 0.6 lx in color and 0.06
lx in B/W at F1.3, allowing it to capture
clear and detailed images even under
low light conditions.
The high-quality CCD imager, in
combination with the camera’s
state-of-the-art DSP technology,
produces a high horizontal resolution
of 540 TV lines via the analogue
composite video output, which
provides amazingly clear and
detailed images.
Day/Night Function
The SNC-DF85 and SNC-DF80 cameras
can switch from day mode (color)
to night mode (B/W) by replacing its
infrared-cut filter with a clear filter.
Users can toggle between the
two manually, on a predefined
schedule using an external sensor, or
automatically in response to available
light. In night mode, sensitivity to near-IR
illuminators, allow operation in even
in zero conditions.
Dynamic Frame Integration
Frame Integration (DFI) technology
detects movement within the image
and reproduces those areas with
minimal blurring, while displaying areas
with little or no movement naturally.
DFI provides clear images – even in
low light conditions.
JPEG Picture Quality Settings With
Constant Bitrate Algorithm
Users can preset the JPEG picture
quality from a choice of ten levels.
Data bitrate can be limited while still
maintaining high-quality images - ideal
for calculating storage capacity and
bandwidth during installation.
Wall- or Ceiling-mountable/Easy
Viewing-angle Adjustment
This range can be easily wall- or ceiling
mounted.** An analogue composite
output (RCA jack), enables the camera
image to be monitored locally while the
viewing angle is adjusted, making
focus and viewing-angle adjustment
both accurate and easy.
** Supplied bracket is required when the SNC-DF85
and SNC-DF80 are wall- or ceiling-mounted.
Powerful 3.6x Zoom, Vari-focal Lens
These cameras come equipped with
a 3.6x zoom, vari-focal lens that covers
an extremely wide range of viewing
angles from 100.8° (wide-angle) to 27.7°
(telephoto).
Ball-Joint Lens Mount Technology
Sony patented Ball-Joint Lens Mount
mechanism enables the lens to be
rotated freely in any direction. Unlike
conventional cameras, it takes only one
action to adjust the pan and tilt angles,
ideal for viewing angle adjustment
during installation.
Ruggedized Design
The vandal-resistant SNC-DF85 and
SNC-DF80 comply with the IP66
standard, and offer additional water
resistance by using a special inner
conduit for the camera cables. The
optional YT-HU75 Heater Unit allows
the camera to be used in severe
temperatures as low as -40 °C (-40 °F).
Features
SNC-DF85/DF80/DF50
Camera Image
Conventional
Camera Image
Image Comparison Between SNC-DF85/DF80/DF50
Camera and a Conventional Camera
High-quality Images Flexible and Easy Installation
Ceiling Flush Mount (SNC-DF50/YT-ICB45 Ceiling Mount Bracket)
Normal Shutter
Speed
High Shutter
Speed
SNC-DF85/DF50
Camera Image*
*Simulated images

Selectable JPEG, MPEG-4, H.264
Compression Formats
These multi-codec cameras support
three compression formats: JPEG,
MPEG-4, and H.264. The industry-
standard JPEG compression format
is the best choice for high-quality still
images. MPEG-4 provides clear moving
images efficiently over networks when
bandwidth is limited. And H.264 provides
twice the efficiency of MPEG-4, for when
bandwidth is even more limited.
Dual-encoding Capability
With a dual-encoding capability, these
cameras can generate both MPEG-4
and JPEG images simultaneously. For
example, the system can be set up to
transfer MPEG-4 images over a WAN or
an Internet VPN where network
bandwidth is limited, while storing
high-resolution JPEG images on a
server that’s configured on your LAN.
Bi-directional Audio
Users can connect an external
microphone to these cameras
in order to pick up audio from a
preferred location. They are also
equipped withan active speaker
output, enabling users to sound an
alert or make an announcement from
the camera unit via a remote location.
This significantly expands the possibilities
of monitoring applications.
Voice Alert
The Voice Alert function allows users to
upload up to three pre-recorded audio
files to the camera. These can then be
played out via a locally connected
speaker upon an alarm trigger.
WAN/VPN
SNC-DF50
Local Area Network (LAN)
ROUTER
Monitoring PCIMZ-RS Series Server
MPEG-4
JPEG
JPEG &
MPEG-4
Images
Dual Image Encoding
Powerful 3.6x Zoom
Operational Flexibility
Ceiling Surface Mount (SNC-DF50)

Date/Time Superimposition
The date and time of images
recorded by these cameras can be
superimposed on the video while it is
being monitored and recorded. This
feature is ideal for easily identifying the
exact date and time of an event
during playback. Also because the
information becomes part of the video
image, it is a useful feature when
providing video evidence to authorities.
File Export to Removable Media
The SNC-DF85 and SNC-DF80 cameras
are equipped with a Compact FlashTM
(CF) card slot, allowing users to export
images on CF media as required.
Privacy Zone Masking*8
These cameras can mask up to seven
unwanted or prohibited areas within an
image for privacy protection.
*8Supplied “SNC Privacy Masking Tool” software is
required to set masking areas.
24 V AC, 12 V DC, or PoE Operation
These cameras offer a choice of three
types of power: 24 V AC, 12 V DC, or
PoE (Power-over-Ethernet, IEEE 802.3af).
They automatically adapt to whichever
power source is used, making
installation fast and effective.
Network Features
• Simultaneous Access for up to 20 Users
• Multicasting Capability
Other Features
High Level of Security
Intelligent Motion Detection (IMD)
The built-in IMD function can trigger a
variety of actions, such as the storage
and transfer of images or the activation
of an external device through its output
relays. False alarms caused by noise
and repeated motion patterns are
minimized thanks to an advanced
Sony algorithm. Plus, when used in
conjunction with DEPA-enabled
recorders or software, a multitude of
filter functions are available. These
allow you to initiate alarms based on
more specific movements, such as
passing a virtual borderline or
appearing into a virtual area.
Intelligent Object Detection (IOD)
The SNC-DF85, SNC-DF80, and SNC-
DF50 cameras can detect objects that
have been abandoned or become
stationary for a specified duration
within up to four designated detection
areas. This feature is useful for detecting
suspicious objects left in public places,
or for detecting stalled cars or
accidents on the road.
As with IMD, filters can be
used to refine this intelligence if
the camera is configured with
DEPA-enabled products.
Sensor IN/Alarm OUT Ports
Equipped with a sensor input, these
cameras can receive triggers from an
external sensor. Also, two alarm relay
outputs can be used to trigger external
devices to perform a variety of actions.
Pre-/Post-alarm Image Storage
These cameras are capable of
storing both preand post-alarm
images on 16 MB of built-in memory
or on removable storage media.
Network Security Features
IEEE802.1X Compliant
The SNC-DF85, SNC-DF80, and SNC-
DF50 support IEEE802.1X port-based
network access control. This means they
can be integrated to a network
environment that uses the IEEE802.1X
client authorization protocol for
security purposes.
Versatile Interfaces
Analogue Composite Video Output
These cameras can output an
analogue composite video signal via
the BNC connector. This feature is ideal
for outputting images to a local
recording device or monitor.
Compact Flash™ Card Slot available
on the SNC-DF85 and SNC-DF80.
Features

System Configurations
Standalone Configuration
Client-Server Configuration
Dimensions
Optional Accessories Rear Panel
YT-ICB45
In-Ceiling Mount Bracket
YT-HU75
Heater Unit
SNC-DF50N/DF50P
PC
Network Recorder
NSR Series
Network
Network
Machine Room
Network Recorders
NSR Series
Network Attached
Storage
Monitoring Room
Network
Network Cameras
Network
Intelligent Monitoring Software
RSM Controller Installed PC
SNC-DF85N/SNC-DF85P
SNC-DF80N/SNC-DF80P
Template
ø177.5 (7)
Conduit hole (3/4in.)
141.5 (5 5/8)
85.7 (3 3/8)
46 (1 13/16)
85.7 (3 3/8)
83.5 (3 9/32)
Hole for cables
ø58 to 72
(2 3/6to 2 7/8)
Horizontal
marker
Hole for bracket
Vertical marker
SNC-DF50N/SNC-DF50P
ø126 (5)
ø5 (7/32) hole x 2
83.5 (5 9/32)
140.5 (5 5/8)

SNC-DF/85P/80N/80P/50P Specifications
Camera SNC-DF85N SNC-DF85P SNC-DF80N SNC-DF80P SNC-DF50N SNC-DF50P
Image device 1/3-type CCD with DynaView Technology 1/3-type CCD with SuperExwave Technology 1/3-type CCD with DynaView Technology
Number of effective pixels (H x V) 380,000 (768 × 494) 440,000 (752 × 582) 380,000 (768 x 494) 440,000 (752 x 582) 380,000 (768 x 494) 440,000 (752 x 582)
Electronic shutter 1/60 to 1/10,000 s 1/50 to 1/10,000 s 1/60 to 1/10,000 s 1/50 to 1/10,000 s 1/60 to 1/10,000 s 1/50 to 1/10,000 s
Auto gain control Auto, EV compensation, DynaView On/Off (0 dB to +24 dB) Auto, EV compensation, DynaView
Exposure control Auto, Backlight compensation
White balance mode ATW, ATW Pro
Lens type Vari-focal lens
Zoom ratio 3.6× optical zoom (1.5× digital zoom)
Horizontal viewing angle 100.8° to 27.7°
Focal length f=2.8 to 10.0 mm
F-number F1.3 (wide), F3.0 (tele)
Minimum object distance 300 mm
Image size (H x V) 640 × 480, 320 × 240, 160 × 120 (JPEG, MPEG-4, H.264)
Compression format JPEG, MPEG-4, H.264
Maximum frame rate JPEG/MPEG-4
H.264
30 fps (640 × 480)
10 fps (640 × 480)
25 fps (640 × 480)
8 fps (640 × 480)
30 fps (640 x 480)
10 fps (640 x 480)
25 fps (640 x 480)
8 fps (640 x 480)
30 fps (640 x 480)
10 fps (640 x 480)
25 fps (640 x 480)
8 fps (640 x 480)
Audio
Audio compression G.711/G.726 (40, 32, 24, 16 Kb/s)
Network
Protocols TCP/IP, HTTP, ARP, ICMP, FTP, SMTP, DHCP, SNMP, DNS, NTP, RTP/RTCP
Number of clients 20
Authentication IEEE802.1X
Interface
Ethernet 10Base-T/100Base-TX (RJ-45)
Card slot CF card ×1 -
Analogue video output BNC ×1, 1.0 Vp-p, 75 Ω, RCA × 1
I/O port Sensor in × 1, Alarm out × 2
External microphone input Mini-jack (monaural, 2.2 K 2.5 V plug-in power)
Audio line output Mini-jack (monaural), max output level: 1 Vrms
Analogue video output
Signal system NTSC (Composite) PAL (Composite) NTSC (Composite) PAL (Composite) NTSC (Composite) PAL (Composite)
Horizontal resolution 480 TV lines 540 TV lines 480 TV lines
S/N ratio more than 50 dB
Min. illumination Color: 0.7 lx (50IRE, F1.3, AGC ON)
B/W: 0.15 lx (50IRE, F1.3, AGC ON)
Color: 0.6 lx (50IRE, F1.3, AGC ON)
B/W: 0.06 lx (50IRE, F1.3, AGC ON)
0.7 lx (50IRE, F1.3, AGC ON)
General
Mass Approx. 1.8 kg (3 lb 15 oz) Approx. 920 g (2 lb)
Dimensions (Ø x H) 177.5 x 141.5 mm (7 x 5 5/8 inches) 126 x 140.5 mm (5 x 5 5/8 inches)
Power requirements PoE (IEEE-802.3af)/AC24V/DC12 V
Power consumption 10 W max. 9 W max.
Operating temperature -10 to 50 °C (14 to 122 °F)
-40 to 50 °C (-40 to 122 °F) w/heater unit -10 to 50 °C (14 to 122 °F)
Storage temperature -20 to 60 °C (-4 to 140 °F)
Supplied accessories
Bracket, Template, Torx wrench, M4 screws (4), Wire rope, M4 shoulder screw, Audio cable,
I/O cable, CD-ROM (User’s guide, IP setup program, Audio Upload Tool, Privacy Masking
Tool, Video Player, Custom Homepage Installer), Installation manual
Template, Wire rope, M4 shoulder screw, AC
power cord, Monitor cable, CD-ROM (User‘s
guide, IP setup program, Audio Upload Tool,
Privacy Masking Tool, Video Player, Custom
Homepage Installer), Installation manual
System requirements
Operating system Microsoft® Windows® 2000/XP
Processor CPU: Intel® Pentium® IV 1.5 GHz or higher (2.4 GHz or higher is recommended)
Memory RAM: 256 MB or more
Web browser Microsoft Internet Explorer® Ver. 6.0
*The SNC-DF85N/DF85P, SNC-DF80N/DF80P, and SNC-DF50N/DF50P include software developed by the OpenSSL project for use in the OpenSSL Toolkit. (http://www.openssl.org/)
*The SNC-DF85N/DF85P, SNC-DF80N/DF80P, and SNC-DF50N/DF50P include cryptographic software written by Eric Young ([email protected])
© 2008 Sony Corporation. All rights reserved. Reproduction in whole or in part without written
permission is prohibited. Features and specifications are subject to change without notice.
All non-metric weights and measurements are approximate. Projected images in this brochure
are simulated. Sony is a registered trademark of Sony Corporation. All other trademarks are the
property of their respective owners.
Distributed by
www.sonybiz.net/videosecurity
