NOTES AND FUNCTIONS OF THE 6210 MACHINE
THE 6210 is a single flavor, gravity feed, countertop, soft serve
machine. The machine is capable of producing a variety of products
that include: Soft Serve Frozen Yogurt, Ice Cream, select custard
products, and sorbets.
Product is poured into the refrigerated hopper
(product should be below 41°F) and flows into the
freezing cylinder via the air tube.
Inside the freezing cylinder, the beater mixes the product
while freezing and produces a soft serve product
On the front of the machine is an analog rocker
switch that controls the function of the machine
(off, wash, and cooling).
Spaceman USA 6210 Training rev111918

ROUTINE MAINTENANCE OPERATIONS
Clean and Lubricate Daily
Replace Wearable Parts Every
1 to 3 months*
Internal Cleaning Quarterly**
* Based on machine usage and cleaning intervals; a
Tune-Up Kit is available with all wearable parts (O-rings,
gaskets, etc.) except scraper blades
** Based on cleanliness of location and proximity to
powder-based machines
For optimal machine performance and
many years of efficiency and reliability
from your machine, Spaceman USA
recommends cleaning and sanitizing the
machine and its parts daily. The machine
comes equipped with a brush kit
specifically designed to efficiently and
properly clean the machine.
Spaceman USA 6210 Training rev111918

IMPORTANT:
Cleaning and sanitizing
schedules are governed by state
or local regulatory agencies and
MUST be followed accordingly.
Routine maintenance MUST be
performed a minimum of once
every three days.
CAUTIONS:
Do NOT run the machine without properly lubricating
required parts.
Do NOT clean the machine with abrasive or toxic chemicals
and cleaners. Doing so may cause damage to the stainless
steel material.
ONLY use Spaceman-USA-included cleaning brushes and lubrication.
NEVER use metal objects to clean or operate the machine.
ALWAYS replace wearable parts a minimum of every 3 months.
ALWAYS prime machine prior to operating.
ALWAYS inspect parts for excess wear and damage.
Spaceman USA 6210 Training rev111918

DISASSEMBLY
12a
Remove dispensing-door hand-screws (4)
Remove dispensing door
assembly from cylinder
1.TURN POWER
SWITCH OFF
2.REMOVE
DISPENSING DOOR
2b
Spaceman USA 6210 Training rev111918

DISASSEMBLY
Remove beater guide from door
assembly; remove gasket from door
assembly using O-ring removal tool
Remove prime plug from door
assembly; remove O-rings (2) from
prime plug using O-ring removal tool
Remove retention pin
Remove draw handle, pushing
down first to pop up draw valve,
then pulling out
3c
3d
3a
3b 3b
3.
Disassemble
dispensing
door
Spaceman USA 6210 Training rev111918

DISASSEMBLY
Remove draw valve, twisting while removing to prevent
damage
3e
Remove O-rings (2) from draw valve using
O-ring removal tool
3f
Rotate star cap so that tab is
accessible; snap off star cap
3g
3.
Disassemble
dispensing
door
Spaceman USA 6210 Training rev111918

DISASSEMBLY
4.
Disassemble
beater
assembly and
drive shaft
Remove scraper blade
from beater
assembly; separate
scraper blade clip
from scraper blade
*some new models
will not have blade
clips
Remove beater
assembly from cylinder
4a
4b
4b
“clip-less” blade
Spaceman USA 6210 Training rev111918

DISASSEMBLY
4.
Disassemble
beater
assembly and
drive shaft
Remove drive shaft from
inside cylinder using a dry
towel; separate gasket
from drive shaft ** If you
experience assembly
difficulty with drive shaft,
Spaceman offers a
specialized removal tool
for purchase.
Pull off beater shoes (2)
* some new models will
not have beater shoes
“shoe-less” beater
4c
4d
4d
Spaceman USA 6210 Training rev111918

DISASSEMBLY
5.
Remove internal drip tray and front drip tray + splash shield
5b5a
Spaceman USA 6210 Training rev111918

WASH ALL PARTS
Verify power switch is in
the OFF position
Use the large brush and cool water
to thoroughly clean inside the
cylinder; be sure to scrub the back
of the cylinder and verify the
cylinder is free of ALL product
Thoroughly clean and dry the
rear of the cylinder with the
supplied black brushes and a
clean, dry towel
Gently clean and wipe down the
outside of the machine
3
1
2
4
Spaceman USA 6210 Training rev111918

WASH ALL PARTS
When cleaning the dispensing
door assembly, clean the priming
port with a small brush
Carefully and thoroughly wash all
parts removed from the machine
using supplied brushes, sponges, and
clean towels
Carefully and thoroughly clean all
gaskets and O-rings removed from
the machine; be sure to wipe
gaskets and O-rings to remove
excess lubricant
Verify all parts are clean and free
of all food product prior to re-
assembling machine
5
7
6
8
Spaceman USA 6210 Training rev111918

ASSEMBLE
1. VERIFY POWER SWITCH
IS IN THE OFF POSITION
2. INSTALL DRIVE SHAFT
Place drive shaft
gasket on drive shaft
Seal gasket open
space with Spaceman
lubricant, extending
onto drive shaft and
avoiding the top
square part
Insert drive shaft into rear
shell bearing at the back of
the cylinder, and turn it until
the key engages firmly into
the socket (when inserted
correctly, the drive shaft will
no longer turn 360°)
12a 2b 2c
Spaceman USA 6210 Training rev111918

ASSEMBLE
3.
Install beater
assembly
3a
3b
3c
3d
Attach beater shoes (2) onto beater; when properly
placed, neither shoe overhangs beater edge * move to
step c for new models
Install scraper blade clips onto scraper blades *move to step c
for new models
Fit scraper blades onto beater
Insert beater assembly into cylinder, making sure beater shoes stay in place;
turn assembly until it engages the drive shaft key and no longer turns 360°
NOTE: * Newer models will not have blade clips OR beater shoes
Spaceman USA 6210 Training rev111918

ASSEMBLE
4. Install dispensing door
4a
Place O-rings (2) on
draw valve; place O-
rings (2) on prime plug;
coat all ring areas with
Spaceman lubricant
4b
Push prime plug
into hole on top of
dispensing door
4c
Insert draw valve
into dispensing
door, O-rings-first
Spaceman USA 6210 Training rev111918

ASSEMBLEASSEMBLE
4.
Install
dispensing
door
Slide retention pin through draw
handle; secure with nut
Set draw handle into slot on
dispensing door, with adjustment
screw facing down
Snap star cap onto bottom of
dispensing door
4e
4f
4d
Spaceman USA 6210 Training rev111918

ASSEMBLEASSEMBLE
4. Install dispensing door
4g 4h 4i
Insert dispensing door assembly
into cylinder, beater rod first,
pushing handle all the way up
as you insert
Fit gasket into grooves on back of
door, flat side out; slide beater
guide over beater rod, with flanged
edge against the door
Secure door assembly in a
cross-pattern using hand-
screws (4)
Spaceman USA 6210 Training rev111918

ASSEMBLEASSEMBLE
4.
Install
dispensing
door
4h
4g
4i
Insert dispensing door assembly into
cylinder, beater rod first, pushing
handle all the way up as you insert
Fit gasket into grooves on back of door, flat
side out; slide beater guide over beater
rod, with flanged edge against the door
Secure door assembly in a cross-
pattern using hand-screws (4)
Spaceman USA 6210 Training rev111918

ASSEMBLE
6.
Install hopper lid
and drip trays
6a 6b 6b
Install internal
and front drip
trays
If machine will be left unused, install
air tube and place hopper lid on top;
otherwise, set air tube aside until
after machine has been primed
Spaceman USA 6210 Training rev111918

SANITIZATION
Verify assembly
is complete
If installed,
remove hopper lid
and air tube
Mix a minimum of 2
gallons of food-grade
sanitizer in a bucket
or container
Verify draw valve
is in the CLOSED
position (UP)
Pour the food-
grade sanitizer
solution into
hopper
2345
1
Always use food-grade, no-rinse sanitizer (Stera-Sheen green label or equivalent)
to sanitize. If warm water is required to dissolve sanitizer, allow the solution time
to cool before adding to machine.
