170 Watts Total: 85 Watts per Channel x 2 (RMS 10% THD)
Plenty
of power for small to large size rooms or offices.
PC/Audio In for Digital Music Players or PC Input
An exciting new
feature that takes music playback beyond tape and CD. It allows simple
plug
-and-
play integration with a digital music device or PC via a 2.5mm
jack.
5 Disc CD Changer with CD Pop
-
Up Loading
Mechanism
Provides a unique way to keep the music going all day, or
all night long. Pop
-
up mechanism ejects CD
’
s vertically for convenience
and style.
2
-
Way Main Speakers
A 2 driver design helps ensure audio accuracy
by providing a greater frequency range. The speaker's crossover splits
the frequency band into 2 ranges: bass frequencies go to the woofer, and
treble frequencies go to the tweeter.
Plays Back CD
-
R/RW Discs
For customers who already have
extensive music libraries. Use CD burning software to music compilations
tailored to your listening preference.
S
-
Master Digital Amplifier
More efficient than traditional analog
amplifiers by using less energy to produce the same signal. The audio
benefits are higher resolution sound quality, monitored noise reduction
and accurate sound reproduction
Specifications
General
Type of Use: Desktop Micro System
Disc Changer:
5
Tray Type:
5 Disc CD Changer with CD Pop
-
Up Loading Mechanism
(Semiconductor Laser 780nm)
Audio
Digital
-
to
-
Analog Converter:
1 Bit
Frequency Response:
CD: 20
-
20000Hz (
±
0.3db); Cassette: 50
-
13000Hz
(±0.5db)
Format(s) Supported: CD-
DA, CD
-
R/RW, CDs with
MP3/ATRAC3
®
/
ATRAC3 plus
™
Audio Playback Capability
Tuning:
Auto Scan Radio
Antenna System:
AM: Loop Antenna, FM: Lead Antenna
Tape System:
4 Track, 2 Channel Stereo Cassette, CD Synchronized
Recording
Frequency Range:
AM: 530
-
1710kHz; FM: 87.5
-
108.0MHz
CD Play Mode(s):
Program, Shuffle, Repeat
Station Preset(s):
30 (10 AM, 20 FM)
Sound Enhancer: DSGX (Dynamic Sound Generator X-tra)
Equalizer:
7 Presets (Rock, Jazz, Classic, Hall, Live, Movie, Flat)
Tape Operation:
Single Cassette Deck
Tuner Type: FM/AM Superheterodyne Tuner
Convenience
Power Save Mode: Yes
Hardware
Display:
LCD
Remote Control: Yes (Remote Commander
®
)
Power
Power Requirements:
AC 120V, 60Hz
Output Power:
170W Total (85 W + 85 W (6 ohms at 1 kHz, 10% THD))
Power Consumption:
145W
Battery Type:
Remote: "AA" x 2
Power Handling Capacity:
With 6 ohms loads, both channels driven from
120
-
10000 Hz; rated 85 W per channel
-
minimum RMS power, with no
more than 10% total harmonic distortion from 250 milliwatts to rated output.
Speaker
Speaker System:
2
-Way Bass Reflex Type
Speaker Dimensions:
1.6" (4cm) Tweeter
Woofer Size(s):
5.9" (15cm)
Software
Supplied Software:
SonicStage
®
Inputs and Outputs
Analog Audio Input(s):
1 (Rear, Stereo Mini)
Headphone Input(s):
1 (Front, Stereo Mini)
Antenna Terminal(s): 2 (Rear)
Optical Audio Digital Output(s): 1 (Rear)
Dimensions
Weight:
Speaker: 6 lbs 3 oz (2.8 Kg) (each x 2); Main Unit: 16 lbs 12 oz (7.6
Kg)
Measurements:
Speaker: 7 1/12 x 11 9/14 x 9 9/14" (180 x 296 x 245mm)
(each x 2); Main Unit: 7 4/5 x 10 5/6 x 13 3/7" (198 x 275 x 341mm)
Supplied Accessories
Power Requirements
Instruction Manual
Remote Commander
®
Remote Control (RM
-SC3)
Batteries x 2
FM Lead Antenna
UPC Code:
027242683563
1. CD-R/RW media/formats are not universally compatible.
