Spirax Sarco PN9400E Series Instruction manual

Local regulations may restrict the use of this product to below the conditions quoted.
In the interests of development and improvement of the product, we reserve the right to change the specification without notice. © Copyright 2018
Page 1 of 3
Description
The PN9400 series are a compact range of linear pneumatic
actuators. They have been designed for matching the requirements
of valves at various differential pressures. Each actuator is fitted
with a mechanical travel indicator and incorporates a fully-rolling
diaphragm, which provides good linearity over the operating stroke.
Available types and options
See the 'PN9400 series selection guide' on page 2, to fully
understand the product nomenclature quoted throughout this
document.
PN9400 Series Pneumatic Actuators
for Spira-trolTM
K and L Series DN125 - DN300, C Series and QL Series
Technical data
Temperature range -20 °C to +80 °C
Maximum operating inlet pressure 4 bar g
Air supply connection 2 x ½" NPT
Actuator travel 80 mm
PN9400 Series with handwheelPN9400 Series
TI-P357-31
CTLS Issue 6

Page 2 of 3
PN9400 Series Pneumatic Actuators for Spira-trolTM K and L Series DN125 - DN300, C Series and QL Series
TI-P357-31 CTLS Issue 6
G
Dimensions / weights (approximate) in mm and kg
Actuator F G H I Weight
With handwheel
PN9400E and variants PN94_6E 732 465 300 1120 60 30
PN94_3E 732 465 300 1120 60 30
PN9400R and variants PN94_6R 732 465 300 1050 60 28
PN94_3R 732 465 300 1050 60 28
PN9400 series selection guide:
Type PN =Polyester powder coated (standard) PN
Series 9=9000 series 9
Actuator size 4=1 110 cm24
Valve travel 8=80 mm 8
Spring rating and
Actuator force in relation to
the motive air pressure
3=Min. 1.8 - 3.0 bar Max. Force 20 000 N Area of diaphragm
1 110 cm²
3
6=Min. 0.9 - 1.5 bar Max. Force 10 000 N
Spring action E=Spring-extend (Closed) E
R=Spring-retract (Open)
Optional - Bolting S=Stainless steel
Optional - Handwheel H=Handwheel
Selection example: PN 9 4 8 3 E - -
How to order example: 1 off Spirax Sarco PN9483E pneumatic piston actuator.
F
I
H

Page 3 of 3
PN9400 Series Pneumatic Actuators for Spira-trolTM K and L Series DN125 - DN300, C Series and QL Series
TI-P357-31 CTLS Issue 6
Materials
Spare parts
The only spare parts available are clearly indicated below and are common for
both spring-extend and spring-retract versions.
Available spares
Stem seal kit 3,4 and 5
Diaphragm kit 9 and 30
Travel indicator kit 23,28 and 29
Spring kit 11
Linkage 19,20,21,22,25 and 26
Handwheel
How to order spares
Always order spares by using the description given in the column headed 'Available
spares' and state the model.
Example: 1 off Spring kit for a PN9483E pneumatic piston actuator.
No. Part Material
1Yoke SG iron
2Bearing and seal
insert Carbon steel
3Bearing PTFE / steel composite
4Seal Polyurethane
5Gasket Reinforced graphite
6Housing lower Carbon steel
7Spindle Stainless steel
8Diaphragm
protection plate Carbon steel
9Diaphragm Reinforced NBR
10 Spacer Carbon steel
11 Spring Carbon steel
12 Housing upper Carbon steel
13 Lock-nut Carbon steel
14 Up guide Carbon steel
15 Screw Carbon steel
16 Screw Carbon steel
17 Screw Carbon steel
18 Nut Carbon steel
19 Connector Stainless steel
20 Adaptor Stainless steel
21 Collar Stainless steel
22 Clamp Stainless steel
23 Scale Stainless steel
24 Lock-nut Carbon steel
25 Screw Carbon steel
26 Nut Carbon steel
27 Screw Carbon steel
28 Nut Carbon steel
29 Screw Carbon steel
30 'O' ring Viton
31 Vent plug Brass
32 Washer 'O' ring Carbon steel
33 Intermediate
plate Carbon steel
34 Diaphragm
guide plate Carbon steel
35 Spring plate Carbon steel
36 Spring guide
plate Carbon steel
37 Cap protection Plastic
38 Washer Carbon steel
37 12
28 +29
25 +26
23
1
14
4
3
2
36
33
7
31
13
35
33
18
16
17
11
10
9
34
32
30
15
6
8
5
23
24
21
19
20
38
