SpectraLink 8400 Series Installation instructions

©2013 Spectralink 1
Durability and Performance
DISPLAY
• 2.2-inch240x320resolution
• 65,000colorpalette    

BUTTONS
• Four(4)context-sensitivesoftkeybuttons
• Push-to-Talk
• Five-waynavigationandselectcontrol
• Home&Backnavigationkeys
• Up/Downvolumecontrol
• Barcodereader(8452/8453handsets)
• StartandEndKeys
• Panic/Duress
STATUS LED
• Message(voicemail)waiting
• Outofcoverage
• Phoneringing
PERIPHERAL INTERFACES
• MicroUSBinterfaceforwallchargingandconguration
• 2.5mmconnectorforwiredheadset
• Bluetooth
BATTERIES
• Twoeasy-accesscosmeticbatterycapacityoptions
• Standard–Upto8hrstalktime,80hrsstandbytime
• Enhanced–Upto12hrstalktime,120hrsstandbytime
Spectralink 8400 Series
product specifications
TheSpectralink®8400VoWLANhandsetsdeliveronafundamentalneedforenterprise-gradeon-sitevoicemobility.Characterized
bymarket-leadingHDvoicequality,durability,andbroadtelephonyandWLANinteroperability,Spectralink8400handsetsdelivera
reliableuserexperienceandpredictablereturnoninvestment.
TheSpectralink8400seriesenhancesthecustomervaluepropositionthroughanoptionalintegratedbarcodescannerandan
enhancedstandards-basedapplicationsinterface.InpartnershipwiththeSpectralinkapplicationsdevelopmentecosystem,the
Spectralink8400productsenablenewopportunitiesforend-userproductivitysolutions.
physical characteristics

©2013 Spectralink 2
DURABILITY
• Drop/shock:MILSTD810F,method516.5procedureVI
• Ingressprotectionstandard:IP-64perIEC60529
• Rubberizedmolding
• MagnesiumLCDmounting
ENVIRONMENTAL
• Operationaltemperature:32Fto104F(0to40C)
• Storagetemperature:-22to140F(-30to60C)
DIMENSIONS & WEIGHT
SPECTRALINK
8440/8441
SPECTRALINK
8452/8453
Dimensions 147mmx53mmx
25mm
146mmx54mmx
34mm
Weight 5.1oz 5.7oz
Asmeasuredwithstandardbattery.
FRONT VIEW - ALL MODELS
Wi-Fi
BAND FREQUENCY DATA RATES
802.11a
5.15-5.25GHz
5.25-5.35GHz
5.47-5.725GHz
5.725-5.825GHz
6,9,12,18,24,36,
48,54Mbps
802.11b 2.4-2.4835GHz 1,2,5.5,11Mbps
802.11g 2.4-2.4835GHz 6,9,12,18,24,36,
48,54Mbps
802.11n* 2.4&5GHz 21.7,43.3,65,72.2
Mbps
2.4GHzand5GHzdynamicbandroamingsupported
*Single-stream,20MHzchannelwithSGI
Bluetooth Headset Support
• Version2.1,HSPVersion1.2
• Class1supportwithrangeof~10meters
physical characteristics Wireless NetWOrKiNG
spectralink 8440

©2013 Spectralink 3
Rich call server feature integration and
native Push-to-Talk
CALL HANDLING FEATURES*
• Upto6telephonelineappearances
• CallHold/Resumefunction
• LastCallReturn
• MusiconHold
• ConsultationHold
• CallTransfer(Attended,Unattended)
• Overlapdialing
• BridgedLineAppearance(BLA)
• Three-WayConferencing(local)
• Find-Mecallforking
• CallScreening(Incoming,Outgoing)
• AutomaticAnswer
• CallPark&Retrieve
• GroupCallPickup
• CallWaiting
• MultipleCallsperLine
• DoNotDisturb
• CallingpartyID(NameandNumber)
• CalledpartyID(NameandNumber)
• ConnectedpartyID(NameandNumber)
• CallForward(Busy,NoAnswer,Unconditional)
• CallReject
*Summary only – actual feature support will vary among call platforms
CODECS
• G.711(a-law,u-law),G.729,G.722,G.722.1
PUSH-TO-TALK (PTT)/PAGING
• On-boardnative‘walkie-talkie’capability
• One-to-one,one-to-manybroadcastcommunication
• 24congurablechannels
• Priority,defaultchannel
ADDITIONAL TELEPHONY FEATURES
• RTCP(RFC3550,RFC1889)
• Callserverredundancy
• Predictivedialingfromcontactslist
• Recentcalllists
Intuitive and user-friendly
USER PROFILES
• DownloadabletoanyhandsetwithIDandLogin
PERSONAL SAFETY
• Duress/Panicbutton
• Nomotion,running,tiltdetection
• Alarmnotications
ADDITIONAL
• IntuitiveGraphicalUserInterface
• Selectablewallpaper/background
• Adjustabledisplaybrightness
• Backlitkeypadwithadjustabletimeoutperiod
• Ten(10)selectableringtones
• Ten(10)selectablealerttones
• Multiplevibratecadenceoptions
• Vibrate-to-ringoptions
• Audibleandvibratenoticationoptions
• Speeddialmenulist
• Contactsdirectorywithsupportfor1000localentries
• Calllogs-Minimumof20loggedentriesforeachcalltype
(Incoming,dialed,andmissed)
• Emergencysystem-widespeeddial
• Auto-answer&anykeyanswercapability
• Selectableringtones
• UnicodeUTF-8MultilingualUserInterface
telephONy FeatUres UsaBility
SPECTRALINK
8440
SPECTRALINK
8441
SPECTRALINK
8452
SPECTRALINK
8453
Duress XXXX
Running X X
No
Motion X X
Tilt X X

©2013 Spectralink 4
Ease of provisioning, performance and fault
management
PROVISIONING
• ServerbasedcentralprovisioningviaFTP,FTPS,TFTP,
HTTPorHTTPS
• Centralizeduseradministration
• Provisioningandcallserverredundancy
• InitialcongurationviaUSB
• UnicodeUTF-8MultilingualUserInterface
PERFORMANCE AND FAULT MANAGEMENT
• On-boardsitesurveyanddiagnosticstools
• Enhancedsyslogreporting
• Roamingandhandoffreporting
• Eventlogging
• Hardwarediagnostics
• Statusandstatusreporting
• PINGsupport(initiateandresponse)
• Traceroute
CONFIGURATION MANAGEMENT
• Userandadministratorloginandprivileges
• PC-connected(USB)andremoteover-the-airconguration
management
Feature rich data applications interface options
XML APPLICATIONS PROGRAM INTERFACE
• Standards-basedXHTMLAPI
• On-boardWebKit-basedbrowser(JavaScript,CSS,DOM)
forrichapplicationsintegration
• CorporatedirectoryaccessLDAP
SPECTRALINK OPEN APPLICATION INTERFACE (OAI)
• BackwardcompatibilitywithSpectralinkOAIapplications
INSTANT MESSAGING
• Handset-to-handset,PCclient-to-handsetIMsupportvia
Microsoft®OCSand/orMicrosoftLync
REAL TIME LOCATION SERVICES (RTLS)
• EmbeddedRTLSbeacon(Ekahau)forlocationtracking
• AeroScout
CALENDAR - EXCHANGE SERVER INTEGRATION
• Dayandmonthview
• Meetingreminders
MaNaGeMeNt applicatiONs tOOls

©2013 Spectralink 5
Industry leading voice and call quality
AUDIO QUALITY
• TIA810B,TIA920audioqualitystandards
• Full-duplexaudio(compliantwithIEEE1329fullduplex
standards)
• Voiceactivitydetection(VAD)
• Comfortnoisell
• Adaptivejitterbuffer&packetlossconcealment
• Acousticechocancellation&backgroundnoise
suppression
QUALITY OF SERVICE (QOS)
• Wi-FiMultimedia(WMM)
• WMM-PowerSave
• WMM-AdmissionControl(draft)
• IEEE802.1p/Qtagging(VLAN)/DSCPtagging
SECURITY
• WEP,WPA-Personal,WPA2-Personal,WPA2-Enterprise
with802.1X(EAP-FAST,PEAP-MSCHAPv2)with
OpportunisticKeyCaching(OKC)andCiscoClientKey
Management(CCKM)
• MediaencryptionviaSecureReal-TimeProtocol(SRTP)
• SIPsignalingencryptionviaTransportLayerSecurity(TLS)
• Server-basedcongurationleencryption(AES128bit)
• HTTPSsecureprovisioning
• Supportforsignedsoftwareexecutables
perFOrMaNce NetWOrKiNG
Data captUre speciFicatiONs
Strong support for networking standards
• AddressassignmentviaManualorDynamichost
congurationprotocol(DHCP)
• DomainnameresolutionviaDomainNameService(DNS)
• TimeanddatesynchronizationusingSimpleNetworkTime
Protocol(SNTP)
• LightweightDirectoryAccessProtocol(LDAP)fordirectory
lookupanddownload
• IEEE802.1p/Qtagging(VLAN)/DSCPtagging
High-performance scanning

FEATURE SPECTRALINK 8452/8453
Type 1D/2DAreaImagers
LightSource 617nmHighlyVisibleLED(5)
ScanAngle 38.9°Horiz.,25.4°Vert.
Labelprint
contrast Downto25%
Resolution OpticalResolution
752x480pixels
Reading
distance Upto86cm(34in.)
BARCODE SYMBOLOGIES
• 1D:RSS,StackedRSS,RSS-14,GS1-DataBar,Code39,
Code93,Code128,UPC(E&A)
• 2D:Aztec,Codabar,Code11,Code39,Code93/93I,Code
128,GS1-128,ISBT8,Databar(RSS),Datamatrix,EAN13,
EAN8,Interleaved2of5,MicroPDF417,MSI,PDF417,
Plessey,QCcode,Telepen,UPCA,UPCE,UPC/EAN

©2013 Spectralink 6
Accessories that deliver mobile communication
solutions to the Enterprise
SPEAKERPHONE DOCK
• Dockingbaseprovidesfull-duplexHDVoicespeakerphone
andcharging
• Idealforsmallgroupconferencesettings
• Suitableforreplacementofadesktopphone
• Includeson-boardmute,volumeandspeakerphone
controls
• Wiredheadsetoptions
• Provideshandsetandsparebatterycharging
DUAL CHARGER
• Idealfordesktopusetoaugmentorreplaceadesktop
phone
• Provideshandsetandsparebatterycharging
QUAD CHARGER
• Chargesupto4sparebatterypackssimultaneously
• Idealforshift-workenvironmentsandhighly-mobileusers
• Designedfortabletoporwall-mounting
MULTI-CHARGER
•  Chargesupto12batterypackssimultaneously
•  Wallordeskmount
•  Idealformulti-shiftenvironment
accessOries
