SSC-CD Series
Fixed Mini-dome Cameras
www.sony.com/security
SONY52958_SSCCD 5/21/07 2:52 PM Page 3

Sony introduces a new line of fixed mini-dome cameras. All of these cameras employ
highly sensitive imagers that produce amazingly clear and detailed images in a
number of security and surveillance monitoring applications. For easy setup, they
incorporate the Sony patented Ball-Joint Lens Mount mechanism, which provides
quick and easy adjustment of the camera‘s viewing angle during installation.
The SSC-CD77/CD77P and SSC-CD75/CD75P are vandal-resistant mini-domes
designed for either indoor or outdoor use. The SSC-CD77/CD77P camera
incorporates the latest 1/3-type CCD with SuperExwaveTM technology, which provides
superb sensitivity. Designed for 24x7 operation, it also incorporates a Day/Night
function that can produce detailed images even in zero lx
* 1lighting conditions. The
SSC-CD75/CD75P utilizes a 1/3-type Super HAD CCDTM to deliver high-quality color
images and is perfect for security applications that do not require a day/night
capability.
The SSC-CD49/CD49P and the SSC-CD45/CD45P are compact and discreet dome
cameras designed for indoor security and surveillance monitoring applications. The
SSC-CD49/CD49P camera incorporates unique Sony DynaViewTM technology to
provide a wide dynamic range when viewing high-contrast scenes with severe
backlighting, such as a window or an entrance to a building.
Feature rich and flexible, this line of mini-dome cameras offers a wide variety of
options to choose from. Each camera has a unique feature set, which allows users
to choose exactly the right camera for their solution requirements.
*1 Zero lx means the absence of visible light to the naked eye. IR illuminators are required to operate at zero lx.
Reproducing Extremely Clear and Detailed Images,
Sony Analog Mini-dome Cameras are Ideal for use
in Commercial and Industrial Locations Such as
Airports, Schools, Offices, and Many More!
FEATURES AT A GLANCE
SSC-CD77/CD77P SSC-CD75/CD75P SSC-CD49/CD49P SSC-CD45/CD45P
CCD Imager 1/3-type CCD With 1/3-type Super HAD CCD 1/3-type CCD With 1/3-type Super HAD CCD
Super Exwave Technology Dynaview Technology
Horizontal Resolution (TV lines) 540 540 480 540
Ruggedized Design ––
(Vandal- and Weather-Resistant)
Wall- or Ceiling-Mountable
3.6x Zoom, Auto-Iris Vari-Focal Lens
Sony Patented Ball-Joint Lens Mount
Day/Night Function – – –
Wide Dynamic Range With DynaView – – –
Backlight Compensation
Auto Tracing White Balance (ATW)/ATW pro
SONY52958_SSCCD 5/21/07 2:52 PM Page 4

<Normal Shutter Speed> <High Shutter Speed>
<SNC-CD49 Camera Image> (simulated images)
DynaView Technology
Superb Picture Quality
SuperExwave Technology
The SSC-CD77/CD77P incorporates an advanced
1/3-type CCD with SuperExwave technology that
achieves extremely high sensitivity levels. This CCD
imager provides a minimum illumination of 0.6 lx in
color and 0.06 lx in B/W at F1.3, enabling the camera
to capture clear and detailed images even under
low light conditions.
Wide Dynamic Range With
DynaView Technology
The SSC-CD49/CD49P incorporates DynaView
technology, which dramatically improves the camera‘s
dynamic range by 128 times when compared to
conventional cameras. This results in clear image
reproduction, even in extreme high-contrast
environments. The camera captures the same image
twice – first with a normal shutter speed, and then with
a high shutter speed. The dark areas captured at
normal shutter speed and the bright areas captured
at high shutter speed are then combined into one
image using an advanced DSP LSI. Additionally, as
these high-contrast scenes may have different lighting
conditions, two white balance circuits are employed –
one for normal shutter speed and the other for high
shutter speed. This advanced technique reproduces
high-contrast images with proper color.
Super HADTM CCD
The SSC-CD75/CD75P and SSC-CD45/45P incorporate
a 1/3-type Super HAD CCD that delivers high sensitivity
levels and high picture quality for a number of
monitoring applications. The minimum illumination of
these cameras is 0.9 lx at F1.3.
FEATURES
SSC-CD75/CD75P SSC-CD45/CD45P
High Horizontal Resolution
The high-quality CCD imager of the
SSC-CD77/CD77P/CD75/CD75P/CD45/CD45P,in
combination with the camera‘s state-of-the-art DSP
technology, produces a high horizontal resolution of
540 TV lines for amazingly clear and detailed images.
Powerful 3.6x Zoom, Vari-focal Lens
These cameras come equipped with a 3.6x zoom,
vari-focal lens that covers an extremely wide range
of viewing angles from 100.8° (wide-angle) to 27.2°
(telephoto). This feature provides installation flexibility
for a number of different applications and locations.
Flexible and Easy Installation
Wall- or Ceiling-mountable/Easy Viewing-
angle Adjustment
These cameras can be easily wall- or ceiling-mounted*2,
for installation flexibility. Also, in addition to the BNC
video output on the rear of the camera, a secondary
video output (RCA phono jack) is provided on the
front of the camera. This allows installers to monitor
images during installation for accurate and quick
adjustment of the focus and viewing-angle.
*2 Supplied bracket is required when the
SSC-CD77/CD77P is wall- or ceiling-mounted.
SSC-CD77/CD77P SSC-CD75/CD75P SSC-CD45/CD45P
108°(wide)
27.2°(tele)
Ceiling Surface Mount
(SSC-CD45)
Ceiling Flush Mount
(SSC-CD45/ YT-ICB45
Ceiling Mount Bracket)
SSC-CD77/CD77P
SSC-CD49/CD49P
SONY52958_SSCCD 5/21/07 2:52 PM Page 5

Special Inner Conduit
Cable
Ball-Joint Lens Mount Technology
With the Sony patented Ball-Joint Lens Mount
mechanism incorporated into the vari-focal lens of
these cameras, the lens can be rotated freely in any
direction. Unlike conventional cameras, it takes only
one action to pan, tilt and rotate the imager/lens,
allowing for quick and easy adjustment of the
camera‘s viewing angle during installation.
Ruggedized Design
The vandal-resistant SSC-CD77/CD77P and
SSC-CD75/CD75P cameras are housed in a heavy-
duty, aluminum die-cast enclosure with an impact-
resistant polycarbonate dome. The camera complies
with the IP66*3 standard, and offers additional water
resistance by using a special inner conduit for the
camera cables. For cold-weather outdoor
applications, the optional YT-HU75 Heater Unit is
available. This allows the camera to be used in
severe temperatures as low as
-40 °C (-40 °F).
*3 Ingress Protection (IP) standard is a system for numerically
classifying the degree of protection provided by enclosures
of electrical equipment against solid objects and liquids.
IP66 means there is no ingress of dust and the equipment is
protected against powerful water jets.
Sony Patented Ball-Joint Lens Mount
Operational Flexibility
Day/Night Function
The SNC-CD77/CD77P camera can switch from day
mode (color) to night mode (B/W) by replacing its
infrared-cut filter with a clear filter. Based on user presets,
the camera can toggle between day mode and night
mode when triggered by an external sensor, or
automatically in response to surrounding light conditions.
The camera can simultaneously switch to night mode
and provide a trigger for near-IR illuminators via its
external control port, allowing it to operate even in zero
lx*4 conditions.
*4 Zero lx means the absence of visible light to the naked eye.
IR illuminators are required to operate at zero lx.
Other Convenient Features
Backlight Compensation (BLC)
Unwanted backlight can often cast a shadow in front
of the subject of an image, making it appear dark to
the camera. The BLC function incorporated in the
SSC-CD77/CD77P/CD75/CD75P/CD45/CD45P
cameras automatically compensates for such
conditions, making the subject more visible.
Automatic Gain Control (AGC)
These cameras are equipped with an advanced
AGC function. This automatically boosts the camera
gain up to 24 dB, allowing operators monitoring the
image to distinguish the subject more easily in low
light conditions.
Auto Tracing White Balance (ATW)/ATW Pro
ATW is a feature that automatically adjusts the
camera's white balance to adapt to changing light
conditions. With ATW, these cameras can compensate
for a color temperature range of between 2,000 K and
10,000 K, allowing for operation under a variety of
lighting conditions, including common outdoor light
sources such as high pressure sodium vapor lamp.
When operating under natural light, incandescent
lamps, or fluorescent light sources, ATW Pro – which
compensates for a color temperature range of
between 2,500 K and 6,000 K – is ideal for reproducing
color images closer to what we see with our eyes.
AC Line Lock/Internal Line Lock
These cameras feature both an AC line lock and an
internal line lock for synchronization. The AC line lock is
ideal in multi-camera operations, as it synchronizes all
cameras connected to the same power line.
This helps to prevent the video from rolling vertically
when switching between cameras. The vertical
phase can be adjusted by ±90 degrees.
Flexible Power Operation
These cameras offer a choice of two types of power:
24 V AC or 12 V DC. The camera automatically adapts
to whichever power source is used, making installation
fast and effective.
SSC-CD77/CD77P SSC-CD75/CD75P
SSC-CD77/CD77P
SSC-CD77/CD77P SSC-CD75/CD75P SSC-CD45/CD45P
Water-resistant Design (SSC-CD77/CD75 inside)
SONY52958_SSCCD 5/21/07 2:52 PM Page 6

OPTIONAL ACCESSORIES
SYSTEM CONFIGURATIONS
DIMENSIONS
YT-ICB45
In-Ceiling Mount Bracket
YT-HU75 Heater Unit
SSC-CD77/CD77P
SSC-CD75/CD75P
5 5/8(141.5)
R1
13
/
16
(44.5)
ø7 (177.5)
Conduit hole (3/4)
Template
3 3/8(85.7)
1 13/16 (46)
3 3/8(85.7)
3 9/32 (83.5)
Hole for cables
ø2 3/6to 2 7/8
(58 to 72)
Horizontal
marker
Hole for bracket
Vertical marker
SSC-CD49/CD49P
SSC-CD45/CD45P
ø7/32 (5) hole x 2
5 9/32 (83.5)
ø5 (126)
3 7/8(97.5)
VIDEO OUT
(Coaxial Cable)
PC
Ethernet
Ethernet
Sony Video Network Station LAN
Monitor OUT
(Coaxial Cable)
Color Video Monitor
Digital Hard Disk Recorder
Color Video Monitor
VIDEO OUT (Coaxial Cable)
VIDEO OUT (Coaxial Cable)
AC outlet
AC 24 V or DC 12 V
Power Supply
AC 24 V or DC 12 V
Power Supply
Multiple Camera Operation
Multiple Camera Operation over LAN
Single Camera Operation
AC outlet
VIDEO OUT (Coaxial Cable)
SSC-CD Series Cameras
SSC-CD Series Cameras
SSC-CD Series Cameras
Color Video Monitor
NSR Series
NETWORKSURVEILLANCE RECORDER NSR-100
POWER NETWORK
Unit: inches (mm)
SSC-CD77/CD77P
SSC-CD75/CD75P
SONY52958_SSCCD 5/21/07 2:52 PM Page 1

Printed in U.S.A. 4/07
Sony Electronics Inc.
One Sony Drive
Park Ridge, NJ 07656
www.sony.com/security
S-A3001
MK10393V1
© 2007 Sony Electronics Inc. All rights reserved.
Reproduction in whole or in part without written permission is prohibited.
Features and specifications are subject to change without notice.
All non-metric weights and measurements are approximate.
Some images in this brochure are simulated.
Sony, SuperExwave, Super HAD, and DynaView are trademarks of Sony.
All other trademarks are the property of their respective owners.
SPECIFICATIONS
SSC-CD77 SSC-CD77P SSC-CD75 SSC-CD75P
Camera
Image device 1/3-type CCD with SuperExwave Technology 1/3-type CCD with Super HAD Technology
Number of effective pixels (H x V) 380,000 (768 x 494) 440,000 (752 x 582) 380,000 (768 x 494) 440,000 (752 x 582)
Gain control ON/OFF
White balance mode ATW/ATW Pro
Lens type Auto iris vari-focal lens
Zoom ratio 3.6x optical zoom (1.5x digital zoom)
Horizontal viewing angle 100.8° to 27.7°
Focal length f=2.8 to 10.0 mm
Backlight compensation ON/OFF
Day/Night function Auto/External control –
Analog video output BNC x1, 1.0 Vp-p, 75 Ω, RCA x 1
Signal system NTSC (Composite) PAL (Composite) NTSC (Composite) PAL (Composite)
Sync system AC Line Lock/Internal Lock
Horizontal resolution 540 TV lines
S/N ratio more than 50 dB (AGC ON/Weight ON)
Min. illumination Color: 0.6 lx (50IRE, F1.3, AGC ON) 0.9 lx (50IRE, F1.3, AGC ON)
B&W: 0.06 lx (50IRE, F1.3, AGC ON)
General
Weight approx. 3 lb 11 oz (1.75 kg)
Dimensions (Ø x H) approx. 7 x 5 5/8inches (177 x 141 mm)
Power requirements AC24V/DC12V
Power consumption 4 W max. (16 W with heater option)
Operating temperature -4 to 122 °F (-20 to 50 °C)
-40 to 122 °F (-40 to 50 °C) w/heater unit
Storage temperature -40 to 140 °F (-40 to 60 °C)
Supplied accessories
Bracket, Template, Torx wrench, M4 screws (4), Wire rope, M4 shoulder screw, Operation instructions
SSC-CD49 SSC-CD49P SSC-CD45 SSC-CD45P
Camera
Image device 1/3-type CCD with DynaView technology 1/3-type CCD with Super HAD Technology
Number of effective pixels (H x V) 380,000 (768 x 494) 440,000 (752 x 582) 380,000 (768 x 494) 440,000 (752 x 582)
Gain control ON/OFF
White balance mode ATW/ATW Pro
Lens type Auto iris vari-focal lens
Zoom ratio 3.6x optical zoom (1.5x digital zoom)
Horizontal viewing angle 100.8° to 27.7°
Focal length f=2.8 to 10.0 mm
Backlight compensation DynaView ON/OFF ON/OFF
Analog video output BNC x1, 1.0 Vp-p, 75 Ω, RCA x 1
Signal system NTSC (Composite) PAL (Composite) NTSC (Composite) PAL (Composite)
Sync system AC Line Lock/Internal Lock
Horizontal resolution 480 TV lines 540 TV lines
S/N ratio more than 50 dB (AGC ON/Weight ON)
Min. illumination Color: 0.7 lx (50IRE, F1.3, AGC ON) 0.9 lx (50IRE, F1.3, AGC ON)
General
Weight approx. 15 lb (440 g)
Dimensions (Ø x H) approx. 5 x 3 7/8inches (126 x 97 mm)
Power requirements AC24V/DC12V
Power consumption 4.2 W max. 4.0 W max.
Operating temperature -4 to 122 °F (-20 to 50 °C)
Storage temperature -40 to 140 °F (-40 to 60 °C)
Supplied accessories
Template, Wire rope, M4 shoulder screw, Operation instructions
SONY52958_SSCCD 5/21/07 2:52 PM Page 2
