SOYO SY-K7AIA User manual

SY-K7AIA
Motherboard
****************************************************
AMD™K7
Processor supported
AMD 750 AGP/PCI Motherboard
100 MHz Front Side Bus supported
ATX Form Factor
****************************************************
User's Manual

SOYO™SY-K7AIA
ii
Copyright © 1999 bySoyo Computer Inc.
Trademarks:
Soyo is the registered trademark of Soyo Computer Inc. All trademarks are the
properties of their owners.
Product Rights:
All names of the product and corporate mentioned in this publication are used for
identification purposes only. The registered trademarks and copyrights belong to
their respective companies.
Copyright Notice:
All rights reserved. This manual has been copyrighted by Soyo Computer Inc. No
part of this manual may be reproduced, transmitted, transcribed, translated into any
other language, or stored in a retrieval system, in any form or by any means, such
as by electronic, mechanical, magnetic, optical, chemical, manual or otherwise,
without permission in writing from Soyo Computer Inc.
Disclaimer:
Soyo Computer Inc. makes no representations or warranties regarding the contents
of this manual. We reserve the right to amend the manual or revise the
specifications of the product described in it from time to time without obligation to
notify any person of such revision or amend. The information contained in this
manual is provided to our customers for general use. Customers should be aware
that the personal computer field is subject to many patents. All of our customers
should ensure that their use of our products does not infringe upon any patents. It is
the policy of Soyo Computer Inc. to respect the valid patent rights of third parties
and not to infringe upon or to cause others to infringe upon such rights.
Restricted Rights Legend:
Use, duplication, or disclosure by the Government is subject to restrictions set
forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer
Software clause at 252.277-7013.
About This Guide:
This Quick Start Guide can help system manufacturers and end users in setting up
and installing the Motherboard. Information in this guide has been carefully
checked for reliability; however, to the correctness of the contents there is no
guarantee given. The information in this document is subject to amend without
notice.
For further information, please visit our Web Site on the Internet. The address is
"http://www.soyo.com.tw".
Edition: January 2000
Version 1.0
K7AIA SERIAL
FC
CTested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
POST CONSUMER
RECYCLED PAPER
100%

Table of Contents SY-K7AIA
iii
Table of Contents
CHAPTER 1 MOTHERBOARD DESCRIPTION .............................1
1-1 INTRODUCTION...........................................................1
1-2 KEY FEATURES............................................................1
1-3 HANDLING THE MOTHERBOARD .............................5
1-4 ELECTROSTATIC DISCHARGE PRECAUTIONS ........5
1-5 SY-K7AIA MOTHERBOARD LAYOUT........................6
1-6 SY-K7AIA MOTHERBOARD COMPONENTS .............7
1-7 MICROPROCESSOR......................................................9
1-8 MEMORY.....................................................................10
1-9 CHIPSET ......................................................................11
1-10 I/O INTERFACE CONTROLLER.................................15
1-11 HARDWARE MONITOR..............................................17
1-12 WAKE ON LAN TECHNOLOGY.................................17
CHAPTER 2 HARDWARE INSTALLATION..................................18
2-1 PREPARATIONS ..........................................................18
2-2 UNPACKING THE MOTHERBOARD .........................19
2-3 INSTALLATION GUIDE..............................................20
2-3.1 CPU Fan Installation..................................................21
2-3.2 SDRAM Memory Module Installation..........................25
2-3.3 Motherboard Connector..............................................27
3-3.4 Power On...................................................................42
2-3.5 Quick BIOS Setup.......................................................43
2-3.6 Troubleshooting at First Start .....................................45
2-3.7 Power Off...................................................................46
CHAPTER 3 BIOS SETUP UTILITY ..............................................47
3-1 SOYO COMBO SETUP.................................................50
3-2 STANDARD CMOS SETUP..........................................53
3-3 ADVANCED BIOS FEATURES.....................................56

Table of Contents SY-K7AIA
iv
3-4 ADVANCED CHIPSET FEATURES..............................60
3-5 INTEGRATED PERIPHERALS....................................63
3-6 POWER MANAGEMENT SETUP................................67
3-7 PNP/PCI CONFIGURATION SETUP.............................70
3-8 PC HEALTH STATUS....................................................73
3-9 LOAD FAIL-SAFE DEFAULTS.....................................75
3-10 LOAD OPTIMIZED DEFAULTS...................................76
3-11 SUPERVISOR PASSWORD..........................................77
3-12 USER PASSWORD........................................................78
3-13 IDE HDD AUTO DETECTION .....................................79
CHAPTER 4 DRIVERS INSTALLATION ........................................79

Motherboard Description SY-K7AIA
1
Chapter 1
MOTHERBOARD DESCRIPTION
1-1 INTRODUCTION
The SY-K7AIA AGP/PCI Motherboard is a high-performance Slot A
supported ATX form-factor system board. SY-K7AIA uses the AMD 750
Chipset technology and supports Slot A class processors. This
Motherboard is fully compatible with industry standards and adds many
technical enhancements.
1-2 KEY FEATURES
ØCPU SUPPORT
The SY-K7AIA supports a wide range of AMD™CPUs:
nAMD™(500~750+) MHz
New released Intel Slot A CPUs will very likely be supported by the SY-
K7AIA as well.
ØCPU SETTINGS
The SY-K7AIA provides the user with a very complete and convenient
CPU setting environment. The CPU settings are auto detected and set
automatically, therefore rendering the use of jumpers obsolete.
nCPU FSB Frequency
The SY-K7AIA supports a wide range of CPU FSB frequency settings:
500,550,600,650,700,750,750+

Motherboard Description SY-K7AIA
2
nCPU Multiplier
The SY-K7AIA supports a wide range of multipliers:
5.0,5.5,6.0,6.5,7.0,7.5.
nCPU Core Voltage
The CPU Core voltage is set automatically according to CPU needs. This
makes the use of voltage jumpers unnecessary.
ØEXPANDABILITY
The SY-K7AIA provides all the standard expansion slots, and many more
additional expansion features:
uExpansion slots
n1 x 32-bit bus mastering AGP slot
n5 x 32-bit bus mastering PCI slots
n2 x 16-bit ISA slots
uEnhanced IO
nFloppy disk controller
n2x EIDE controllers with support for up to 4 Ultra DMA 33/66
devices
nStandard/EPP/ECP parallel port
n2x 16550 compatible serial ports
nIrDA compatible infrared port
n4x USB (Universal Serial Bus) connectors
nPS/2 mouse connector
nPS/2 keyboard connector
ØADVANCED FUNCTIONS
The SY-K7AIA supports advanced functions such as:
nATA 66 IDE Ports
In addition to the original two ATA33 (Ultra DMA/33)IDE ports, the
SY-K7AIA supports two ATA66 (Ultra DMA/66) IDE ports that is
capable of transferring data up to 66 Mbytes/sec (IDE DMA Mode 4).
ØWake-On-LAN
Supports Wake-On-LAN (Some advanced network cards can
wake the system up over the network, the WOL connector are
provided by the SY-K7AIA to support this function).

Motherboard Description SY-K7AIA
3
nMultiple boot
The SY-K7AIA supports booting from devices such as CD-ROM.
nPower on by modem or alarm
If the SY-K7AIA system is in suspend mode, it can be switched back
on through the modem or RTC alarm through this function. This
opens a lot of possibilities, such as remote access that switches the
system on only after the modem receives a call.
ØFAIL SAFE
The SY-K7AIA comes with added functionality to make managing the
system easy and safe.
uHardware Monitor
The integrated Winbond Hardware Monitor IC and Hardware doctor
software enables the user the monitor system voltages, temperatures and
FAN speeds. This makes sure that the user is full control of the system
ØNORTON SOFTWARE PACK
nAntivirus
nGhost
nVirtual Drive

Motherboard Description SY-K7AIA
4
ØCOMPLIANCE
The SY-K7AIA complies with all important industry standards. The
following underlines the reliability of the SY-K7AIA, a motherboard to
trust.
nYear 2000 compliant
nPC99 compliant
nFCC/CE complaint
ØUSER FRIENDLY
nSOYO Combo Setup
nJumperless design
nYou can set up the following options trough the BIOS setting
CPU FSB frequency (auto detect)
CPU multiplier (auto detect)
PCI clock
AGP Clock
SDRAM Clock

Motherboard Description SY-K7AIA
5
1-3 HANDLING THE MOTHERBOARD
To avoid damage to your Motherboard, follow these simple rules while
unpacking:
ØBefore handling the Motherboard, ground yourself by grasping an
unpainted portion of the system's metal chassis.
ØRemove the Motherboard from its anti-static packaging. Hold the
Motherboard by the edges and avoid touching its components.
ØCheck the Motherboard for damage. If any chip appears loose, press
carefully to seat it firmly in its socket.
Warning: Do not apply power if the Motherboard appears
damaged. If there is damage to the board, contact your dealer
immediately.
1-4 ELECTROSTATIC DISCHARGE PRECAUTIONS
Make sure to ground yourself before handling the Motherboard or other
system components. Electrostatic discharge can easily damage the
components. Note that you must take special precautions when handling
the Motherboard in dry or air-conditioned environment.
To protect your equipment from electrostatic discharge, take the following
precautions:
ØDo not remove the anti-static packaging until you are ready to install.
ØGround yourself before removing any system component from its
protective anti-static packaging. (To ground yourself, grasp the expansion
slot covers or other unpainted portions of the computer chassis.)
ØFrequently ground yourself while working or use a grounding strap.
ØHandle the Motherboard by its edges and avoid touching its
components.

Motherboard Description SY-K7AIA
6
1-5 SY-K7AIA MOTHERBOARD LAYOUT
Back Panel SY-K7AIA Platform
COM 1
COM 2
PRT
USB 1USB 2
PS/2 KB
Connector
PS/2 Mouse
Connector
PCI Slot #1
PCI Slot #2
PCI Slot #3
PCI Slot #4
PCI Slot #5
ISA Slot #1
ISA Slot #2
3V
Lithium
Battery
®
®
J3
J4
1
1
5
5
Winbond
W83977ATF
IDE 1 IDE 2
1
1
1
1
FDC
®
AGP Slot
PWR1
Slot A
AMD
756AC
DIMM 1
DIMM 2
DIMM 3
828A C
Hardware
Monitoring
Winbond
W83782D
AMD
751AC
Speaker
Keylock
Power
LED
SLPBT
HDD
LED
+
+
+
_
_
_ _
+
Reset
PWRBT
1
1
CHAFAN
CPUFAN
J17
WOL
Header
3 1
14
J16
Flash
ROM
2MB

Motherboard Description SY-K7AIA
7
1-6 SY-K7AIA MOTHERBOARD COMPONENTS
®
®
1
®
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
V
U

Motherboard Description SY-K7AIA
8
ASlot A Connector
BCPU Cooling Fan Connector
CAMD 751AC Chipset
DATX Power Supply Connector
EDIMM Banks
FWinboand W83782M hardware monitoring
GFloppy Disk Drive (FDD) Port
HBus Mastering E-IDE/ATAPI Ports
I32-bit AGP Slot
JSerial Infrared (IrDA) Device Header
KUSB Ports
LAMD 756AC Chipset
MFront panel connectors
N32-bit PCI Mastering Slots
OChassis Cooling Fan Connector
P3V Lithium Battery
Q16-bit ISA Slots
RFlash ROM 2MB
SWinbond W83977ATF I/O Chipset
TWake-On-LAN (WOL) Header
UWake-On-Modem Header
VBack panel Connectors

Motherboard Description SY-K7AIA
9
1-7 MICROPROCESSOR
The motherboard supports a single Slot A processor. The processor’s VID
pins automatically program the voltage regulator on the motherboard to
the required processor voltage. In addition, the front side bus speed (66
MHz and 100 MHz) is automatically selected. The motherboard supports
all (available at time of publication) Slot A processor speeds, voltages, and
bus frequencies.
1-7.1 Microprocessor Packaging
The processor is packaged in a Single Edge Contact Cartridge (SECC or
SECC2) or Single Edge Processor Package (S.E.P.P). The cartridge
includes the processor core, second-level cache subsystem, thermal plate,
and back cover.
The processor connects to the motherboard through the SlotA connector, a
242-pin edge connector. When mounted in SlotA, the processor is secured
by a retention mechanism attached to the motherboard. A passive heatsink
is stabilized by the heatsink supports.
1-7.2 Second Level Cache
The second-level cache is located on the substrate of the CPU package.
The cache includes 512 KB of synchronous pipelined burst static RAM.
All supported onboard memory can be cached.
1-7.3 Microprocessor Upgrades
The motherboard can be upgraded with Slot A processors that run at
higher speeds.

Motherboard Description SY-K7AIA
10
1-8 MEMORY
1-8.1 Main Memory
The motherboard has four DIMM sockets. SDRAM can be installed in one,
two, three, or four sockets. Using the serial presence detect (SPD) data
structure, programmed into an E²PROM on the DIMM, the BIOS can
determine the SDRAM’s size and speed. Minimum DIMM memory size is
8 MB; maximum DIMM memory size is 256MB. Memory size and speed
can vary between sockets.
The motherboard supports the following memory features:
l168-pin DIMMs with gold-plated contacts
l66/100/133 MHz SDRAM
lNon-ECC (64-bit) and ECC (72-bit) memory
l3.3V memory only
lSupports 8/16/32/64/128/256 MB DIMM Modules
lSupports unbuffered single- or double-sided DIMMs
1-8.2 SDRAM
SDRAM improves memory performance through memory access that is
synchronous with the front-side bus clock. Burst transfer rates at x-1-1-1
timing can be achieved using SDRAM, while asynchronous memory
subsystem are typically limited at x-2-2-2 transfer rates.
Note
All memory components and DIMMs used with the SY-K7AIA
motherboard must comply with the PC SDRAM specifications. These
include: the PC SDRAM Specification (memory component specific), the
PC Unbuffered DIMM Specification, and the PC Serial Presence Detect
Specification.
1-8.3 ECC Memory
ECC memory detects multiple-bit errors and corrects single-bit errors.
When ECC memory is installed, the BIOS supports both ECC and non-
ECC mode. ECC mode is enabled in the Setup program. The BIOS

Motherboard Description SY-K7AIA
11
automatically detects if ECC memory is installed and provides the Setup
option for selecting ECC mode. If any non-ECC memory is installed, the
Setup option for ECC configuration does not appear and ECC operation is
not available.
1-9 CHIPSET
The AMD-K7™processor powers the next generation in computing
platforms, delivering the ultimate performance for cutting-edge
applications and an unprecedented computing experience.
The AMD-750™Chipset is a highly integrated system logic solution that
delivers maximum performance for the AMD-K7 processor and other S2K
interface-compatible processors. The AMD-750 chipset consists of the
uniprocessor AMD-751™system controller in a 492-pin plastic ball-grid
array (PBGA) package and the AMD-756™peripheral bus controller. The
AMD-751 system controller features the S2K interface, system memory
controller, accelerated graphics port (AGP) controller, and peripheral
component interconnect (PCI) bus controller.
The AMD-751 system controller is designed with the following features:
lThe S2K interface supports a 100-MHz clock and double-data-rate
(DDR) transfers
lThe 33-MHz 32-bit PCI 2.2-compliant bus interface supports up to
six masters
lThe 66-MHz AGP 2.0-compliant interface supports 2x data transfer
mode
lHigh-speed memory –The AMD-751 system controller is designed
to support a 100-MHz PC-100 SDRAM DIMMs
1-9.1 S2K interface
The S2K interface has the following fetures:
lHigh-performance point-to-point bus
lHSTL-like 1.5 V high-speed transceiver logic signal levels
lIndependent address, data, and snoop interfaces
lDouble-data-rate transfers on address and data buses
lData Buffers:

Motherboard Description SY-K7AIA
12
Memory write FIFO (MWF)
Memory read FIFO (MRF)
PCI/APCI (AGP-PJCI) write buffer
PCI/APCI read buffer
lTransaction Queues:
Command queue (CQ)
Memory write queue (MWQ)
Memory read queue (MRQ)
Probe (snoop) queue (PQ)
1-9.2 Integrated memory controller
The integrated memory controller has the following features:
lMemory Request Organizer (MRO) –Serves as a data crossbar,
determines request dependencies, and optimizes scheduling of
memory requests.
lThe AMD-751 system controller supports the following
concurrences:
Processor-to-main-memory with PCI-to-Main-memory
Processor-to-main-memory with AGP-to-Main-memory
Processor-to-=PCI with PCI-to-Main-memory or AGP-to-main-
memory
lMemory error correcting code (ECC) support
lSupports the following DRAM:
Up to three non-buffered PC-100 SDRAM DIMMs using 16-
Mbit, 64Mbit-, and 128Mbit technology
64-bit data width, plus 8-bit ECC paths
Flexible row and column addressing
lSupports up to 768 Mbytes of memory
lFour open pages within one CS (device selected by chip select) for
one quadword
lDefault two-page leapfrog policy for eight quadword requests
lBIOS-configurable memory-timing parameters and configuration

Motherboard Description SY-K7AIA
13
parameters
l3.3-V memory interface operation with no external buffers
lFour cache lines (32 quadwords) of processor-to-DRAM posted write
buffers with full read-around capability
lConcurrent DRAM write back and read-around-write
lBurst read and write transactions
lDecoupled and burst DRAM refresh with staggered CS timing
lProvides the following refresh options:
Programmable refresh rate
CAS-before-RAS
Populated banks only
Chipset powerdown via SDRAM automatic refresh command
Automatic refresh of idle slots –improves bus availability for
memory access by the processor or system
1-9.3 PCI Bus Controller
The PCI bus controller has the following features:
lCompliance with PCI Local Bus Specification, Revision 2.2
lSupports six PCI masters
l32-bit interface, compatible with 3.3-V and 5-V PCI I/O
lSynchronous PCI bus operation up to 33 MHz
lPCI-initiator peer concurrence
lAutomatic processor-to-PCI burst cycle detection
lFour-entry, 64-bit PCI master (processor or AGP) write FIFO
lExtensive utilization of FIFOs
lZero wait-state PCI initiator and target burst transfers
lPCI-to-DRAM data streaming up to 132 Mbytes per second
lEnhanced PCI command optimization, such as memory read line
(MRL), memory read multiple (MRM), and memory-write-and-
invalidate (MWI)
lTimer-enforced fair arbitration between PCI initiators
lSupports advanced concurrency
lSupports retry disconnect for improved bus utilization

Motherboard Description SY-K7AIA
14
lPCI read buffer keeps track of each master
lPCI target request queue
1-9.4 AGP Features
The AGP features include the following:
lBus Features
Compliance with AGP 2.0 specification
Synchronous 66-MHz 1x and 2x data-transfer modes
Multiplexed and demultiplexed transfers
Up to four pipelined grants
Support of side band address (BA) bus
lRequest Queue Features
Separate read-request and write-request queues
Reordering of high-priority requests over low-priority requests
in queue
Simultaneous issuing of requests form both the write queue and
read 2queue
Selects next request to optimize bus utilization
lTransaction Queues
Memory-to-AGP and processor-to-AGP transaction queues
lFIFO Features
16-entry (64-bit) AGP-to-memory write FIFO
64-entry (64-bit) memory-to9-AGP read FIFO
lSecondary PCI Bus Features
Pipelined burst reads and writes
Extensive utilization of FIFOs
lGART (graphics address remapping table) Features
Conventional (two-level) GART scheme
Eight-entry, fully-associative GART table cache (GTC)
Three fully-associative GART directory caches (GDC)
uOne 4-entry for PCI
uOne 8-entry for the processor
uOne 16-entry for AGP

Motherboard Description SY-K7AIA
15
1-9.5 Power management
The power management features include the following:
lFull-compliance support for both ACPI and Microsoft® PC 98 power
management
lAMD-751 system controller supports the following three power
states:
lFull-on –Fully operational
Halt/Stop Grant –The AMD-7851 disconnects the processor
and, in the Stop Grant state, the SDRAMs are put into self-
refresh.
1-10I/O INTERFACE CONTROLLER
The motherboard uses the Winbond W83977ATF I/O controller which
features:
lSingle diskette drive interface
lTwo serial ports
lFIFO supports on both serial and diskette interfaces
lOne parallel port with Extended Capabilities Port (ECP) and
Enhanced Parallel Port (EPP) support
lPS/2 style mouse and keyboard interfaces
lPCI PME interface
lIntelligent auto power management, including:
ØShadowed write-only registers for ACPI compliance
ØProgrammable wake-up event interface
The Setup program provides configuration option for the I/O controller.
1-10.1 Serial Ports
The NS16C5450-compatible UARTs support data transfers at speeds up to
115.2 Kbits/sec with BIOS support.
1-10.2 Parallel Port
In the Setup program, there are four options for parallel port operation:
lCompatible (standard mode)
lBi-directional (PS/2 compatible)

Motherboard Description SY-K7AIA
16
lBi-directional EPP. A driver from the peripheral manufacturer is
required for operation.
lBi-directional high-speed ECP
1-10.3 Diskette Drive Controller
The I/O controller is software compatible with the 82077 diskette drive
controller and supports both PC-AT and PS/2 modes. In the Setup program,
the diskette drive interface can be configured for the following diskette
drive capacities and sizes.
l360 KB, 5.25-inch
l1.2 MB, 5.25-inch
l720 KB, 3.5-inch
l1.2 MB. 3.5-inch (driver required)
l1.25-1.44 MB, 3.5-inch
l2.88 MB, 3.5-inch
1-10.4 Keyboard and Mouse Interface
The +5 V lines to keyboard and mouse connectors are protected with a
fuse that prevents motherboard components from being damaged when an
over-current condition occurs.
The keyboard controller contains code, which provides the traditional
keyboard and mouse control functions, and also supports Power On/Reset
password protection. Power On/Reset password can be specified in the
BIOS Setup program.
The keyboard controller also supports the hot-key sequence
<Ctrl><Alt><Del>, software reset. This key sequence resets the
computer’s software by jumping to the beginning of the BIOS code and
running the Power On Self Test (POST).
1-10.5 Infrared Support
The IR connection can be used to transfer files to or from portable devices
like laptops, PDAs, and printers.
