MHC-EC70
Mini Hi -Fi Component System
NEW
320 Watts Total: 160 Watts per Channel x 2 (RMS 10% THD, 120-10
kHz)
3-Way Main Speakers with huge 6 3/10" Woofers for Maximum Bass
PC/Audio In for Digital Music Players or PC Input
3 Disc CD Changer with Play Exchange
CD-R/CD-RW with MP3 Playback Capability
1
Piano Key Cassette Controls
Tuner with 20 FM/10 AM Station Presets
4 Preset EQ settings
Bass Reflex Speaker System
Synchronized CD/Cassette Dubbing
Two Timer Functions
DSGX Bass Boost Function

Last Updated: 10/08/2007
MHC-EC70
Mini Hi -Fi Component System
Please visit the Dealer Network for current information at
www.sony.com/dn
Features
320 Watts Total Power 160 per channel x 2(RMS 10% THD, 120 -
10 kHz)
3 Way Main Speakers with huge 6 3/10" Woofers for
Maximum Bass A two driver design helps ensure audio
accuracy by providing a greater frequency range. The
speaker's crossover splits the frequency band into three
ranges: bass frequencies to the woofer, treble frequencies go
to the tweeter and the middle frequencies are sent to a third
drive commonly referred to as the midrange.
3 Disc CD Changer with Play Exchange A feature that allows 2
discs to be changed while the third continues to play.
CD - R/CD - RW with MP3 Playback Capability Plays back MP3
files recorded onto CD - R/RW discs.
1
Piano Key Single Cassette Often referred to as a "soft - touch"
design, a full - logic transport's controls require less effort to use
than older style mechanical transports.
Tuner with 20 FM/10 AM Station Presets Provides easy access
to the most listened to radio stations.
4 Preset EQ settings Creates enhanced sound modes for
differnt types of music, such as rock and pop.
PC/Audio In for Digital Music Players or PC Input An exciting
new feature that takes music playback beyond tape and CD. It
allows simple plug - and - play integration with a digital music
device or PC via a 2.5 mm jack.
Bass Reflex Speaker System A type of speaker enclosure that
includes a "tuned" port to increase and extend bass response
(by releasing some of the energy created by the inward
movement of the woofer cone).
Synchronized CD/Cassette Dubbing Starts cassette recording
when compact disc playback begins
Two Timer Modes Provides a Sleep and Wake timers for ease of
use.
Specifications
General
Type of Use: Shelf System
TrayType: Tray Loading 3 Disc CD Changer with Play Exchange
(Semiconductor Laser 780nm)
DiscCapacity: 3
Audio
Digital - to - AnalogConverter: 1 Bit
FrequencyResponse: CD: 20 - 20000Hz (±0.5dB); Cassette: 50 -
13000Hz (±0.3db)
Format(s)Supported: CD - DA, CD - R/RW, CD's WITH MP3 Playback
Capability
Tuning: Auto Scan Radio
AntennaSystem: AM: Loop Antenna, FM: Lead Antenna
TapeSystem: 4 Track, 2 Channel Stereo Cassette, CD
Synchronized Recording
FrequencyRange: AM: 530 - 1710kHz; FM: 87.5 - 108.0MHz
CD Play Mode(s): Program, Shuffle, Repeat
StationPreset(s): 30 (10 AM, 20 FM)
SoundEnhancer: Groove Bass Boost Function, Virtual Surround
Sound Mode
Equalizer: 9 Presets (Rock, Pop, Jazz, Dance, Soul, Oriental,
Reggae, Salsa, Samba), 3 Personal File Settings
TapeOperation: Full Logic Dual Cassette Deck
TunerType: FM/AM Superheterodyne Tuner
Convenience Features
TimerEvents: Record/Play/Sleep (Wake - up or Fall Asleep To
Music - Select from 10 Timed Shut Offs)
Power Save Mode: Yes
Hardware
Display: LCD
RemoteControl: Yes (Remote Commander ® Remote Control)
Power
PowerRequirements: AC 120V, 60Hz
OutputPower: 300W Total (150 W +150 W (6 ohms at 1 kHz, 10%
THD))
PowerConsumption: 205W
Manual: 210W
BatteryType: Remote: "AA" x 2
Power Handling Capacity: With 6 ohms loads, both channels
driven from 120 - 10000 Hz; rated 150 W per channel - minimum
RMS power, with no more than 10% total harmonic distortion
from 250 milliwatts to rated output.
Speaker
SpeakerSystem: 3 Way, 3 Unit, Bass Reflex Type
SpeakerDimensions: 2" (5cm)
WooferSize(s): 5.1" (13cm); 5.1" (13cm) (Subwoofer)
Inputs and Outputs
Analog Audio Input(s): 1 (Rear, Stereo Mini)
HeadphoneInput(s): 1 (Front, Stereo Mini)
AntennaTerminal(s): 2 (Rear)
PC Audio Input(s): Yes
Dimensions
Weight: Speaker: 8 lbs 6 oz (3.8 Kg) (each x 2); Main Unit: 22 lbs 1
oz (10 Kg)
Measurements: Speaker: 9 1/16 x 13 7/12 x 9 1/4" (230 x 345 x
235mm) (each x 2); Main Unit: 11 x 12 4/5 x 16 13/14" (280 x
325 x 430mm)
Supplied Accessories
Instruction Manual
Remote Commander ® Remote Control (RM - SC50)
AM Roop Antenna
FM Lead Antenna
UPC Code: 027242683624
1.CD - R/RWmedia/formatsarenotuniversallycompatible.
©2006SonyElectronicsInc.
Reproductioninwholeorinpartwithoutwrittenpermissionisprohibited. All rights reserved. Sony, Remote
Commander,and like.no.other are trademarks of Sony.Allothertrademarks are property of their respective
owners.
Features and specifications are subject to change without notice. Non - metricweights and measuresare
approximate.
