Sony LSM-100 User manual

A-CNK-100- 13 (1)
Screen Management System
Projectionist Terminal
Operating Instructions
Before using the Projectionist Terminal, please read this manual thoroughly
and retain it for future reference.
Refer to the Chapter appropriate to your System configuration.
LSM-100
Software Version 1.30
© 2007 Sony Corporation

i
Program © 2007 / Documentation © 2007 Sony
Corporation
All rights reserved. This manual or the software described
herein, in whole or in part, may not be reproduced,
translated or reduced to any machine readable form
without prior written approval from Sony Corporation.
SONY CORPORATION PROVIDES NO
WARRANTY WITH REGARD TO THIS MANUAL,
THE SOFTWARE OR OTHER INFORMATION
CONTAINED HEREIN AND HEREBY EXPRESSLY
DISCLAIMS ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR ANY
PARTICULAR PURPOSE WITH REGARD TO THIS
MANUAL, THE SOFTWARE OR SUCH OTHER
INFORMATION. IN NO EVENT SHALL SONY
CORPORATION BE LIABLE FOR ANY
INCIDENTAL, CONSEQUENTIAL OR SPECIAL
DAMAGES, WHETHER BASED ON TORT,
CONTRACT, OR OTHERWISE, ARISING OUT OF
OR IN CONNECTION WITH THIS MANUAL, THE
SOFTWARE OR OTHER INFORMATION
CONTAINED HEREIN OR THE USE THEREOF.
Sony Corporation reserves the right to make any
modification to this manual or the information contained
herein at any time without notice.
The software described herein may also be governed by
the terms of a separate user license agreement.
Microsoft and Windows are registered trademarks of
Microsoft Corporation in the United States and/or other
countries. Adobe, Acrobat and Acrobat Reader are
trademarks of Adobe Systems Incorporated in the United
States and/or other countries. All other company and
product names are trademarks or registered trademarks of
the respective companies or their respective makers.
The projection system uses HIGH PRESSURE XENON
SHORT-ARC LAMPS as a light source. These lamps
have a high internal pressure. Depending upon the lamp,
the internal pressure can exceed 10 ATM or 147 PSI, even
when not in operation. In addition, Xenon arc lamps can
burst when not in operation causing serious injuries! It is
critical to follow the lamp manufacturer’s safety
instructions when handling Xenon arc lamps. Always wear
eye/face and body protection when handling Xenon arc
lamps.
Large XENON short-arc lamps are shipped inside special
protective shields which will contain the envelope
fragments if the lamp is dropped and explodes. The shield
is removed once the lamp is installed in the lamp housing.
When the lamp reaches the end of its useful life, the
protective shield is put back on the lamp, and the spent
lamp is then removed from the equipment and disposed of.
Note: The risk of explosion increases as the lamp is used.
For this reason, it is important to observe the
manufacturer's recommended operating life limits.
Refer to the handling and disposal instructions for the
XENON ARC LAMPS which were provided by the
manufacturer and included with the lamp.
Ultraviolet Radiation
All XENON short-arc lamps generate significant amounts
of ultraviolet radiation while in operation. Xenon has
strong spectral lines in the UV bands, and these readily
pass through the fused quartz lamp envelope. Projector
systems should always be operated with all covers closed
even when testing the system and content security is not an
issue.
The SRX Controller application exercises direct control
over the projector via the projector’s serial control port.
Operations using the SRX Controller can be in conflict
with operations using the Projectionist Terminal or the
SMS Controller. The SRX Controller application should
not be used at the same time the Projectionist Terminal or
SMS Controller is in operation. Once changes using the
SRX Controller are completed, REFRESH the Projector
Data (Maintenance screen) to the SMS Server stored data.
NOTICE TO USERS
WARNING
NOTICE

Table of Contents ii
Table of Contents
Chapter 1 User Guide - R110
Login .................................................................................................2
Logout ................................................................................................... 2
Show Information ............................................................................3
Base Screen ........................................................................................... 3
View Show Status ................................................................................. 3
STOP/PLAY Show Presentation........................................................... 4
Show Schedules ..............................................................................5
View Show Schedules ........................................................................... 5
View Show Details................................................................................ 5
View Content Element Details .............................................................. 6
Media Block......................................................................................7
Access Media Block.............................................................................. 7
Projector Control .............................................................................9
Set Projector to ON/STANDBY ........................................................... 9
Douse the Projector ............................................................................... 9
Select Projector Function .................................................................... 10
Function Setup...............................................................................11
Select “Target” Function Key ............................................................. 11
Select Test Pattern ............................................................................... 12
Adjust Lamp Power............................................................................. 12
Adjust Projector................................................................................... 12
Maintenance ...................................................................................14
Lamp Select......................................................................................... 14
Lamp Hours/Reset............................................................................... 15
Theater Network Setup..................................................................16
IP Address Assignment ....................................................................... 16
DNS Address Assignment................................................................... 17
Status..............................................................................................18
Power Status ........................................................................................ 18
Lamp Status......................................................................................... 18
Fan ....................................................................................................... 19
Temperature......................................................................................... 20
System Message .................................................................................. 20
Power ON/OFF ...............................................................................20
MAINS - A/C ON ............................................................................... 21
Power Up............................................................................................. 21
Shutdown............................................................................................. 22

iii Table of Contents
Chapter 2 User Guide - R220
Login ...............................................................................................25
Logout ................................................................................................. 25
Show Information ..........................................................................26
Base Screen ......................................................................................... 26
View Show Status ............................................................................... 26
STOP/PLAY Show Presentation......................................................... 27
Show Schedules ............................................................................28
View Show Schedules ......................................................................... 28
View Show Details.............................................................................. 28
View Content Element Details ............................................................ 29
Media Block....................................................................................30
Access Media Block............................................................................ 30
Projector Control ...........................................................................32
Set Projector to ON/STANDBY ......................................................... 32
Douse the Projector ............................................................................. 33
Change Projector Function.................................................................. 33
Set Luminance Offset.......................................................................... 34
Function Setup...............................................................................35
Verify “Target” Function .................................................................... 35
Adjust Lamp Power............................................................................. 35
Adjust Projector................................................................................... 36
Maintenance ...................................................................................38
Refresh Projector Data ........................................................................ 39
Lamp Information................................................................................ 39
Adjust/Test .......................................................................................... 40
Theater Network Setup..................................................................41
IP Address Assignment ....................................................................... 41
DNS Address Assignment................................................................... 42
Status..............................................................................................43
Power Status ........................................................................................ 44
Lamp Status......................................................................................... 44
Fan ....................................................................................................... 45
Temperature......................................................................................... 46
System Message .................................................................................. 46
Power ON/OFF ...............................................................................46
MAINS - A/C ON ............................................................................... 46
Power Up............................................................................................. 47
Shutdown............................................................................................. 47

Chapter
1
Chapter 1 User Guide - R110
User Guide - R110
This Chapter provides a convenient “How To” guide to
SRX-R110 projector based Auditorium Unit operation
including Power ON/OFF, Status Indicator information,
and executing specific functions via the Projectionist
Terminal The location of these on the Digital Cinema
Auditorium Unit are show below.
The Status Indicator Lamp table provides a basic outline of
the meaning of the Lamp Color and Lamp State (solid,
flashing). A brief description of the meanings is also
included where appropriate.
Projectionist Terminal
AUDITORIUM UNIT - R110
Status Indicator Lamp
Power ON/OFF
Status Indicator Lamp
Lamp
Color
Lamp State Meaning
OFF OFF Power OFFa, or
System Shutdownb
a.Power OFF - All power is removed from the sys-
tem, all components are shutdown, & UPS Power is
unavailable.
b.System Shutdown - Power is applied to the system.
However, all components are shutdown except for
the primary power control computer (Enclosure
Power button blinking Green),
RED FLASHING Major Errorc
c.Major Error - Raid Offline, Media Block offline.
SMS Server offline, Enclosure Temperature Error,
PDU is offline. Additional Status information may be
displayed in the upper right-hand (Date/Time) area
of the Projectionist Terminal.
YELLOW FLASHING Minor Errord
d.Minor Error - Fan off (Enclosure, Media Block),
Temperature warning, Projector Standby, UPS ab-
normal condition, UPS replace battery. Additional
Status information appears in the upper right-hand
(Date/Time) area of the Projectionist Terminal.
GREEN ON Operation Normal,
System Stable, Projector ON
GREEN FLASHING Power ON/OFF Sequence, or
Projector Transitione
e.Projector Transition - Projector changing from
STANDBY mode to ON mode.

2Login
Chapter 1 User Guide - R110
Login
Access to control functions for the Screen Management
System requires the projectionist to login to the system.
Your Login ID and password must be previously assigned
by the SMS Administrator using the SMS Controller
application.
1 Tap Login on
the Projectionist
Terminal. The
Log-in screen
appears
containing the
SELECT USER
NAME list.
2 If your User
Name is not
visible in the
SELECT USER NAME list, tap the
DOWN ARROW until it can be seen. Tap your User
Name and then tap Accept. The Log-in screen
displays your User Name and the ENTER
PASSWORD keypad appears.
3 Using the keypad, tap your PIN and then tap Accept.
If you make an error in entering your PIN, tap CLEAR
to remove the last number entered or tap DEL to
remove all numbers entered so you can start again. As
you enter your PIN it is masked and appears above the
keypad.
To abort the Login process tap Cancel. When the
Login is cancelled the display returns to the Welcome
screen.
The Show Information screen appears the Login process is
successful.
Logout
Once you have Logged In to the Projectionist Terminal it
remains active and available to user input. To close
terminal access, tap Menu and then tap Logout. The
Welcome screen will appear.
Tap Login
Tap User Name
Tap Accept DOWN
ARROW
User Name Masked PIN Tap PIN
Clear Last Delete All Accept

3
Show Information
Chapter 1 User Guide - R110
Show Information
Show Information is the Projectionist Terminal default
appearance and automatically displays the status of the
Current Show Information following a successful login to
the SMS Projectionist Terminal. The Show Information
screen is comprised of two areas, the “Base Screen” or
View and the “information” pane where all menu selected
functions and information appears.
Note: The Base Screen or “View” or Frame appears on
ALL Projectionist Terminal screens.
Base Screen
The Base Screen area includes a Menu button, the Current
User information, and a Date & Time area along the top of
the screen. The Status Lamps & Selector Buttons buttons
along the bottom of the screen are also integrated with the
Base frame. These display warning indicators related to
the status of that hardware sub systems. Tap any of the
Status Selector Buttons to view the specific Status pane.
Show Information is the default screen for the Projectionist
Terminal and it is automatically returned to when no
terminal input is received for a time-out period. In the
Show Information pane (shaded in the above) you will find
the controls most often used to manage the show
presentation.
To access other screens form the Projectionist Terminal,
tap the Menu button and then tap the desired Screen Name
button. This is to insure that the Operator/Projectionist is
able to see the status of the Current Show irrespective of
what screen was most recently used.
To access the various Status Screens, tap the appropriate
button located at the bottom of the Projectionist Terminal.
You can also adjust the Time Zone for the Projectionist
Terminal should the setting not agree with the SMS Server
setting. To set the Time Zone, double-tap the clock in the
upper right-hand corner. The standard Windows® Time
Zone dialog appears. Tap to navigate and select your Time
Zone.
Note: In the Show Information pane (shaded in the
illustration) you will find the controls most often used to
manage the show presentation.
View Show Status
You view the status of the current show in the Show
Information pane. To access Show Information, tap
anywhere in the Projectionist Terminal “Base” frame
when viewing any screen.
The central portion of the Show Information pane provides
a quick summary of the status of the current show and what
is being presented.
Show related information are; the Show Title, the Show
Current Position, and the Running Time/Remaining Time.
Additionally, information for the current Element is
displayed.
• Show Title
The Title of the show currently playing. The Show
Title is assigned using the SMS Controller during the
process of building of the Show Playlist. The Show
Title is the “reference” for the consolidation of the
various Content Elements included in the named
show. When there are instances of Content Elements
associated with the same Feature on the same Screen
or, Content Elements have different characteristics,
e.g., MPAA Rating, each variation is created as a
different Show Playlist and identified by a different
Show Name.
Tap for Menu Current User Date & Time
Terminal Version Comm Status Server Version
Status
Lamps &
Selector
Buttons
Progress
Bar
Element
Type
Show Title
Element
Title
Current
Position
Running/Remaining
Time
REWIND
button PLAY/STOP
button

4Show Information
Chapter 1 User Guide - R110
•ElementType
Indicates the type of the currently playing Content
Element, e.g., Feature, Trailer, etc.
•ElementTitle
The Name or Title of the currently playing Content
Element, e.g., MI-4.
• Progress Bar
The Progress Bar provides a graphic representation of
the progress of the presentation.
• Current Position
Indicates the current position of the presentation.
When the Show is running this indicates the elapsed
running time. When the Show is stopped the Current
Position indicates the point in the presentation where
presentation will resume when you tap PLAY.
• Running/Remaining Time
An alternate display indicating either the Remaining
Time or the Total Running Time for the current
presentation. (Tap to change.)
• PLAY/STOP button
An alternate action (PLAY/STOP) screen “button”
which indicates what action will occurs when it is
tapped. In the illustration the current element has been
stopped.
• REWIND button
Available only when the current presentation has been
stopped. Normal action when a presentation is stopped
is to RESUME on PLAY from the presentation’s
current position. Tap REWIND to reset the
presentation’s current position to the beginning of the
Show.
STOP/PLAY Show Presentation
Basic Show Controls appear on the Show Information
pane. These controls are “modal”, that is they are current
mode dependant. For example, when the show is in the
Play mode the only control available to the projectionist is
STOP
STOP Show Presentation
To terminate presentation of the Current
Show, tap the STOP button (shown to the
right) on the Show Information pane. Show
presentation halts and the screen goes dark.
The current position of the presentation is
retained and subsequent execution of
PLAY will resume the presentation from the current
position in the Show timeline.
When STOP has been executed the
REWIND button appears to allow you to
reset the current position of the presentation to the Start of
the Show. REWIND only appears when the current
presentation has been stopped. To reset the presentation’s
starting point to the Start of Show, tap REWIND.
STOP processing requires nominally 3 seconds before the
presentation on the screen ends.
START Show Presentation
When the show is in the Stop mode the PLAY control is
available to the projectionist. In addition, the REWIND
control will be available if a running presentation was
stopped.
To initiate presentation of the indicated
Show (in Show Information) from the
Current Position, tap the PLAY button.
PLAY processing requires 6 seconds
(nominally) before the presentation appears
on the screen.
Note: Executing PLAY begins presentation
of the show from the current position as
displayed in the Show Information pane. To
reset the start point to the beginning of the presentation tap
REWIND and then tap PLAY.
Pause/Resume Show Presentation
To pause presentation of the current Show, tap STOP and
then, when ready to resume presentation, tap PLAY. The
current position of the presentation is retained unless
REWIND is executed.

5
Show Schedules
Chapter 1 User Guide - R110
Show Schedules
Shows which have been Scheduled are viewable from the
Projectionist Terminal. Schedules are based on a single
day view and, using the Projectionist Terminal, you can
“scroll” to view schedules currently available for the
selected day. Once you have located the specific Show you
can view the details of the specific Show.
View Show Schedules
To view Show Schedules,
tap Menu in the upper-
left corner of the screen
and then tap Schedule on
the popup menu. The
SHOW SCHEDULE
pane appears in place of
the SHOW
INFORMATION pane.
The SHOW SCHEDULE
is set, by default, to
present a list of shows
scheduled for
presentation on the
current date. To view
schedules for other dates
tap Previous Day/Next
Day. Information in the
Show Schedule pane
includes the (Show) Title and the Start Time/End Time for
each show.
The Show Schedule pane indicates the date of the
displayed schedule at the top-center. Each “show”
presented during the day appears in the SHOW
SCHEDULE list as a distinct item with a specific Start
Time and End Time. Because of the limited amount of
display space it will likely be necessary to scroll to see the
complete schedule for any specific day.
To scroll the screen to see additional Show Schedules for
the indicated day, tap either the Scroll Up or
Scroll Down on the SHOW SCHEULDE screen.
•View Previous Day/Next day - When the SHOW
SCHEDULE pane appears it displays shows
scheduled to play on the current day. When you wish
to view schedules for another day tap either Previous
Day or Next Day in the lower portion of the pane.
•View Today - To return to viewing the show schedule
for today, tap Today in the lower portion of the SHOW
SCHEDULE pane.
View Show Details
Each “Show” or “Title” displayed in the
SHOW SCHEDULE pane is comprised of one or more
individual content elements. These elements may be Show
Playlists (SPL) or Composition Playlists (CPL). The
sequence of presentation of the elements comprising the
Show (Playlist) is displayed in the SHOW DETAILS pane.
To view detail information
for a specific Show, locate
the show in the SHOW
SCHEDULE list for the day
of interest and then tap the
Show Title. The Show
Details pane appears.
Note: If the Title of interest is
not visible, verify that you
are viewing the correct
schedule date and, if
necessary, scroll the schedule
list until the specific Title is
found.
The SHOW DETAILS pane contains three major areas.
They are: the Show Information, the Valid Use Dates and,
a scrollable sequence of Content Elements.
Tap Menu Tap
Schedule
Pop-Up Menu
Show Titles Schedule Date
Go To Today Previous
Day
Next
Day
Scroll
Up
Scroll
Down
TITLES
Tap TITLE for
Show Details
Show Information Valid Use Dates
Content Elements
Tap Content Element
for Element Details
Detail Level
Close
Details

6Show Schedules
Chapter 1 User Guide - R110
• Show Information
The Show Information group contains basic
information regarding the show. This includes the
Title, Duration, and MPAA Rating.
•DetailLevel
Shows may contain Composition Playlist content
elements or (nested) Show Playlist content elements.
The Show Details screen will always indicate which
“level” (Top Details or Zoom Details) you are
viewing.
• Valid Use Dates
The right to present any specific show is a complex
issue and may involve licensing restrictions for any or
all Content Elements. The Valid Use Dates group
indicates the date range during which the selected
show can be presented. These dates are validated on a
periodic basis and are subject to change even after the
Content Elements have been loaded into the SMS.
Note: Valid Use Dates apply only to the screen
associated with the current System. Other systems in
the same facility may have different Valid Use Dates
for the same Content Element(s).
• Close [level] Details
To close the Details screen for the Content Element,
tap Close [level] Details.This will return you to the
previous level of Show Details.
• Content Elements
The Content Elements group provides a sequenced,
scrollable graphic representation of the individual
Content Elements that comprise the Show. Tap
LEFT ARROW to scroll and see elements earlier in
the Show or tap the RIGHT ARROW to scroll and
see elements later in the Show.
Show Content Elements may be either Composition
Playlists (CPL) or other Show Playlists (SPL) in a nested
arrangement. Tap the Content Element to view its details.
View Content Element Details
Each show is comprised of one or more Content Elements
with their own characteristics, e.g., Audio Format, Aspect
Ratio, etc. In addition, a Content Element may be either a
Composition Playlist (CPL) or another Show Playlist
(nested playlists).
To view detail
information for a
specific Content
Element, open
Show Details and
then tap the
Content Element
of interest. When
the element is a CPL the CONTENT DETAILS popup
appears containing additional information, e.g., Image
Format, Aspect Ratio, etc. about the selected element.
When the Content Element of interest is another Show
Playlist (nested) then a new SHOW DETAILS pane
appears with the SHOW DETAILS level indicating Zoom
Details.

7
Media Block
Chapter 1 User Guide - R110
Media Block
The SMS Media Block is the combined Media Block unit
and any attached storage (RAID) devices. This is generally
referred to as the Media Block. Each Show Playlist is an
assemblage, in presentation sequence, of one or more
Composition Playlist which must be present in the Media
Block/Storage.
The Media Block is the point where playout of the CPL is
managed, the CPL associated files are stored, when
necessary the files are decrypted and, the Content
Elements are decoded and sent to the Projector. Through
the use of “Keys” contained in the Key Delivery Message
(KDM), the Media Block decrypts CPLs as necessary for
presentation as part of a Show Playlist (SPL).
Access Media Block
Controls for Media Block
functions and information
about CPL resident in the
Media Block are available
through the MEDIA
BLOCK CONTROL
pane. To access the Media
Block Control pane, tap
Menu and then tap Media
Block. The MEDIA
BLOCK CONTROL pane
appears.
From the MEDIA
BLOCK CONTROL pane
you can execute a
RESTART of the Media
Block, MUTE the audio
output from the CPL, and
determine how much of
the RAID storage space allocated to DCPs has been used.
Restart Media Block
The Media Block is the central storage unit for all digital
components that make up the screen presentation.
• RESTART
To restart the Media Block, tap Menu and then tap
Media Block. The MEDIA BLOCK CONTROL pane
appears. Tap RESTART. You will be prompted to
confirm the action.
Caution: The RESTART operation will take
approximately 10 minutes during which time the
system is not available for presentation of content.
RESTART of the Media Block provides a controlled
start up process during which time the system verifies
the content of the SMS RAID.
Muting (Audio)
Content Elements include the audio component of the
presentation. However, the audio component exists as one
or more separate data files within the DCP. During
presentation the processing of the Audio Component
occurs in the Media Block. As a result, Muting of the
Audio Component is under control of the Media Block
(“muting” or dousing of the picture occurs in the
Projector).
• Muting (ON/OFF)
To silence the audio output from the Media Block, tap
Menu, tap Media Block,and then tap the Muting
OFF button. This is an alternate action button that
indicates what action will be taken when activated.
•OFF — Audio Output will Mute when tapped.
•ON — Audio Output will un-Mute when tapped.
DCP Storage Capacity
The amount of storage space available on the RAID for
DCPs is set using the SMS Controller application. The
DCP Used Space indicator provides you with a graphic
indication of how much of the allocated space has been
used as a percentage of the space allocated. A numeric
value is also shown.
Available Shows
Show Playlists must be composed in a separate
application, e.g., The SMS Controller. Once created, they
are saved in the SMS Server and can be scheduled as
Shows.
• Available Shows
As soon as the Show Playlist (SPL) has been saved on
the SMS Server it appears in the Available Shows list.
Tap Menu Tap
Media Block
Pop-Up Menu
Power
RESTART DCP Space Used
Muting
ON/OFF
Available
Shows
Show
Information
PLAY/STOP Show Details

8Media Block
Chapter 1 User Guide - R110
The appearance of the Show TITLE indicates its
current state as show in the following table.
Below the list of Available Shows a status line
provides information about either the current show or
the Next Show.
An Available Show can be viewed on the auditorium
screen using the controls available here. To view
information about an Available Show, tap the
LEFT ARROW or RIGHT ARROW to scroll and
locate the specific Show. Tap the Show [TITLE]. The
selected Show appears in the Show Information group.
If the system is not being used for presentation of a
Show you can view an Available Show. This function
is provided essentially to allow quality assurance
viewing of content stored under Media Block control.
To view the selected Title on the auditorium screen,
locate and select the specific TITLE. If the selected
Title is available, i.e., valid Key(s), the PLAY/STOP
button becomes available1. To play the selected Title,
tap the PLAY/STOP button. The icon will indicate the
action that will be taken when tapped. Note: The
system should be in ON mode (lamp energized) for
approximately 10 minutes to obtain optimum
presentation quality.
• Show Details
To view information about each Content Element
comprising the selected SPL, tap Show Details. The
Show Details panel appears providing details related
to the Show, its presentation availability, and a graphic
representation of the individual Content Elements.
The SHOW DETAILS pane contains three major
areas. They are: the Show Information, the Valid Use
Dates and, a scrollable sequence of Content Elements.
The information and functions available are the same
as found on the SHOW DETAILS screen under
SHOW SCHEDULE.
To view
additional
details for any
of the Content
Elements, tap
the specific
Content
Element and
either a
CONTENT DETAILS popup will appear (if the
element is a CPL) or another SHOW DETAILS screen
appears if the Content Element is a nested SPL.
TITLE Color SPL Status
Orange Playing
White Available for Presentation
Grey One or more components not
available.
1.If the Key(s) are not valid for the current date then
the PLAY/STOP button will not appear.
Show Information Valid Use Dates
Content Elements
Tap Content Element
for Element Details
Detail Level
Close
Details

9
Projector Control
Chapter 1 User Guide - R110
Projector Control
Basic control of selected Projector system functions are
available from the Projectionist Terminal. In the
following, reference to the “Projector” means the projector
subsystem only. When in STANDBY many of the
functions are unavailable. However, other functions
remain active and are accessible via either the Projectionist
Terminal or the SMS Controller application. To place the
Auditorium Unit in Standby or to Shutdown the
Auditorium Unit refer to “Power ON/OFF” on page 20.
Note: When the Projector is in STANDBY mode the
system remains active and accessible via either the
Projectionist Terminal or the SMS Controller application.
When the Auditorium Unit is Shutdown only the Power
ON/OFF button on the enclosure remains active.
Projector System
Controls are available on
the Projector Control
pane. To access the
Projector Control pane,
tap Menu and then tap
Projector Control. The
PROJECTOR
CONTROL pane appears.
From the PROJECTOR
CONTROL pane you can
place the Projector in
STANDBY or return it to
ON (operational mode),
DOUSE the image output,
and recall a preset
configuration for the
Digital Cinema projection
system.
Set Projector to ON/STANDBY
Selecting STANDBY insures that various components of
the Digital Cinema projector will shutdown in a orderly
manner and, where necessary, fans will continue to run so
proper cooling is received during the process.
Refer to “Power ON/OFF” on page 20 to Shutdown the
Auditorium Unit. DO NOT REMOVE AC MAINS
POWER TO SHUT DOWN THE SYSTEM AS
COOLING WILL BE LOST AND KDMs MUST BE
RELOADED.
• Set Projector To ON
To place the Projector in the ON mode, tap Menu, tap
Projector Control and then in the Power group tap
ON. The system will transition from STANDBY to
ON and the projection lamp(s) will be illuminated.
While operation is possible in approximately 5
minutes optimum image presentation will not be
realized for a minimum of 30 minutes. This additional
time is required to allow the imaging panels and
projector lamps to achieve operating temperature and
stabilize.
• Set Projector To STANDBY
To place the Projector in STANDBY mode, on the
Projectionist Terminal tap Menu, tap Projector
Control and then, in the Power group, tap
STANDBY. You will be prompted to confirm the
action. Tap YES to confirm.
The Projector will transition from an operational mode
to STANDBY. This includes internal fans which will
continue to run until the lamps/lamp assembly has
cooled.
Douse the Projector
The DOUSER control function in the PROJECTOR
CONTROL screen serves the same purpose as the
“douser” on the film projector. In fact it works in much the
same way by placing a opaque blade in the output light
path.
When you set the projector DOUSER to ON the
auditorium screen goes dark. However, this only applies to
the image portion of the presentation. The audio portion of
Tap Menu Tap
Projector Control
Pop-Up Menu
POWER Group ON
STANDBY

10 Projector Control
Chapter 1 User Guide - R110
the presentation continues and must be muted using the
Muting control on the Media Block screen.
• Douser ON (Closed)
The DOUSER control is an alternate action button
whose current state is indicated by the status label and
a status indicator in the ON/OFF button. When the
control’s status indicator is out (label shows OFF) the
the douser is open and the current presentation (image)
appears on the auditorium screen.
To douse the projector output, tap Menu, tap
Projector Control and then, in the DOUSER block,
tap the alternate action ON/OFF button. The projector
output is doused, the auditorium screen goes dark and
the control button label changes to ON and its status
indicator is lit (see inset in illustration). The Projector
Lamps remain energized ON).
• Douser OFF (Open)
The projector Douser is activated by an alternate
action control button whose current state is indicated
by the status indicator located in the ON/OFF button.
When the indicator is illuminated (label shows ON)
the projector DOUSER is closed and the auditorium
screen is dark.
To restore the projector output (open the “douser”), tap
Menu, tap Projector Control and then, in the
DOUSER block, tap the alternate action ON/OFF
button. The projector output is restored, the auditorium
screen is illuminated, the control button label changes
to OFF and the button status indicator is dark.
Select Projector Function
Seven FUNCTION selections (F1 to F7) are available on
the PROJECTOR CONTROL screen and can be used by
you to recall stored settings which effect the projector
setup. Each FUNCTION is configured using the SRX
Controller application and is set to optimize the on-screen
presentation. In addition, a limited number of settings
associated with a specific FUNCTION and be configured
using the FUNCTION SETUP screen
The configurations are stored and available on the
Projectionist Terminal as single button FUNCTION
selections. In addition, a FUNCTION can be associated
with a SPL or CPL using the SMS Controller application.
In this was the same configuration is recalled whenever the
associated Content Element is presented.
MANUALLY SELECTING A FUNCTION WILL
CHANGE THE PROJECTOR SETTINGS FOR THE
CURRENT PRESENTAION ONLY.
The FUNCTION selection is made from the PROJECTOR
CONTROL screen. To access the PROJECTOR
CONTROL screen, tap Menu and then tape Projector
Control. The “FUNCTION” is simply identified as F1
through F7. The “stored value” of these Function settings
are projector related and are used to tailor the projector
output to meet specific presentation requirements for the
CPL.
• Select Function
In the FUNCTION area of the PROJECTOR
CONTROL screen tap the LEFT ARROW or
RIGHT ARROW until the specific FUNCTION
number, e.g., F1, F2, etc., is visible then tap the desired
FUNCTION button.
Caution: The projector adjustments and settings
stored as the selected FUNCTION are immediately
applied to the projector. No confirmation message of
the FUNCTION key selection is required. Also, there
is no “undo”. If the previous settings were the results
of a previously applied FUNCTION setting then select
the previous FUNCTION key.
DOUSER OFF/ON
FUNCTION Select

11
Function Setup
Chapter 1 User Guide - R110
Function Setup
Just as in film projection, there are a number of issues
related to the configuration of the Digital Cinema projector
for the content being presented. One easily called to mind
in film is the aperture plate which is selected based on the
image format. Because the Digital Cinema system can
present content of varying formats the settings are much
more complex. The majority of these are set using the SRX
Controller1application and stored in the FUNCTIONs (F1
through F7). However, some settings may require
adjustment of a more immediate nature. These are
available to you on the FUNCTION SET-UP screen.
Function Setup Controls
are available on the
FUNCTION SETUP
pane. To access the
Function Setup pane, tap
Menu and then tap
Function Setup. The
FUNCTION SET-UP
pane appears.
Below the Current
Function indicator select
the target FUNCTION
using Change
FUNCTION. After
selecting the FUNCTION
(F1, F2, etc.), you can set
the LAMP POWER and
adjust various image
related settings (ADJUST PROJECTOR). The settings are
stored in the selected FUNCTION as they are made for
later recall by selecting the specific FUNCTION.You can
also select from a number of Test Patterns for projection on
the auditorium screen to assist in alignment.
Caution: Any changes made to adjustments on the
FUNCTION SET-UP pane appear as they are made and
will be reflected in the settings returned the next time the
indicated FUNCTION is selected on the Projector Control
panel or recalled as part of a SPL where the included CPL
are associated with a FUNCTION.
Select “Target” Function Key
Prior to making any adjustments to settings appearing on
the FUNCTION SET-UP pane select the desired Function
Number (if necessary).
To select the Function, tap Menu, tap Function Setup,
and then tap Change FUNCTION. The CHANGE
FUNCTION popup appears.
To select the FUNCTION
to be applied to the
projector, tap the target
FUNCTION (F1, F2,
etc.).
The Projector settings
will change, e.g., Focus,
Zoom, Lamp Power, etc.,
to reflect the stored
settings for the selected
FUNCTION. The Current Function indicates the new
selection.
Note: It may take some seconds for the process to
complete as some adjustments are mechanical in nature,
e.g., Zoom, Focus, etc.
MAKE SURE THAT THE CORRECT FUNCTION, e.g.,
F1, APPEARS IN “CURRENT FUNCTION” BEFORE
MAKING ANY ADJUSTMENT ON THIS SCREEN.
THERE IS NO “UNDO” AND THE CHANGES YOU
MAKE WILL EFFECT THE PRESENTATION
EVERYTIME THE INDICATED FUNCTION IS
RECALLED USING EITHER THE PROJECTOR
CONTROL SCREEN OR WHEN THE FUNCTION IS
ASSOCIATED WITH A CPL AS PART OF A SHOW
OR SPL.
1.The SRX Controller exercises direct control over
the projector and therefore should not be used at the
same time the Projectionist Terminal or SMS Control-
ler is in operation.
Tap Menu Tap
Function Setup
Pop-Up Menu
Change FUNCTION
Current Function
Current FUNCTION
Tap to Select

12 Function Setup
Chapter 1 User Guide - R110
Select Test Pattern
Projector Function Setup may require the use of one or
more of the internal Test Patterns.
To select the desired test image, tap Menu, tap Function
Setup, and then tap Test Pattern. The TEST PATTERN
popup appears.
To select the desired
TEST PATTERN to be
projected, tap the
appropriate Pattern
Name.
Note: When making the
various Test Pattern
selections the Projector
Settings will remain
unchanged but the
selected test pattern will appear on the screen.
Patterns available are:
•Crosshatch and Crosshatch Inverted
•100% White, 100% Red, 100% Blue, and 100%
Green
•Checker Flag and Checker Flag Inverted.
•OFF
Insure that OFF is selected when adjustments are
complete.
Adjust Lamp Power
To adjust LAMP POWER, tap Menu, tap Function
Setup, and then either tap, or press and hold, the
LEFT ARROW (Lower) or RIGHT ARROW (Raise)
while viewing the projected image on the screen.
Lamp Power changes are made in predefined steps.The
Indicator shows the current Lamp Power setting.
THERE IS NO “UNDO”. THE CHANGES YOU MAKE
TO LAMP POWER WILL EFFECT THE CURRENT
PRESENTATION AND ANY PRESENTATION
WHENEVER THE INDICATED FUNCTION IS
RECALLED USING EITHER THE PROJECTOR
CONTROL SCREEN OR WHEN THE FUNCTION IS
ASSOCIATED WITH A CPL AS PART OF A SHOW
OR SPL.
Adjust Projector
The remaining settings are in the ADJUST PROJECTOR
group where Zoom, Focus, Shift and Electric V Shift
adjustments are located.
To operate controls in the ADJUST PROJECTOR group,
you tap or press and hold the (plus) or (minus)
buttons.
Zoom Adjust (Image Size)
The digital image (from the Content Element file) appears
on the imaging devices as a “flat” picture. For this reason,
Select Test Pattern
Tap Desired Pattern
to Select
LAMP POWER
Raise
Lower
ADJUST PROJECTOR
Zoom
Focus

13
Function Setup
Chapter 1 User Guide - R110
it is practical to use projection lenses that optically zoom
to properly size the image to the auditorium screen. The
lens Zoom setting is associated with the Current Function
and recalled when that FUNCTION is selected on the
PROJECTOR CONTROL screen or associated with a
CPL. This is a mechanical adjustment of the projector lens
and should not be confused with any kind of image
manipulation creating a zoom effect.
To adjust Zoom (the image size), tap Menu, tap Function
Setup, and then either tap, or press and hold, the
(minus) or (plus) button associated with Zoom while
observing the projected image on the screen. It may be
necessary to observe the actual content (CPL) while setting
Zoom to insure that the screen is properly filled will still
not spilling the image onto the screen mask or surround.
Focus Adjust (Image Sharpness)
The Focus setting is associated with the Current Function
and recalled when that FUNCTION key is selected on the
PROJECTOR CONTROL screen or associated with the
CPL. This is a mechanical adjustment of the projector lens
and should not be confused with any kind of electrical
focus adjustments.
To adjust Focus (image sharpness), tap Menu, tap
Function Setup, and then either tap, or press and hold, the
(minus) or (plus) button associated with Focus
while observing the projected image on the screen.
Adjusting Focus is normally realized using a DCP
containing a suitable test image. Observing actual Show
content while adjusting Focus is not recommended.
Shift Adjust (Vertical Image Position)
Allows you to make an adjustment to the vertical position
of the on-screen image to compensate for vertical
displacement of the projector.
To adjust Shift, tap Menu, tap Function Setup, and then
either tap, or press and hold, the (minus) or (plus)
button associated with Shift while observing the projected
image on the screen. It may be necessary to view actual
content (CPL) while setting Zoom to insure that the screen
is properly filled will still not spilling the image onto the
screen mask while leaving an opposite area dark.
Electric V shift Adjust (Image V Centering)
Allows you to electrically compensation for vertical image
displacement when the aspect ratio of the image is changed
from 2.39:1 to 1.86:1. Refer to the Projector
documentation for additional details.
The Electric V shift control shows the relative vertical
“position” of the image on the auditorium screen and is
associated with the Current Function. In addition, this
control has a numeric display which allows you to
reposition the image to a known location.
To adjust the Electric V shift (image V Centering), tap
Menu, tap Function Setup, and then touch & drag the
Control Bar/Indicator to a new setting and release. To
make incremental adjustments to the Electric V shift,
either tap, or press and hold, the (minus) or (plus)
button associated with Electric V shift while observing
the projected image on the screen. A numerical value is
shown to allow for easy resetting of Electric V shift to a
previous value.
Note: Response to setting the Electric V shift will
experience some delay. You should use the Control
Bar/Indicator to place the image in the approximate
position desired.
ADJUST PROJECTOR Shift
ADJUST PROJECTOR
Electric V shift Value Raise
Lower Touch & Drag

14 Maintenance
Chapter 1 User Guide - R110
Maintenance
The Maintenance pane allows you to set the way in which
Lamps are used and to Reset Lamp Timer(s) following a
lamp replacement.
CAUTION: When replacing/handling the lamp(s)
observe manufacturer’s recommendations and procedures.
Xenon arc lamps could burst when not in operation
causing serious injuries! It is critical to follow safety
instructions when handling Xenon arc lamps.
Settings available on the
Maintenance screen apply
globally to the projector
and, unlike Functions,
cannot be changed based
on the Show.
Changing settings found
on the Maintenance
screen should be done
with care as these can
effect Lamp usage and
reset the Lamp Hours
information. Lamp Hours
should be carefully
tracked to insure that the
maximum number of
hours are not exceeded.
Exceeding the maximum
number of hours can result in failure of the Lamp
envelope.
To access Maintenance, tap Menu and then tap
Maintenance. The Maintenance screen appears.
Settings available on the Maintenance screen are;
•Lamp Select
Lamp A or Lamp B or A/B combined (manual)
•Auto
Projector determines which lamp will be used.
•ResetTimer
Reset Lamp A or Lamp B individual Lamp Hours
timers.
Lamp Select
In the Lamp Select group you can select the way in which
the two projection lamps are utilized during system
operation.
Single Lamp Mode
In Single Lamp mode you manually select a single lamp to
be used as the source of illumination. Either of the two
lamps can be selected as long as the selected lamp does not
exceed the lamp operating life.
To select one of the two lamps as the single source of
illumination, tap Menu, tap Maintenance, and then tap
either “A” or “B” to select the respective Lamp as the
current single source of illumination.
Lamp A/B Mode
In Lamp A/B mode you manually select to have both
lamps operated simultaneously as the source of
Tap Menu Tap
Maintenance
Pop-Up Menu
LAMP SELECT Auto Lamp Mode
RESET TIMER
LAMP SELECT
Select
“A”
Select
“B”
Select “A/B”
Combined

15
Maintenance
Chapter 1 User Guide - R110
illumination. The outputs the two lamps is combined into
a single source of illumination through a prism. The Lamp
A/B mode is provided to accommodate situations where
the screen image may be too dim due to screen size, e.g.,
wide-screen image, or when the content requires
additional illumination.
To select operation where both lamps are combined into a
single source of illumination (Lamp A/B mode), tap
Menu, tap Maintenance, and then tap A/B to select Lamp
A/B mode.
Note: When operation uses Lamp A/B mode care should
be taken to keep lamp usage hours approximately the
same.
Auto Lamp Mode
In Auto Lamp mode a single lamp is used as the source of
illumination. However, the lamp selection is made by the
projector when the projector is switched from STANDBY
to ON. Either of the two lamps will be selected for
illumination with the determination made by the projector
based on which lamp has the most operating hours
remaining.
To select Auto Lamp mode operation where the projector
determines which lamp acts as the illuminating source
(Auto), tap Menu, tap Maintenance, and then tap Auto.
Lamp selection is done by the projector using the
remaining hours for each lamp. The selection is done at the
time the system operating mode is changed from
STANDBY to ON.
Lamp Hours/Reset
Each lamp has an associated timer (and Reset) to allow
tracking of hours of usage following lamp replacement.
Lamp usage must be monitored to insure the quality of the
projected image as the spectral content of the lamp will
change over its useful life with a more rapid change after
the recommended usable hours have been exceeded.
Caution: The risk of lamp explosion increases when the
lamp is used beyond its maximum number of hours. For
this reason, it is important to observe the manufacturer's
recommended operating life limits.
For information related to the recommended maximum
number of useable hours for the lamp refer to the lamp
specification document.
To Reset the individual Lamp Hours Timers, tap Menu,
tap Maintenance, and then tap Reset Timer in either the
Lamp A or Lamp B group. The Hours shown for Lamp A
or Lamp B are hours of operation since the most recent
Reset Timer action.
Auto Lamp Mode
Lamp “A” Hours
& Timer Reset
Lamp “B” Hours
& Timer Reset

16 Theater Network Setup
Chapter 1 User Guide - R110
Theater Network Setup
The Auditorium Unit’s configuration for connecting to the
Theater Network is via a dedicated network connection on
the SMS Server. Configuration of this connection is
realized using the Network Setup screen on the
Projectionist Terminal.
Settings available on the Network Setup screen apply to
the SMS Server’s Theater Network connection only.
Typically, the Screen
Management System
Controller is connected to
the Theater Network. If
the Theater Network
settings are incorrect then
access to the Auditorium
Unit from the Screen
Management System
Controller is not possible.
To access Theater
Network Setup, tap Menu
and then tap Network
Setup. The Network
Setup screen appears
Two groups appear on the
Theater Network Setup
screen. They are; IP
ADDRESS ASSIGNMENT and DNS ADDRESS
ASSIGNMENT.
IP Address Assignment
The IP ADDRESS ASSIGNMENT group includes
settings for the SMS Server’s IP address, the Subnet Mask,
and, when needed, the IP address of the Gateway between
the Auditorium Unit and the Theater Network.
Address assignments can be either Static or Automatic (if
DHCP is in use).
Static (IP address)
A static (or predetermined) IP address can be assigned
to the SMS Server’s Theater Network connection. To
set the Static IP address option, tap STATIC in the IP
ADDRESS ASSIGNMENT group and enter the
values for IP Address, Subnet Mask and Gateway.
•IPAddress
To set a static IP address, tap IP Address and the
Enter Address popup appears.
To set a new IP address, tap CLEAR, set the new IP
address by tapping the numbers on the Keypad, and
then tap Accept.
Note: Entering the IP addresses from the ENTER
ADDRESS popup uses the “dotted decimal” format
and must include the “dot(s)” as part of the entry.
Tap Menu Tap
Network Setup
Pop-Up Menu
IP ADDRESS ASSIGNMENT
Static Automatic
IP Address
Subnet Mask
Gateway
ACCEPT
ENTER ADDRESS (popup)
Current
IP address
Accept
CLEAR
Keypad “dot”
