Sony SS-RG66 User manual

SS-RG66/RG66A
Canadian Model
SS-RG66A
AEP Model
UK Model
E Model
SS-RG66/RG66A
Australian Model
SS-RG66
SERVICE MANUAL
SPEAKER SYSTEM
•SS-RG66/RG66A are speaker systems
in MHC-GX30/RG33/RG55/RG66.
EXPLODED VIEW AND PARTS LIST
Ver 1.1 2003. 12
Ref. No. Part No. Description Remarks
SPECIFICATIONS
SS-RG66
Speaker system : 3-way, 3-unit, bass-reflex type
Sub Woofer : 13 cm, cone type
Woofer : 13 cm, cone type
Tweeter : 5 cm, cone type
Nominal impedance : 6 ohms
Dimensions (w/h/d) : Approx. 215 ×356 ×290 mm
Mass : Approx. 4.5 kg net per speaker
SS-RG66A
Speaker system : 3-way, 3-unit, bass-reflex type
Sub Woofer : 13 cm, cone type
Woofer : 13 cm, cone type
Tweeter : 5 cm, cone type
Nominal impedance : 6 ohms
Dimensions (w/h/d) : Approx. 215 ×356 ×260 mm
Mass : Approx. 4.2 kg net per speaker
Design and specifications are subject to change without notice.
1A-4746-917-A SPEAKER (L) ASSY (RG66)
1A-4746-918-A SPEAKER (R) ASSY (RG66)
14-241-701-11 SPEAKER (L) ASSY (RG66A)
14-241-702-11 SPEAKER (R) ASSY (RG66A)
1
Sony Corporation
Home Audio Company
Published by Sony Engineering Corporation
9-873-579-02
2003L16-1
© 2003.12
Photo : SS-RG66 (L-ch)
L-ch

SS-RG66/RG66A
REVISION HISTORY
Clicking the version allows you to jump to the revised page.
Also, clicking the version at the upper right on the revised page allows you to jump to the next revised
page.
Ver. Date Description of Revision
1.0 2002.02 New
1.1 2003.12 Addition of Part. No. for SPEAKER ASSY (L/R)(RG66A) (SPM-03133)
