Source SEM-EXB-P04 User manual

For more information contact:
IP20
COMPLIANT
Self Test Method: Please ensure this product is tested monthly and half yearly
MODE METHOD FOR
MODE
IF LED INDICATOR STATUS BEEP SOUND RESULT
Mains ON No Action Needed Battery Ok Green (Permanently On) OFF Green LED
No Action Needed Battery Fault Red (Flashes every 1 second) Beep every 45
Seconds*
Red LED, Loud Beep
sound*
No Action Needed LED Fault* Amber (Flashes every 1
second)*
Beep every 45
Seconds*
Amber LED, Loud Beep
Sound
Monthly self
test battery
discharge
(discharges
the battery for
10 seconds)
Self Testing Battery Ok All Indicators O󰀨 OFF Green LED
Battery Fault Red (Flashes every 1 second) Beep every 45
seconds
Red LED, Loud Beep
sound
LED Fault Amber (Flashes every 1 Second) Beep every 45
seconds
Amber LED, Loud Beep
Sound
Half yearly self
test battery
discharge
(discharges
the battery for
3 hours)
Self Testing Battery Ok All Indicators O󰀨 OFF Green LED
Battery Fault Red (Flashes every 1 second) Beep every 45
seconds
Red LED, Loud Beep
sound
LED Fault Amber (Flashes every 1 Second) Beep every 45
seconds
Amber LED, Loud Beep
Sound
Mains Failure No action needed
Luminaire enters
3 hour emergency
mode
Battery Ok All Indicators O󰀨 OFF
*During Non-Maintained Mode if the battery is faulty the LED indicator will light red and beep. If the LEDs on the heads are faulty,
this will be only shown on monthly self test and not before. SEM-EXB P04 has di󰀨erent wiring to SEM-EXB-NI
Note:
• No AC power will cause luminaire to enter Emergency mode
• After a repair, please connect AC power and perform a test (for performance conrmation). To do this, operate your emergency key
switch.
• If the battery and LED board failure simultaneously, the red LED will ash.
• Any beep sound will stop after correct maintenance or repair.
• Manual testing will not a󰀨ect the monthly and half-yearly testing schedule
Installation &
Self Test Instructions
SLIM EMERGENCY EXIT BOX
PRODUCT CODE: SEM-EXB-P04 / SEM-EXB-NI
Quality
Assurance
years
DISASSEMBLY INSTRUCTIONS
Product end of life instruction.
This Lighting product is in the scope of EU 2019/2020 directive on Waste Electrical and Electronic Equipment
(WEEE). This product must be disposed of, according to the legislation. This document is intended for use by
end of life recyclers or treatment facilities. It provides the basic information to assure an appropriate end of life
treatment for the components and materials of the product.
Please follow pictured diagram on the back of this manual showing how to dismantle the product into di󰀨erent
components which should be disposed of correctly. These components consist of plastic, metal and electronic
materials.
It is the responsibility of the end user to dispose of this product correctly. Contact www.weeeireland.ie or your
local council for further information.
Unit 7/8 Ashbourne Business Centre, Ballybin Road, Ashbourne, Co. Meath, Ireland, A84 YP58,
Phone: [phone]
Unit 32 Junction One Business Park, Valley Road, Birkenhead, Merseyside, UK, CH41 7ED,
UK Ph: 0330 551 7000
Website: www.sgd.ie
Loosen screws with
screwdriver
Slide block to open
Dismantle Driver/LED, Plate/Battery
Dismantle Legend and Led Plate
Please check here, if there is screw, please
loose them firstly
Slide the block to
“Open”
Dismantle driver/LED
plate/battery
Dismantle legend and Led
plate
Self Test
LED Light Status Beep Sound Status
Green LED Constant OFF Battery Charging, No faults, Mains On
Red LED (ashes every 1 second) Beep every 45 seconds Battery Fault
Amber LED (ashes every 1 second) Beep every 45 seconds LED Fault
Mains Failure No indicator Check Power Supply
Product Code:[AWLED/LI/3M/ST]
Issue Number: [1]
Ansell Electrical Products
Unit 6B, Stonecross Industrial Park,
Yew Tree Way,
Warrington,
WA3 3JD
Warrington Tel: [phone]
Ansell (Sales & Distribution
Unit 2, M2 Business Park,
Duncrue Street,
Belfast,
BT3 9AQ
Belfast Tel: [phone] Spain Tel: [phone]International Tel: [phone]
Unswitched Line
Earth
Line
Neutral
Product Code:[AWLED/LI/3M/ST]
Issue Number: [1]
Ansell Electrical Products
Unit 6B, Stonecross Industrial Park,
Yew Tree Way,
Warrington,
WA3 3JD
Warrington Tel: [phone]
Ansell (Sales & Distribution
Unit 2, M2 Business Park,
Duncrue Street,
Belfast,
BT3 9AQ
Belfast Tel: [phone] Spain Tel: [phone]International Tel: [phone]
Unswitched Line
Earth
Line
Neutral
Product Code:[AWLED/LI/3M/ST]
Issue Number: [1]
Ansell Electrical Products
Unit 6B, Stonecross Industrial Park,
Yew Tree Way,
Warrington,
WA3 3JD
Warrington Tel: [phone]
Ansell (Sales & Distribution
Unit 2, M2 Business Park,
Duncrue Street,
Belfast,
BT3 9AQ
Belfast Tel: [phone] Spain Tel: [phone]International Tel: [phone]
Unswitched Line
Earth
Line
Neutral
Product Code:[AWLED/LI/3M/ST]
Issue Number: [1]
Ansell Electrical Products
Unit 6B, Stonecross Industrial Park,
Yew Tree Way,
Warrington,
WA3 3JD
Warrington Tel: [phone]
Ansell (Sales & Distribution
Unit 2, M2 Business Park,
Duncrue Street,
Belfast,
BT3 9AQ
Belfast Tel: [phone] Spain Tel: [phone]International Tel: [phone]
Unswitched Line
Earth
Line
Neutral

Important Installation Information
1. Installation should be carried out in accordance with the current edition of the National Wiring Regulations.
If in doubt, consult a qualied electrician
2. Maximum Input Voltage - 220V-240V AC 50/60Hz
3. Connect the battery pack to the PCB by connecting the female socket on the battery wires to the male plug
mounted on the PCB, ensuring the correct orientation
4. Ensure that all electrical connections are tight with no loose strands
5. Before commencing installation or maintenance, ensure electricity is switched o󰀨 at the mains.
6. Class II, double insulated and earth is not required
7. This luminaire is not dimmable
8. All green charge indicator LED are illuminated when the battery is charging. During situations where there is
no power from mains electricity and the battery is discharging, all green charge indicator LEDs will be o󰀨.
EMERGENCY TESTING
After connecting the mains supply check the following:
1. The unit should be left on charge for a minimum of 24 hours before testing the emergency mode
2. There is one green indicator in the middle. After power is on, the LED indicator will be on. The LED indicator
is o󰀨 when the xture is in emergency mode
3. To simulate normal mains supply failure, operate your key switch
4. The lamp will now light under emergency conditions
5. When the unit no longer meets its rated duration of operation, the battery pack must be replaced with a
battery of the same type, voltage and AMP-hour rating
6. All Emergency lighting tests must be logged. The Emergency lighting logbook must be provided in order to
be covered by any warranties.
Emergency Installation and Inspection
Serial/ Luminaire Number:
Installation / Test
Installed By: Date:
Record
Commissioned By: Date:
Year 1 Year 3*
*Recommended Battery Change LiFe P04
Year 4
Monthly test Signed Date Signed Date Signed Date Signed Date
1
2
3
4
5
6
7
8
9
10
11
12
Year 2*
*Recommended Battery Change NiCd
Product Code:[AWLED/LI/3M/ST]
Issue Number: [1]
Ansell Electrical Products
Unit 6B, Stonecross Industrial Park,
Yew Tree Way,
Warrington,
WA3 3JD
Warrington Tel: [phone]
Ansell (Sales & Distribution
Unit 2, M2 Business Park,
Duncrue Street,
Belfast,
BT3 9AQ
Belfast Tel: [phone] Spain Tel: [phone]International Tel: [phone]
Unswitched Line
Earth
Line
Neutral
Product Code:[AWLED/LI/3M/ST]
Issue Number: [1]
Ansell Electrical Products
Unit 6B, Stonecross Industrial Park,
Yew Tree Way,
Warrington,
WA3 3JD
Warrington Tel: [phone]
Ansell (Sales & Distribution
Unit 2, M2 Business Park,
Duncrue Street,
Belfast,
BT3 9AQ
Belfast Tel: [phone] Spain Tel: [phone]International Tel: [phone]
Unswitched Line
Earth
Line
Neutral
Product Code:[AWLED/LI/3M/ST]
Issue Number: [1]
Ansell Electrical Products
Unit 6B, Stonecross Industrial Park,
Yew Tree Way,
Warrington,
WA3 3JD
Warrington Tel: [phone]
Ansell (Sales & Distribution
Unit 2, M2 Business Park,
Duncrue Street,
Belfast,
BT3 9AQ
Belfast Tel: [phone] Spain Tel: [phone]International Tel: [phone]
Unswitched Line
Earth
Line
Neutral
SEM-EXBP04 Wiring:
SEM-EXB NI Wiring:

Declaration Number:
