spaceslide BEDSIDE UNIT User manual

UNB_BU_INSTR_01.19Page 1 of 4
DRAWER UNIT & BEDSIDE UNIT
(450mm wide)
V1
BEDSIDE UNIT
(450MM WIDE)
We recommend assembling on a soft surface
(e.g a carpet). If this isn’t possible, use a
protective cover on your hard surface floor.
20x Wooden
dowels
14x
Dowels
14x
Cams
4x
Leg brackets
12x
Euro screws
16x
Wood screws
BEDSIDE UNIT
DRAWER PACK
• Tools: Pozidrive screwdriver
RECOMMENDED:
Assembly Instructions
4x
Dowels
16x Wooden
dowels
4x
Cams
CONTENTS:
1x Top panel
1x Back panel
1x Side panel (right)
1x Side panel (left)
1x Drawer inll panel
1x Base
4x Soft close drawer runners
(2x left, 2x right)
1x Metal inll strip
2x Drawer backs
2x Drawer sides (left)
2x Drawer sides (right)
2x Drawer fronts
2x Drawer bases
4x Legs
98-BST-2DW-INST
10
2x
Glue*
*A drop of glue needs to be added into all holes the
wooden dowels are placed into (items 3 & 9).

UNB_BU_INSTR_01.19
PRELIMINARY DRAWING
ISSUED BY: A.SIMMONS
ISSUE DATE:18/06/12
QUOTATION PURPOSES ONLY
ISSUED DRAWING
ISSUED BY: A.SIMMONS
ISSUE DATE:18/06/12
ISSUED TO: SUPPLIER
PRELIMINARY DRAWING
ISSUED BY: A.SIMMONS
ISSUE DATE:18/06/12
QUOTATION PURPOSES ONLY
ISSUED DRAWING
ISSUED BY: A.SIMMONS
ISSUE DATE:18/06/12
ISSUED TO: SUPPLIER
PRELIMINARY DRAWING
ISSUED BY: A.SIMMONS
ISSUE DATE:18/06/12
QUOTATION PURPOSES ONLY
ISSUED DRAWING
ISSUED BY: A.SIMMONS
ISSUE DATE:18/06/12
ISSUED TO: SUPPLIER
Page 2 of 4
1 2 3
4Apply to both panels (D&C).
1 - Insert the dowels and cams into the drawer inll (E).
2 - On the metal strip (H) remove the plastic backing from the
double-sided tape then stick the metal strip to the inll (E).Apply to both panels (A&F).
PRELIMINARY DRAWING
ISSUED BY: A.SIMMONS
ISSUE DATE:18/06/12
QUOTATION PURPOSES ONLY
ISSUED DRAWING
ISSUED BY: A.SIMMONS
ISSUE DATE:18/06/12
ISSUED TO: SUPPLIER
PRELIMINARY DRAWING
ISSUED BY: A.SIMMONS
ISSUE DATE:18/06/12
QUOTATION PURPOSES ONLY
ISSUED DRAWING
ISSUED BY: A.SIMMONS
ISSUE DATE:18/06/12
ISSUED TO: SUPPLIER
6
C
D
DC
1
2
5Lay panel (D) on a at surface. (Shown from the side).
D
x8
x4 x4
x2
x2
x4 x3
x1
Slot infill (E)
onto the
sticky side of
the tape on
the drawer
infill strip (H).
Back
panel
x8
x7
x6 x2

UNB_BU_INSTR_01.19Page 3 of 4
10 (Repeat on all drawer sides). (Repeat on all drawer fronts).
10 11
7 8
Top panel
Back
panel
Cams
C
C
D
D
If the top panel (A) won’t locate, loosen the cams in the
back panel (B).
If the base panel (F) won’t locate, loosen the cams in the back panel
(B). Once in place, tighten the cams.
Insert the screws into the holes shown on both sides (D & C).
Left-hand runner shown above. Repeat on both sides.
5
9
x2
x3
1 2
Fix through these holes highlighted
3
x1
x4
x2
Top panel
Top panel
Back panel
Back
panel
BaseShown from underneath:
Cams
Cams
Making the drawers x4 x4
10

UNB_BU_INSTR_01.19Page 4 of 4
1 2 3
1 – Lay drawer side (J) on a at surface, insert the base (M) into the
groove then hold the back panel (I) in place.
2 – Place the other drawer side (K) over the base and fasten the
back panel (I).
3 – Turn the drawer around and add the drawer front (L) .
(Repeat on all drawers).
12
13
1 - Pull the sliding part of the lower drawer runners out and sit the
drawer on top. Whilst holding the runners in place, slide the drawer
back until the drawer clicks into place.
2 - Use the locking button to secure the drawer. Repeat for all
drawers. To remove a drawer, reverse the operation.
1 2
14 Fix the brackets in place using the wood screws, repeat on all four
corners. Screw the feet in place by turning them clockwise.
x4
Drawer base
Drawer base
Drawer side
Pull the sliding part of the lower
drawers out first and hold in place.
Drawer side
Drawer back
Drawer back
Drawer front
Drawer shown
from underneath. Locking button
Turn to
adjust height
Turn the unit on
its side to attach
the feet.
Turn the
feet clockwise
to attach.
Ensure the
bracket
slopes
towards
the corners.
x2 x2
