Published by Sony Techno Create Corporation
Sony Corporation
Audio&Video Business Group
SERVICE MANUAL
MHC-GZR88D/GZR99D
MINI Hi-Fi COMPONENT SYSTEM
9-889-537-01
2009F04-1
© 2009.06
E Model
Ver. 1.0 2009.06
• MHC-GZR88D/GZR99D are composed of the following models.
As service manuals are issued for each component model,
please refer to them.
SPECIFICATIONS
General
Power requirements
Argentine and Thai models:
AC 220 V, 50/60 Hz
Mexican model: AC 127 V, 60 Hz
Other models: AC 120, 220, 230 −240 V, 50/60 Hz,
adjustable with voltage selector
Power consumption
MHC-GZR99D: 215 W
MHC-GZR88D: 170 W
Dimensions (w/h/d) (excl. speakers)
Approx. 280 ×326 ×440 mm
Mass (excl. speakers)
MHC-GZR99D: Approx. 13.2 kg (Latin American models),
approx. 13.7 kg (other models)
MHC-GZR88D: Approx. 13.2 kg
Supplied accessories:
Remote Commander (1)
AM loop antenna (1)
FM lead antenna (1)
Video cord (1)
Speaker foot (MHC-GZR99D (20), MHC-GZR88D (16))
Speaker cords (2)
Microphone (1) (Philippine model only)
R6 (Size AA) batteries (2)
Design and specifications are subject to
change without notice.
COMPONENT MODEL NAME
ACCESSORIES
1-487-202-11 REMOTE COMMANDER (RM-AMU051)
1-501-374-11 ANTENNA, LOOP (AM loop antenna)
1-542-236-11 MICROPHONE, DYNAMIC (F-VJ22) (PH)
1-793-184-23 CONNECTOR (F TYPE ADAPTOR)
(FM lead antenna)
1-830-758-31 CORD, SPEAKER CONNECTION (8m)
(Speaker cord)
1-833-579-11 CORD, CONNECTION (1.2m) (Video cord)
3-218-463-11 FOOT (20 pcs) (for SPEAKER) (GZR99D)
3-218-463-41 FOOT (16 pcs) (for SPEAKER) (GZR88D)
4-143-231-13 MANUAL, INSTRUCTION (ENGLISH)
(E3,E4,E12,E15,E51,PH,SP)
4-143-231-22 MANUAL, INSTRUCTION (FRENCH) (E3,E4)
4-143-231-32 MANUAL, INSTRUCTION (SPANISH)
(E2,E51,AR,MX)
4-143-231-42 MANUAL, INSTRUCTION
(TRADITIONAL CHINESE) (SP)
4-143-231-52 MANUAL, INSTRUCTION (ARABIC) (E3,E4)
4-143-231-62 MANUAL, INSTRUCTION (PERSIAN) (E15)
4-143-231-71 MANUAL, INSTRUCTION (THAI) (TH)
4-143-231-82 MANUAL, INSTRUCTION (PORTUGUESE) (E4)
Ref. No. Part No. Description Remark
MHC-GZR88D MHC-GZR99D
DVD PLAYER DECK
RECEIVER HCD-GZR88D HCD-GZR99D
FRONT SPEAKER SS-GZR99D SS-GZR99D
SATELLITE SPEAKER SS-RSX99D SS-RSX99D
SUBWOOFER −SS-WGV99D
• Abbreviation
AR : Argentina model
E2 : 120V AC area in E model
E3 : 240V AC area in E model
E4 : 110 − 120V/220 − 240V AC area in E model
E12 : 220 − 240V AC area in E model
E15 : Iran model
E51 : Chilean and Peruvian model
MX : Mexican model
PH : Philippines model
SP : Singapore model
TH : Thai model
