Spear & Jackson CLGT2425H User guide

CLGT2425H
ORIGINAL
INSTRUCTION
MANUAL
24V
Important - Please read these instructions
fully before starting assembly AFTER SALES SUPPORT
Cordless
Grass Trimmer
0345 605 2068
These instructions contain important information that will help
you get the best from your trimmer, ensuring it is assembled
correctly and safely. If you need help or have damaged or
missing parts, call the Customer Helpline on 0345 605 2068

AFTER SALES HELPLINE 03456 052 0682
SPEAR & JACKSON SINCE 1760
For more than 250 years gardeners have enjoyed high quality performance and great results using
Spear & Jackson tools.
Our garden power tools combine continuous innovation and the latest in manufacturing technologies
with a proud heritage.
Each product is carefully designed with performance,comfort and durability rmly in mind,which has
earned Spear & Jackson an enviable reputation as a maker of tools to trust.
As a testament to the quality of our products, we offer a 3 year manufacturers warranty and a
comprehensive after sales service.
The warranty covers manufacturing faults, however in the event that the item has been deliberately
damaged, used in a commercial environment or disassembled then the warranty will be null and void.
Please retain proof of purchase.
We want you to get the best out of your products. Our easy-to-read instruction manual guides you with
best practice use and maintenance tips. Please call 03456 052 068 for technical support, we can solve
around 80% of questions directly over the phone.
We hope you enjoy your product and we look forward to any feedback, as this allows us to develop
even better products for the future.
3 YEARS GUARANTEE
TECHNICAL SUPPORT

AFTER SALES HELPLINE 03456 052 068 3
Safety Information..................................................................................................................... 4
Desription Of Symbols...................................................................................................................... 4
General Safety .................................................................................................................................. 5
Additional Safety Instructions For Batteries And Chargers .............................................................. 7
Additional Safety Instructions For Grass Trimmers......................................................................... 10
Maintenance And Storage Safety.................................................................................................... 11
Intended Use.................................................................................................................................... 12
In the Box........................................................................................................................................ 13
Parts ................................................................................................................................................. 13
Assemble................................................................................................................................... 14
Prepare ...................................................................................................................................... 17
Operate...................................................................................................................................... 19
Maintenance ............................................................................................................................. 22
Technical Data .......................................................................................................................... 24
Troubleshooting........................................................................................................................ 26
Warranty .................................................................................................................................... 27
CONTENTS

AFTER SALES HELPLINE 03456 052 0684
Do not expose and
operate the tool in rain.
Beware of thrown
or ying objects to
bystanders. Keep by
standers a safe distance
away from the machine.
Waste electrical
products should not
be disposed of with
household waste. Please
recycle where facilities
exist. Check your Local
Authority or retailer for
recycling advice.
The charger is for indoor
use only.
Double insulation.
Fuse.
Batteries contain Li-ion,
waste batteries should
be sorted for ecofriendly.
Do not dispose of waste
batteries as unsorted
municipal waste.
Do not dispose of
batteries in rivers or
immerse in water.
Do not litter to re.
SAFETY INFORMATION
DESCRIPTION OF SYMBOLS
WARNING! This is
a warning symbol.
This symbol is used
throughout the user
guide whenever there
is a risk of personal
injury. Ensure that these
warnings are read and
understood at all times.
Read instruction
handbook before
operating this machine.
Wear hearing protection.
Wear eye protection.
Keep bystanders away.
Disconnect the battery
pack before any repair or
maintenance.
Guaranteed sound
power level.
The product complies
with the applicable
European directives and
an evaluation method
of conformity for these
directives was done.
li-ion
T/3.15A

AFTER SALES HELPLINE 03456 052 068 5
SAFETY INFORMATION
GENERAL SAFETY
IMPORTANT! Read all
instructions. Failure to
follow all instructions
listed below may result in
electric shock, re and/
or serious injury. The
term “power tool” in all
warnings listed below
refers to your mains
operated power tool.
• Read the instruction
carefully. Be familiar with
the controls and the correct
use of the appliance.
Read and understand the
operator’s manual and
observe the warnings and
instruction labels afxed to
the appliance.
• Users. Never allow children
or people unfamiliar with
these instructions to
use the appliance. Local
regulations may restrict
the age of operator. Never
operate the tool under
the inuence of alcohol,
medication or drugs.
Do not subject the
battery to strong sunlight
over long periods and do
not leave it on a heater
(max.45°C).
• Use appropriate tool. This
device is only intended for
trimming hedge outdoors
and only designated for
use on private property.
Do not force small tools or
attachments to do the job
of a heavy duty tool.
• Keep work areas clean.
Cluttered areas can cause
accidents.
• Consider work area
environment. Do not expose
the tool to high humidity or
rain. Do not use the tool in
damp and wet conditions.
Keep the work area well lit.
Do not use the tool where
there is a risk of causing
re or explosion, e.g. in
the presence of ammable
liquids and gases.
• Keep all bystanders,
children, and pets away.
The operator or user is
responsible for accidents or
hazards occurring to other
people or the property.
• Grip the tool securely.
Operator should have one
hand on the main handle,
the other on the front
handle. Keep nger off
trigger until ready to use.
• Risk of cut. Do not try to
grasp or remove trimmings

AFTER SALES HELPLINE 03456 052 0686
when the product is
running. Only remove
trimmings when the
product is switched off
and disconnected from the
power supply.
• Check for damaged parts.
Before further use, carefully
check the tool for damage.
Check for alignment of
moving parts, binding of
moving parts, breakage of
parts, mounting and any
other condition that may
affect its operation. Do not
use the tool if any parts
are damaged or defective.
Have any damaged or
defective parts repaired or
replaced by an authorized
service agent. Never
attempt any repairs yourself.
• Store idle tools. When not in
use, tools should be stored
in a dry, locked-up place
out of reach of children.
• Maintain tools with care.
Keep tools clean and in
good condition for better
and safer performance.
Follow the instructions for
maintenance and changing
accessories. Keep handles
and switches dry, clean and
free from oil and grease.
SAFETY INFORMATION
PERSONAL SAFETY
• Stay alert, watch what
you are doing and use
common sense when
operating a power tool. Do
not use a power tool while
you are tired or under the
inuence of drugs, alcohol
or medication. A moment of
inattention while operating
power tools may result in
serious personal injury.
• Use personal protective
equipment. Always wear
eye protection. Protective
equipment such as dust
mask, non-skid safety
shoes, hard hat, or hearing
protection used for
appropriate conditions will
reduce personal injuries.
• Prevent unintentional
starting. Ensure the switch
is in the off-position before
connecting to power source
and/or battery pack, picking
up or carrying the tool.
Carrying power tools with
your nger on the switch or
energising power tools that
have the switch on invites
accidents.
• Do not overreach. Keep
proper footing and balance
at all times. This enables
better control of the
power tool in unexpected

AFTER SALES HELPLINE 03456 052 068 7
other metal objects, like
paper clips, coins, keys,
nails, screws or other small
metal objects, that can
make a connection from
one terminal to another.
Shorting the battery
terminals together may
cause burns or a re.
• Do not expose battery pack
to heat or re. Avoid storage
in direct sunlight.
• Do not subject battery pack
to mechanical shock.
• In the event of battery
leaking, do not allow the
liquid to come into contact
with the skin or eyes. If
contact has been made,
wash the affected area with
copious amounts of water
and seek medical advice.
• Seek medical advice
immediately if a cell or
battery pack has been
swallowed.
• Keep battery pack clean
and dry.
• Wipe the battery pack
terminals with a clean dry
cloth if they become dirty.
• Battery pack needs to be
charged before use. Always
refer to this instruction and
use the correct charging
procedure.
SAFETY WARNINGS FOR
BATTERY PACK
WARNING! Read all
safety warnings and all
instructions. Failure to
follow the warnings and
instructions may result in
electric shock, re and/
or serious injury.
SAVE ALL WARNINGS
AND INSTRUCTIONS FOR
FUTURE REFERENCE.
• Do not dismantle, open or
shred cells or battery pack.
• Do not short-circuit a
battery pack. Do not store
battery packs haphazardly
in a box or drawer where
they may short circuit each
other or be short-circuited
by conductive materials.
When battery pack is not
in use, keep it away from
situations.
• Dress properly. Do not wear
loose clothing or jewellery.
Keep your hair, clothing and
gloves away from moving
parts. Loose clothes,
jewellery or long hair can be
caught in moving parts.
SAFETY INFORMATION
ADDITIONAL SAFETY INSTRUCTIONS FOR
BATTERIES AND CHARGERS

8
reference.
• Remove the battery from
the equipment when not in
use.
• Dispose of properly.
SAFETY WARNINGS FOR
YOUR BATTERY CHARGER
WARNING! Read all
safety warnings and all
instructions. Failure to
follow the warnings and
instructions may result in
electric shock, re and/
or serious injury.
SAVE ALL WARNINGS
AND INSTRUCTIONS FOR
FUTURE REFERENCE.
• This appliance is not
intended for use by persons
(including children) with
reduced physical, sensory
or mental capabilities, or
lack of experience and
knowledge, unless they
have been given supervision
or instruction concerning
use of the appliance by a
person responsible for their
safety.
• Children should be
supervised to ensure that
they do not play with the
appliance.
• Do not maintain battery
pack on charge when not in
use.
• After extended periods
of storage, it may be
necessary to charge and
discharge the battery pack
several times to obtain
maximum performance.
• Battery pack gives its best
performance when it is
operated at normal room
temperature (20 °C ± 5 °C).
• When disposing of battery
packs, keep battery packs
of different electrochemical
systems separate from
each other.
• Recharge only with the
charger specied by
manufacturer. Do not use
any charger other than that
specically provided for
use with the equipment. A
charger that is suitable for
one type of battery pack
may create a risk of re
when used with another
battery pack.
• Do not use any battery
pack which is not designed
for use with the equipment.
• Keep battery pack out of
the reach of children.
• Retain the original product
literature for future
AFTER SALES HELPLINE 03456 052 068
SAFETY INFORMATION

AFTER SALES HELPLINE 03456 052 068 9
suited models.
• Ensure that the connection
between the battery
charger and battery is
correctly positioned and is
not obstructed by foreign
bodies.
• Keep battery charger’s slots
are free of foreign objects
and protect against dirt and
humidity. Store in a dry and
frost-free place.
• When charging batteries,
ensure that the battery
charger is in a wellventilated
area and away from
inammable materials.
Batteries can get hot
during charging. Do not
overcharge any batteries.
Ensure that batteries
and chargers are not
left unsupervised during
charging.
• Do not recharge
nonrechargeable batteries,
as they can overheat and
break.
• Longer life and better
performance can be
obtained if the battery pack
is charged when the air
temperature is between
18°C and 24°C. Do not
charge the battery pack
in air temperatures below
ADDITIONAL SAFETY
INSTRUCTIONS FOR YOUR
BATTERY CHARGER
• Before charging, read the
instructions.
• After charging, disconnect
the battery charger from the
supply mains. Then remove
the chassis connection and
then the battery connection.
• Do not charge a leaking
battery.
• Do not use chargers for
works other than those for
which they are designed.
• Before charging, ensure
your charger is matching
the local AC supply.
• For indoor use, or do not
expose to rain.
• The charging device must
be protected from moisture.
• Do not use the charging
device in the open.
• Do not short out the
contacts of battery or
charger.
• Respect the polarity “+/-”
when charging.
• Do not open the unit and
keep out of the reach of
children.
• Do not charge the batteries
of other manufactures or ill-
SAFETY INFORMATION

AFTER SALES HELPLINE 03456 052 06810
of the trimmer when in use.
• Only use the trimmer in
daylight or good articial
light.
• Before using the trimmer
and after any impact, check
for signs of wear or damage
and repair as necessary; Do
not use the trimmer if the
cutting device is not secured
properly or is damaged.
• Always check the good
working order of the trimmer
which, if not adequate,
could endanger the user.
• Never operate the trimmer
with damaged guards or
without the guards in place.
• Before starting the trimmer,
make sure that the nylon
line is not touching stones
or debris.
• Take care against injury to
feet and hands from the
cutting means.
• Take care against injury
from the cutter blade tted
for trimming the lament
line length. Switch on the
motor only when the hands
and feet are away from the
cutting means.
• Never t metal cutting
elements.
• Never use replacement
0°C, or above 45°C.This is
important as it can prevent
serious damage to the
battery pack.
• Charge only battery pack of
the same model provided
by manufacturer and of
models recommended by
manufacturer.
• Wear safety goggles when
operating this tool.
• Wear gloves when
operating this tool.
• Do not expose the tool to
rain or high humidity.
• Be familiar with the controls
and proper use of trimmer.
• Never allow children or
people unfamiliar with the
instructions to use the
trimmer.
• Keep children, other people
and pets away from the
trimmer; the grass which
is cut and dispersed may
contain stones and debris.
Stop using the trimmer
while people, especially
children, or pets are nearby.
• Do not let other people or
animals come within 15 m
ADDITIONAL SAFETY INSTRUCTIONS
FOR GRASS TRIMMERS
SAFETY INFORMATION

AFTER SALES HELPLINE 03456 052 068 11
• Disconnect the product
from the power supply
(i.e. remove the plug from
the power supply or the
battery pack) and check for
damage after use.
• Disconnect the product
from the power supply (i.e.
remove the plug from the
power supply or the battery
pack) before carrying out
maintenance or cleaning
work.
• Use only the
manufacturer’s
recommended
replacement parts and
accessories.
• Inspect and maintain the
product regularly. Have
the product repaired only
by an authorised service
centre or similar qualied
specialist.
• When not in use, store the
product out of the reach of
children.
• Have your power tools
parts or accessories not
provided or recommended
by the manufacturer.
• Remove the battery before
checking, cleaning or
working on the trimmer and
when it is not in use.
• Always ensure that
ventilation openings are
kept clear of debris.
• To avoid unintentional
starting, do not carry the
machine with a nger on
the on/off switch.
• Remain in a stable and
secure position while
operating the trimmer.
• Keep the area being cut
free from wires, stones and
debris.
• Do not cut against hard
objects. This could cause
injury or damage the
trimmer.
• Warning! Cutting elements
continue to rotate after the
motor is switched off.
• Do not try stopping the
cutting device (nylon line)
with your hands. Always let
it come to a stop by itself.
• Do not use the trimmer to cut
grass which is not in contact
with the ground; for example
do not cut grass which is on
SAFETY INFORMATION
walls or rocks etc.
• Do not cross roads or
gravel paths with the
trimmer still running.
MAINTENANCE AND STORAGE SAFETY

AFTER SALES HELPLINE 03456 052 06812
• This Cordless grass
trimmer is designed for
domestic use only: to trim
grass, lawn edges and light
foliage.
• This machine is not
designed for heavy duty or
commercial use.
• Any use of the machine
that deviates from its
intended use and is
not included in these
instructions is considered
unauthorized use and
relieves the manufacturer
from his or her legal liability.
INTENDED USE
serviced by a qualied
repair person using only
identical replacement
parts. This will ensure that
safety of the power tool is
maintained.
SAFETY INFORMATION

AFTER SALES HELPLINE 03456 052 068 13
IN THE BOX
16
3
9
11
13
10
12
15
14
8
PARTS
1Handle
2Lock-off button
3Trigger switch
4Front handle
5Handle
adjustment clamp
6Trimming/edging
locking system
7Locking collar
8Shaft
9Motor housing
10 Line cutting blade
11 Flower guard
12 Automatic feed
spool
13 Nylon line
14 Guard
15 Head adjustment
button
16 Battery
17 Battery charger
2
4
6
7
5
1
17

AFTER SALES HELPLINE 03456 052 06814
ASSEMBLE
2
1
3
Unpacking
i. Unpack all parts and lay them on a flat, stable surface.
ii. Remove all packing materials and shipping devices if
applicable.
iii. Make sure the delivery contents are complete and free
of any damage. If you find that parts are missing or show
damage do not use the product but contact the aftersales
helpline within 28 days of purchase. Using an incomplete
or damaged product represents a hazard to people and
property.
iv. Ensure that you have all the accessories and tools needed
for assembly and operation. This also includes suitable
personal protective equipment.
Connect the upper and lower handle
Assemble the shaft into the upper handle and fully engaged,
fix the handle using the locking collar.
Fitting the Guard
Place the guard onto the housing as shown, secure the guard
by screws.

AFTER SALES HELPLINE 03456 052 068 15
ASSEMBLE
4
5
Front handle assemble
i. Loosen the knob and remove it together with the bolt from
the front handle.
ii. Align the front handle to the housing and place it onto it.
iii.Insert the bolt from the right through the opening, ensure
that the bolt head sits properly then tighten the knob.
Preparation: The charging process starts as soon as
the mains plug of the battery charger is plugged into a
mains socket and the battery is inserted into the charging
compartment.
If the battery is not inserted, a continuous red light indicates
that the mains plug is plugged into a mains socket and the
battery charger is ready for operation.
Charging: a flashing green LED on the charger indicates that
the battery is charging normally.
Charged: continuous green LED on the charger indicates
that the battery is ready for use.
The indicator lights on the charger show the charger status:
Charging the battery
i. Plug the charger into an appropriate AC power outlet.
ii. Install the battery on the slot of charger.
Symbol Indicator lights Status
red, flashing technical issue see
instructions below
red, continuous connected to
power supply
green, flashing charging
green, continuous fully charged

AFTER SALES HELPLINE 03456 052 06816
ASSEMBLE
6
The intelligent charger measures the charge level of the
battery and charges the battery accordingly with the required
current and voltage based on battery temperature and
voltage. This ensure maximum battery life charge it fully
before storage.
A flashing red LED light on the charger indicates that the
battery temperature is not within the charging temperature
range of -5°C– 50°C or the charging current is too high. As
soon as the permitted temperature and the charging current
ranges are reached, the battery charger will automatically
switch to charging.
After continuous or repeated charging cycles without
interruption, the charger may warm up. This is normal and
does not indicate a technical defect of the battery charger.
Green LED flashing rapidly indicates that the battery voltage
is low, the battery will receive an extended charge cycle
approximately 30mins longer. This does not indicate a defect
with the battery.
Check battery capacity
Push the power indicator to show remaining battery capacity.
LED indicators on battery Battery Capacity
Continuous lighting of 4 LEDs
(inc 2 green)
Fully charged
Continuous lighting of 3 LEDs
(inc 1 green)
≥ 50%
Continuous lighting of 2 LEDs
(orange & red)
≥ 25%
Continuous lighting of 1 LED
(red only)
≤ 25%. Recharge required.

AFTER SALES HELPLINE 03456 052 068 17
1
2
3
PREPARE
Insert and remover battery Pack
i. Insert battery pack into the battery slot and ensure it clicks
firmly into place.
ii. To remove the battery back press the release button on the
battery.
Adjusting the Front handle
i. Release the clamp and rotate the handle to the desired
position then lock the clamp.
Head angel Adjustment
Adjust the vertical angle of the trimmer head to fit the
trimming conditions.
i. Press the press head adjustment button.
ii. Adjust the angle, up or down.
iii.Release the button, make sure it locks in place.
Press

AFTER SALES HELPLINE 03456 052 06818
PREPARE
Edge
i. Push the locking button forward and hold it in position.
ii. Twist the shaft 180 degree and allow automatically engage
the lock as figure show.
Plant protector
Use the plant protector to keep distance to plants like flowers,
trees or other objects that could be hit by the cutting device.
i. Slide the plant protector out for trimming/edging operation.
ii. Slide the plant protector in for storage.
WARNING! Adjust the plant protector position only
when the product is switched off and the cutting
device is at a complete stop!
WARNING! Take care to have a look at the yellow
warning label and rip off before use.
Take great care when doing this as there is a very
sharp line trimming blade on the guard.
4
5

AFTER SALES HELPLINE 03456 052 068 19
OPERATE
30o
Trimming
i. Ensure the knife protector label is removed before use.
Ensure you wear gloves when removing this label.
ii. Adjust the trimmer head angle to a proper position for
trimming operation.
iii. Hold the grass trimmer firmly, keeping your balance with
feet slightly apart. Alter the height of the product if needed
to ensure an upright posture.
iv. Hold the trimmer head just above the ground at an angle
of approximately 30°.
v. Move the product slowly from side to side in a swinging
motion.
vi. Ensure the cutting device remains clean and free from
off-cuts that may cause it to jam. Check regularly. Release
the on/off switch and take the battery pack off before
checking.
Switching on/off
i. Push safety switch, and press the on/off switch to turn the
product on.
ii. Release the on/off switch to turn the product off.
Automatic line feeding
The equipment features a fully automatic single line system.
The lines will automatically elongate every time you turn on
the appliance. To support proper line elongation, ensure that
the coil has stopped moving completely before turning on the
appliance again.
The lines are automatically cut to the correct length by the line
cutter.
1
2

AFTER SALES HELPLINE 03456 052 06820
OPERATE
vii. Trim longer grass in stages; do not cut long grass in one
cut. For the best results, cut longer grass in steps.
viii. Place the trimmer along the edge of the lawn.
ix. Turn product on and push the trimmer forward slowly.
WARNING!
• Always fit the guard before using the product
• When cutting longer/high grass, please make sure
that you cut this down in 2 to 3 stages.
• Do not cut long grass in one cut, as this will damage
your grass trimmer, and make your warranty invalid.
