SERVICE MANUAL
Published by Sony Techno Create Corporation
Sony Corporation
Audio&Video Business Group
MINI HI-FI COMPONENT SYSTEM
9-889-428-03
2010B05-1
© 2010.02
US Model
Canadian Model
UK Model
Australian Model
MHC-EC69i/EC79i/EC99i
Mexican Model
MHC-EC69i
Ver. 1.2 2010.02
• MHC-EC69i/EC79i/EC99i are composed of following models.
As service manuals are issued for each component model,
please refer to them.
SPECIFICATIONS
COMPONENT MODEL NAME
MHC-EC69i MHC-EC79i MHC-EC99i
Compact Disc Receiver HCD-EC69i HCD-EC79i HCD-EC99i
Front Speaker SS-EC69i SS-EC79 SS-EC79
Subwoofer – – SS-WG99i
MHC-EC69i/EC79i/EC99i
iPod section
Compatible iPod models:
iPod nano 5th
generation
(video camera) iPod touch 2nd
generation
iPod nano 4th
generation
(video)
iPod touch 1st
generation
iPod nano 3rd
generation
(video) iPod classic
iPod nano 2nd
generation
(aluminum)
iPod 5th
generation
(video)
iPod nano 1st
generation
iPod 4th
generation
(color display)
iPod 4th
generation
iPod mini
iPod is a trademark of Apple Inc., registered in the U.S.
and other countries.
MPEG Layer-3 audio coding technology and patents
licensed from Fraunhofer IIS and omson.
All other trademarks and registered trademarks are of
their respective holders. In this manual, TM and ®marks
are not specied.
ACCESSORIES
1-754-399-11 ANTENNA, LOOP (FM lead/AM loop antenna)
2-055-382-01 LID, BATTERY CASE (for RM-AMU009)
2-159-896-01 CUSHION (FOOT) (8 pieces, 1 set)
(Speaker pads for front speakers)
4-131-119-12 MANUAL, INSTRUCTION (ENGLISH)
4-131-119-22 MANUAL, INSTRUCTION (FRENCH) (Canadian)
4-131-119-32 MANUAL, INSTRUCTION (SPANISH) (US)
4-182-959-31 MANUAL, INSTRUCTION (SPANISH) (Mexican)
4-972-322-01 FOOT (Y) (4 pieces, 1 set)
(Speaker pads for subwoofer) (MHC-EC99i)
A-1438-479-B RM-AMU009 (Remote commander)
(Including battery case lid)
Ref. No. Part No. Description Remark
Power requirements:
North American and Mexican models:
Australian model: AC 230 –240 V, 50/60 Hz
UK model: AC 230 V, 50/60 Hz
Power consumption:
MHC-EC99i
250 W
(0.5 Wat the Power Saving Mode)
MHC-EC79i
200 W
(0.5 Wat the Power Saving Mode)
MHC-EC69i
80 W
(0.5 Wat the Power Saving Mode)
Dimensions (w/h/d) (excl.speakers):
MHC-EC99i
Approx. 200 ×311 ×375 mm
MHC-EC79i (Australian and UK modelsonly)
Approx. 200 ×311 ×375 mm
MHC-EC79i (NorthAmerican model only)
Approx. 200 ×306 ×375 mm
MHC-EC69i
Approx. 200 ×306 ×305 mm
Mass (excl.speakers):
MHC-EC99i
Approx. 6.2 kg
MHC-EC79i (Australian and UK modelsonly)
Approx. 6.0 kg
MHC-EC79i (NorthAmerican model only)
Approx. 5.7 kg
MHC-EC69i
Approx. 3.8 kg
Supplied accessories: Remote Commander (1), R6 (Size AA) batteries (2)
(except for MHC-EC69i), FM lead/AM loop antenna (1), Speaker padsMHC-
EC99i (8) and for SS-WG99i (Subwoofer) (4)/MHC-EC79i (8)/EC69i (8)
Standby power consumption: 0.5 W
wiring boards.
Halogenated ameretardants are not used in the certain printed
Designand specications are subject to changewithout notice.
