Spectra 1728/EX & 1738/EX - 1 - Programming Guide
1728EX, 1728, 1738EX AND 1738
SYSTEM PROGRAMMING GUIDE
Software Version 2.1
DEFAULT INSTALLER CODE
0000 / 000000 (see section [281] on page 17)
DEFAULT SYSTEM MASTER CODE
1234 / 123456 (see section [301] on page 17)
HOW DO I ENTER PROGRAMMING MODE?
ST EP 1: Pr ess [ ENTE R ]
ST EP 2: Enter yo u r [ IN ST A LL E R CODE ]
ST EP 3: En ter 3 -dig it [ SE CTION ] you wish to program
ST EP 4: En ter r eq ui re d [DATA]
DECIMAL AND HEXADECIMAL PROGRAMMIN G TABLE
TR OUB LE DI SPL AY
Press the [TBL]or [TRBL]key to view the Trouble Display. Please note that the keypad ca n be pr ogrammed to emit a BEEP
every 5 seconds whenever a new trouble condition has occurred. Press the [TBL]or [TRBL]key to stop the beeping.
[1] - No Battery or Low Battery [8] - Timer Loss**
[2] - Wireless Transmitter Low Battery [9] - Tamper or Zone Wiring Failure*
[3] - Power Failure [10] - Telephone Line Monito ring Failure
[4] - Bell Output Disconnected [11]/[STAY]- Fire Loop Trouble*
[5] - Maximum Bell Curr ent [12]/[BYP]- Module Loss
[6] - Maximum Auxiliary Current [13]/[MEM]- Wireless Transmitter Supervision Loss*
[7] - Communicator Report Failure [16]/[FORCE]and [TBL]/[TRBL]flashes - Keypad Fault
* press the illuminated key ([9], [STAY ] or [ME M]) to view which zones are causing the trouble. Enter the Installer Code to clear
Tamper troubles.
** press [8] to re-program the time.
Value or Action What Do I
Press?
What Do I See?
10-Zone LED 16-Zone LED LCD
Values 1 to 9 [1] to [9] [1] to [9] [1] to [9 ] [1] to [9 ]
A (hexa only) [0] [0 (10)][10] 0
B (hexa only) [ST A Y][STAY][11] B
C (hexa only) [BYP][BYP][12] C
D (hexa only) [MEM][MEM][13] D
E (hexa only) [TBL] / [ TRBL][TBL][14] E
F (hexa only) [PG ] / [FNC1][PG][15] F
Exit Without Saving [CLEAR][ENTER] flashes [ARM1] & [STAY 1] flash “SECTION [ ]”
Era se Cu rr en t Di git [FORC E]Displays next digit or next section
Save Data (hexa only) [ENTER]Advances to the next section

TABLE OF CONTENTS
Default Installer Code........................................................................................................... .. .. .. .. .. ... .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 1
Def ault Sys tem M ast er code ......................................................................................................................................................................... 1
How Do I Enter Programming Mode? ........................................................................................................................................................... 1
Decimal and Hexadecimal Programming Table.............................................................................................................................. .. .. .. .. .. .. .. 1
Trouble Display ............................................................................................................................................................................................. 1
Data Display Mode (LED Keypads Only) ...................................................................................................................................................... 3
Configuring The 1686H, 1686V and 1689 Keypads (v2.0 or higher)............................................................................................................ 3
Configuring The 1686H, 1686V and 1689 Keypads (prior to V2.0)............................................................................................................... 4
Zone Programming ....................................................................................................................................................................................... 4
System Timers..................................................................................................................... .. .. .. .. .. ... .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 6
Programmable Outputs................................................................................................................................................................................. 7
Sys tem Opt ions .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ........................................................................... 10
Com munic ation Sett ings .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..................................................................... 14
Report Codes..................................................................................................................... .. .. .. .. .. .. ... .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 15
System Settings ................................................................................................................... .. .. .. .. .. ... .. .... .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .... .. .. .. .. .. .. .. .. .. 17
User Code Options.................................................................................................................................. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 17
Reprogram ALL Modules ........................................................................................................... .. .. ... .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 18
Paradox Memory Key (PMC-3) ................................................................................................................................................................... 18
4-Output Bus Module V2.0 ................................................................................................................... 19
Printer Bus Module V2.0 ....................................................................................................................... 20
Voice-assisted Arm/Disarm Bus Module V2.0 ...................................................................................... 22
Wireless Bus Modules .......................................................................................................................... 23
Zone Expansion Bus Modules .............................................................................................................. 26
User Operation ..................................................................................................................................... 27
Appendix A - Ademco CID Report Code List (Prog.)............................................................................ 29
Appendix B - Ademco CID Report Code List (all Codes) ..................................................................... 30
Bus Module Connections ...................................................................................................................... 32
Hardware Connections ......................................................................................................................... 36
