PL House Light MKII LED Luminaire User’s Manual
©2012 - 2016 Philips Group. All rights reserved.
Website:
www.vari-lite.com

1
PL House Light MKII LED Luminaires User’s Manual
IMPORTANT INFORMATION
Warnings and Notices
When using electrical equipment, basic safety precautions should always be followed including the following:
a. READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
b. Do not use outdoors. Only suitable for indoor use.
c. Do not mount near gas or electric heaters.
d. Equipment should be mounted in locations and at heights where it will not readily be subjected to
tampering by unauthorized personnel.
e. The use of accessory equipment not recommended by the manufacturer may cause an unsafe
condition.
f. Do not use this equipment for other than intended use.
g. Refer service to qualified personnel.
h. This luminaire is specified to operate in an ambient temperature of 40oC. The luminaire’s exterior
surface temperatures:
• After 5 minutes of operation: 42oC
• When steady state is achieved: 47oC
SAVE THESE INSTRUCTIONS.
WARNING: You must have access to a main circuit breaker or other power disconnect device before installing
any wiring. Be sure that power is disconnected by removing fuses or turning the main circuit breaker off before
installation. Installing the device with power on may expose you to dangerous voltages and damage the device.
A qualified electrician must perform this installation.
WARNING: Refer to National Electrical Code® and local codes for cable specifications. Failure to use proper
cable can result in damage to equipment or danger to personnel.
WARNING: This equipment is intended for installation in accordance with the National Electric Code® and
local regulations. It is also intended for installation in indoor applications only. Before any electrical work is
performed, disconnect power at the circuit breaker or remove the fuse to avoid shock or damage to the control.
It is recommended that a qualified electrician perform this installation.
WARNING: The PL House Light MKII LED Luminaire is a NON-IC Rated Lighting Fixture and IS NOT for
residential installation or use.
If the space that a light fixture is to be installed does not contain insulation, a NON-IC rated fixture should
be used (NON-IC stands for NON Insulated Contact). If insulation is present in an application where a
NON-IC rated fixture is used, a minimum 6-inch (153 mm) clearance should exist on all sides of the fixture,
and no insulation may be present across the top of the installed fixture. By maintaining these clearance
requirements, overheating should not be an issue according to testing conducted on the fixture.
WARNING: Basic insulation has been maintained between low-voltage supply and control conductors.
IMPORTANT!
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE
INSTALLATION CODE BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND
OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED.
CE PRODUIT DOIT ÊTRE INSTALLÉ SELON LE CODE D'INSTALLATION PERTINENT, PAR
UNE PERSONNE QUI CONNAÎT BIEN LE PRODUIT ET SON FONCTIONNEMENT AINSI QUE
LES RISQUES INHÉRENTS.

User’s Manual PL House Light MKII LED Luminaires
2IMPORTANT INFORMATION
FCC Notice
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will
be required to correct the interference at his own expense.
Additional Resources for DMX512
For more information on installing DMX512 control systems, the following publication is available for purchase
from the United States Institute for Theatre Technology (USITT), "Recommended Practice for DMX512: A Guide
for Users and Installers, 2nd edition" (ISBN: 9780955703522). USITT Contact Information:
USITT
315 South Crouse Avenue, Suite 200
Syracuse, NY 13210-1844
Phone: [phone] or 1.315.463.6463
www.usitt.org
Philips Selecon Limited Three-Year Warranty
Philips Selecon offers a three-year limited warranty of its luminaires against defects in materials or workmanship
from the date of delivery. A copy of Philips Selecon three-year limited warranty containing specific terms and
conditions can be obtained from the Philips Selecon or Philips Strand Lighting web sites at www.selecon-
light.com or www.strandlighting.com or by contacting your local Philips Selecon / Philips Strand Lighting
office.
WARNING! Risk of electric shock! The light source contained in this luminaire shall only be replaced by the
manufacturer, a qualified technician, or an Authorized Service Center.

3
PL House Light MKII LED Luminaires User’s Manual
TABLE OF CONTENTS
Philips Selecon Offices ................................................................................................................................... 0
IMPORTANT INFORMATION
Warnings and Notices ..................................................................................................................................... 1
FCC Notice...................................................................................................................................................... 2
Additional Resources for DMX512 ................................................................................................................ 2
Philips Selecon Limited Three-Year Warranty............................................................................................... 2
TABLE OF CONTENTS
PREFACE
About this Manual .................................................................................................................................................. 4
Accessories ............................................................................................................................................................. 4
Accessories - DMX Cable Adapters ............................................................................................................... 4
Additional Mounting Accessories................................................................................................................... 4
PL HOUSE LIGHT LED LUMINAIRE OVERVIEW
PL House Light MKII LED Luminaire Components............................................................................................. 5
Major Luminaire Components ........................................................................................................................ 5
Luminaire Connections (Power and Control) ................................................................................................. 5
LCD Display / Menu System .......................................................................................................................... 6
INSTALLATION AND SET UP
Power Requirements............................................................................................................................................... 7
Connecting Power .................................................................................................................................................. 7
Connecting to the DMX512 Network .................................................................................................................... 7
Mounting and Connecting Power........................................................................................................................... 8
OPERATION AND PROGRAMMING
LCD Menu Operation........................................................................................................................................... 12
LCD Menu System ............................................................................................................................................... 13
Menu Structure.............................................................................................................................................. 14
Security................................................................................................................................................................. 16
Locking Fixture ............................................................................................................................................. 16
Presets................................................................................................................................................................... 17
Editing Preset Names .................................................................................................................................... 17
Settings ................................................................................................................................................................. 17
DMX CONTROL
16-Bit Mode.......................................................................................................................................................... 19
8-Bit Mode............................................................................................................................................................ 21
DMX 5-Channel (5-Chan) Mode ......................................................................................................................... 23
PL House Light MKII LED Luminaire DMX Timing Channel Detail................................................................ 23
PL House Light MKII LED Luminaire RDM Parameter IDs.............................................................................. 30
CLEANING AND CARE
Special Cleaning and Care Instructions................................................................................................................ 33
Front Lens / Reflector Cleaning ........................................................................................................................... 33
Service and Maintenance...................................................................................................................................... 33
Accessories ........................................................................................................................................................... 34
TROUBLESHOOTING
Troubleshooting Guide ......................................................................................................................................... 35
TECHNICAL SPECIFICATIONS
PL House Light MKII LED Luminaire Operational Specifications .................................................................... 36
PL House Light MKII LED Luminaire Dimensions............................................................................................ 36
PL House Light MKII LED Luminaire Optical Specifications............................................................................ 37
Photometrics (Feet / Foot Candles)............................................................................................................... 37
Photometrics (Meters / Lux) ......................................................................................................................... 37

User’s Manual PL House Light MKII LED Luminaires
4PREFACE
PREFACE
1. About this Manual
The document provides installation and operation instructions for the following products:
• PL House Light MKII LED Luminaire (catalog number: PLHLIBMKII)
Please read all instructions before installing or using this product. Retain this manual for future reference. Additional
product information and descriptions may be downloaded at www.seleconlight.com
Note: The PL House Light MKII LED Luminaire is universal voltage for 100VAC to 240VAC applications.
2. Accessories
Accessories - DMX Cable Adapters
Additional Mounting Accessories
Additional mounting accessories (other than the components included with the fixture as described in "PL House
Light MKII LED Luminaire Components" on page 5) are sold separately and by others. Below is a list of compatible
mounting components for other types of mounting options.
Note: Catalog and descriptions are for reference only. The catalog numbers and descriptions are current as of time of
creation of this manual. Check with authorized suppliers for additional product information and descriptions.
• 18-inch Mounting Bars, Philips Lightolier Catalog Number 1950 (set of 2)
• 27-inch Mounting Bars, Philips Lightolier Catalog Number 1951 (set of 2)
• Telescoping Wood Joist Mounting Bars, Philips Lightolier Catalog Number 7994 (set of 2)
• T-Bar Anchor Clips, Philips Lightolier Catalog Number 1956 (set of 4, for use with 1950 & 1951 bars)
• 3/4-inch or 1-1/2-inch Channel
WARNING! Supporting mechanism and structure must be capable of supporting the weight of the PL House Light
MKII LED Luminaire. For product technical information (including weight), refer to "TECHNICAL
SPECIFICATIONS" on page 35. DO NOT mount the PL House Light MKII LED Luminaire into suspended ceiling
tiles unless properly supported. Check applicable codes in your area for specific requirements.
Part Number Description
PL1DMXFRJ45 PL House Light MKII LED Luminaire DMX512 cable XLR5 Female to RJ45 12 in. / 305 mm White
PL1DMXFRJ46 PL House Light MKII LED Luminaire DMX512 cable XLR5 Female to RJ45 12 in. / 305 mm Black
PL1DMXMRJ47 PL House Light MKII LED Luminaire DMX512 cable XLR5 Male to RJ45 12 in. / 305 mm White
PL1DMXMRJ48 PL House Light MKII LED Luminaire DMX512 cable XLR5 Male to RJ45 12 in. / 305 mm Black
To Luminaire (RJ45) DMX512 (XLR) Female
To Luminaire (RJ45) DMX512 (XLR) Male

PL House Light MKII LED Luminaire Components 5
PL House Light MKII LED Luminaires User’s Manual
PL HOUSE LIGHT LED LUMINAIRE OVERVIEW
1. PL House Light MKII LED Luminaire Components
Major Luminaire Components
Figure 1: PL House Light MKII LED Luminaire
Luminaire Connections (Power and Control)
Figure 2: PL House Light MKII LED Luminaire Connections
Trim Ring / Reflector
J-Box
Luminaire Power Supply / Control / Menu*
LED Engine Assembly
Fixture / Ring
Mounting Brackets (x3)
Reflector Assembly
Mounting Assembly
Lens Tube
(Beam Spread Adjustment)
*Refer to "LCD Menu Operation" on page 12
for more information.
DMX512 In / Out *
(both connectors)
J-Box for AC Input
Connection
Note, retrofit model shown. Same for all
models. * RJ45 to XLR 5-Pin Male (or XLR
5- Pin Female) available.

User’s Manual PL House Light MKII LED Luminaires
6PL HOUSE LIGHT LED LUMINAIRE OVERVIEW
LCD Display / Menu System
Figure 3: LCD Display & Menu System
1) LCD Display (Menu System)
2) Preset / Intensity / Menu Access Buttons
3) Function (Menu System) Select Push Buttons
1
Note: For Menu operation and programming details,
refer to "LCD Menu Operation" on page 12.
2
3

Power Requirements 7
PL House Light MKII LED Luminaires User’s Manual
INSTALLATION AND SET UP
1. Power Requirements
WARNING! The PL House Light MKII LED Luminaire should be connected to a constant circuit or a relay device.
It should never be connected to a dimmer or circuit controlled by a dimmer.
The PL House Light MKII LED Luminaire operates on single phase 100 to 240 volts
AC (+/- 10%, auto-ranging). The luminaire contains an auto-ranging power supply.
Depending on supply voltage, each luminaire can draw up to 140 Watts.
WARNING! Maximum Allowable Input Current of 20 Amps (maximum power supply limit of 140 Watts). A
maximum of eight (8) PL House Light MKII LED Luminaires can be daisy-chained on a circuit. Do not overload
circuits! Must be supplied by a branch circuit protected by a maximum 20 Amp circuit protector. Doit être
alimenté par un circuit de dérivation protégé par un maximum de 20 ampères circuit protecteur. Do not overload
circuits!
IMPORTANT AC POWER CONNECTION NOTES:
a. Must be supplied by a branch circuit protected by a maximum 20 Amp circuit protector. Doit être
alimenté par un circuit de dérivation protégé par un maximum de 20 ampères circuit protecteur.
b. Use only approved cable types.
c. Do not overload circuits!
d. Do not connect PL House Light MKII LED Luminaires to dimmed circuits.
2. Connecting Power
Refer to "Mounting and Connecting Power" on page 8 for installation and power connections.
3. Connecting to the DMX512 Network
Basic DMX512 installation consists of connecting multiple PL House Light MKII LED Luminaires together (up to
30 luminaires) in "daisy-chain" fashion. A cable runs from the control console (or DMX512 control source) to the
DMX connector on the first PL House Light MKII LED Luminaire. Another cable runs from the other DMX
connector on the first unit to a DMX connector on the next PL House Light MKII LED Luminaire (or DMX512
device to be controlled).
AC Input Only!
Model: PLHLIBMKII
Input Voltage: 100-240 VAC, 50/60Hz
Wattage: 140 Watts (max.)
For support call +1.214.647.7880
or visit www.seleconlight.com
Label: 04.9688.2005
▲ CONFORMS TO UL STD 1598 & UL STD 8750; CERTIFIED TO CSA STD
C22.2 NO. 250.0 & CSA STD C22.2 NO. 250.13
▲ MIN 90°C SUPPLY CONDUCTORS. LES FILS D’ALIMENTATION 90°C MIN.
▲ DRY LOCATIONS ONLY. POUR EMPLACEMENTS SECS SEULEMENT.
▲ SUITABLE FOR OPERATION IN AMBIENT NOT EXCEEDING 40°C
PEUT ÊTRE UTILISÉ À UNE TEMPÉRATUREAMBIANTE N’EXCÉDANT PAS 40°C (S24-L2)
▲ DO NOT INSTALL INSULATION WITHIN 153 mm (6 in) OF ANY PART OF THE LUMINAIRE. NE PAS METTRE
L’ISOLANT À MOINS DE 153 mm (6 po) DE TOUTE PARTIE DU LUMINAIRE.
▲ NOT FOR RESIDENTIAL INSTALLATION OR USE. PAS POUR L'INSTALLATION HABITATION OU A USAGE.
WARNING!
Serial Number / Date Code:

User’s Manual PL House Light MKII LED Luminaires
8INSTALLATION AND SET UP
Note: For more information on DMX512 networking and systems, refer to "Additional Resources for DMX512" on
page 2. For PL House Light MKII LED Luminaire DMX Mapping, refer to "DMX CONTROL" on page 19.
Figure 4: PL House Light LED Luminaires - DMX512 Connections
4. Mounting and Connecting Power
Note: The PL House Light MKII LED Luminaire is intended for installation in accordance with the National
Electric Code and local regulations. To assure full compliance with local codes and regulations, check with your local
electrical inspector before installation. The PL House Light MKII LED Luminaire is not intended for residential use
or installation.
WARNING! To prevent injury or death, you must have access to a main circuit breaker or other power disconnect
device before installing any wiring. Be sure that power is disconnected by removing fuses or turning the main circuit
breaker off before installation. Installing the device with power on may expose you to dangerous voltages and
damage the device. A qualified electrician must perform this installation.
DMX512 DMX512
(out from first to second luminaire)
DMX512 (out to the next luminaire
or DMX512 controlled device)
PL House Light LED Luminaires
DMX512 Connections
Note: Remaining pins on each connector are not used.
DMX512 Signal XLR Pin RJ45 Pin
Common (Drain) 1 7
DMX512 - 2 2
DMX512 + 3 1
(from console or
DMX Cables (DMX to RJ45)
DMX512 Cable Options
To Luminaire (RJ45) DMX512 (XLR) Female
To Luminaire (RJ45) DMX512 (XLR) Male
Sold Separately
Note: For cables required to operate and control
PL House Light MKII LED Luminaires via
DMX512, see "Additional Mounting
control device)

Mounting and Connecting Power 9
PL House Light MKII LED Luminaires User’s Manual
WARNING! The PL House Light MKII LED Luminaire is not suitable for mounting to
combustible surfaces is a NON-IC Rated Lighting Fixture. If the space that a light fixture is to be
installed does not contain insulation, a NON-IC rated fixture should be used (NON-IC stands for
NON Insulated Contact). If insulation is present in an application where a NON-IC rated fixture is
used, a minimum 3-inch (76 mm) clearance should exist on all sides of the fixture, and no
insulation may be present across the top of the installed fixture. By maintaining these clearance
requirements, overheating should not be an issue according to testing conducted on the fixture.
To mount PL House Light MKII LED Luminaire:
Step 1. Cut 7-7/8 inch hole in ceiling as desired.
CAUTION: PL House Light MKII LED Luminaires must be installed with mounting bars (by others). Mounting
bars must always be secured to structural ceiling members. Refer to "Additional Mounting Accessories" on page 4 for
more information. Check applicable codes in your area for specific requirements.
Step 2. If not already installed, attach Control / Menu Assembly to J-Box.
Step 3. Mount luminaire assembly into ceiling.
Figure 5: PL House Light MKII LED Luminaire Components
INSTALL WITH MINIMUM SPACINGS BETWEEN:
(a) CENTER-TO-CENTER OF ADJACENT LUMINAIRES:
153 mm (6 in);
(b) TOP OF LUMINAIRE TO OVERHEAD BUILDING MEMBER:
153 mm (6 in);
(c) LUMINAIRE CENTER TO SIDE BUILDING MEMBER:
153 mm (6 in).
ASSURER LES DÉGAGEMENTS MINIMAUX SUIVANTS:
(a) ENTRE L’ENTRAXE DES LUMINAIRES ADJACENTS:
153 mm (6 po);
(b) ENTRE LE DESSUS DU LUMINAIRE ET L’ÉLÉMENT DE
CHARPENTE SE TROUVANT AU-DESSUS:
153 mm (6 po);
(c) ENTRE LE CENTRE DU LUMINAIRE ET UN ÉLÉMENT DE
CHARPENTE LATÉRAL: 153 mm (6 po) (S24-L2).
04.9668.2006 0
Trim Ring / Reflector
J-Box
Luminaire Power Supply / Control / Menu
LED Engine Assembly
Fixture / Ring
Mounting Brackets (x3)
Reflector Assembly
Mounting Assembly
Lens Tube
(Beam Spread Adjustment)
Sample Drawings - Brackets
Note: brackets shown - channels and bars (by others)

User’s Manual PL House Light MKII LED Luminaires
10 INSTALLATION AND SET UP
Step 4. Make electrical connections from power source at J-Box according to your market as follows:
a. For 120VAC Markets ONLY:
1) Remove cover from Junction (J) Box.
2) At J-Box, connect AC input wiring as illustrated in Figure 6. Refer to "Power Requirements" on
page 7 for power requirements.
Figure 6: J-Box Electrical Connections - 120VAC Markets
b. Connecting Power for Markets Other Than 120VAC Markets:
1) Remove cover from Junction (J) Box.
2) At J-Box, remove the Thermal Protective Switch as shown in Figure 7 and discard. It will not be
used.
3) Install supplied metal plug into Thermal Protective Switch hole.
4) Connect AC input wiring as illustrated in Figure 7. Refer to "Power Requirements" on page 7 for
power requirements.
Figure 7: J-Box Electrical Connections - Other Than 120VAC Markets
Step 5. Make any DMX512 control wiring connections as desired. Refer to "Connecting to the DMX512 Network"
on page 7 for more information.
Note: When using luminaire on a DMX512 network, the unit must be addressed via the on-board menu system.
Refer to "LCD Menu System" on page 13 for DMX addressing. The menu system may be accessed anytime the trim
ring / reflector assembly is removed.
Black (Main / Hot)
Light Blue (Main / Hot)
White (Neutral)
White
(Neutral)
Dark Blue
(Neutral)
Green (Earth / Ground)
Green/Yellow (Earth / Ground)
Thermal Protective Switch Brown
(Main
/ Hot)
Bare Copper (Unit
Chassis Ground)
J-Box
Connecting to 120VAC Power (North American Markets)
From AC Supply
To Fi xtu re
Brown (Main / Hot)
Blue (Neutral)
Green/Yellow (Earth / Ground)
Brown
(Main / Hot)
Dark Blue (Neutral)
Green/Yellow (Earth / Ground)
Bare Copper (Unit
Chassis Ground)
J-Box
Connecting to Power Other Than 120VAC
From AC Supply
To Fi xture

Mounting and Connecting Power 11
PL House Light MKII LED Luminaires User’s Manual
Step 6. As shown in Figure 8, adjust luminaire beam spread as desired by loosening the lens tube / zoom
adjustment knob and moving lens tube in or out. Once adjustment is complete, re-tighten lens tube / zoom
adjustment knob. Note, beam spread can be adjusted at anytime throughout the installation process and
after-installation as desired.
Figure 8: Lens Tube (Beam Spread Adjustment) Setting
CAUTION: If installation is performed prior to the ceiling being painted DO NOT install the trim ring / reflector
assembly. Properly mask the end of the fixture being exposed to paint to ensure that the lens and the interior of the
unit is protected from over spray and debris.
Step 7. To finish installation, fit trim ring/reflector assembly up and through hole where luminaire assembly is
installed. Firmly press trim ring/reflector assembly into place. Note, retaining clips on sides of trim
mounting ring assembly will "capture" the trim ring / reflector assembly.
Lens Tube / Zoom
Lens Tube
(Beam Spread
Adjustment Knob
Adjustment)
Table 1: Beam Spread Chart
Lens Tube
Marking
Beam Spread
(in Degrees)
145
534
10 35 Align desired tube
position with plate.

User’s Manual PL House Light MKII LED Luminaires
12 OPERATION AND PROGRAMMING
OPERATION AND PROGRAMMING
1. LCD Menu Operation
The PL House Light MKII LED Luminaire’s LCD Display and Menu System provides local control for accessing all
the fixture’s status information, menu options, and settings.
Note: If there are multiple luminaires in a system, changes would need to be made at each LCD Menu as desired.
Upon power up, the LCD will display the main screen showing the product type/name. If DMX is enabled, the
programmed address will appear after power up.
Figure 9: LCD Display and Menu System
Up/Down/Left/Right Arrow Buttons -
Navigates menu system and used for
Escape Button -
Enters menu options. Navigates
OK (Enter) Button -
Accesses details, activates
a field, or enters a setting
depending on the current menu item.
selecting and setting options.
(backs up) one menu level.
PRESET Button -
Allows the recall of
LCD Display -
Displays all menu parameters and
option settings. Also displays DMX512
address (DMX models only).
INTENSITY Button -
Allows the customization of current
intensity (light output). Note, using the
LEFT and RIGHT arrow buttons you can
select each RGBW channel individually
and change their intensity using the UP
and DOWN arrows.
stored presets.

LCD Menu System 13
PL House Light MKII LED Luminaires User’s Manual
2. LCD Menu System
The LCD Display Menu system consists of several categories. Use the four arrow buttons as required (refer to Figure
9 on page 12) to access and make changes to the menu items. When the desired menu item is reached, press [OK] to
display the menu options. Use navigation and [OK] buttons to view status and configure the LCD Menu as required.
Note: Refer to "Menu Structure" on page 14 for complete structure and settings.
To navigate and access menu settings/selections:
Step 1. At Main Menu, press [ESC] / [MENU] button once. Another window will appear with sub-menu categories:
• Save as Preset
• Edit a Preset
• Color Mixer
• Settings
• Lock Fixture
• Fixture Status
• Normalize Colors
Step 2. Press [OK] at desired menu item to access and make changes.
Step 3. Make changes as desired.
Note: When DMX512 signal is present, Edit Preset and Color Mixer options will not appear in menu structure.
To navigate fixture status menus:
Step 1. At default screen, press LEFT or RIGHT arrow button once. The default menu screen will change to allow
for quick reference to the following items (note, depending on which arrow button is pressed, status screens
may appear in reverse order):
a. DMX Address (note, if fixture is UNLOCKED, hit [OK] to change DMX address).
b. Fixture Hours (displays fixture operating hours since last reset).
c. Fixture Power (displays present power consumed by fixture (in Watts).
d. Fixture Status (displays DMX or Preset selected, temperature, LED Status, fan status).
Step 2. Press LEFT or RIGHT arrow buttons to scroll through status screens.
Step 3. Press [ESC] at anytime to access Main Menu.

User’s Manual PL House Light MKII LED Luminaires
14 OPERATION AND PROGRAMMING
Menu Structure
LCD Display /
Menu System
MAIN MENU
Save a Preset
Sub Menu Options Comments
Select Preset to Save - (Option)
Scrolls and sets current user-defined
color mix to various recallable presets
in the fixture using arrow buttons.
Note: To edit a current (set) preset,
see Edit Presets.
Off Users can:
• Save the current settings (look) to
a specific recallable Preset in the
fixture’s memory.
• Edit the levels (values) for Red,
Green, Blue, White, and Intensity
values (in percent%) by using the
arrow buttons. Once the values
are adjusted, the preset is saved
as desired.
*Only intensities may be stored on
White Color Temperature presets.
RGBW in these presets cannot be
edited or changed.
Scratch Pad
Warm White* (Default)
Cool White*
Day Light*
Preset X (5 through 31)
Continued next page

LCD Menu System 15
PL House Light MKII LED Luminaires User’s Manual
Menu Structure (continued)
Edit a Preset
Sub Menu Options Comments
Select Preset to Edit - (Option)
Selects a current preset and outputs
the preset, so preset can be edited.
Note: To save a specific look of the
fixture, see Save Presets.
For additional information, refer to
"Presets" on page 17.
Off
Users can:
• Edit the current settings (look) to a
specific recallable Preset in the fix-
ture’s memory.
• Edit the values for Red, Green,
Blue, White, and Intensity values
(in percent%) by using the arrow
buttons.
• Once the values are adjusted, the
"Save Preset" menu option
appears to save the edits.
NOTES:
*Only intensities may be stored on
White Color Temperature presets.
RGBW in these presets cannot be
edited or changed.
**If a Calibrated Preset's Color Mix is
changed (5 thru 25), an asterisk '*' is
appended to the end of the name to
indicate that it has been modified.
This only happens if the name
matches the original calibrated name,
stored in EEPROM. This does not
happen if the Intensity is changed,
only the color mix.
Scratch Pad
Warm White*
Cool White*
Day Light*
Preset X (5 through 31)**
Note: When DMX512 signal is present, Edit a Preset option will not appear in menu structure.
Color Mixer
Sub Menu Options Comments
Select Color or Intensity to Adjust -
(Option)
Red
Users can:
• Edit Red, Green, Blue, White, and
Intensity values (in percent%) by
using the arrow buttons.
• Once the values are adjusted,
press [OK] to save the edits to
scratch pad.
Green
Blue
White
Intensity
Note: When DMX512 signal is present, Color Mix option will not appear in menu structure.
Continued next page
Continued from previous page
Settings
Sub Menu Options Comments
SETTINGS - (Option)
Scrolls and sets the various fixture
settings using arrow buttons.
See "Settings" on page 17 for details.

User’s Manual PL House Light MKII LED Luminaires
16 OPERATION AND PROGRAMMING
Menu Structure (continued)
3. Security
Unwanted changes to the Fixture's Configuration or Setting can be controlled by locking the fixture’s menu.
PL House Light MKII LED Luminaires are shipped with a default numeric PIN code of "0000" (four zeros). Users
may set their own PIN code (four-digit number) via Settings > General > Set PIN. When setting a PIN code,
write it down and keep it in a secure location. Note, Philips Selecon does not have records of PIN codes established
by users or owners.
Note: Contact Philips Selecon technical support if a unit is locked and the PIN code is lost for instructions on how to
reset luminaire.
Note: If the Fixture is locked when it is powered down the fixture will remain in the locked state when powered up.
Locking Fixture
To lock the fixture:
Step 1. At Main Menu, press [MENU] and scroll to Lock Fixture. Note, default PIN is "0000" (four zeros).
Step 2. Press [OK].
Step 3. Enter four-digit, user-selectable, PIN code.
Step 4. Use [LEFT ARROW] or [RIGHT ARROW] keys to highlight "YES", press [OK] or [ESC] twice to cancel
action.
Step 5. Fixture is now locked if locking process was not canceled as described in previous step.
Continued from previous page
Lock Fixture
Sub Menu Options Comments
Enter PIN Lock / Are you sure?
Use arrow buttons to make selection.
Press [OK] to accept. Note, a PIN
code must be established (set) in
order to lock a fixture. Locking the
fixture will disable access to changing
menu settings. For details, refer to
"Locking Fixture" on page 16.
Fixture Status
Sub Menu Options Comments
LED Status Information
Scrolls through the various levels.
Depending on the arrow button
pressed, the screens may appear in a
different order that shown in
"Options".
LED 1
Displays LED’s current status (in
percentage%) of Intensity, Red,
Green, Blue, and White elements of
the LED). Fan Speed, operational
LED junction temperature, power
settings.
Levels
Displays DMX levels for each LED
element (Red, Green, Blue, and
White) and total power.
Normalize Colors
Sub Menu Options Comments
Normalize Colors Adjustment of RGBW Intensities
Allows for fine adjustments to color
intensities for near perfect color
matching.

Presets 17
PL House Light MKII LED Luminaires User’s Manual
Note: When the Fixture is Locked only the [ESC]/[MENU] key is functional. Pressing this key will display a request
for a password. When a valid PIN code is entered the fixture is unlocked.
4. Presets
Presets are Color Mixes that are stored in the Fixture, they can be recalled to reproduce a specific output from the
fixture. Presets are made up of a Color Mix; Red, Green, Blue, and White. They also have Intensity associated with
them.
Presets can be recalled via the User interface or by a DMX channel, when under DMX control. The Preset’s Intensity
is applied if the User Interface is used; if DMX, the DMX Intensity channel is used for Intensity.
If the fixture is locked, Presets cannot be changed at the menu.
• Locked Presets are factory Calibrated, and their Color Mix cannot be changed by the user. Their Intensity can be
changed. Three Presets 5 through 25 are Locked.
• Preset 0, the "off" preset is also Locked to the OFF value.
• If the fixture is unlocked, User Presets can have their Color Mix and Intensity changed without restriction.
Note: If the Color Mix of a Factory Calibrated Preset is changed, by turning protection Off, an '*' is appended to the
end of the Preset's Name to indicate that the Calibrated values have been changed.
Note: DMX will take priority over any menu selected preset.
Editing Preset Names
On the Edit Preset screen, the option is available to edit the name of a preset, via Screen button. However, the names
of Presets 2, 3, and 4 cannot be edited. Scratch Pad, preset 1, can be changed but retains its original functionality.
Use the [LEFT ARROW] and [RIGHT ARROW] keys to select the character to be changed and use the [UP
ARROW] and [DOWN ARROW] keys to change that character. The Character Scroll order is A-Z, space, 0-9. If you
are scrolling up the Alpha character displays as Upper Case; if you are scrolling down the Alpha character displays as
Lower Case. Stop on the character you want, ignoring case, then press the opposite [UP ARROW] or [DOWN
ARROW] key if you want to change the case. [OK] to save changes, [ESC] to cancel changes.
5. Settings
Table 2, “Settings Menu User-Settable Parameters,” on page 18 shows the user-settable parameters available in the
Settings menu section.
To edit a value on the Setting Screen, use the [UP ARROW] or [DOWN ARROW] keys to move the highlight to the
settings value you wish to change. Press [OK] to begin editing that value. Use the [UP ARROW], [DOWN
ARROW], [LEFT ARROW] or [RIGHT ARROW] keys to make changes to the value. Press [OK] when complete to
save changes, or [ESC] to cancel changes to that value.
When done making changes on the Settings Screen press [ESC] to re-boot fixture and implement changes. Fixture
will not re-boot if nothing was changed.

User’s Manual PL House Light MKII LED Luminaires
18 OPERATION AND PROGRAMMING
Table 2: Settings Menu User-Settable Parameters
Note: To Exit the Settings screen, use the [ESC] key. [ESC] and [OK] can be used to cancel or save changes to an
individual parameter. However, once a parameter has been accepted, by pressing [OK] that change cannot be undone/
canceled by pressing the [ESC] key.
Parameter Values Default Description
General
Fan Full, Medium, or Quiet
Mode Quiet Mode Sets the luminaire’s output mode - Full
Mode, Medium Mode, or Quiet Mode.
Power-Up All presets Warm White
Users can set what the default preset is
when the unit is powered up. Factory
default is Warm White.
Red Correct No (off) / Yes (on) No
Red Correct (Correction) is internal
processing by the fixture that
compensates for the output variations that
occur in all red LEDs due to changes in
temperature. This compensation is
important if the colors of a fixture in a hot
environment needs to appear similar to
the colors of a fixture in a cooler
environment. With red correction on, there
will be a perceptible difference in output
vs. red correction off.
Power Save*** Not Applicable to this
Fixture
Not Applicable to this
Fixture
***This setting is only applicable to
PLPROFILE4 MKII LED Luminaries
Reset Hours No, Yes No Resets luminaire’s operational hours.
Set PIN #### 0 0 0 0 (four zeros) A four-digit user-settable PIN code to lock
the fixture.
Presets
Protected No, 5 - 25 5 - 25 Determines if the factory Presets' Color
Mix is protected from changes.
Load Factory No, Yes No Reload Factory Presets, Intensity changes
will also be reloaded.
DMX
Address 001 to 512 001 DMX512 address. Note, it can be set if
displayed.
Map 8-bit, 16-bit, or 5-Chan 16-bit
Defines size/precision of DMX map. Color
Mixing/Intensity in 16-bit provides higher
resolution for precision control. 5-Chan
provides minimal channel usage.
When no DMX
Off, Hold, Hold 10min,
Hold 30min, Hold 1 hr,
Hold 8hr, Power Up
Hold
If DMX is detected and then goes away,
this defines what will happen to the output.
At end of 8Hr hold Fixture goes to No
Output setting.
Display
Flip Display No, Yes No Flips (inverts) Display and Keypad Arrows.
Adj Contrast 0 - 100% 50% Use left or right arrow keys to adjust
display contrast as desired.
Fixture
Fixture ID Shows Fixture Type - PLProfile4, Profile, Cyc,
Fresnel or PL House Light Shows luminaire type.
