Catalina 340 Z
Installaon and Operang Manual

2

3
Program Mode allows checks and adjustments of
all system sengs. Please consult your manual be-
fore making any adjustments. See page 74.
Auto Run
To Start and run for one hour, press once. Press
again for each addional hour of run me.
For Auto Fill mode, press and hold for 5 seconds
and system will run unl your Tank Switch closes.
Auto Run funcons always terminate with a fresh
water ush.
In Program mode, press to REDUCE value
Stop (or Start)
Press once to start or stop system.
If you stop the system by pressing stop, the sys-
tem will not fresh water ush itself.
To bypass the Purge Mode, only if you are
sure there are no chemicals in the system,
Press Auto Run and Stop, momentarily at
the same me.
Alarm Display
Push to silence alarm
When system is running, press to scroll through
system readings
In program mode, push to scroll through the sys-
tem parameters
Auto Store
Press and hold for 3 sec for one me fresh water
ush
Press once to fresh water ush and acvate the
ush mer interval. The light blinks when in this
med ush mode.
In Program mode, press to INCREASE value
MPC Controller Quick Guide

4

5
1. The system must have a dedicated sea water inlet to guarantee a solid ow of water to the
system. The inlet should be as low in the boat as possible and with a forward facing scoop-
type thru-hull ng installed.
2. Both the Catalina 340 Z feed pump module and the Clark Pump/Membrane module must
be installed in a well venlated compartment where temperatures will not exceed 120F
(48C). Many engine compartments exceed this temperature when underway. Warranty
will be void if the installaon does not meet this requirement.
3. Follow the wire gauge charts in the instrucons. Using larger wire than specied is ac-
ceptable.
4. If you are separang the Clark Pump/membrane assembly, please review the high pressure
tube assembly instrucons. Improper assembly will cause failure.
5. Run, test, then sea trial the complete system before assuming the system is operaonal. If
the boat is in fresh or dirty water, see Dry Tesng with an Arcial Ocean. Aer tesng,
make sure that the ush cycle operates properly. The water going overboard at the end of
the ush should only taste slightly salty and measure <1000 PPM salinity.
6. The MPC control must have DC power connuously to achieve the full benets of the fresh
water ush system. The domesc fresh water pressure must be on and the fresh water
tank level maintained. Calculate 7 gallons (12L) per ush.
7. The MPC 5000 control must be de-powered (DC power o) aer the system is put in stor-
age.
8. Spectra dealers are responsible for educang the vessel owners on the operaon and
maintenance of the system. We request that you walk through the installaon with the
customer.
9. Please have the owner ll out the warranty card or ll one out on Spectra’s website,
www.spectrawatermakers.com.
Catalina Installation Quick Start
Important Details for Installer

6

7
Operation
Table of Contents
Installaon.................................................................................................................11
Geng Started ..............................................................................................................13
Introducon ..................................................................................................................14
Installaon Basics ..........................................................................................................17
Catalina Plumbing Schemac.........................................................................................18
Product Water plumbing ...............................................................................................21
Tube Fing Assembly Procedures .................................................................................22
Wiring ...........................................................................................................................24
Remote Display Installaon ...........................................................................................26
MPC Tank Switch Wiring and Operaon ........................................................................27
Z-Ion and Z-Brane Membrane Protecon Systems………………………………………………………..29
Z-Ion Installaon…………………………………………………………………………………………………………..30
Z-Ion Tesng………………………………………………………………………………………………………………...32
Z Brane Installaon........................................................................................................33
Operaon ...................................................................................................................37
New Systems Start Up and Tesng ................................................................................39
Nominal Operang Parameters .....................................................................................41
Dry Tesng with an Arcial Ocean ...............................................................................42
Normal Operaon and Fresh Water Flush......................................................................43
Auto Store and Flush Cycle Adjustment .........................................................................44
Alarm Override and Manual Operaon..........................................................................45
Maintenance, Storage, and Troubleshoong.....................................................47
Suggested Spares...........................................................................................................49
Maintenance .................................................................................................................50
Introducon to Spectra Chemicals.................................................................................52
Long Term Storage Procedures ......................................................................................54
Winterizing with Propylene Glycol.................................................................................55
Membrane Cleaning Procedure .....................................................................................56
Troubleshoong ............................................................................................................57
Poor Water Quality........................................................................................................59
Catalina Flow Test .........................................................................................................60
Technical Bullens.........................................................................................................62

8

9
Table of Contents connued...
MPC-5000 Programming & Controls…………………………………………………………………..67
Introducon.................................................................................................................. 69
MPC 5000 Operaon Guide .......................................................................................... 70
Display Controls ............................................................................................................ 71
Programming from the Display ..................................................................................... 74
Salinity Probe Calibraon.............................................................................................. 77
Wiring Schemac .......................................................................................................... 78
MPC 5000 PCB Fuses and Electrical Specicaons......................................................... 79
Exploded Views and Part Numbers………………………………………………………….………...81

10

11
Installaon

12

13
Unpack the system and inspect it for damage during shipping. Freight damage must be report-
ed to the carrier within 24 hours.
Refer to the shipping list for your system to ensure you received all of the components listed.
Do not discard any packaging unl you have found and idened all of the parts. The small
installaon parts are listed on the kit list.
Warning! We will not be held responsible for shortages that are not reported within thirty
days of the ship date.
Study the system layout diagram, component photos, and descripons before beginning in-
stallaon.
Lay out the system. Before starng the installaon idenfy where each module and compo-
nent will be placed. Ensure that there is enough clearance around the components for remov-
al of lters and system service. Make sure you have adequate tubing and hose before starng.
Addional parts may be ordered.
Geng Started
Catalina 340 Z Shipping List:
Catalina Feed Pump Module
10% Clark Pump and Reverse Osmosis Membrane Module
Boost Pump and Sea Strainer Module
Fresh Water Flush Module or Z-Ion
Service Kit
3/4-inch Black Spiral Sucon Hose (25 feet)
5/8-inch Vinyl Hose (25 feet)
3/4-inch Vinyl Hose (10 feet)
1/2-inch Vinyl Hose (25 feet) ed with Quick Connect Fing on
one end, and John Guest stem ng on the other end.
1/4-inch Black Product Tubing (25’)

14
Thank you for your purchase of a Spectra Catalina 340 Z system. Properly installed, it will provide
years of trouble free service. Please read through the installaon instrucons and the system lay-
out prior to installing. Like any piece of mechanical equipment, the system will require inspecon
and service from me to me. Plan for service access and place the components in accessible are-
as. If you are having a dealer install the system, review the locaon of the components to make
sure that the installaon will meet your approval upon compleon. The MPC 5000 automac con-
trol system adds programmability, automated operaon, and system monitoring. Prudent opera-
on is required with any marine equipment. Always maintain enough reserve water to get to your
next port safely.
Front View
Pressure Relief Valve
Double rubber mounts
to absorb vibraon
The Clark Pump Membrane Module is pre-mounted and plumbed together as a single unit to
save me and add reliability. This module must be installed in an area that maintains a tem-
perature below 120F (50C) and may be placed as high in the boat as you desire. Make sure
that the area around and under the pump does not have any water sensive equipment. Allow
access to the pressure relief valve. You may mount the Clark Pump in any posion, even up-
side down, but the salinity probe on the diversion valve manifold must always be down. Note:
If your machine is equipped with the oponal Z-Brane, see the instrucons on page 33 for in-
stalling the Z-Brane anodes. The anodes should be installed before installing the Clark Pump
membrane module.
Introducon to Catalina 340 Z Components
Quick disconnect
ng eases mainte-
nance.

15
Feed Pump Module: Mount the feed pump module on a
vercal surface, which can be up to 3feet (1.0M) above the
waterline. It is preferable to mount as low as possible. Lo-
cate in an area that allows easy access to the lter housing
and the le side of the enclosure. Place where water spills
during lter changes will not be a problem, and keep future
maintenance in mind. The feed pump has overheat protec-
on and will not operate properly at ambient temperatures
over 120F (48C).
Note: When plumbing the Catalina feed pump module, route the feed water hose so that the
front cover may be opened without removing the hose or tubing. All tubing connecons are made
using John Guest connectors, shown on page 22. Aer assembling all plumbing ngs, thorough-
ly check for leaks.
Feed Pressure Sensor
(red) measures pressure
aer the feed pump.
Boost pump voltage
booster.
Motor Speed Controller
Introducon to Components connued...
Absolute Pressure
Sensor (yellow)
measures boost pump
pressure.
MPC Control Box
Auto/Manual/Service
Toggle Switch
Pump
Motor
Mag Drive
Pump
Pre-lter
Loosen the thumb screws and fold out the front cov-
er of the feed pump module for access:

16
Sea Strainer and Boost Pump Module: Mount
close to the intake through-hull in a locaon
that can handle water spillage during service.
The boost pump cable will connect to the feed
pump module.
Z-Ion or Fresh Water Flush Module: The Z-Ion or fresh wa-
ter ush module (both contain the charcoal lter for fresh
water ushes, but the Z-Ion has added sterilizaon) may be
located in any convenient locaon near the feed pump
module. It should be mounted with the lter housing ver-
cal and accessible for changing lters, with 2” below the
housing for lter changes. Do not install over electrical
equipment. The unit contains the charcoal lter, a solenoid
shut o valve, and a ush water ow regulator. SEE PAGE
29 FOR Z-ION INSTALLATION AND INSTRUCTIONS.
Introducon to Components connued...
Remote Control Panel: Can be mounted anywhere that is dry
and convenient. Cut a 4-9/16” (116 mm) wide by 2-7/8” (68mm)
high opening for the panel. Take care when roung the cable so
the plugs on each end are not damaged. Use only Spectra ap-
proved remote cable. The cable is not a standard LAN cable or
phone cord.

17
Installaon Basics
 Read the direcons!
 Avoid ght hose bends and excessive runs.
 Use heavy gauge wire.
 Install feed pump module as low as possible.
 Boost pump module must be installed below the waterline.
 Use a dedicated thru-hull with scoop-type strainer.
 Do not mount components over electrical devices.
 Avoid geng dirt or debris into the piping or hoses during
assembly. A small bit of debris can stop the system!
Thru-hull Locaon: The system must be connected to a dedicated 3/4” to 1” forward-facing
scoop-type intake thru-hull and seacock.
Install the thru-hull intake as far below the waterline and as close to centerline as possible to
avoid contaminaon and air entering the system. Do not install the intake close to, or down-
stream of, a head discharge, behind the keel, stabilizer ns, or other underwater xtures.
Thru-hulls in the bow area are suscepble to air intake in rough condions. Sharing a thru-hull
can introduce unforeseen problems such as intermient ow restricons, air bubbles, contami-
nants, and will void the warranty. For racing boats and high speed boats traveling above 15
knots, a retractable snorkel-type thru-hull ng is preferred because it picks up water away
from the hull.
The brine discharge thru-hull should be mounted above the waterline, along or just above the
boot stripe, to minimize water li and back pressure.
Double clamp all hose connecons below the waterline.
Avoid restricons or long runs on the enre inlet side of the plumbing from the thru-hull to the
feed pump module.
Secure the piping away from moving objects such as engine belts and hatches. Prevent chafe on
the tubing as required. Test and inspect all piping and hose clamps aer several hours of opera-
on.
Pipe Fing Instrucons: To seal plasc-to-plasc ngs, wrap 6 to 8 layers of Teon tape over
their threads. Hold the ng in your le hand and ghtly wrap the threads clockwise. For
smoother assembly, do not tape the rst (starng) threads.
Wiring
 Pay aenon to wire size or system performance will be impaired
 Perform wiring to UL, ABYC, CE or applicable standards
Seawater Flow
Thru-hull
Not Supplied.

18
Use the supplied 3/4” (19mm) suc-
on hose (clear with black spiral)
from the inlet thru-hull to the boost
pump/sea strainer module, and from
the boost pump/sea strainer module
to the feed pump.
From the Clark pump brine discharge con-
nector use the supplied 5/8 (16 mm) clear
braided vinyl hose with Quick Connect
ng to the brine overboard ng.
Plumbing Schemac
Flush water from ship’s
pressure water system
25 psi (2bar) minimum
Use part of the 25-feet (8 meters)
of 1/2-inch vinyl hose, pre-ed
with a 1/2-inch John Guest stem
ng, to connect the feed pump
to the Clark Pump feed water inlet.
(see following pages)
Use the 1/2-inch vinyl hose with
the Quick Connect ng be-
tween the Z-Ion/fresh water
ush module and the top of the
sea strainer. (see following pag-
es)
The oponal Z-ION will re-
place the Fresh Water
Flush module

19
Plumbing Detail
Your system includes 25-feet of 1/2-inch vinyl hose with a Quick
Connect ng on one end and a 1/2-inch John Guest stem
ng on the other, both crimped on with ferrules. You will CUT
THIS HOSE and, using the ngs found in the installaon kit,
use one end for the feed water inlet hose and the other for
the fresh water ush hose:
Fresh Water Flush: Route a feed line from the domesc cold pressure water system to the
1/2-inch hose barb on the fresh water ush module. This needs to be pressurized when the
boat is unaended for the fresh water ush system to funcon properly. The domesc fresh
water pump must be able to deliver 1.5 gallons per minute (6 LPM) at 25 PSI (1.7 bar).
Aaching 1/2-inch vinyl hose to sea
strainer using the 3/8” John Guest
stem ng and hose clamp found in
installaon kit:
Aaching 1/2-inch vinyl hose to Z-Ion/
fresh water ush module with the pre-
ed Quick Connect ng:
Flush water from ship’s
pressure water system
25 psi (2bar) minimum
The oponal Z-ION will re-
place the Fresh Water
Flush module
From the intake sea cock to the sea strainer/boost pump module,
and from the sea strainer/boost pump module to the pre-lter
housing on the feed pump module, use the 3/4-inch black, spiral-
wound sucon hose:

20
Quick Disconnect Fing
Plumbing Detail connued...
Brine Discharge: Route the brine discharge from the quick disconnect ngs to a thru-hull
above the waterline using the supplied 5/8” braided vinyl hose and the male Quick Disconnect
ng from the installaon kit:
From the feed pump to the Clark Pump feed water inlet, use the remaining 1/2-inch vinyl hose,
with the 1/2-inch John Guest stem ng pre-ed with a ferrule. Insert the pre-ed end into
the feed pump (Figure 1), and the 1/2” John Guest stem ng and hose clamp from the instal-
laon kit for the Clark Pump feed water inlet (Figure 2). Refer to John Guest assembly instruc-
ons on page 22:
Figure 1: Figure 2:
