Source SFES10M User manual

Product Information Sheet
COMMISSION DELEGATED REGULATION (EU) 2019/2015 with regard to energy labelling of light
sources
Supplier's name or trade mark: Source
Supplier's address: SGD, Unit 7/8 Ashbourne Business Centre Ballybin Road Ashbourne Co. Meath
Ireland A84YP58
Model identifier: SE27GOLF
Type of light source:
Lighting technology used: LED Non-directional or
directional:
NDLS
Light source cap-type
(or other electric interface)
E27
Mains or non-mains: MLS Connected light
source (CLS):
No
Colour-tuneable light source: No Envelope: -
High luminance light source: No
Anti-glare shield: No Dimmable: Only with spe-
cific dimmers
Product parameters
Parameter Value Parameter Value
General product parameters:
Energy consumption in on-
mode (kWh/1000 h), rounded
up to the nearest integer
2 Energy efficiency
class
G
Useful luminous flux (ɸuse), in-
dicating if it refers to the flux in
a sphere (360º), in a wide cone
(120º) or in a narrow cone (90º)
117 in
Sphere (360°)
Correlated colour
temperature,
rounded to the near-
est 100 K, or the
range of correlat-
ed colour temper-
atures, rounded to
the nearest 100 K,
that can be set
3 000
On-mode power (Pon), ex-
pressed in W
2,0 Standby power (Psb),
expressed in W and
rounded to the sec-
ond decimal
-
Networked standby power
(Pnet) for CLS, expressed in W
and rounded to the second dec-
imal
- Colour rendering in-
dex, rounded to the
nearest integer, or
the range of CRI-val-
ues that can be set
55
Height 95
Width 50
Outer dimen-
sions without
separate con- Depth 50
Spectral power dis-
tribution in the
See image
in last page
Page 1 / 2

trol gear, light-
ing control
parts and non-
lighting con-
trol parts, if
any (millime-
tre)
range 250 nm to 800
nm, at full-load
Claim of equivalent power(a) - If yes, equivalent
power (W)
-
Chromaticity coordi-
nates (x and y)
0,474
0,430
Parameters for LED and OLED light sources:
R9 colour rendering index value 0 Survival factor 0,00
the lumen maintenance factor 0,00
Parameters for LED and OLED mains light sources:
displacement factor (cos φ1) 0,00 Colour consistency
in McAdam ellipses
0
Claims that an LED light source
replaces a fluorescent light
source without integrated bal-
last of a particular wattage.
-(b) If yes then replace-
ment claim (W)
-
Flicker metric (Pst LM) 0,0 Stroboscopic effect
metric (SVM)
-
(a)'-' : not applicable;
(b)'-' : not applicable;
Page 2 / 2

FEATURES:
• Static, 230v, Connectable Version, IP44
• Size: 10m Festoon Set with E27 Lamp Holder
• Socket Spacing: 50cm
• Lamps not included
• With 1.5m Power Cable + BS Plug
• For Indoor Outdoor Use
SPECIFICATION:
Model Socket Spacing Rated Power Lamp Holder Number of
Lamp Holders
IP
Rating
SFES10M 50cm 230V E27 20 IP44
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install the
product.
WARNING:
When using outdoor with this portable lighting products, basic safety precautions should always be
followed to reduce the risk of re, electric shock and personal injury. This is not a toy, please keep it out
of the reach of children.
INSTALLATION:
• Read and follow all instructions that are on the provided product
• This seasonal product is not intended for permanent installation or use
• This light chain is suitable for outdoor use
• For outdoor use ensure that the socket outlet or any extension cord is complying with the protection class
IP65
• Do not operate the light chain when it is still in the packaging
• Never connect the light chain to the mains during installation
• Up to 25 sets of the same version can be connected. Max Load 1000w
• Never exceed this limit otherwise the risk of overheating and/or electric shock will be incurred
•Ensure that the power source is the same as the specied power
• Check if any part of the lighting chain is damaged before connecting to the mains
• Avoid any damage incurred to the isolation of the wire, cable and light chain etc
• The light chains must be suitably mounted against tensile forces
Installation Instructions
10m 20L LED FESTOON LIGHT
Product Code: SFES10M
Connector
BS Plug with 5A fuse
E27 Lamp holders
50CM

• Protect the 230V plug against moisture and always make sure it is dry at all times
• Operate out of the reach of children or animals. This light chain is not a toy
•Do not use the light chain near ammable or generally sensitive objects
•Do not mount or place the light chain near gas or electric heaters, replace, candles or other similar sources
of heat
• Do not secure the wiring of the product with staples or nails, or place on sharp hooks or nails
• Do not let lamps rest on the supply cord or on any wires
• Unplug the product when leaving the vicinity of the product or when left unattended
• Do not use this product for anything other than its intended use
•Do not hang ornaments or other objects from cord, wire, or light string
• Do not close doors or windows on the product or extension cords as this may damage the wire insulation
• Do not cover the product with cloth, paper or any material not part of the product when in use
• Do not place the product against carpeting, furniture, any fabric, or home vinyl siding when in use
•This product has a plug, if the plug does not t fully in the outlet, contact a qualied electrician. Don’t use with
an extension cord unless plug can be fully inserted. Do not alter or replace the supplied plug
• Retain this instruction manual for reference
PRODUCT END OF LIFE INSTRUCTION.
This Lighting product is in the scope of EU 2019/2020 directive on Waste Electrical and Electronic Equipment
(WEEE). This product must be disposed of according to the legislation. This document is intended for use by
end of life recyclers or treatment facilities. It provides the basic information to assure an appropriate end of
life treatment for the components and materials of the product. Please follow pictured diagram showing how
to dismantle the product into dierent components which should be disposed of correctly. These components
consist of plastic, metal and electronic materials. It is the responsibility of the end user to dispose of this product
correctly. www.weeeireland.ie or contact your local council for further information. Some local authorities accept
small electricals such as Christmas tree lights as part of their home recycling scheme. If yours does there may be
special instructions on how to put them out for collection - for example, place them in a clear plastic bag tied to
your recycling bin. It is best to check with them rst. Do not put the lights directly into your recycling bin.
Disassembly Diagrams
Unit 7/8 Ashbourne Business Centre, Ballybin Road, Ashbourne, Co. Meath, Ireland, A84 YP58,
Phone: 00353 1 835 7447
Unit 32 Junction One Business Park, Valley Road, Birkenhead, Merseyside, UK, CH41 7ED,
UK Ph: 0330 551 7000
Website: www.sgd.ie
For more information contact:
COMPLIANT
Quality
Assurance
years
2
IP44
Unscrew each Lamp
from festoon set before
recycling
Cut plug from festoon set and recycle
"

Installation Instructions
25m 50L LED FESTOON LIGHT
Product Code: SFES25M
FEATURES:
• Static, 230v, Connectable Version, IP44
• Size: 25M Festoon Set with E27 Lamp Holder
• Socket Spacing: 50cm
• Lamps not inclued
• With 1.5m Power Cable + BS Plug
• For Indoor Outdoor Use
SPECIFICATION:
Model Socket Spacing Rated Power Lamp Holder Number of
Lamp Holders
IP
Rating
SFES25M 50cm 230V E27 50 IP44
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install the
product.
WARNING:
When using outdoor with this portable lighting products, basic safety precautions should always be
followed to reduce the risk of re, electric shock and personal injury. This is not a toy, please keep it out
of the reach of children.
INSTALLATION:
• Read and follow all instructions that are on the provided product
• This seasonal product is not intended for permanent installation or use
• This light chain is suitable for outdoor use
• For outdoor use ensure that the socket outlet or any extension cord is complying with the protection class
IP65
• Do not operate the light chain when it is still in the packaging
• Never connect the light chain to the mains during installation
• Up to 10 sets of the same version can be connected. Max load 1000w
• Never exceed this limit otherwise the risk of overheating and/or electric shock will be incurred
•Ensure that the power source is the same as the specied power
• Check if any part of the lighting chain is damaged before connecting to the mains
• Avoid any damage incurred to the isolation of the wire, cable and light chain etc
• The light chains must be suitably mounted against tensile forces
Connector
BS Plug with 5A fuse
E27 Lamp holders
50CM

• Protect the 230V plug against moisture and always make sure it is dry at all times
• Operate out of the reach of children or animals. This light chain is not a toy
•Do not use the light chain near ammable or generally sensitive objects
•Do not mount or place the light chain near gas or electric heaters, replace, candles or other similar sources
of heat
• Do not secure the wiring of the product with staples or nails, or place on sharp hooks or nails
• Do not let lamps rest on the supply cord or on any wires
• Unplug the product when leaving the vicinity of the product or when left unattended
• Do not use this product for anything other than its intended use
•Do not hang ornaments or other objects from cord, wire, or light string
• Do not close doors or windows on the product or extension cords as this may damage the wire insulation
• Do not cover the product with cloth, paper or any material not part of the product when in use
• Do not place the product against carpeting, furniture, any fabric, or home vinyl siding when in use
•This product has a plug, if the plug does not t fully in the outlet, contact a qualied electrician. Don’t use with
an extension cord unless plug can be fully inserted. Do not alter or replace the supplied plug
• Retain this instruction manual for reference
PRODUCT END OF LIFE INSTRUCTION.
This Lighting product is in the scope of EU 2019/2020 directive on Waste Electrical and Electronic Equipment
(WEEE). This product must be disposed of according to the legislation. This document is intended for use by
end of life recyclers or treatment facilities. It provides the basic information to assure an appropriate end of
life treatment for the components and materials of the product. Please follow pictured diagram showing how
to dismantle the product into dierent components which should be disposed of correctly. These components
consist of plastic, metal and electronic materials. It is the responsibility of the end user to dispose of this product
correctly. www.weeeireland.ie or contact your local council for further information. Some local authorities accept
small electricals such as Christmas tree lights as part of their home recycling scheme. If yours does there may be
special instructions on how to put them out for collection - for example, place them in a clear plastic bag tied to
your recycling bin. It is best to check with them rst. Do not put the lights directly into your recycling bin.
Disassembly Diagrams
Unit 7/8 Ashbourne Business Centre, Ballybin Road, Ashbourne, Co. Meath, Ireland, A84 YP58,
Phone: 00353 1 835 7447
Unit 32 Junction One Business Park, Valley Road, Birkenhead, Merseyside, UK, CH41 7ED,
UK Ph: 0330 551 7000
Website: www.sgd.ie
For more information contact:
COMPLIANT
Quality
Assurance
years
2
IP44
Unscrew each Lamp
from festoon set before
recycling
Cut plug from festoon set and recycle
"

Spectrum Test Report
Sample : E27 -WH Date : 2022-06-17 11:01:49
Specification : E27 bulbs-WH(SE-27GOLF-WH) Sam. Status : Standard :
Sample No. : SE27GOLF Instrument : HaasSuite
Manufacturer : Test by
Assessor : SGD Ltd
Remark :
Test Condition
Temprature : 25Deg RH : 45%
WL Range : 380nm-780nm IP : 47927 (73%)
T : 2203 msTest Mode : Accuracy Test
Sensitivity : High
Spectrum
1.0 = 2.053e+000mW/nm
380 480 580 680 780
Wavelength(nm)
0.0
0.2
0.4
0.6
0.8
1.0
1.2
Spectrum
x = 0.3147 y = 0.3360
CCT = 6351K
Spectral Distribution CIE1931 Chromaticity Diagram
Colorimetric Parameters
Chromaticity Coordinate: x = 0.3147 y = 0.3360 / u' = 0.1966 v' = 0.4723 (duv=5.74e-03) Dx,Dy:-0.0012,0.0100
CCT= 6351K Prcp WL: Ld=493.5nm Purity=6.1%
Peak WL: Lp=449nm FWHM: =24.5nm Ratio:R=12.2% G=83.9% B=3.9%
Render Index: Ra = 72.9
R1 =70 R2 =76 R3 =79 R4 =74 R5 =72 R6 =68 R7 =83
R8 =62 R9 =0 R10=42 R11=71 R12=42 R13=71 R14=88 R15=66
LEVEL:OUT WHITE:ANSI_6500K
Photometric & Radiometric Parameters
Flux = 66.402 lm Eff. : 34.17 lm/W Fe = 206.78 mW
Flux of emitted photons(μmol/s):0.93195 Fluo. and blue light ratio:2.377 Fluorescent eff.:70.30
__________________________________________________________________________________
Electrical parameters
V = 230.24 V I = 0.008994 A P = 1.943 W PF = 0.9383 F=49.99 Hz

Declaration
Declaration Number
Declaration Number
Declaration Number
Declaration Number
048-E320LED-WH
048-E120LED-WW
048-E5M80LEDICE-WW
048-E32024V-WH
048-E320LED-BE
048-E120LED-BE
048-ECURT2X2-WH
048-E32024V-WW
048-E320LED-RD
048-E120LED-RD
048-ECURT2X2-BE
048-SFES5M-PLS
048-E320LED-WW
048-E120LED-WW
048-ECURT2X2-WW
048-S14E27-WW
048-E320LED-CC+CON
048-E120LED--CC+CON
048-EWCURT2X2 WH-WW
048-RL-WHLED
048-RL-WWLED
048-RL-BELED
048-RL-RDLED
048-SE27GOLF-WW
048-SE27GOLF-WH
048-SE27GOLF-BE
048-SE27GOLF-GR
048-SE27GOLF-YW
048-SE27GOLF-RD
048-LED-PL-320-25.6M-24V-B
This declaration of conformity is issued under the sole responsibility of the manufacturer.
Products:
LED Lighting Chain 220v, 24v Black &White cables, Golfball lamps for Festoons
Model Number:
Codes
Codes
Codes
Codes
E320LED-WH
E120LED-WW
E5M80LEDICE-WW
E32024V-WH
E320LED-BE
E120LED-BE
ECURT2X2-WH
E32024V-WW
E320LED-RD
E120LED-RD
ECURT2X2-BE
SFES5M-PLS
E320LED-WW
E120LED-WW
ECURT2X2-WW
S14E27-WW
E320LED-CC+CON
E120LED--CC+CON
EWCURT2X2 WH-WW
RL-WHLED
RL-WWLED
RL-BELED
RL-RDLED
SE27GOLF-WW
SE27GOLF-WH
SE27GOLF-BE
SE27GOLF-GR
SE27GOLF-YW
SE27GOLF-RD
LED-PL-320-25.6M-24V-B
The product/model of the declaration described above is in conformity with the relevant
Community harmonisation legislation:
Low Voltage Directive (2014/35/EU)
EMC Directive (2014/30/EU)
Signed 14/09/2022
This manual suits for next models
1
Table of contents
Other Source Lighting Equipment manuals
Popular Lighting Equipment manuals by other brands

Mountfield
Mountfield AQUA JET 100 Instruction for Installation, Mounting and Operation

Ayra
Ayra ERO Laser user manual

CMP
CMP Brilliant wonders 25677 series installation instructions

Merlin
Merlin myQ 827AU quick start guide

LEAD energy
LEAD energy PDC Series operating manual

Command Light
Command Light Knight Series manual
