Spirit Club Instruction Manual

CLUB
SPIN BIKE
NOTE
Thank you for purchasing
the SPIRIT Club spin bike.
Please read carefully
through all the precautions
and instructions in this
manual before using this
equipment and keep this
manual for your future
reference.
SERVICE CENTRE
NUMBER
For immediate help with
assembly or for additional
product information,
please call our service
center.
(DBN)
031 702 5784
(JHB)
011 907 1660
(CT)
021 934 0862
(PE)
041 487 0573
please have your model
name ready when you
call us.
MAXIMUM USER
WEIGHT
130kg 10165
INSTRUCTION AND USER’S MANUAL

CONTENTS
SAFETY PRECAUTIONS page 1
PRE-ASSEMBLY CHECK LIST page 2
PARTS LIST page 3-4
HARDWARE PARTS LIST page 5
EXPLODED DIAGRAM page 6
ASSEMBLY INSTRUCTION page 7-10
EXERCISE INSTRUCTIONS page 11-12
WARRANTY INFORMATION page 13-15

page-1
10165
To reduce the risk of serious injury, read the following safety instructions before using the Spirit
Club Spin Bike.
1. Use the Spirit Club Spin Bike only on a level surface.
2. Keep children and pets away from this equipment at all times.
3. The Spirit Club Spin Bike should not be used by persons weighing more than 130kgs.
4. The Spirit Club Spin Bike should be used by only one person at a time.
5. Be careful to maintain your balance while using, mounting, dismounting, folding, unfolding or
assembling the Spirit Club Spin Bike. Loss of balance may result in a fall and / or serious bodily
injury.
6. Use the Spirit Club Spin Bike only as described in the manual.
7. Do not attempt to adjust the seat position while you are on the Spirit Club Spin Bike.
8. Before using this equipment to exercise, ensure you warm up properly, by doing stretching
exercises.
9. Always make sure all bolts and nuts are tightened prior to each use.
10.Always wear appropriate workout clothing and shoes when exercising, do not wear robes or
other clothing that could become caught in the equipment.
WARNING:
Before starting any exercise or conditioning program you should consult with your personal
physician to see if you require a complete physical exam. This is especially important if you are
over the age of 35, have never exercised before, are pregnant, or suffer from any illness.
SAFETY PRECAUTIONS

page-2
10165
Thank you for choosing the Spirit Club Spin Bike. We took great pride in producing this quality
product and hope it will provide you with many hours of quality exercise to make you feel better,
look better and enjoy life to its fullest.
Yes, it’s a proven fact that a regular exercise program can improve your physical and mental health.
Too often, our busy lifestyles limit our time and opportunity to exercise. The Spirit Club Spin Bike
provides a convenient and simple method to begin your assault on getting your body in shape and
achieving a healthier lifestyle.
Please read this manual carefully and familiarize yourself with the parts of the Spirit Club Spin Bike
before using it for the first time.
PRE ASSEMBLY CHECK LIST

page-3
10165
PART LIST
No. Description Q’ty No. Description Q’ty
10165-01 Main Frame 1 10165-24 Bolt (M8 x 20mm) 2
10165-02 Rear Stabilizer 1 10165-25 Nut (ø17.5 x ø8 x M6) 2
10165-03 Rear Stabilizer Cap 4 10165-26 Pedal (Left Side) 1
10165-04 Round Foot 4 10165-27 Crank (Right Side) 1
10165-05 Hex Head Bolt (M10 x 60mm) 4 10165-28 Pedal (Right Side) 1
10165-06 Washer (ø10 x ø26 x T2mm) 4 10165-29 Flywheel 1
10165-07 Washer (ø10 x ø26 x T2mm) 12 10165-30 Bearing 6
10165-08 Nut Cap (M10) 4 10165-31 Belt Wheel 1
10165-09 Front Stabilizer 1 10165-32 Steel-plate 1
10165-10 PU Wheel 2 10165-33 Flywheel Axle 1
10165-11 Bolt (M6 x 30mm) 2 10165-34 Washer (12.2 x 16.6) 4
10165-12 Bolt (M6 x 12mm) 2 10165-35 Nylock Nut (M12 x P1.5) 6
10165-13 Pulley Axle 1 10165-36 Zip 2
10165-14 Pulley 1 10165-37 Washer (ø13 x ø20 x 2mm) 2
10165-15 Belt 1 10165-38 Flywheel Spacer 1
10165-16 Spring Washer (M10) 4 10165-39 Plastic Cap 4
10165-17 Bolt (10 x 15) 4 10165-40 Nut (M8 x P1.25) 4
10165-18 Bearings 2 10165-41 Bolt (M8 x 50 x P1.25) 2
10165-19 Spacer 1 10165-42 Bolt (M4 x 10mm) 8
10165-20 Bearings Spacer 2 10165-43 Bolt (M8 x 20mm) 2
10165-21 Nylock Nut (M20 x P1.0) 1 10165-44 Seat 1
10165-22 Plastic Cap (42 x 13) 1 10165-45 Handlebar 1
10165-23 Crank (Left Side) 1 10165-46 Bushing 2

page-4
10165
PART LIST
No. Description Q’ty No. Description Q’ty
10165-47 Upper Upright Post 1 10165-70 Nylon Nut (M8) 1
10165-48 Bolt (M5 x 9mm) 1 10165-71 Round Steel-plate 2
10165-49 Adjustable Knob 2 10165-72 Spring (2 x 16 x 30) 1
10165-50 Seat Post 1 10165-73 Bolt (M10 x 101.5mm) 1
10165-51 Chain Cover L 1 10165-74 Spring (1.5 x 15 x 25) 1
10165-52 Chain Cover R 1 10165-75 Nut (16.8 x 16.8 x 25) 1
10165-53 Front Cap 1 10165-76 Nut (M8 x P1.25) 2
10165-54 Protect Cap 2 10165-77 Brake Adjust Pin (20 x 30) 1
10165-55 Bolt (M5 x16mm) 17 10165-78 Nut (M6) 2
10165-56 Washer (ø5 x ø10) 19 10165-79 Bolt (M6 x 20mm) 2
10165-57 Washer (ø6 x ø12) 4 10165-80 U-Tube 1
10165-58 Protect Cap For Main Frame 2 10165-81 Spacer 2
10165-59 Bearing 4 10165-82 Fixed Clip 1
10165-60 L-Adjustable Knob 2 10165-83 Strap 1
10165-61 Lower Cap 4 10165-84 PVC Washer (176 x 59 x 1.5) 2
10165-62 Bolt (M5 x 10mm) 2 10165-85 Rubber Pad 1
10165-63 U-bar For Seat 1 10165-86 Washer (ø8 x ø18 x T1.0) 2
10165-64 Bolt (M4 x 10mm) 1 10165-87 Washer (ø14 x ø20 x T0.5) 2
10165-65 Washer (ø8 x ø19) 2 10165-88 Seat 1
10165-66 Brake Bolt (M10 x 133mm) 1 10165-89 Roll 4
10165-67 Brake Nut (16.8 x 16.8 x 31) 1
10165-68 Bolt (M5 x 5mm) 2
10165-69 Nut (M10 x P11.5) 6

page-5
10165
HARDWARE PARTS LIST
No. Description Drawing Q’ty
10165-05 Hex Head Bolt (ø10x30mm) 4
10165-08 Nut Cap (M10) 4
10165-06 Plastic Washer
(ø10 x ø26 x T 2 mm) 4
10165-07 Flat Washer
(ø10 x ø26 x T 2 mm) 4
10165-60 Adjustable Knob
(for Saddle) 1
Tool-A Screw Driver (14/19) 1
Tool-B Screw Driver (14/15) 1
Tool-C Allen Wrench (M3) 1
Above described parts are all the parts you need to assemble this machine. Before you start to
assemble, please check the hardware packing to make sure they are included.

page-6
10165
EXPLODED DIAGRAM

page-7
10165
ASSEMBLY INSTRUCTION
STEP 1
Attach the Stabilizer (9 and 2) to Main Frame (1), through two Steel Plates (84) and secure with four
ø10 x 30mm Hex Bolts (5), eight ø10 x ø26 x T2 mm Washers (7), four ø10 x ø26 x T2 mm Plastic
Washers (6) and four M10 Nut Caps (8).

page-8
10165
ASSEMBLY INSTRUCTION
STEP 2
Loosen the Adjustable Knob (49), insert the Upright Post (47) and Seat Post (50) into Main Frame
(1). Then tighten the Adjustable Knob (49).
