Source Technologies 10 Series User manual

10-Series Kiosk Installation Manual | Source Technologies
10-Series Kiosk
Installation Guide
Released Electronic Copy
ST Doc Control
09/22/2020

Notice 1
10-Series Kiosk Installation Manual | Source Technologies
Copyright © 2020 by Source Technologies. All rights reserved.
No part of this document may be reproduced or utilized in any form or by any means,
electronic or mechanical, including photocopying, recording or by any information
storage and retrieval system, without permission in writing from Source Technologies.
Published in the United States of America by:
Source Technologies
4205B Westinghouse Commons Drive Charlotte, North Carolina 28273
Author: Source Technologies.
NOTICE
To the best of our knowledge the information in this publication is accurate; however,
Source Technologies does not assume any responsibility or liability for the accuracy or
completeness of, or consequences arising from, such information.This document is
intended for informational purposes only. Mention of trade names or commercial
products does not constitute endorsement or recommendation for use by Source
Technologies. Final determination of the suitability of any information or product for use
contemplated by any user, and the manner of that use, is the sole responsibility of the
user. We recommend that anyone intending to rely on any recommendation of materials
or procedures mentioned in this publication should satisfy himself as to such suitability,
and that he can meet all applicable safety and health standards.
All trademarks and registered trademarks appearing in this document are the property of
their respective owners.
Document Number: 108594
Revision: A

Operational Guidelines 2
10-Series Kiosk Installation Manual | Source Technologies
WARNING AND CAUTION SYMBOLS
The following Warning and Caution symbols are used throughout this manual:
Cautions alert you to the potential for
equipment damage.
Warnings alert you to possible safety risks.
General Safety Information
This kiosk is intended for indoor use only.
All service procedures should be performed by properly trained and qualified service
personnel.
Any on-site assembly required during the installation process must be performed by
properly trained and qualified service personnel.
The kiosk must be connected to a properly grounded and appropriately rated AC
receptacle using the supplied cord set.
The socket-outlet powering this equipment shall be installed near to the equipment and
be easily accessible.
The kiosk must be properly shut down and then disconnected from the AC power supply
before connecting signal cables to a host computer.
This kiosk is suitable for connection to IT power systems.

Operational Guidelines 3
10-Series Kiosk Installation Manual | Source Technologies
Les mises en garde vous alertent des
risques de dommages matériels.
Les avertissements vous alertent des
risques de sécurité possibles.
Consignes générales de sécurité.
Ce kiosque est destiné à un usage intérieur seulement.
Toutes les procédures d'entretien doivent être effectuées par du personnel d'entretien
dûment formé et qualifié.
Tout montage sur site requis pendant le processus d'installation doit être effectué par un
personnel de service qualifié et dûment formé.
Le kiosque doit être connecté à une prise secteur correctement mise à la terre et de
calibre approprié à l'aide du cordon fourni.
La prise de courant qui alimente cet équipement doit être installée à proximité de
l'équipement et être facilement accessible.
Le kiosque doit être correctement fermé puis déconnecté de l'alimentation secteur avant
de connecter les câbles de signal à un ordinateur hôte.
Ce kiosque est approprié pour la connexion à des systèmes d'alimentation informatique.

FCC Statement 4
10-Series Kiosk Installation Manual | Source Technologies
This kiosk contains sensitive electronic
components that could be damaged if
exposed to excessive force.
Use only factory-approved consumables and
cleaning kits. Use of any non-approved
supplies could permanently damage the kiosk
and may void your warranty.
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of the equipment in
a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
This Class A digital apparatus complies with Canadian ICES-003.

FCC Statement 5
10-Series Kiosk Installation Manual | Source Technologies
Ce kiosque contient des composants
électroniques sensibles qui pourraient être
endommagés s'ils étaient exposés à une force
excessive.
N'utilisez que des produits consommables et
des kits de nettoyage approuvés en usine.
L'utilisation de fournitures non approuvées
pourrait endommager le kiosque de façon
permanente et annuler votre garantie.
Cet équipement a été testé et déclaré conforme aux limites d'un appareil numérique de
classe A, conformément à la partie 15 des règles de la FCC. Ces limites sont conçues pour
fournir une protection raisonnable contre les interférences nuisibles lorsque l'équipement
est utilisé dans un environnement commercial. Cet équipement génère, utilise et peut
émettre de l'énergie radiofréquence et, s'il n'est pas installé et utilisé conformément au
manuel d'instructions, peut causer des interférences nuisibles aux communications radio.
L'utilisation de l'équipement dans une zone résidentielle est susceptible de causer des
interférences nuisibles, auquel cas l'utilisateur devra corriger ces interférences à ses
propres frais.
Cetappareilnumérique de la classe A estconforme à la norme NMB-003 du Canada.

Product Overview 6
10-Series Kiosk Installation Manual | Source Technologies
TABLE OF CONTENTS
NOTICE........................................................................................................................................................ 1
Operational Safety Information ............................................................................................................2
General Safety Information ....................................................................................................................2
Chapter 1 –PRODUCT OVERVIEW......................................................................................................7
Kiosk Description.......................................................................................................................................7
OVERALL KIOSK DIMENSIONS .............................................................................................................8
INSTALLATION CLEARANCE REQUIREMENTS .................................................................................9
Chapter 2 –Installation Location Requirements ............................................................................12
Chapter 3 - Unpacking the Kiosk .......................................................................................................13
Chapter 4 –Installation.........................................................................................................................19
Anchor Bolt Installation ........................................................................................................................ 20
Chapter 5 –Removing Cash Recycler Shipping Restraints......................................................... 23
Chapter 6 –Installing Check Printer and Option Tray................................................................. 26
Chapter 7 –Installing the Coin Dispenser Coin Tray ................................................................... 28
Chapter 8 –External Cable Connections ........................................................................................ 29
Chapter 9 –Powering on the Kiosk.................................................................................................. 29
Chapter 10 –Loading Receipt Paper................................................................................................ 30
Chapter 11 –Loading Check Printer Paper .....................................................................................34
Chapter 12 –Hardware Verification Test......................................................................................... 36

Product Overview 7
10-Series Kiosk Installation Manual | Source Technologies
Kiosk Description
Source Technologies’ 10-Series kiosk is a next-generation, self-service
platform designed from the ground up to manage secure, distributed
financial transactions and consumer banking.

Kiosk Dimensions 8
10-Series Kiosk Installation Manual | Source Technologies
DIMENSION UNITS: mm (inches)

Clearance Rquirements 9
10-Series Kiosk Installation Manual | Source Technologies
FLOOR CLEARANCE FOR KIOSK SERVICING
DIMENSION UNITS: mm (inches)

Clearance Rquirements 10
10-Series Kiosk Installation Manual | Source Technologies
FLOOR CLEARANCE FOR FRONT WHEELCHAIR ACCESS
DIMENSION UNITS: mm (inches)

Clearance Rquirements 11
10-Series Kiosk Installation Manual | Source Technologies
FLOOR CLEARANCE FOR SIDE WHEELCHAIR ACCESS
DIMENSION UNITS: mm (inches)

Location Requirements 12
10-Series Kiosk Installation Manual | Source Technologies
Using the Service and Wheelchair Clearance requirements as a guide, install the kiosk in a
location with adequate space on each side.
Complete all necessary Site Surveys and review facility drawings to ensure that no
gas, water, electrical lines, etc. will be near any of holes that will be drilled in the
flooring. Kiosk location mustcomply with all other applicable codes (fire escape routes,
etc.). Floor must be flat and sub-flooring material must be concrete with a minimum
thickness of 4.0in.
Before installing, obtain any necessary permits or property owner authorizations. All
work must be done in full accordance with the requirements of all agencies and
authorities having jurisdiction; all applicable state and city codes; Barrier Free
requirements, OSHA and the local utility companies’ requirements.
Make sure that the appropriate electrical and network connections are present before
installation (appropriate surge suppression is recommended). The connections should be
located such that all cords will be safely routed away from any human traffic and will not
cause anyone to trip over them. Do not modify the AC power cord supplied with the
kiosk.
The kiosk must be connected to an individual
branch circuit that is properly grounded and
appropriately rated for the device power
requirements. For specific power requirements,
see the product label on the back of the kiosk.
In an environment where the ambient temperature exceeds 90° F.
Where it will be exposed to direct sunlight or hot air from an HVAC system.
Within 8 feet of Electronic Article Surveillance devices that generate radio frequency
energy or magnetic fields.

Unpacking the Kiosk 13
10-Series Kiosk Installation Manual | Source Technologies
•
•
•
•
•
•
•
•
10 Series Kiosk
(Accessory Kit Located Inside)
Optional
Paper Tray
Check
Printer
Component
Cabinet Key
Coin
Dispenser Key
Recycler Cash
Cassette Key

Unpacking the Kiosk 14
10-Series Kiosk Installation Manual | Source Technologies
Straps
Staples

Unpacking the Kiosk 15
10-Series Kiosk Installation Manual | Source Technologies

Unpacking the Kiosk 16
10-Series Kiosk Installation Manual | Source Technologies

Unpacking the Kiosk 17
10-Series Kiosk Installation Manual | Source Technologies
Lag Screws Located in
Bottom of Component
Cabinet on Left-Hand Side
Remove
Remove
Remove

Unpacking the Kiosk 18
10-Series Kiosk Installation Manual | Source Technologies

Installation 19
10-Series Kiosk Installation Manual | Source Technologies
•
•
•
•
•
•
•
•
NOTE:
There are two notches on each side
of the pallet that provide access to
lift points that may be used to
remove the kiosk from the pallet.
35%
65%
Approximate Weight Distribution
