Speco SIPB1 User manual

Speco Internet Protocol (SIP)
Features
• Compatible with major third party software suites such as Milestone Systems and ONSSI
• All cameras in the SIP series come with advanced NVR software at no extra charge
• Power Over Ethernet (IEEE 802.3af) and/or 12V DC (not available on SIPSD10X)
• 2-way audio
• Works with Speco Technologies hybrid DVRs as well as other major manufacturers
• Adjustable bandwidth to meet all network infrastructures
• Available in normal resolution and megapixel versions
• Remotely view up to 16 cameras in one window… from anywhere in the world!
• Changeable/Selectable Ports allow one IP address to handle multiple cameras
• Support of Dynamic and Static IP addresses
• Analog composite video output for local viewing (normal reoslution models only)
• Video servers and decoders also available
• 5 year warranty
Specifications subject to change
For more information contact us at:
Speco Technologies 200 New ighway, Amityville, NY 11701 eb: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: [phone] or 631-957-3880
An enterprise level network solution for IP cameras
Normal Resolution Cameras
feature Intensifier Technology,
Network and Com osite video out uts
eatherproof Bullets
SIPB1
2.8-11mm auto iris varifocal lens
SIPB2
5-50mm auto iris varifocal lens
Tamperproof/ eatherproof Domes
SIPD3
2.8-11mm auto iris varifocal lens
SIPD4
5-50mm auto iris varifocal lens
Traditional Camera
SIPT5
Uses CS type lenses
SIPSD10X
Motorized Speed Dome Indoor/Outdoor
3.8-38mm lens with mechanical IR filter
1.3 Megapixel Cameras
include day/night function w/ mechanical IR filter
eatherproof Bullet
SIPMPB
4.2mm megapixel lens – 48 LEDs
Tamperproof/ eatherproof Dome
SIPMPD
4.2mm megapixel lens
Traditional Megapixel Camera
SIPMPT5
Uses CS type lenses

Specifications: Speco Internet Protocol (SIP) Cameras - Normal / 1.3 Megapixel Resolution
For more information contact us at:
Speco Technologies 200 New ighway, Amityville, NY 11701 eb: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: [phone] or 631-957-3880
SIPB1
2.8-11mm auto iris varifocal lens SIPB2 5-50mm auto iris varifocal lens SIPD3 2.8-11mm auto iris varifocal lens SIPD4 5-50mm auto iris varifocal lens
Specifications for 1.3 megapixel cameras
eatherproof Bullet
SIPMPB
4.2mm megapixel lens – 48 LEDs
Tamperproof/ eatherproof Dome
SIPMPD
4.2mm megapixel lens
Traditional Megapixel Camera
SIPMPT5
Uses CS type lenses
Specifications for normal resolution cameras
Camera Specifications
Image Sensor 1/3" Sony™ Super- AD CCD 410K Network Specifications
orizonal Resolution 540 TV Lines Video Compression
Total Pixels 811 x 508(NTSC) Compression MPEG-4
Effective Pixels 768 x 494 (NTSC) Resolution Full D1 (720x480 in NTSC, 720x576 in PAL)
Electric Shutter 1/60 ~ 1/200,000sec (NTSC) VGA (640x480 inNTSC, 640x480 in PAL)
1/50 ~ 1/200,000sec (PAL) CIF (352 x 240 in NTSC, 352x288 in PAL)
Min. Scene Illimination 0.002Lux (Intensifier), 0.3Lux (Shutter) QCIF (176x120 in NTSC, 176x144 in PAL)
Scanning System 2:1 Interlaced 525 Lines / 60Fields / 30 Bit Rate 28 K ~ 3 M bps
Synchronization Internal Image Frame Rate 30 fps at full D1 resolution (NTSC)
S/N Ratio 50dB(Weight On) 25 fps at full D1 resolution (PAL)
Day/Night Software method Audio Input
OSD (On Screen Display) Built-in Compression 8k z, Mono, PCM
White Balance ATW / AWC / Manual Audio Line Input Unbalanced, 1.4 Vp-p 1Vrms, terminal Block
SLC (Speco Light Compensation) Off / Low / Middle / igh Audio Output
AGC Off / Low / Middle / igh Compression 8k z, Mono, PCM
Dynamic Noise Reduction (DNR) Off / Low / Middle / igh Audio Line Output Unbalanced, 1.4 Vp-p 1Vrms, terminal Block
Intensifier Built-in (selectable Limit ~ X128) External I/O
Off / Low / Middle / igh Reset Button Factory default
Color Auto (Auto Day/Night) / On Joystick OSD Control
Motion Detection Off /On Network
Privacy Off /On (4 Programable Zones) Ethernet Ethernet(10/100 Base-T),RJ-45 connector
Video output 1.0V [p-p] NTSC Composite, 75 / BNC Protocol TCP, UDP ,IP, TTP, D CP, PPPoE, RTP, RTSP
Power Source 12V DC (300mA) Software
PoE (IEEE802.3af) with Class 3 Web Browser MS Internet Explorer 6.0 or above
Operational Temperature -10 ~ +50 ( - 14 ~122 ) Security Password protection: configured by administator
Operational umidity 30% ~90% R Compatibility Most major 3rd party software suites
Dimensions (Wx xD) 64 mm x 55.4 mm x 120mm NVR Software Included at no additional charge
Weight 0.7kg
Camera Specifications
Image Device Micron Progressive Scan Super CMOS
Image Size 1/3 inch
Effective Pixels 1280 x 1024
Min. Illumination Color: 0.5 Lux at F1.8 (30 IRE,MAX AGC)
B/W: 0.05 Lux at F1.8 (30 IRE,MAX AGC)
CDS Sensor Yes (SIPMPB)
IR Sensitivity from 700 nm to 1100 nm (SIPMPB)
Lens Mount C /CS with adaptor (SIPMPT5)
Sync. System Internal
Mech. IR Cut Filter Yes (SIPMPB & SIPMPD)
Motion Detection Yes (3 Windows)
Electronic Shutter 1/10 ~ 1/2,000 sec. (60 z); 1/10 ~ 1/2,000 sec. (50 z)
Flickerless 1/120 sec. (60 z); 1/100 sec. (50 z)
BLC Yes
AGC Automatic (User defined)
White Balance 6 modes (AUTO, INDOOR1, INDOOR2, OUTDOOR1,
OUTDOOR2, OLD CURRENT, MANUAL) configurable
S/N Ratio Better than 48 dB
Video Compression MPEG-4, MJPEG selectable
Picture Resolution SXGA (1280x1024); D 720 (1280x720);VGA (640x480)
Image Frame Rate Up to 8 fps at SXGA resolution; Up to 10 fps at
D720 resolution; Up to 30 fps at VGA resolution
Audio Input 8 k z, Mono, PCM
Audio Line Input Unbalanced, 1.4Vp-p, 1Vrms, 3.5 mm Jack
Audio Output 8 k z, Mono, PCM
Audio Line Output Unbalanced, 1.4Vp-p, 1Vrms, 3.5 mm Jack
Alarm Digital Input 1, terminal block
Transistor Ouput 1, terminal block
Reset Button Factory default
External I/O LED System status
Network Ethernet (10/100Base-T), RJ-45 connector
Protocol TCP, UDP, IP, TTP, D CP, PPPoE, RTP, RTSP, FTP, SMTP,
DNS, DDNS, NTP, ICMP, IGMP, ARP, 3GPP
Web Browser Microsoft Internet Explorer 6.0 or above
SDK ActiveX control, C SDK
Security Password protection: configured by administrator
Operating Temp. 0 ºC ~ 50 ºC (32 ºF ~ 122 ºF)
Power Requirement PoE (IEEE802.3af) with Class 3
Power Consumption 3.3 W (DC 12 V); 4.3 W (PoE)
Dimensions (Wx xD) 2.64” x 2.17” x 5.10”
Weight 0.88 lb.
SIPSD10X
Motorized Speed Dome Indoor/Outdoor 3.8-38mm lens with mechanical IR filter
Tamperproof/ eatherproof Domes
eatherproof Bullets
SIPT5
Traditional Camera - Uses CS type lenses
