Sony CMT-NEZ30 Marketing User manual

CMT-NEZ30
Micro Hi -Fi Component System
NEW
30 Watts Total: 15 Watts per Channel x 2 (RMS 10% THD)
CD-R/CD-RW with MP3 Playback Capability
1
Top- Loading Single CD Player
Synchronized CD/Cassette Dubbing
Bass Reflex Speaker Design
PC/Audio In for Digital Music Players or PC Input
Full Range Bass Reflex Speaker System
FM/AM Tuner with 30 Presets
3- Way Timer (Play/Record/Sleep)

Last Updated: 10/08/2007
CMT-NEZ30
Micro Hi -Fi Component System
Please visit the Dealer Network for current information at
www.sony.com/dn
Features
30 Watts Total: 15 Watts per Channel x 2 (RMS 10%
THD) Plenty of power for small rooms or offices.
Top - Loading Single CD Player Provides direct access to insert
or replace CD ’ s.
CD - R/CD - RW Playback Compatible Plays all CD - R/RW discs
burned either in a PC or a home recording deck. Create
custom mixes from your existing music collection and always
have the right music at hand.
1
Synchronized CD/Cassette Dubbing Starts cassette recording
when compact disc playback begins
Bass Reflex Speaker Design A speaker enclosure that includes
a "tuned" port to increase and extend bass response (by
releasing some of the energy created by the inward
movement of the woofer cone).
MP3 Playback The player will decode and play back MP3 files
that have been recorded onto a CD - R/RW disc. This allows the
customer to record hours of music from their PC onto a CD -
R/RW disc.
PC/Audio In for Digital Music Players or PC Input An exciting
new feature that takes music playback beyond tape and CD. It
allows simple plug - and - play integration with a digital music
device or PC via a 2.5 mm jack.
Specifications
General
Type of Use: Desktop Micro System
TrayType: Top Loading Single CD (Semiconductor Laser 780nm)
DiscCapacity: 1
Audio
Digital - to - AnalogConverter: 1 Bit
FrequencyResponse: CD: 20 - 20000Hz
Format(s)Supported: CD - DA, CD - R/RW, CDs with MP3 Playback
Capability
Tuning: Auto Scan Radio
AntennaSystem: AM: Loop Antenna, FM: Lead Antenna
TapeSystem: 4 Track, 2 Channel Stereo Cassette, Synchronized
CD/Cassette Dubbing
FrequencyRange: AM: 530 - 1710kHz; FM: 87.5 - 108.0MHz
CD Play Mode(s): Program, Shuffle, Repeat
StationPreset(s): 30 (10 AM, 20 FM)
SoundEnhancer: DSGX (Dynamic Sound Generator X - tra), Mega
Bass ®
Equalizer: 7 Presets (Rock, Jazz, Classic, Hall, Live, Movie, Flat)
TapeOperation: Single Cassette Deck
TunerType: FM/AM Superheterodyne Tuner
Convenience Features
TimerEvents: Record/Play/Sleep (Wake - up or Fall Asleep To
Music - Select from 10 Timed Shut Offs)
Power Save Mode: Yes
Hardware
Display: LCD
RemoteControl: Yes (Remote Commander ® Remote Control)
Power
PowerRequirements: AC 120V, 60Hz
OutputPower: 30W Total (15 W + 15 W (6 ohms at 1 kHz, 10%
THD))
PowerConsumption: 45W
BatteryType: Remote: "AA" x 2
Power Handling Capacity: With 6 ohms loads, both channels
driven from 120 - 10000 Hz; rated 9 W per channel - minimum RMS
power, with no more than 10% total harmonic distortion from
250 milliwatts to rated output.
Speaker
SpeakerSystem: Bass Reflex Type (Full Range Speaker System)
SpeakerDimensions: 3.1" (8cm) (Full Range Driver)
Inputs and Outputs
Analog Audio Input(s): 1 (Rear, Stereo Mini)
PC Audio Input(s): Yes
Antenna Terminal (AM Loop): 1 (Rear)
Antenna Terminal (FM 75 Ohm): 1 (Rear)
Dimensions
Weight: Speaker: 3 lbs 2 oz (1.5 Kg) (each x 2); Main Unit: 6 lbs 9
oz (3.2 Kg)
Measurements: Speaker: 5 5/7 x 9 1/4 x 6 1/10" (145 x 235 x
155mm) (each x 2); Main Unit: 6 5/11 x 9 1/4 x 10 7/16" (164 x
235 x 265mm)
Supplied Accessories
Instruction Manual
Remote Commander ® Remote Control (RM - SC1)
Batteries x 2
FM Lead Antenna
UPC Code: 027242683600
1.CD - R/RWmedia/formatsarenotuniversallycompatible.
©2005SonyElectronicsInc.
Reproductioninwholeorinpartwithoutwrittenpermissionisprohibited.Allrightsreserved.SonyandRemote
CommanderaretrademarksofSony.
Features and specifications are subject to change without notice. Non - metricweightsandmeasuresare
approximate.
