Spektrum DX8e User manual

Instruction Manual
Bedienungsanleitung
Manuel d’utilisation
Manuale di Istruzioni
8e
8®
®
In
st
r
uct
i
o
n M
a
n
ua
l
Bedienungsanleitung
M
a
n
ue
l
d
’
ut
ili
sat
i
o
n
M
a
n
ua
l
e
d
i I
st
r
u
zi
o
n
i
®

2SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating.
Failure to operate the product correctly can result in damage to the product, personal property and cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic mechanical ability.
Failure to operate this Product in a safe and responsible manner could result in injury or damage to the product or other property. This
product is not intended for use by children without direct adult supervision. Do not attempt disassembly, use with incompatible compo-
nents or augment product in any way without the approval of Horizon Hobby, LLC. This manual contains instructions for safety, operation
and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in
order to operate correctly and avoid damage or serious injury.
WARNING AGAINST COUNTERFEIT PRODUCTS
Always purchase from a Horizon Hobby, LLC authorized dealer to ensure authentic high-quality Spektrum product. Horizon Hobby,
LLC disclaims all support and warranty with regards, but not limited to, compatibility and performance of counterfeit products or products
claiming compatibility with DSM or Spektrum technology.
NOTICE: This product is only intended for use with unmanned, hobby-grade, remote-controlled vehicles and aircraft. Horizon Hobby
disclaims all liability outside of the intended purpose and will not provide warranty service related thereto.
Age Recommendation: Not for Children under 14 years. This is not a toy.
WARRANTY REGISTRATION
Visit spektrumrc.com today to register your product.
NOTICE: While DSMX technology allows you to use more than 40 transmitters simultaneously, when using DSM2 receivers, DSMX
receivers in DSM2 mode or transmitters in DSM2 mode, do not use more than 40 transmitters simultaneously.
General Notes
• Models are hazardous when operated and maintained incorrectly.
• Always install and operate a radio control system correctly.
• Always pilot a model so the model is kept under control in all
conditions.
• Please seek help from an experienced pilot or your local
hobby store.
• Contact local or regional modeling organizations for guidance
and instructions about flying in your area.
• When working with a model, always power on the transmitter
first and power off the transmitter last.
• After a model is bound to a transmitter and the model is set
up in the transmitter, always bind the model to the transmitter
again to establish failsafe settings.
Pilot Safety
• Always make sure all batteries are fully charged before flying.
• Time flights so you can fly safely within the time allotted by
your battery.
• Perform a range check of the transmitter and the model
before flying the model.
• Make sure all control surfaces correctly respond to transmitter
controls before flying.
• Do NOT fly a model near spectators, parking areas or any
other area that could result in injury to people or damage to
property.
• Do NOT fly during adverse weather conditions. Poor visibility,
wind, moisture and ice can cause pilot disorientation and/or
loss of control of a model.
• When a flying model does not respond correctly to controls,
land the model and correct the cause of the problem.
All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-
date product literature, visit horizonhobby.com and click on the support tab for this product.
The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product:
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage and serious injury
OR create a high probability of superficial injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a possibility of serious injury.
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND little or no possibility of injury.
NOTICE
Meaning of Special Language

3SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
• DX8e Transmitter (SPMR8105)
• 4 – AA Alkaline cells with holder
• Manual
BEFORE USING YOUR TRANSMITTER
Before going any further, visit the Spektrum Community website at spektrumrc.com to register your transmitter and
download the latest Spektrum AirWare™ firmware updates. A registration reminder screen occasionally appears until
you register your transmitter. When you register your transmitter, the reminder screen does not appear again.
BOX CONTENTS
Support Videos:
For helpful videos on programming the DX8e and other Spektrum AirWare™ equipped transmitters, go to www.spektrumrc.com/
CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to state and local laws.
Failure to exercise caution while using this product and comply with the following warnings could result in product malfunction, electrical
issues, excessive heat, FIRE, and ultimately injury and property damage.
• NEVER LEAVE THE BATTERY AND CHARGER UNATTENDED DURING USE
• NEVER CHARGE BATTERIES OVERNIGHT
• Read all safety precautions and literature prior to use of this product
• Never allow minors to charge battery packs
• Never drop charger or batteries
• Never attempt to charge damaged batteries
• Never attempt to charge a battery pack containing different types of batteries
• Never charge a battery if the cable has been pinched or shorted
• Never allow batteries or battery packs to come into contact with moisture at any time
• Never charge batteries in extremely hot or cold places (recommended between 50–80˚ F or 10–27˚ C) or place in direct sunlight
• Always disconnect the battery after charging, and let the charger cool between charges
• Always inspect a new battery before charging
• Always terminate all processes and contact Horizon Hobby if the product malfunctions
• Always keep batteries and charger away from any material that could be affected by heat (such as ceramic and tile), as they can
get hot
• Always end the charging process if the charger or battery becomes hot to the touch or starts to change form (swell) during the
charge process
BATTERY AND CHARGING PRECAUTIONS AND WARNINGS

4SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
TABLE OF CONTENTS
Battery and Charging Precautions and Warnings .....................3
Box Contents..................................................................................3
Installing the Transmitter Batteries.............................................5
Installing Optional Lithium Ion Battery Pack..............................5
Charging the Lithium Ion Battery Pack.......................................5
Transmitter Functions...............................................................6–7
Main Screen ...................................................................................8
Navigation ......................................................................................8
Auto Switch Select...........................................................................8
SD Card...........................................................................................9
Installing the SD Card.......................................................................9
Registering the Transmitter with Spektrum .......................................9
Update Spektrum AirWare™Software.............................................10
Binding..........................................................................................11
Receiver Power System Requirements.....................................12
Recommended Power System Test Guidelines...............................12
European Union Receiver Requirements.........................................12
QuickConnect™Technology with Brownout Detection.....................12
How QuickConnect Technology
with Brownout Detection Works...................................................12
Programming Failsafe Positions................................................13
SmartSafe™Failsafe......................................................................13
Hold Last Command......................................................................13
Preset Failsafe...............................................................................13
Model Type Programming Guide................................................14
SYSTEM SETUP ............................................................................15
Model Select..................................................................................15
Model Type....................................................................................15
Model Name..................................................................................16
F-Mode Setup................................................................................16
Flight Mode Setup..........................................................................17
Channel Assignment......................................................................17
Channel Input Configuration...........................................................17
Trim Setup.....................................................................................18
Model Utilities ................................................................................18
Warnings.......................................................................................19
Telemetry......................................................................................20
Preflight Setup...............................................................................21
Frame Rate....................................................................................21
Bind...............................................................................................21
Digital Switch Setup.......................................................................23
System Settings...........................................................................24
User Name ....................................................................................24
Contrast.........................................................................................24
Backlight .......................................................................................24
Mode.............................................................................................24
Battery Alarm.................................................................................24
Selecting a Language ....................................................................25
Inactive Alarm................................................................................25
Extra Settings.................................................................................25
Serial Number................................................................................26
Exporting the Serial Number to the SD Card...................................26
Locating the Transmitter Spektrum AirWare Software Version.........26
Calibrate........................................................................................26
Transfer SD Card..........................................................................27
Import Model.................................................................................27
Export Model .................................................................................27
Update AirWare Software...............................................................28
FUNCTION LIST.............................................................................29
Servo Setup...................................................................................29
Travel Adjust ..................................................................................29
Sub-Trim .......................................................................................29
Reverse .........................................................................................29
Speed............................................................................................30
Balance .........................................................................................30
AS3X Gain Live View (ACRO and SAIL Types Only)..........................30
D/R & Exponential..........................................................................31
Differential (ACRO and SAIL Types Only).........................................31
Throttle Cut (ACRO and HELI Types Only)........................................31
Throttle Curve (ACRO and HELI Types Only)....................................31
Mixing ...........................................................................................32
Assigning a Mix to a Switch ...........................................................32
Back Mixing...................................................................................33
Range Test.....................................................................................33
Timer.............................................................................................33
Telemetry.......................................................................................34
System Setup ................................................................................34
Monitor..........................................................................................34
ACRO (AIRPLANE) ........................................................................35
Aircraft Type...................................................................................35
Recommended Servo Connections ................................................35
Icon...............................................................................................35
Elevon Servo Control......................................................................36
Flap System...................................................................................36
ACRO Mixing .................................................................................36
HELI (HELICOPTER) ......................................................................37
Swash Type ...................................................................................37
Collective Type...............................................................................37
Pitch Curve....................................................................................37
Swashplate....................................................................................38
Gyro ..............................................................................................38
Tail Curve ......................................................................................38
Mixing ..........................................................................................38
SAIL (SAILPLANE) ........................................................................39
Sailplane Type................................................................................39
Camber Preset ..............................................................................39
Camber System.............................................................................39
SAIL Mixing ...................................................................................40
V-Tail Differential............................................................................40
MULTI (MULTIROTOR) ..................................................................41
Multirotor Model Type ....................................................................41
F-Mode Setup................................................................................41
Trim Setup.....................................................................................41
D/R & Exponential..........................................................................41
Motor Cut ......................................................................................41
Motor Curve ..................................................................................41
PHYSICAL TRANSMITTER ADJUSTMENTS ................................43
Ratcheted Throttle –Smooth Throttle Adjustment ...........................43
Adjust Stick Tension.......................................................................43
Mode Change Slider ......................................................................44
Programming Conversion...............................................................44
Calibrating .....................................................................................44
TROUBLESHOOTING GUIDE..........................................................45
1-YEAR LIMITED WARRANTY .....................................................46
WARRANTY AND SERVICE CONTACT INFORMATION................47
FCC INFORMATION.......................................................................47
ANTENNA SEPARATION DISTANCE.............................................47
IC INFORMATION ..........................................................................47
FAA INFORMATION.......................................................................47
AMA NATIONAL MODEL AIRCRAFT SAFETY CODE ...................47
COMPLIANCE INFORMATION FOR THE EUROPEAN UNION.......48
Instructions for disposal of WEEE by users in the
European Union.........................................................................48

5SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
INSTALLING OPTIONAL LITHIUM ION BATTERY PACK
INSTALLING THE TRANSMITTER BATTERIES
1. Remove the battery cover from the back of the transmitter.
2. Remove the AA battery holder and disconnect from the
transmitter power port.
3. Remove the rectangular foam and flat foam from the battery
compartment.
4. Connect the battery pack (SPMA9602) to the transmitter
power port.
5. Install the optional Li-Ion battery pack into the transmitter.
6. Install the battery cover.
CAUTION: When installing a Li-Ion battery pack, always
set the battery chemistry to Li-Ion in the Systems Setting
screen and correctly set the low voltage alarm.
1. Remove the battery cover from the back of the transmitter.
2. Install the included 4 AA batteries into the battery holder.
3. Install the battery cover.
The optional Li-Ion battery has an internal charger designed to
quick charge at a rate of 0.5 amps. The charge port on the battery
is not polarity-dependent.
CAUTION: Never connect an external battery charger to
your DX8e transmitter.
Always charge the transmitter on a heat-resistant surface.
1. Power off your transmitter.
2. Connect the power supply (SPM9551) connector to the Li-Ion
charge port located under the rubber flap on the battery door.
3. Connect the power supply to a power outlet using the
appropriate adapter.
4. Disconnect the transmitter from the power supply once
charging is complete and disconnect the power supply from
the power outlet.
CAUTION: Never leave a charging battery unattended.
CAUTION: Never charge a battery overnight.
Battery Alarm
The System Settings Screen allows you to change the battery type
and low voltage alarm settings. See “System Settings” for more
information.
• An alarm will sound when the battery reaches the low voltage
limit (6.4V for LiPo/Li-Ion).
CAUTION: Never change the low voltage limit for
LiPo/Li-Ion batteries from 6.4V. Doing so could over-
discharge the battery and damage both battery and transmitter.
CHARGING THE LITHIUM ION BATTERY PACK

6SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
TRANSMITTER FUNCTIONS
Function
1LED
2Elevator Trim (Mode 2, 4)
Throttle Trim (Mode 1, 3)
3R Knob
4Switch H
5Switch G
6Switch F
7
Throttle Tension Adjustment
Throttle Ratchet Adjustment
(Mode 1, 3)
8
Throttle/Aileron Stick (Mode 1)
Elevator/Aileron Stick (Mode 2)
Throttle/Rudder Stick (Mode 3)
Elevator/Rudder Stick (Mode 4)
Function
9Left/Right Gimbal Stick
Tension Adjustment
10 Up/Down Gimbal Stick
Tension Adjustment
11 Aileron Trim (Mode 1, 2)
Rudder Trim (Mode 3, 4)
12 Neck Strap Mount
13 Scroll wheel
14 LCD
15 Buzzer Grill
16 Back Button
17 Clear Button
18 Rudder Trim (Mode 1, 2)
Aileron Trim (Mode 3, 4)
Function
19
Throttle Tension Adjustment
Throttle Ratchet Adjustment
(Mode 2, 4)
20
Elevator/Rudder Stick (Mode 1)
Throttle/Rudder Stick (Mode 2)
Elevator/Aileron Stick (Mode 3)
Throttle/Aileron Stick (Mode 4)
21 Left/Right Gimbal Stick
Tension Adjustment
22 Up/Down Gimbal Stick
Tension Adjustment
23 Switch D
24 Switch B
25 Switch A
Function
26 Switch C
27 Bind/Switch
28 Elevator Trim (Mode 1, 3)
Throttle Trim (Mode 2, 4)
29 On/Off Switch
30 Antenna
The transmitter comes with a
thin, clear plastic film applied to
some front panels for protection
during shipping. Humidity and
use may cause this film to come
off. Carefully remove this film as
desired.
1
5
6
2
4
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
24
23
26
27
28
29 30
3
25

7SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
TRANSMITTER FUNCTIONS
Powering the DX8e On and Off
1. Press the power button to turn on the DX8e.
2. Press and hold the power button for about 4 seconds to power
off the DX8e.
Function
1Bind Button
2Switch A
3Handle
4Mode Change Slider
5SD Card Opening
Function
6Charge Port for Use w/
Optional Lithium Ion Battery
7Battery Cover
8Mode Change Door
9Antenna Rotation Tension
1
3
4
5
6
7
8
9
2

8SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
• Scroll the scroll wheel to move through the screen content or
change programming values. Press the scroll wheel to make
a selection.
• Use the Back button to go to the previous screen (for example,
to go from the Mixing Screen to the Function List).
• Use the Clear button to return a selected value on a screen to
the default setting.
• Direct Model Access enables you to access the Model Select
screen without powering off the transmitter. Anytime the
transmitter power is on, press the Clear and Back buttons to
access the Model Select screen.
• Press and hold the scroll wheel while powering on the
transmitter to show the System Setup list. No radio
transmission occurs when a System Setup screen is
displayed, preventing accidental damage to linkages and
servos during changes to programming.
• At the main screen you can scroll to view the servo monitor.
• The Main Screen appears when you power on the transmitter.
Press the scroll wheel once to display the Function List.
• When you want to change a value in a screen for a particular
control position, move the control to the desired position to
highlight the value you want to change, such as 0/1/2, up/
down or left/right.
Enter, Choose
or Exit
Move between
options or change
value in an option
Hold for 3
seconds and
release to move to
the Main Screen
Scroll HoldPress
Tip: The tick mark below shows the current switch position.
Rolling and clicking the scroll wheel turns the selected box black,
indicating that the value or condition will act on that position.
MAIN SCREEN
NAVIGATION
Auto Switch Select
To easily select a switch in a function, such as a program mix,
roll with the scroll wheel to highlight the switch selection box, and
press the scroll wheel. The box around the switch should now
flash. To select a switch, toggle the switch you wish to select.
Verify the switch selection is now displayed as desired. When
correct, press the scroll wheel to select this switch and complete
the switch selection.
Function
AModel Name
DSMX/DSM2 If not shown, this indicates not bound
Displays throttle position
DDigital Battery Voltage (an alarm sounds and the screen flashes
when battery charge gets down to 6.4V for a LiPo/Li Ion battery.)
EModel Avatar
FElevator Trim (Mode 2, 4)
Throttle Trim (Mode 1, 3)
GAileron Trim (Mode 1, 2)
Rudder Trim (Mode 3, 4)
HModel Memory Timer
Function
IRudder Trim (Mode 1, 2)
Aileron Trim (Mode 3, 4)
JThrottle Trim (Mode 2, 4)
Elevator Trim (Mode 1, 3)
KTimer
E
D
B C
J
K
A
F
GI H
B
C

9SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
Installing an SD Card
An SD Card (not included) enables you to:
• Import (copy) models from any compatible* Spektrum
AirWare™ transmitter
• Export (transfer) models to any Spektrum AirWare transmitter*
• Update Spektrum AirWare software in the transmitter
• Install/Update sound files
• Back up models for safe keeping
To install or remove a SD Card:
1. Power off the transmitter.
2. Remove the battery door.
3. Press the SD Card into the card slot with the card label facing
up as shown.
Registering the Transmitter with Spektrum
Exporting the transmitter serial number to the SD Card allows you
to upload the serial number directly into the registration screen at
www.spektrumrc.com.
To export the serial number:
1. Press and hold the scroll wheel while powering the
transmitter on until the System Setup list appears.
2. Scroll to the System Settings menu. Press the scroll wheel
once to open the menu.
3. Select NEXT on the System Settings and Extra Settings
screens.
4. When the Serial Number screen appears, select EXPORT.
5. Power off the transmitter and remove the SD Card from the
transmitter.
To Upload the serial number to www.spektrumrc.com:
1. Insert the SD Card in your computer and check the contents
of the SD card on your computer for a “My_DX8e.xml” file.
2. In your favorite browser navigate to www.spektrumrc.com and
find the Product Registration link on the top of the page as
shown.
3. If you do not already have an account, create one now. If you
have an account login in with your secure login.
4. Once logged in go to the “My Spektrum” page. Fill out all
relevant information. Once you select your transmitter model
from the pull down menu you will be asked to upload the serial
number.
5. Click on the Select button to navigate to the “My_DX8e.xml”
file on the SD card that is in your computer’s SD card reader
and select the file.
6. Click on the Upload from xml file... button and the serial
number will populate into the Serial Number fields.
7. Click REGISTER at the bottom of the screen to finish register-
ing your new Spektrum Transmitter.
Alternately you can copy the serial number from the .xml file
and paste directly into the Serial Number field.
SD CARD
*iX12, DX20, DX18t, DX18SE, DX18G2, DX18G1, DX18QQ, DX9Black, DX9, DX10t, DX8G2, DX7G2, DX6G3, DX6e and DX6G2
Screen shots from www.spektrumrc.com are correct at time of
printing but may change at a future date.

10 SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
SD CARD
Update Spektrum AirWare™ Software
NOTICE: The orange LED Spektrum bars flash and a status bar
appears on the screen when Spektrum AirWare software updates
are installing. Never power off the transmitter when updates are
installing. Doing so may damage the system files.
NOTICE: Before installing any Spektrum AirWare files, always
Export All Models to an SD Card separate from the SD Card
containing the update. The update may erase all model files.
For more information on Spektrum AirWare software updates, visit
www.spektrumrc.com
Automatically Installing Spektrum AirWare Software Updates
1. Go to www.spektrumrc.com. Under the Setups/Updates pull
down tab, select the Firmware Updates link (shown).
2. Log into your Spektrum account.
3. Find your registered transmitter in the MY PRODUCTS list and
click on Download Updates. Follow directions on the screen
for downloading the update to an SD card through your
computer.
4. Eject the SD card from the computer.
5. Make sure the transmitter is powered off and install the SD
card into the transmitter.
6. Power on the transmitter and the update automatically
installs in the transmitter.
Manually Installing Spektrum AirWare Software Updates
1. Save the desired Spektrum AirWare version to an SD Card.
2. Install the SD card into the transmitter.
3. Select Update Firmware in the SD Card Menu options. The
Select File screen appears.
4. Select the desired Spektrum AirWare version from the File
List. When updates are installing, the transmitter screen is
dark. The orange LED Spektrum bars flash and the update
status bar appears on the screen.
NOTICE: Do not power off the transmitter when updates are
installing. Doing so will damage the transmitter.
Screen shots from www.spektrumrc.com are correct at time of
printing but may change at a future date.

11SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
BINDING
Binding is the process of programming the receiver to recognize the GUID (Globally Unique Identifier) code of a single specific transmitter.
You must bind the receiver to your transmitter before it will operate.
Binding Using the Receiver and Receiver Battery
Binding Using the Receiver and ESC
1. Lower throttle to the lowest position and make sure the
transmitter is powered off.
2. Insert the bind plug into the BIND/DATA port.
3. Insert the receiver battery into ANY open port. The receiver’s
LED will flash when the receiver is ready to bind.
4. While pressing the Bind button, power on the transmitter.
5. Release the Bind button after the receiver has stopped
flashing rapidly, once the receiver’s LED stays illuminated; this
indicates the receiver is bound to the transmitter. The screen
also provides binding information.
6. Remove the bind plug from the receiver.
1. Lower the throttle to the lowest position and make sure the
transmitter is powered off.
2. Insert the bind plug into the BIND/DATA port.
3. Insert the ESC plug into the THRO port.
4. Connect the battery to ESC and turn on the ESC switch,
if available. The receiver’s LED will flash rapidly when the
receiver is ready to bind.
5. While pressing the Bind button, power on the transmitter.
6. Release the Bind button after the receiver’s LED stays
illuminated. This indicates the receiver is bound to the
transmitter. The transmitter screen also provides binding
information.
7. Remove the bind plug from the receiver.
2
5
3
6
1
5
2
6
3 4
7
1
4

12 SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
RECEIVER POWER SYSTEM REQUIREMENTS
Inadequate power systems that do not provide the necessary
minimum voltage to the receiver during flight have become the
number one cause of in-flight failures. Some of the power system
components that affect the ability to properly deliver adequate
power include:
• Receiver battery pack (number of cells, capacity, cell type,
state of charge)
• The ESC’s capability to deliver current to the receiver in
electric aircraft
• The switch harness, battery leads, servo leads, regulators etc.
The AR8010T has a minimum operational voltage of 3.5 volts; test
the power system per the guidelines below.
Recommended Power System Test Guidelines
If you are using a questionable power system, (e.g. a small or old
battery, an ESC that may not have a BEC that will support high-
current draw, etc.), perform the following test with a voltmeter. The
Hangar 9®Digital Servo and Receiver Current Meter (HAN172) or
the Spektrum Flight Log (SPM9540) work well for this test.
Connect the voltmeter to an open channel port in the receiver and,
with the system on, load the control surfaces (apply pressure with
your hand) while monitoring the voltage at the receiver. The voltage
should remain above 4.8 volts, even when all servos are heavily
loaded.
CAUTION: When charging Ni-MH batteries, make sure
the battery fully charges. Ni-MH batteries charged with
peak detection fast chargers have a tendency to false peak
(i.e. not fully charge), which could lead to a crash.
QuickConnect™ Technology with Brownout Detection (DSM2 Only)
The AR8010T features QuickConnect technology with Brownout
Detection.
• Should an interruption of power occur (brownout), the system
will reconnect immediately when power is restored.
• The LED on the receiver will flash slowly, indicating a power
interruption (brownout) has occurred.
• Brownouts can be caused by an inadequate power supply
(weak battery or regulator), a loose connector, bad switch,
inadequate BEC when using an electronic speed controller,
etc.
• Brownouts occur when the receiver voltage drops below
3.5 volts. This interrupts control, as the servos and receiver
require a minimum of 3.5 volts to operate.
How QuickConnect Technology with Brownout Detection Works
• When the receiver voltage drops below 3.5 volts, the system
drops out (ceases to operate).
• When power is restored, the receiver immediately attempts to
reconnect to the last two frequencies it was connected to.
• If the two frequencies are present (the transmitter was left
on), the system reconnects typically in about 4/100 of a
second.
QuickConnect with Brownout Detection is designed to allow you
to fly safely through most short duration power interruptions.
However, you must correct the cause of these interruptions before
your next flight to prevent a crash.
CAUTION: If a brownout occurs in flight, determine the
cause of the brownout and correct it before attempting
to fly again.
EU versions of the DX8e are not compatible with DSM2®receivers.
Make sure all receivers are DSMX®compatible.
European Union Receiver Requirements

13SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
You establish failsafe positions when you bind your transmitter
and receiver. If the radio signal connection is lost between the
transmitter and receiver, the receiver immediately moves the
aircraft control surfaces to the failsafe positions. If you assign the
receiver THRO channel to a transmitter channel other than throttle,
we recommend using Preset failsafe with the throttle in the low
position.
NOTICE: Failsafe features vary according to receiver. Always
consult the receiver instruction manual for failsafe features.
Before flight, ALWAYS confirm the failsafe functions as you would
expect.
SmartSafe™ Failsafe
SmartSafe failsafe is a technology that only acts on the throttle
channel and offers the following benefits:
• Prevents electric motors from operating when the receiver
power is on and the transmitter power is off.
• Prevents the speed controller from arming until the throttle is
moved to the low throttle position.
• Powers off an electric motor and reduces gas/glow engines to
idle if signal is lost.
To Program SmartSafe, move the throttle to the low or off position
before putting the transmitter into bind mode.
To Test the SmartSafe failsafe:
1. Power the transmitter and receiver on.
2. Power off the transmitter. The throttle should immediately
move to the failsafe position.
CAUTION: Make sure the aircraft is fully restrained on
the ground. If the failsafe is not set correctly, your aircraft
might advance to mid or full throttle.
Hold Last Command
The Hold Last Command failsafe maintains the last command on
all channels except throttle. If the radio signal is lost, the aircraft
maintains the commanded control inputs until the receiver regains
signal.
To program Hold Last Command, follow the provided binding
instructions in this manual.
To Test Hold Last Command:
1. Power on the transmitter and receiver.
2. Move one of the control sticks to the desired Hold Last
Command position and hold the input.
3. While holding the control input (for example, a small amount
of rudder) power off the transmitter. The rudder should
maintain the input command.
CAUTION: Make sure the aircraft is fully restrained on
the ground. If the failsafe is not set correctly, the aircraft
throttle might advance to mid or full throttle.
Preset Failsafe
The Preset failsafe moves all channels to their programmed
failsafe positions.
We recommend using Preset failsafe to deploy spoilers on sail-
planes to prevent a flyaway if the radio signal is lost.
To program Preset failsafe:
1. Insert the bind plug in the bind port on the receiver and power
on the receiver.
2. Remove the bind plug when the orange LED on the main
receiver and all attached remote receivers flash rapidly. The
orange receiver LEDs will continue flashing.
3. Move the transmitter control sticks and switches to the
desired Preset failsafe position. Power the transmitter on.
4. Failsafe programming is complete when the orange LEDs on
the transmitter and all receivers turn solid.
CAUTION: Make sure the aircraft is fully restrained on
the ground. If the failsafe is not set correctly, the aircraft
throttle might advance to mid or full throttle.
PROGRAMMING FAILSAFE POSITIONS
IMPORTANT: Not all receivers support Preset Failsafe. Consult
your receiver manual for more information.

14 SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
MODEL TYPE PROGRAMMING GUIDE
Menu options show up on model type selection. These menu options vary between Model Types (Airplane, Helicopter,Sailplane and
Multirotor), but are identical for all models in that type. Subsequent aircraft type (Aircraft, Swashplate,Sailplane or Multirotor) selections
make other menu options appear.
System Setup List:
Model Select
Model Type
Model Name
Aircraft Type
F-Mode Setup
Spoken Flight Mode
Channel Assign
Trim Setup
Model Utilities
Warnings
Telemetry
Preflight Setup
Frame Rate
Bind
Trainer
Digital Switch Setup
Sound Utilities
System Settings
Function List:
Servo Setup
D/R and Expo
Differential
V-Tail Differential
Throttle Cut
Throttle Curve
AS3X Gains
Flap System
Mixing
Range Test
Timer
Telemetry
Custom Voice Setup
System Setup
Monitor
System Setup List:
Model Select
Model Type
Model Name
Swashplate Type
F-Mode Setup
Spoken Flight Mode
Channel Assign
Trim Setup
Model Utilities
Warnings
Telemetry
Preflight Setup
Frame Rate
Bind
Trainer
Digital Switch Setup
Sound Utilities
System Settings
Transfer SD Card
Function List:
Servo Setup
D/R and Expo
Throttle Cut
Throttle Curve
Pitch Curve
Swashplate
Gyro
Tail Curve
Mixing
Range Test
Timer
Telemetry
Custom Voice Setup
System Setup
Monitor
System Setup List:
Model Select
Model Type
Model Name
Aircraft Type
F-Mode Setup
Spoken Flight Mode
Channel Assign
Trim Setup
Model Utilities
Warnings
Telemetry
Preflight Setup
Frame Rate
Bind
Trainer
Analog Switch Setup
System Settings
Model Utilities
Transfer SD Card
Function List:
Servo Setup
D/R and Expo
Throttle Cut
Throttle Curve
Pitch Curve
Camera Gimbal
Motor Cut
Motor Curve
Mixing
Sequencer
Range Test
Timer
Telemetry
Custom Voice Setup
System Setup
Monitor
System Setup List:
Model Select
Model Type
Model Name
Sailplane Type
F-Mode Setup
Spoken Flight Mode
Channel Assign
Trim Setup
Model Utilities
Warnings
Telemetry
Preflight Setup
Frame Rate
Bind
Trainer
Digital Switch Setup
Sound Utilities
Function List:
Servo Setup
D/R and Expo
Differential
V-Tail Differential
Throttle Cut
Motor Curve
AS3X Gains
Camber Presets
Camber System
Mixing
Range Test
Timer
Telemetry
Custom Voice Setup
System Setup
Monitor

15SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
Press and hold the scroll wheel while powering on the transmitter to show the System Setup list. No radio transmission occurs when a
System Setup screen is displayed, preventing accidental damage to linkages and servos during changes to programming.
You can also enter the System Setup from the Function list without turning the transmitter off. A Caution screen will appear that warns
that RF will be disabled (the transmitter will no longer transmit). Press YES if you are sure and want to access the System List. If you are
not sure, press NO to exit to the main screen and continue operation.
If you do not press YES or NO, the system will exit to the main screen and continue operation within approximately 10 seconds.
WARNING: Do not press YES unless the model is turned
off or the model is secured.
Model Select enables you to access any of the 250 internal model
memory locations in the Model Select list.
1. Scroll to the desired model memory in the Model Select list.
2. When the desired model memory is highlighted, press the
scroll wheel once to select the model. The transmitter returns
to the System Setup List.
3. Add a new model by rolling to the bottom of the list. You will
then be prompted with the Create New Model screen, with
the option to create a new model or cancel. If you select
Cancel, the system will return to the Model Select function. If
you select Create, the new model will be created and now be
available in the model select list.
Direct Model Access
Press the Clear and Back buttons from the Main Screen or a
telemetry screen to access Model Select.
SYSTEM SETUP
Select from Airplane, Helicopter, Sailplane or Multicopter model
types.
IMPORTANT: When you select a new model type, you will delete
any programming data in the current model memory. Always
confirm the desired model memory before changing model
types. It will be necessary to re-bind after resetting the model
type.
To change the model type:
1. Scroll to the desired model type and press the scroll wheel.
The Confirm Model Type screen appears.
2. Select Yes and press the scroll wheel to confirm the model
type. All data will be reset. Selecting No will exit the Confirm
Model Type screen and return to the Model Type screen.
Model Select
Model Type

16 SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
Use the Flight Mode Setup menu to assign switches to
flight modes.
Sailplane Flight Mode Setup
You can assign up to five flight modes using any combination of
up to two switches. You can also assign a priority switch. When
the priority switch position is active, only the current flight mode
is active, regardless of other switch positions.
Sailplane Flight Mode Table
You can assign the available flight modes (up to 5 for Sail) to each
of the switch positions (up to 2 switches can be used for sailplane).
Press NEXT from the Flight Mode Name page to access the flight
mode table assignment page when Custom flight mode has been
selected in the Flight Mode Setup page. The combination of up to
2 switches can be used to access all of the flight modes available.
Number
of Flight
Modes
2 3 3* 4 4 5
Switch 1
(number of
positions)
2P 3P 2P 2P 3P 3P
Switch 2
(number of
positions)
2P 3P 2P 3P
Flight
Mode
1
Launch Launch Launch Launch Launch Launch
2 Cruise Cruise Cruise Cruise Cruise Cruise
3 Land Land Land
4 Thermal Thermal Thermal Thermal
5 Speed Speed
*Must be set up in a 4/5 flight mode.
Model Name enables you to assign a custom name to the current
model memory. Model names can include up to 20 characters,
including spaces.
To add letters to a Model Name:
1. Scroll to the desired letter position and press the scroll wheel
once. A flashing box appears.
2. Scroll left or right until the desired character appears. Press
the scroll wheel once to save the character.
3. Scroll to the next desired letter position. Repeat Steps 1 and
2 until the Model Name is complete. Insert a character by
selecting <+> or delete a character by selecting <->.
4. Select BACK to return to the System Setup list.
To erase a character:
1. Press CLEAR while the character is selected.
2. Press CLEAR a second time to erase all characters to the
right of the cursor.
Aircraft Type 4This menu only available in Airplane Mode. See ACRO (Airplane) section for set up.
Sailplane Type 4This menu only available in Sailplane Mode. See SAIL (Sailplane) section for set up.
Swash Type 4This menu only available in Helicopter Mode. See HELI (Helicopter) section for set up.
Aircraft Options 4This menu only available in Multirotor Mode. See MULTI (Multirotor) section for set up.
SYSTEM SETUP
Model Name
F-Mode Setup
Mode Number of Switches Number of Flight Modes
ACRO 2 5
HELI 3 (including Throttle Hold) 5(including Throttle Hold)
SAIL 3 10
MULTI 2 5

17SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
Enables you to assign custom names to the Flight Mode positions.
Flight Mode names can include up to 20 characters, including
spaces.
To change the Flight Mode name:
1. Scroll to the Flight Mode name you wish to change and press
the scroll wheel.
2. Scroll to the character position you wish to change and press
the scroll wheel once. A flashing box appears.
3. Scroll left or right until the desired character appears. Press
the scroll wheel once to save the character. Insert a character
by selecting <+> or delete a character by selecting <->.
4. Repeat Steps 2 and 3 until the Model Name is complete.
5. Select BACK to return to the Flight Mode Names list.
The Channel Assignment function allows you to reassign almost
any receiver channel to a different transmitter channel. For
example, the receiver gear channel could be re-assigned to the
transmitter throttle channel.
1. Scroll to the receiver channel you wish to change.
2. Press the scroll wheel once and scroll left or right to change
the receiver input selection.
3. Press the scroll wheel a second time to save the selection.
IMPORTANT: You cannot assign a mix to a channel that has
been moved. Create the mix first, then move the channel.
The Channel Input Configuration screen enables you to assign a
transmitter channel to a different control stick or switch.
1. Select NEXT on the RX Port Assignments screen to access
the Channel Input Configuration screen.
2. Scroll to the transmitter channel you wish to re-assign and
press the scroll wheel. The box around the current input
selection flashes.
3. Scroll left or right to select the desired control stick or switch.
4. Press the scroll wheel to save the selection.
SYSTEM SETUP
Flight Mode Setup
Channel Assignment
Channel Input Configuration

18 SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
In the Model Utilities function you can create a new model, delete
a model, copy a model, reset a model to default settings and sort
the model list.
Use the Trim Setup screen to change the size of the trim step and
the trim type.
Trim Step
Adjusting the trim step value determines how many “clicks” of trim
you input each time you press the trim button. Changing the trim
step value to 0 disables the trim for the channel.
To change the trim step value:
1. Scroll to the trim step channel you wish to change.
2. Select the trim step value and scroll left or right to change
the value.
3. Press the scroll wheel to save the selection.
Trim Type
The two Trim Type options are Common and F Mode.
Common trim type maintains the same trim values for all flight
modes.
F Mode trim type enables you to save trim values for individual
flight modes if you find, for example, the aircraft requires aileron
trim in Flight Mode 1 but not in Flight Mode 2.
Trim Assignment
In a few instances, you can reassign a trim to a different
location.
Aircraft Model Type
Throttle
• Throttle Digital trim button (default)
Throttle Trim Type
• Common
• Flight Mode
Trim Location
Normal and Cross trim types are available. Normal trims align with
the control stick; for example, the throttle trim is next to the throttle
stick.
Cross trims reverse the position of the trims; for example, the
throttle trim is next to the elevator stick and vice versa.
To change the Trim Position from Normal to Crossed, select Normal
at the bottom of the Trim Setup screen and press the scroll wheel.
IMPORTANT: Crossed trims will cross both sets of trims for both
gimbals.
Use this selection to create a new model in the model select list.
1. Select Create New Model. Within this screen, you will have
the option to create a new model or cancel.
2. If you select Cancel, the system will return to the Model
Select function.
3. If you select Create, the new model will be created and now
be available in the model select list.
SYSTEM SETUP
Trim Setup
Model Utilities
4Create New Model
Use this selection to permanently delete a model from the model
select list. If you do not wish to delete a model, select Cancel to
exit the page.
1. To delete a model, highlight the model listed. Press to select,
then roll to the model name. Press the scroll wheel to select.
2. Select DELETE to delete the model.
4Delete Model

19SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
The Model Copy menu enables you to duplicate model
programming from one Model List location to another.
Use Model Copy to:
• Save a default model copy before experimenting with
programming values
• Expedite programming for a model using a similar
programming setup
IMPORTANT: Copying a model program from one model
memory to another will erase any programming in the “To”
model memory.
To copy model programming:
1. Make sure the model program you wish to copy is active. If
the desired model program is not active, select Cancel and
change the active model in the Model Select menu.
2. Select the model memory next to “To” and scroll to the
desired model memory. Press the scroll wheel once to save
the selection.
3. Select Copy and the Confirm Copy screen appears.
4. Select Copy to confirm. Selecting Cancel will return to the
System Setup screen.
5. Select the “To” model as the current model, then bind the
transmitter and receiver. Copying a model does not copy the
bind from the original model.
You cannot use the Model Copy screen to copy model
programming to an SD Card. To copy model programming to the
SD Card, please see “Transfer SD Card”.
Use the Model Reset menu to delete all model programming in
the active model memory. Reset returns all model settings to the
default settings and erases all programming in the selected model.
After a model reset, it is necessary to re-bind.
With this function you can sort the model order in the model select
function. This is helpful to group similar models together to make
them easy to find. To move a model, highlight the model that you
wish to move with the scroll wheel, then press the scroll wheel to
select it. Scroll the scroll wheel to move the selected model to the
position desired. Press the scroll wheel when you have the model
in the position desired.
The Warnings menu enables you to program a voice, tone or
vibration alert during power on of the transmitter for any selected
switch or channel position.
The alarm activates and an alert message appears on the screen if
a specific switch or control stick is in an unsafe position when you
power the transmitter on.
Return the switch or control stick to the safe position to silence the
alarm.
For safety reasons, the default throttle alarm activates if the
throttle position is above 10%.
SYSTEM SETUP
Warnings
4Copy Model
4Sort Model List
4Model Reset

20 SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
TELEMETRY
Installing the optional telemetry module and sensors enables the
display of aircraft performance data on the transmitter screen.
You can also enable Data Logging to save a telemetry file on the SD
Card and view the data in the Spektrum STiTM mobile application.
Display
Telemetry display options include:
Tele: When you press the scroll wheel, the Telemetry screens
appear and the Main Screen is disabled.
Main: Telemetry alerts appear on the Main screen, but all
Telemetry screens are disabled.
Roller (Default): Allows you to toggle between the Telemetry
screens and the main screen by pressing the
scroll wheel.
Auto: The Telemetry screen automatically appears as soon as
the transmitter receives data from the telemetry module.
Units
Scroll to Units and press the scroll wheel to change between US
and Metric.
IMPORTANT: The Auto-Config option is not available from the
System Setup>Telemetry menu. RF signal must be transmitting
when you use the Auto-Config option. When the System Setup
menu is active, RF signal is off.
The DX8e transmitter features telemetry Auto-Configuration,
allowing the transmitter to detect new telemetry sensors.
To use Telemetry Auto-Config:
1. Make sure all telemetry components are bound to the
transmitter and receiver.
2. Power on the transmitter, then power on the receiver.
3. Select Telemetry from the Function List, then select Auto
Config. “Configuring” flashes for 5 seconds and any new
sensors appear in the list.
4. Adjust the sensor alert values as necessary.
Status Reports:
Status Reports determines how often the transmitter refreshes
the data on the screen. Each telemetry sensor can be adjusted
independently.
For example, the RPM status report can refresh every 10 seconds
while the altimeter sensor refreshes every 15 seconds.
Warning Reports:
Warning Reports determines how often a telemetry alert occurs,
if an alert is active.
SYSTEM SETUP
When using an AS3X receiver (AR636, AR6335, AR9350, etc.),
AS3X Live Gain View allows:
• Real time display of gain values for Roll, Pitch and Yaw
• Gains to be adjusted from the roller
• Selection of the channel that is used to adjust gains (must
match application)
• Selection of the switch that is used to change flight modes
To activate AS3X Gain Live View:
1. Enter the Telemetry screen from either the Function List or the
System Setup list.
2. Scroll to the desired “Empty” channel to use for gain
adjustment.
3. Press and scroll to select AS3X. The AS3X Gain menu is now
available in the Function List.
4Telemetry Settings
4Telemetry Auto-Configuration
4AS3X Gain Live View (ACRO and SAIL Types Only)
